Configurable 3-way isolating amplifier
MINI MCR-SL-UI-UI
© PHOENIX CONTACT
Data sheet
The 6.2 mm wide MINI MCR-SL-UI-UI... is a configurable 3-
way isolating amplifier. It is used to electrically isolate, condi-
tion, amplify, and filter standard signals.
The standard analog signals 0...20mA, 4...20mA, 0...10V,
2...10V, 0...5V or 1...5V are available electrically isolated on
the input and output sides.
The DIP switches, which can be accessed on the side of the
housing, are used to configure the input and output signal
ranges.
The power supply (19.2 ... 30 V DC) can be supplied either via
connection terminal blocks "3"/"4" or "7"/"8" on the modules
or in conjunction with the DIN rail connector. Please refer to
the section titled "Power supply" for more information.
Features
– Configurable 3-way isolating amplifier
– Input and output signal range configurable via DIP
switches
– Approval for Ex-zone 2 (nA)
– Screw or spring-cage connection can be provided
– Can be supplied configured or unconfigured
NOTE: Correct usage in potentially explosive areas
The module is a category 3 item of electrical equipment. It is absolutely vital to follow the instructions provided
here during installation and observe the information in the "Safety regulations and installation notes".
Make sure you always use the latest documentation.
It can be downloaded from the product at www.phoenixcontact.net/catalog.
This data sheet is valid for all products listed on the following page:
101945_en_05 2012-09-27

MINI MCR-SL-UI-UI
101945_en_05 PHOENIX CONTACT 2
2Tableofcontents
1 Description .............................................................................................................................. 1
2 Table of contents..................................................................................................................... 2
3 Ordering data .......................................................................................................................... 3
3.1 Order key .......................................................................................................................... 3
4 Technical data ......................................................................................................................... 4
5 Safety regulations and installation notes.................................................................................. 6
5.1 Installation notes ................................................................................................................. 6
5.2 Installation in the Ex area (zone 2)............................................................................................ 6
6 Installation ............................................................................................................................... 7
6.1 Connection notes ................................................................................................................ 7
6.2 Structure ........................................................................................................................... 7
6.3 Block diagram..................................................................................................................... 7
6.4 Power supply...................................................................................................................... 7
6.5 Assembly........................................................................................................................... 8
6.6 Connecting the wires ............................................................................................................ 8
7 Configuration ........................................................................................................................... 9
7.1 Configuration table............................................................................................................... 9
8 Adjustment ............................................................................................................................ 10
9 Connection/application example ........................................................................................... 10

MINI MCR-SL-UI-UI
101945_en_05 PHOENIX CONTACT 3
3.1 Order key
(standard configuration entered as example)
Description Type Order No. Pcs. / Pkt.
MCR 3-way isolating amplifier, I/O can be configured via DIP switches, for
the electrical isolation of analog signals, with screw connection, order con-
figuration
MINI MCR-SL-UI-UI 2864383 1
MCR 3-way isolating amplifier, I/O can be configured via DIP switches, for
the electrical isolation of analog signals, with spring-cage connection,
order configuration
MINI MCR-SL-UI-UI-SP 2864710 1
3-way isolating amplifier for the electrical isolation of analog signals, I/O
can be configured via DIP switches, with screw connection, standard con-
figuration
MINI MCR-SL-UI-UI-NC 2864150 1
MCR 3-way isolating amplifier, I/O can be configured via DIP switches, for
the electrical isolation of analog signals, with spring-cage connection, stan-
dard configuration
MINI MCR-SL-UI-UI-SP-NC 2864163 1
3Orderingdata
Accessories Type Order No. Pcs. / Pkt.
DIN rail connector (TBUS), 5-pos., for bridging the supply voltage, can be
snapped onto NS 35/... DIN rails according to EN60715
ME 6,2 TBUS-2 1,5/5-ST-3,81 GN 2869728 10
MCR power terminal block for supplying several MINI Analog modules via
the T-connector, with screw connection, maximum current consumption of
up to 2A
MINI MCR-SL-PTB 2864134 1
MCR power terminal block for supplying several MINI Analog modules via
the T-connector, with spring-cage connection, maximum current consump-
tion of up to 2A
MINI MCR-SL-PTB-SP 2864147 1
DIN rail power supply unit, primary-switched mode, slim design, output: 24
V DC / 1.5 A
MINI-SYS-PS-100-240AC/24DC/1.5 2866983 1
DIN rail power supply unit, primary-switched mode, slim design, output: 24
V DC / 1.5 A, ATEX approval
MINI-PS-100-240AC/24DC/1.5/EX 2866653 1
Eight MINI analog signal converters with screw connection method can be
connected to a control system using a system adapter and system cabling
with a minimum of wiring and very low error risk.
MINI MCR-SL-V8-FLK 16-A 2811268 1
Fold up transparent cover for MINI MCR modules with additional labeling
option using insert strips and flat Zack marker strip 6.2 mm
MINI MCR DKL 2308111 10
Label for extended marking of MINI MCR modules in connection with the
MINI MCR-DKL
MINI MCR-DKL-LABEL 2810272 10
Order No. Input range Output range Factory calibration certificate
2864383 / IN03 / OUT01 / NONE
IN01 =0 ... 20 mA OUT01 =0 ... 20 mA NONE =Without factory calibration certificate
2864383 =IN02 =4 ... 20 mA OUT02 =4 ... 20 mA YES =With factory calibration certificate (a fee is charged)
...-UI-UI IN03 =0 ... 10 V OUT03 =0 ... 10 V
IN04 =2 ... 10 V OUT04 =2 ... 10 V
2864710 =IN05 =0 ... 5 V OUT05 =0 ... 5 V YESPLUS =Factory calibration certificate with 5 measuring
points (a fee is charged)
...-UI-UI-SP IN06 =1 ... 5 V OUT06 =1 ... 5 V

MINI MCR-SL-UI-UI
101945_en_05 PHOENIX CONTACT 4
4 Technical data
Input
Configurable/programmable Yes, preconfigured
Voltage input signal 0 V ... 10 V
0 V ... 5 V
1 V ... 5 V
2 V ... 10 V
Max. voltage input signal 30 V
Current input signal 0 mA ... 20 mA
4 mA ... 20 mA
Max. current input signal 50 mA
Input resistance of voltage input Approx. 100 kΩ
Input resistance current input Approx. 50 Ω
Output
Voltage output signal 0 V ... 10 V
0 V ... 5 V
1 V ... 5 V
2 V ... 10 V
Max. voltage output signal Approx. 12.5 V
Non-load voltage Approx. 12.5 V
Current output signal 0 mA ... 20 mA
4 mA ... 20 mA
Max. current output signal 28 mA
Configurable/programmable Yes, preconfigured
Short-circuit current Approx. 22 mA
Load/output load voltage output ≥10 kΩ
Ripple < 20 mVPP (at 500 Ω)
Load/output load current output < 500 Ω(at 20 mA)
Supply
Nominal supply voltage 24 V DC
Supply voltage range 19.2 V DC ... 30 V DC (The T connector (ME 6,2 TBUS-2 1,5/5-ST-3,81 GN,
Order No. 2869728) can be used to bridge the supply voltage. It can be snapped
onto a 35 mm DIN rail according to EN60715))
Max. current consumption < 19 mA (Current output, at 24 V DC incl. load)
< 9 mA (Voltage output, at 24 V DC incl. load)
Power consumption < 450 mW (Current output)
< 200 mW (Voltage output)
General data
Limit frequency (3 dB) Approx. 100 Hz
Maximum transmission error ≤0.1 % (of final value)
< 0.4 % (Without adjustment)
Temperature coefficient, typical < 0.002 %/K
Maximum temperature coefficient < 0.01 %/K
Step response (10-90%) Approx. 3.2 ms
Electrical isolation Basic insulation according to EN 61010
Surge voltage category II
Mounting position Any
Degree of protection IP20
Pollution degree 2
Rated insulation voltage 50 V AC/DC

MINI MCR-SL-UI-UI
101945_en_05 PHOENIX CONTACT 5
Test voltage, input/output/supply 1.5 kV (50 Hz, 1 min.)
Dimensions W / H / D 6.2 mm / 93.1 mm / 102.5 mm
Type of housing PBT green
General data
Connection data Screw connection Spring-cage conn.
Conductor cross section, solid 0.2 mm² ... 2.5 mm² 0.2 mm² ... 2.5 mm²
Conductor cross section, stranded 0.2 mm² ... 2.5 mm² 0.2 mm² ... 2.5 mm²
Stripping length 12 mm 8 mm
Ambient conditions
Ambient temperature (operation) -20 °C ... 65 °C
Ambient temperature (storage/transport) -40 °C ... 85 °C
Conformance with EMC Directive 2004/108/EC
Noise immunity according to EN 61000-6-2
Noise emission according to EN 61000-6-4
Conformance / approvals
Conformance CE-compliant
ATEX II 3 G Ex nA IIC T4 Gc X
UL, USA / Canada UL 508 Recognized
UL, USA / Canada Class I, Div. 2, Groups A, B, C, D T5
Shipbuilding GL EMC 2 D

MINI MCR-SL-UI-UI
101945_en_05 PHOENIX CONTACT 6
5 Safety regulations and installation notes
5.1 Installation notes
– The category 3 device is suitable for installation in the
zone 2 potentially explosive area. It fulfills the require-
ments of EN60079-0:2009 and EN60079-15:2010.
– Installation, operation, and maintenance may only be car-
ried out by qualified electricians. Follow the installation in-
structions described. When installing and operating the
device, the applicable regulations and safety directives
(including national safety directives), as well as general
technical regulations, must be observed. The technical
data is provided in this package slip and on the certifi-
cates (conformity assessment, additional approvals
where applicable).
– It is not permissible to open or modify the device. Do not
repair the device yourself but replace it with an equivalent
device. Repairs may only be carried out by the manufac-
turer. The manufacturer is not liable for damage resulting
from violation.
– The IP20 degree of protection (IEC60529/EN60529) of
the device is intended for use in a clean and dry environ-
ment. Do not subject the device to any load that exceeds
the described limits.
– The device is not designed for use in atmospheres with a
danger of dust explosions.
5.2 Installation in the Ex area (zone 2)
– Observe the specified conditions for use in potentially ex-
plosive areas.
– The device must be installed in a housing (control or dis-
tributor box) which meets the requirements of EN 60079-
15 and provides at least IP54 (EN 60529) degree of pro-
tection.
– During installation and when connecting the supply and
signal circuits, observe the requirements of EN 60079-
14. Devices may only be connected to circuits in zone 2 if
they are suitable for operation in Ex zone 2 and for the
prevailing conditions at the place of use.
– In potentially explosive areas, terminals may only be
snapped onto or off the DIN rail connector and wires may
only be connected or disconnected when the power is
switched off.
– The device must be stopped and immediately removed
from the Ex area if it is damaged, has been subjected to
an impermissible load, has been stored incorrectly, or if it
malfunctions.
– You can download the latest documents for these devic-
es from www.phoenixcontact.net/catalog.

MINI MCR-SL-UI-UI
101945_en_05 PHOENIX CONTACT 7
6 Installation
6.1 Connection notes
6.2 Structure
Figure 1 Structure
1. Input: Standard signals
2. Cover
3. Potentiometer for adjustment
4. Groove for ZBF 6 zack marker strip
5. Output: Standard signals
6. Supply voltage
7. Connection option for DIN rail connector
8. Universal snap-on foot for EN DIN rails
9. DIP switch S2
10. DIP switch S1
6.3 Block diagram
Figure 2 Block diagram
6.4 Power supply
Supply via the module
Where the total current consumption of the aligned modules
does not exceed 400 mA, the power can be supplied directly
at the connection terminal blocks of the module.
A 400 mA fuse should be connected upstream.
Supply via a power terminal block
The MINI MCR-SL-PTB power terminal block (Order No.
2864134) or the MINI MCR-SL-PTB-SP power terminal block
(Order No. 2864147), which are the same shape, are used to
feed the supply voltage to the DIN rail connector.
A 2 A fuse should be connected upstream.
Supply via a system power supply unit
The system power supply unit with 1.5A output current con-
nects the DIN rail connector to the supply voltage and can
therefore be used to supply several modules from the mains.
– MINI-SYS-PS-100-240AC/24DC/1.5 (Order No.
2866983)
– Potentially explosive areas:
MINI-PS-100-240AC/24DC/1.5/EX (Order No. 2866653)
NOTE: electrostatic discharge!
The device contains components that can be
damaged or destroyed by electrostatic dis-
charge. When handling the device, observe the
necessary safety precautions against electro-
static discharge (ESD) according to EN 61340-
5-1 and EN 61340-5-1.
Serial No.
32825 Blomberg, Germany
MINI MCR–SL–UI–UI
Ord.–No.: 28 64 38 3
www.phoenixcontact.com
Warning – Do n ot seperate
when energized
II 3 G
Ex nA II C T4 Gc X
PROCESS CONTROL
EQUIPMENT
FOR HAZARDOUS
LOCATIONS 31ZN
C l. I, Div. 2,
Grps. A,B,C,D T5
16mA max
Use Class 2 pwr src
IN/OUT: 0...24V,0...30V/0(4)...20mA,0(2)...10V,0(2)...5V
19,2...30VDC
PLC / DCS Sensor / Field
Configurable
Isolating Amplifier
T –20°...+65°C / –4°...+149°F
amb
S2
S1
ON
ON
OFF
OFF
1
12
6
passive active 4-wire U
S
+24V
GND 3
OUT
U,I
GND
IN U,I
GND 1GND 2
OUT U,I
GND 3GND 3
+24+24V
+
+
+
+
-
-
-
-
5
511
62
73
84
2
6
2
3
4
5
6
1
6
9
10
7
8
NOTE:
Never connect the supply voltage directly to the
DIN rail connector. It is not permitted to draw
power from the DIN rail connector or from indi-
vidual modules.
Zone 2
Div. 2
passive
IN
Sensor / Field
OUT
PLC / DCS
4-wire
–
+
–
–
+
+
+
–
+24V
+24V
+24V
GND 3
GND 3
GND 2
active
GND 3
GND 1
OUT U,IIN U,I
1 5
2
6
7
8
3
4
OUT
U,I
GND
U
S
5
6
1
2

MINI MCR-SL-UI-UI
101945_en_05 PHOENIX CONTACT 8
6.5 Assembly
Figure 3 Mounting and removing
– Mount the module on a 35 mm DIN rail according to EN
60715.
– When using the DIN rail connector, first place it into the
DIN rail (see A – C). It is used to bridge the power supply.
It is also absolutely vital that you snap the module and the
DIN rail connector into position in the correct direction:
the snap-on foot should be at the bottom and the connec-
tor on the left.
6.6 Connecting the wires
The MINI MCR-SL-UI-UI... is available with two types of con-
nection:
– Screw terminal blocks (MINI MCR-SL-UI-UI)
– Spring-cage terminal blocks (MINI MCR-SL-UI-UI-SP)
Screw connection:
Figure 4 Screw connection
•Insert the wire into the corresponding connection terminal
block.
•Use a screwdriver to tighten the screw in the opening
above the connection terminal block.
Spring-cage connection:
Figure 5 Spring-cage connection
•Insert a screwdriver into the opening above the connec-
tion terminal block.
•Insert the wire into the corresponding connection terminal
block.
DE
C
B
A
www.interface.phoenixcontact.com
Serial No. XXXXXXXX
A
B
www.interface.phoenixcontact.com
Serial No. XXXXXXXX
A
B

MINI MCR-SL-UI-UI
101945_en_05 PHOENIX CONTACT 9
7 Configuration
DIP switches S1 and S2 are used to specify the combination
of input and output standard signal ranges (see "Configura-
tion table").
Standard Configuration
If it is an "NC version" (MINI MCR-SL-UI-UI-NC or MINI MCR-
SL-UI-UI-SP-NC), the device will have the following standard
configuration:
– 0 ... 10 V input
– Output 0...20 mA
(All DIP switches are set to the "off" position, transmission error < 0.1 %.)
7.1 Configuration table
DIP S2 DIP S1
IN OUT 123456 1 2
0...10 V 0...20 mA off off off off off off off off
4...20mA offoffoffoffoffON off off
0...10 V ON off ON off off off off off
2...10 V ON off ON off off ON off off
0...5 V ON ON off off off off off off
1...5 V ON ON off off off ON off off
2...10 V 0...20 mA off off off ON ON off off off
4...20mA offoffoffoffoffoff off off
0...10 V ON off ON ON ON off off off
2...10 V ON off ON off off off off off
0...5 V ON ON off ON ON off off off
1...5 V ON ON off off off off off off
0...5 V 0...20 mA off off off off off off ON off
4...20mA offoffoffoffoffON ON off
0...10 V ON off ON off off off ON off
2...10 V ON off ON off off ON ON off
0...5 V ON ON off off off off ON off
1...5 V ON ON off off off ON ON off
1...5 V 0...20 mA off off off ON ON off ON off
4...20mA offoffoffoffoffoff ON off
0...10 V ON off ON ON ON off ON off
2...10 V ON off ON off off off ON off
0...5 V ON ON off ON ON off ON off
1...5 V ON ON off off off off ON off
0...20 mA 0...20 mA off off off off off off off ON
4...20mA offoffoffoffoffON off ON
0...10 V ON off ON off off off off ON
2...10 V ON off ON off off ON off ON
0...5 V ON ON off off off off off ON
1...5 V ON ON off off off ON off ON
4...20 mA 0...20 mA off off off ON ON off off ON
4...20mA offoffoffoffoffoff offON
0...10 V ON off ON ON ON off off ON
2...10 V ON off ON off off off off ON
0...5 V ON ON off ON ON off off ON
1...5 V ON ON off off off off off ON

MINI MCR-SL-UI-UI
101945_en_05 10
PHOENIX CONTACT GmbH & Co. KG • 32823 Blomberg • Germany
www.phoenixcontact.com
8Adjustment
A potentiometer is located underneath the cover; this is used
for fine adjustment of the analog signals once the configura-
tion of the DIP switches has been modified.
The module is adjusted via its output final value:
•Connect the calibration source to the input of the isolating
amplifier and specify the final value of the set input signal.
•Use the potentiometer to set the exact final value of the
set output signal.
9 Connection/application example
Figure 6 Example application
Once the configuration of the DIP switches has
been modified, the potentiometer allows the
accuracy to be increased from < 0.4% to <
0.1%.
0...20mA
24V
0...10V
24V
MINI MCR-SL-UI-UI
51
2
3
4
6
7
8
GND3
GND1
IN
GND2
OUT
UB+ UB+
GND3
Control system
Level gauge
Mains voltage
