1
English
About this handbook
This handbook has been designed to help you install and operate yourTV set.
We would strongly advise you to read it thoroughly.
4This little circle in front of a sentence indicates what you must do.
5This arrow shows the result of your action.
The text in italics is a note or comment.
A glossary (p.18) is provided for more detailed information on the terms used
in this handbook.
Table of contents
Installation
TV set and remote control.........................................................................2
Switching on..............................................................................................2
Calling up the installation menu................................................................3
Selecting the menu language and country ..................................................3
Tuning-in TV channels: automatic store....................................................4
Sorting.......................................................................................................4
Manual store..............................................................................................5
Operation
Operating the TV set.................................................................................6
Keys on the TV set.....................................................................................6
Keys on the remote control........................................................................7
16/9 functions ...........................................................................................8
Using the menus: picture and sound adjustment......................................10
Special features.........................................................................................11
Special functions......................................................................................12
Teletext....................................................................................................13
Peripheral equipment
Connecting other equipment...................................................................15
Tips .........................................................................................................17
Glossary...................................................................................................18
Index........................................................................................................18

2
Installation of the TV set
4Place your TV set on a solid, stable surface
(please ensure that this surface is strong enough).
For ventilation allow a space of at least 5 cm around the TV set.
Do not place anything on the TV set which might damage it: plants
(risk of water entering the casing), covering material, lamp, or any
other heat source (risk of overheating).
4Insert the aerial plug into the Msocket at the rear.
4Insert the mains plug into a wall socket (220-240 V / 50 Hz).
In some countries the mains plug may differ from that illustrated.
Remote control
4Open the battery compartment on the remote control.
4Insert the two LR03-type batteries (supplied) making sure they are
the right way round.
In a effort to help protect the environment the batteries supplied with this
television do not contain mercury or nickel cadmium. If a means of recycling
batteries is available please use this (if in doubt contact your dealer).
Switching on
4Press the Akey on the front of the TV set.
5A green indicator appears and the screen lights up.
If the red indicator comes on, the TV set is in standby mode:
4Press the key on the remote control.
5The screen lights up.
When the remote control is being used, the indicator flashes orange.

3
Installation menu
This menu enables you to tune in the channels on the TV set.
4Open the flap on the remote control.
Selecting the menu language
You may choose between several languages for the menu display.
After calling up the INSTALLATION menu :
4Select the LANGUAGE adjustment using the keys.
5A display area appears at the bottom of the screen.
4Select the language you wish to use by means of the keys.
5The text of all themenuswill appear in thelanguageyou have chosen.
Move to the next adjustment.
Selecting the country
You should now select the country in which you are living.
4Select the COUNTRY adjustment using the keys.
4Select your country using the keys (GB for Great Britain).
5Your choice is displayed at the bottom of the screen.
Move to the next adjustment.
The country selected affects the way in which channel frequencies are
allocated to the channel numbers. Your TV set will automatically allocate
the appropriate frequencies for the country you select.
To leave the INSTALLATION menu:
4Press the and keys at the same time.
Using the menus:
4Use the keys to select the adjustment to be made.
4Use the keys to make the adjustment.
To call up the installation menu
4Press the and keys at the same time.
5The INSTALLATION menu appears on the screen.
If the menu display is not stable, press the key.
INSTALLATION x y
LANGUAGE GB
COUNTRY GB
AUTO STORE.
MANUAL STORE.
SORT
INSTALLATION
LANGUAGE GB
COUNTRY GB
AUTO STORE.
MANUAL STORE.
SORT
- GB +
INSTALLATION
LANGUAGE GB
COUNTRY GB
AUTO STORE.
MANUAL STORE.
SORT
- GB +

4
Channel search
There are two ways the television may be tuned in : automatic store
or manual store (tuning-in channel by channel).
Automatic store
From the INSTALLATION menu (keys ).
4Select AUTO STORE using the keys.
4Press .
5The AUTO STORE menu appears. The search begins.
The message SEARCHING PLEASE WAIT appears on the screen.
The TV set searches through the complete frequency range and
stores all the channels it finds. The search operation takes a few
minutes. A horizontal scale indicates the progress of the search.
You must wait for the horizontal bar to reach the end of the line.
When the search is completed:
The INSTALLATION menu reappears automatically.
You must now sort the channels.
If no channels have been found, refer to ‘Tips’ (page 15).
Sorting
This menu enables you to renumber the TV channels in the order
you wish.
4Select SORT ( keys).
4Press .
5The SORT menu appears.
4Select FROM using the keys.
5The program number and its frequency (or channel) appear on
the screen.
4Use the keys (or to ) to look through the channels which
have been found and stored from 69 downwards (press ,
, etc.), until the channel you wish to renumber is present on
the screen. For example, to renumber programme 67 as programme
01, enter , then:
4Select TO using the ( keys).
4Enter the new programme number using the keys (or to ).
In our example, press to enter programme 01.
4Select STORE using the keys.
4Press .
5OK appears. The new programme number is stored.
In our example, programme 67 becomes programme 01
(and programme 01 becomes programme 67).
Repeat this sequence to renumber the remaining programmes.
To leave the SORT menu:
4Press the and keys at the same time.
5The INSTALLATION menu reappears.
To leave the INSTALLATION menu:
4Press the and keys at the same time.
You may now use the TV set (p. 6).
AUTO STORE.
SEARCHING
PLEASE WAIT.
PRESS < > TO START
PRESS 67 TO STOP
STATIONS FOUND : 00
I I I I I I
INSTALLATION
LANGUAGE GB
COUNTRY GB
AUTO STORE.
MANUAL STORE.
SORT
- +
SORT x y
FROM P69
TO P01
STORE
INSTALLATION
LANGUAGE GB
COUNTRY GB
AUTO STORE.
MANUAL STORE.
SORT
- +

5
Manual store
From the INSTALLATION menu (keys ).
4Select MANUAL STORE (keys ).
4Press .
5The MANUAL STORE menu appears.
Selecting channel or frequency mode (depends on country)
For certain countries this adjustment is not available.
4Select the CHANNEL/FREQUENCY adjustment ( keys).
4Use the keys to select the tuning mode: FREQ (frequency
search), or CHAN. Cand CHAN. S (channel search, if you know
the channel numbers on which the programmes are broadcast).
Programme number
4Select the PROG. NUMBER adjustment ( keys).
4Use the keys to enter the channel number.
Storing
4Select the STORE adjustment ( keys).
4Use the keys to store the setting.
5The OK message appears.
Selecting the TV system
4Select the SYSTEM adjustment ( keys).
4Use the keys to select : EUROPE (automatic detection) or
manual selection of the system : EUR.W, EUR. E or UK .
For more information, see the glossary on p.18.
Search
4Select the SEARCH adjustment ( keys).
4If you know the frequency (or channel number) of the programme
that you wish to receive, you can enter the number directly,
otherwise use the keys to start the search.
5The search begins. When a programme is found, the search will stop.
Go to step 2.
If you do not want to store this channel:
4Press again to continue the search.
If no picture is found, refer to ‘Tips’ (page 17).
Fine tuning
If reception is not satisfactory, you can use the fine tuning function.
4Select FINE TUNE from the menu ( keys).
4Use the keys to make the adjustment.
To leave the INSTALLATION menu:
4Press the and keys at the same time.
steps 1, 2, 3to store all the available TV channels.
repeat
1
2
3
To leave the MANUAL STORE menu:
4Press the and keys at the same time.
5The INSTALLATION menu reappears.
INSTALLATION
LANGUAGE GB
COUNTRY GB
AUTO STORE.
MANUAL STORE.
SORT
- +
MANUAL STORE x y
CHANNEL/FREQ FREQ.
SYSTEM EUROPE
SEARCH 815MHZ
FINE TUNE ON
PROG. NUMBER 1
STORE

6
Operating the TV set
Standby
The standby keyenables you to switch off the TV using the remote control.
4Press the key.
5The TV set is switched off and the red indicator lights up.
4To switch the TV set on again, press the key or one of
the keys numbered to (or the key).
For further information, see ‘Tips’: standby (p.17).
Selecting TV programmes
4Use the key or the keys numbered to .
5The number is displayed and the programme selected.
For a 2-figure number, you must enter the second figure before
the dash disappears. If you select a programme below zero using
the key, the EXT sockets are accessed.
Previous programme
4Press .
On Screen Display (OSD)
4Press to view the programme number, sound reception and
time remaining (see SLEEPTIMER, p.11).
Volume control
4Use the key.
Mute key
4Press the key to mute the sound.
Stereo/Mono/Language key
TV programmes may be transmitted with different soundcharacteristics.
4Press the key to choose the type of sound.
5The indication for gappears when two languages are transmitted:
5The indication MONO or STEREO appears when the programme
is in mono or stereo.
If the sound quality in STEREO is not satisfactory (noise,
interference, etc.): use the key to switch to MONO
(the indication STEREO appears in red) .
5For TV sets fitted with NICAM reception, the indication DIGITAL
appears when a NICAM broadcast is received.
In stereo NICAM, the key is used to switch to mono.
In bilingual NICAM, the key is used to choose between
NICAM language f, NICAM language gand mono.
The keys on the TV set
The TV set has three keys: MENU, - and +.
(On some models they may be concealed by a cover).
TheMENUkey isusedtoaccessvolumeand the”smartcontrols”(p.10).
The - and + keys are used to select the TV channels and alter the
adjustments of the MENU key.
Themenuis automatically switched off aftera fewseconds ifno adjustment is made.

7
Remote control keys
On Screen Display (p.6)
EXTconnectorsselection(p.15)
Call upINSTALLATION menu
Press and (p.3)
Personal preferences (p11)
stereo/mono/language (p.6)
16/9 functions (p.8)
Video recorder key (p.12)
Press and .
Menu (p.10)
display/cancel menus
select adjustment
make adjustment
Call up teletext (p.13)
”Smart control” keys (p.12)
picture presets
sound presets
Teletext functions (p.13)
enlarging a page
temporary interruption of
teletext
stop sequence of pages
game solutions
screen overlay
display time or enter a sub-
page n°.
(p.6) programme selection
volume
/ enter a programme
number
mute key
previous programme
Switch to standby (p.6)
Programmable keys (p.12)

8
16/9 Functions
Your TV sets wide screen has a width/height ratio of 16/9.
Not all today’s broadcasts are in a 16/9 format, many are still
transmitted in a conventional 4/3 format.
The key found under the flap of the remote control can be used
to adapt the format of the received pictures to that of your screen.
Your TV also has an automatic switching function.
Video recorders or programmes carrying special switching signals will
automatically switch the TV to the correct screen format.
4 : 3
Use of different screen formats
4Press the key.
5Each time the key is pressed a different picture format is displayed.
Each format has a corresponding symbol which appears on the
screen for a few seconds :
4 : 3, 14 : 9, ,, -, 16 : 9 and 4 : 3 again.
The same adjustments can be made using the keys.
4 : 3 displayed on-screen
This function displays 4/3 format pictures in their original format.
Black bands are seen on either side of the screen.
14 : 9 displayed on-screen
This function is used to display 4:3 pictures that have narrow black
bars at the top and bottom of the picture.
The picture is enlarged, the upper and lower black bars disappear. The
black bands on either are reduced in size.
4/3 picture
4/3 picture Result
4 : 3 14 : 9

9
-
4 : 3 16 : 9
4 : 3
,displayed on-screen
This function is used to display 4:3 pictures that have wide black
bars at the top and bottom of the picture.
The picture is enlarged, the black bars disappear from the screen.
-displayed on-screen
This function is used to display conventional 4:3 pictures so they fill
the entire screen. The sides of the picture are stretched and the loss
of picture at the top and bottom of the screen is minimised.
16 : 9 displayed on-screen
This setting is used to display a picture broadcast in a 16:9 format in
the correct proportions.
N.B. : if you are viewing a 4/3 picture, the picture will be enlarged
horizontally.
Subtitles
When using 14 : 9, ,and -modes, the picture is enlarged,
therefore some information may be lost from the top or bottom of
the picture.
The keys can be used to view the bottom of the picture to
restore important information e. g. subtitles.
4Press the key.
5The xsymbol appears, the bottom of the picture gradually moves
upwards.
4Press the key.
5The ysymbol appears, the bottom of the picture gradually moves
downwards.
This function is not available in 4 : 3 and 16 : 9 modes.
Result
Result
Result
4/3 picture
4/3 picture
16/9 picture
4 : 3 ,

10
PICTURE xy
BRIGHTNESS I I I I I
COLOUR I I I I
CONTRAST I I I I I
SHARPNESS I I
TINT I I I I I I
SOUND xy
BALANCE . . . I . . .
TREBLE I I I I
BASS I I I I I
SPATIAL OFF
Using the menus
The red, green and yellow keys can be used to access
the adjustment menus and special functions directly.
The red key gives access to the PICTURE menu,
The green key calls up the SOUND menu, and
The yellow key displays the FEATURES menu.
4Press one of these keys to display/cancel the menu.
4Use the keys to select the adjustment to be made.
5Use the keys to make the adjustment.
Adjusting the picture
4Press the red key.
5The PICTURE menu appears on the screen.
4Use the keys to select the adjustment to be made.
5A horizontal scale appears at the bottom of the screen.
4Use the keys to adjust.
The TINT adjustment is used to change colour reproduction:
- ‘cool’ picture (bluer whites): minimum position.
- ‘warm’ picture (redder whites): maximum position.
Adjusting the sound
4Press the green key.
5The SOUND menu is displayed on the screen.
4Use the keys to select the adjustment to be made and the
keys to make the adjustment.
The SPATIAL setting gives the impression that the loud-speakers are spaced
futher apart from one another.
To store your settings
See Personal Preference in the FEATURES menu, .
PICTURE menu
SOUND menu
FEATURES menu
