PIET HEIN EEK LINE LAMP User manual

Instruction manual
LINE LAMP

b
a
c
a : Hanging bracket
b : Box with transformer
c : Fixture
+
Instruction manual Line Lamp
Components

Step 1
In order to connect the wires to the transformer, you must first remove the cover of the box (a). The
top cover can be mounted directly in the right place on the ceiling, so that the electricity wire from the
ceiling can be put through the large opening in the cover (b).
a
b

Step 2
The hanging bracket can then be secured to the ceiling. Make sure that the box and the bracket are
mounted in a straight line, and with the correct distance between them (so that the wires will hang
straight down) (a).
The fixture has a wire at both ends. The long wire is the negative wire (–), the short one is the
positive wire (+). The long wire should be put through the bracket, creating a bend in the wire that is
supported by the bracket (b).
a
b

Step 3
The negative and positive wires should be connected to the transformer. There are connection points
at both ends of the transformer, as shown above. Make sure that you connect the wires at the
–
and
+
symbols of the transformer
(a)
, which can be found on one side. The electricity wire from the ceiling
should be connected to the other connection point
(b)
.
a Connection point for - and + wires
b Connection point for electrical wire

Step 4
When the wires have been connected, the bottom of the box can be secured to the top cover, which
has already been secured to the ceiling as described in step 1. Note: the distance between the fixture
and the ceiling, so the length of the wires, should not be more than 2,5 meters.
< 250 cm
