Pinnacle Products International Protemp PT-16-PCH-A Manual

Model:PT-16-PCH-A
CONSUMER: Retain this manual for future reference.
Pinnacle Products International, Inc. 668 Stony Hill Road #302 Yardley, PA 19067 USA
Phone: [phone] Fax: [phone] Web: www.pinnacleint.com Email: [email protected]
User’s Manual and
Operating Instructions
Propane
Cabinet Heaters
IMPORTANT: Read and understand all of the directions in this manual before assembling,
starting or servicing the heater. Improper use of this heater can cause serious injury. Keep this
manual for future reference.
GENERAL HAZARD WARNING:
Failure to comply with the precautions and instructions provided with this heater, can result in
death, serious bodily injury and property loss, or damage from the hazards of fire, explosion,
burn, asphyxiation, and carbon monoxide poisoning.
Only persons who can understand and follow the instructions should use or service this heater.
If you need assistance or heater information such as an instruction manual, labels, etcetera,
contact the manufacturer.
WARNING! This heater is not intended for residential use

Table of Contents
Features ..................................................................3
Specifications ..........................................................3
Safety Information ...................................................3
Propane Supply / Information .................................4
Product Features .....................................................4
Unpacking and Assembly .......................................4
Check for Leaks ..................................................... 4
Ventilation ................................................................5
Connecting to Gas Supply .......................................5
Lighting Instructions ................................................5
Testfiring ..................................................................5
Moving and Positioning ...........................................6
Shutdown .................................................................6
Storage ....................................................................6
Troubleshooting Guide ...........................................7
Exploded Parts Drawing .......................................8
Replacement Parts ................................................9
Warranty ................................................ Back Cover
WARNING:
Fire, burn, inhalation, and explosion hazard. Keep com-
bustibles, such as building materials, paper or cardboard,
a safe distance away from the heater as recommended by
these instructions. Never use the heater in spaces which
do or may contain volatile or airborne combustibles, or
products such as gasoline, solvents, paint thinners, dust
particles or unknown chemicals.
CAUTION: This is an unvented portable heater. It
uses air (oxygen) from the area which it is used. Ample
combustion and ventilation air must be provided. See
VENTILATION page 5.
WARNING:
The state of California requires the following
warning:
Combustion by-products produced when using this prod-
uct contain carbon monoxide, a chemical known to the
state of California to cause cancer and birth defects (or
other reproductive harm).
Propane
Cabinet Heaters
WARNING:
Do not operate this heater until you have read, and thor-
oughly understand these safety and operating instruction.
Failure to comply with the precautions and instructions
provided with this heater can result in death, serious bodi-
ly injury, property loss or damage from the hazards of fire,
explosion, burns, asphyxiation or carbon monoxide poi-
soning. Only persons who can read and understand
these instructions should use or service this heater.
WARNING:
If the information in this manual is not followed exactly, a
fire or explosion may result causing property damage,
personal injury or loss of life.
- Do not store or use gasoline or other flammable vapors
and liquids in the vicinity of this or any other appliance.
- An LP cylinder not connected for use shall not be stored
in the vicinity of this or any other appliance.
- WHAT TO DO IF THE SMELL OF GAS IS PRESENT:
- DO NOT attempt to light heater.
- Extinguish any open flame, and shut off
gas to the heater.
- See Troubleshooting on page 7.
- If odor continues, contact your local gas
supplier or fire department.
- Do not touch any electric switch, do not
use any phone in your building.
- Immediately call your gas supplier from a
neighbor’s phone. Follow the gas supplier’s
instructions.
- If you can not reach your LP gas supplier,
call the fire department.
- Service must be done by a qualified
service agency or gas supplier.
WARNING: Can be used indoors or outdoors, but
never in occupied dwellings.
NEVER LEAVE HEATER
UNATTENDED WHILE BURNING,
OR WHILE CONNECTED TO A
FUEL SOURCE
WARNING! This heater is not intended for residential use.
Page 2 Pinnacle Products International, Inc. Propane Cabinet Heater User’s Manual

Safety Information
This heater is designed for use as a construction heater in
accordance with ANSI Z83.7/CSA 2.14. Other standards
determine the use of fuel gases and heat producing prod-
ucts for specific uses. This infared heater’s intended use
is primarily for the temporary heating of buildings under
construction, alteration or repair.
Infared-fired means that all of the combustion products
enter the heated space. This heater is rated at 98%
combustion efficiency, but still produces small amounts of
carbon monoxide. Carbon monoxide is toxic. Humans
can tolerate small amounts of carbon monoxide, and
caution should be taken to provide adequate ventilation.
Failure to provide adequate ventilation in accordance with
this manual could result in death. Early signs of carbon
monoxide poisoning resemble the flu.
- The symptoms of inadequate ventilation are:
*headache *dizziness *burning of the nose and eyes
*nausea *dry mouth or *sore throat
- If the heater is being used in the presence of others, be
sure to inform them of the proper safety precautions,
operating procedures and the hazards involved. Some
people are more affected by carbon monoxide than
others. These are pregnant women, people with heart
or lung disease or anemia, those under the influence of
alcohol or at high attitudes.
- This heater is not for use on finished floors.
- Check the heater thoroughly for damage before each
use. DO NOT operate a damaged heater.
- DO NOT modify this heater or operate a heater that has
been modified from it’s original state.Modifying this
heater will void your warranty.
- Keep children and animals away from heater.
- Always set heater on a stable, level surface and use the
caster locks to prevent movement of the heater.
- NEVER use heater in occupied dwellings without
proper ventilation.
- Operate in a manner that heater will not be exposed
directly to rain or dripping water.
- Keep heater area free from combustible materials such
as gasoline, paint thinners and other flammable vapors
and liquids. Dust is combustible. Do not use heater in
areas of high dust concentration.
- ALWAYS maintain proper distance from combustibles.
Minimum clearance from Combustibles:
TOP SIDES FRONT
24” 12” 72”
- NEVER leave heater unattended.
- Use heater in accordance with all local codes and with
CSA 5.90 U.S. (5th Ed.) Infrared Patio Heater .In the
absence of local codes, refer to the Standard for the
Storage and Handling of Liquefied Petroleum Gases,
ANSI/NFPA 58 and the Natural Gas and Propane
Installation Code, CSA B149.1.
Propane
Cabinet Heaters
Model # Rating
BTU/Hr Min Max Heating Area Manifold Pressure
Weight
(Lbs)
Size
(L x W x H)
PT-16-PCH-A 18,000 5 PSI 150 PSI 600 Sq. Ft. 11” W.C. 30 16.6” x 20” x 28.8”
Figure 1. Product Features
Specifications subject to change without notice
NEVER LEAVE HEATER
UNATTENDED WHILE BURNING,
OR WHILE CONNECTED TO A
FUEL SOURCE
Inlet Gas Pressure
WARNING! This heater is not intended for residential use.
Pinnacle Products International, Inc. Propane Cabinet Heater User’s Manual Page 3
Features
Specifications
Safety
Guard
Front
Cover
Gas Valve
Knob
Handle
Slot
Back
Cover
Body
Frame
Assy
Front
Castor
Rear
Castor

3URSDQH6XSSO\,QIRUPDWLRQ
<RXPXVWSURYLGHWKHSURSDQHJDVDQGF\OLQGHUV8VH
WKLVKHDWHURQO\ZLWKDSURSDQHYDSRUZLWKGUDZDOVXSSO\
V\VWHP5HIHUWR&KDSWHURIWKH6WDQGDUGIRU6WRUDJH
DQG+DQGOLQJRI/LTXHILHG3HWUROHXP*DV$16,1)3$ 
<RXUORFDOOLEUDU\RUILUHGHSDUWPHQWZLOOKDYHWKLVERRNOHW
7KHF\OLQGHUPXVWEHHTXLSSHGZLWKDFROODUWRSURWHFW
WKHJDVYDOYHDQDUUDQJHPHQWRIYDSRUZLWKGUDZDOD
VKXWRIIYDOYHWHUPLQDWLQJWKHF\OLQGHUYDOYHRXWOHWDV
VSHFLILHGLQWKH$PHULFDQ1DWLRQDO6WDQGDUGIRU
&RPSUHVVHG*DV&\OLQGHU9DOYH2XWOHWDQG,QOHW
&RQQHFWLRQVDQGDVDIHW\UHOLHIYDOYHLQGLUHFWFRQWDFW
ZLWKWKHYDSRUVSDFHRIWKHWDQN
$OZD\VNHHSWKHF\OLQGHULQDQXSULJKWSRVLWLRQ$YRLG
NQRFNLQJWKHF\OLQGHURYHURQLWVVLGHZLWKWKHKRVHUHJ
XODWRUFRQQHFWHGDVWKLVFDQFDXVHGDPDJHWRWKHUHJX
ODWRUGLDSKUDJP
1HYHUVWRUHDSURSDQH/3F\OLQGHULQGRRUVRULQWKH
YLFLQLW\RIDQ\JDVEXUQLQJDSSOLDQFHV
3URWHFWWKHF\OLQGHUYDOYHDQGKDQGOHLWZLWKFDUH
%HVXUHWKDWWKHVKXWRIIYDOYHLVFORVHGWLJKWO\DIWHUHDFK
XVH
%HVXUHWRSURWHFWWKH32/ ILWWLQJIURPGDPDJHZKHQ
GLVFRQQHFWHG'DPDJHWRWKLVILWWLQJFDQOHDGWROHDNV
1HYHUFRQQHFWDQXQUHJXODWHGF\OLQGHUWRWKHKHDWHU
$OZD\VXVHWKHKRVHDQGUHJXODWRUVXSSOLHG
1HYHUXVHDQ\RWKHUKRVHDQGUHJXODWRU
'RQRWVXEMHFWWKHF\OLQGHUWRH[FHVVLYHKHDW
/3 &KDUDFWHULVWLFV
)ODPPDEOHH[SORVLYHXQGHUSUHVVXUHKHDYLHUWKDQDLU
DQGSRROVLQORZDUHDV
,QLWVQDWXUDOVWDWHSURSDQHKDVQRRGRUEXWIRUVDIHW\
DQRGRUDQWWKDWVPHOOVOLNHURWWHQFDEEDJHLVDGGHG
&RQWDFWRI/3 JDVZLWKWKHVNLQFDQFDXVHIUHH]HEXUQV
+HDWHULVPDQXIDFWXUHGIRUXVHZLWK/3 JDVRQO\
'2127 DWWHPSWWRFRQYHUWWRDQ\RWKHUJDV6XFK
PRGLILFDWLRQVDUHGDQJHURXVDQGZLOOYRLG\RXUZDUUDQW\
:KHQKHDWHULVQRWLQXVH/3 VXSSO\PXVWEHVKXW2))
7KHDPRXQWRI/3 JDVXVHGE\WKLVKHDWHUYDULHV7KHWZR
IDFWRUVWKDWZLOOGHWHUPLQHWKLVDUHDVIROORZV
7KHDPRXQWRIJDVLQWKH/3 F\OLQGHU
7KHWHPSHUDWXUHRIWKH/3 F\OLQGHUDQGVXUURXQGLQJ
DUHD
3URGXFW)HDWXUHV
3LH]R,JQLWLRQ 0RGHO373&+$ XVHVDPDQXDO3LH]R
LJQLWHUWRVHQGDVSDUNZKHQ\RXWXUQWKH*DV9DOYH.QRE
WR³3,/27,*1LJQLWLRQ7KHVSDUNLJQLWHVWKHIXHODWWKH
SLORW
7LS6ZLWFK6KXW2II6\VWHP 7KHKHDWHULVSURWHFWHGE\
DV\VWHPZKHUHE\WKHKHDWHUVKXWVRIILILWLVVXEVWDQWLDOO\
WLOWHGLQDQ\GLUHFWLRQ
2'62[\JHQ'HSOHWLRQ6HQVRU 7KLVKHDWHUXVHVDQ
2[\JHQ'HSOHWLRQ6HQVRU2'6WRPRQLWRUWKHR[\JHQ
FRQWHQWLQWKHKHDWHGVSDFH6KRXOGWKHR[\JHQOHYHOIDOO
EHORZWKHIODPHZLOOQRORQJHUWRXFKWKHWKHUPRFRX
SOHVWRSSLQJHOHFWULFDOFXUUHQWDQGWKHKHDWHUZLOOVKXWRII
$GMXVWDEOH,QSXW5DWLQJV 7KHKHDWHUKDVWHPSHUDWXUH
UDWLQJVKLJKPHGLXPDQGORZ7KHDGMXVWPHQWNQRELV
ORFDWHGFRQYHQLHQWO\DWWKHWRSRIWKHKHDWHUIRUHDV\
DFFHVVDQGFRQWURO
8QSDFNLQJDQG$VVHPEO\
5HPRYHKHDWHUIURP&DUWRQ6DYHFDUWRQDQGSDFNLQJ
PDWHULDOVIRUODWHUVWRUDJH
5HPRYHDOOSURWHFWLYHSDFNDJLQJSURWHFWLQJKHDWHUGXU
LQJVKLSSLQJ
,QVSHFWKHDWHUFORVHO\IRUDQ\GDPDJHWKDWPD\KDYH
RFFXUUHGGXULQJVKLSSLQJ,IWKHUHLVDQ\GDPDJHUHWXUQ
WKHKHDWHUWRWKHSODFHRISXUFKDVH
&KHFNLQJIRU/HDNV
7RFKHFNIRUOHDNVPDNHXSDVROXWLRQRIGLVKVRDS
DQGZDWHU$SSO\WKLVVROXWLRQWRDOOJDVFRQQHFWLRQV,I
EXEEOHVDSSHDUWKHUHLVDOHDN,IDOHDNLVIRXQGWXUQRII
WKHJDVVXSSO\UHPDNHWKHOHDNLQJFRQQHFWLRQ,IWKHOHDN
SHUVLVWVDIWHUVHYHUDOWULHVFRQWDFW3LQQDFOH&XVWRPHU
6HUYLFHDW
7KHLQVWDOODWLRQRIWKLVKHDWHUPXVWPHHWDOOORFDOFRGHV
DQGRUJDVXWLOLW\UHTXLUHPHQWV,QWKHDEVHQFHRIORFDO
FRGHVWKH1DWLRQDO)XHO&RGH$16,=VKRXOGEH
IROORZHG
7KHPLQLPXPFOHDUDQFHVWRDQ\FRPEXVWLEOHFRQVWUXFWLRQ
PDWHULDOVPXVWEHPDLQWDLQHGDWDOOWLPHVVHH3DJH
3URSDQH
&DELQHW+HDWHUV
1(9(5/($9(+($7(5
81$77(1'(':+,/(%851,1*
25:+,/(&211(&7('72$
)8(/ 6285&(
&DXWLRQ7KH3URSDQH/3JDVSUHVVXUH
UHJXODWRUDQGKRVHDVVHPEO\VXSSOLHGZLWKWKHKHDWHU
PXVWEHXVHGZLWKRXWDOWHUDWLRQ
&DXWLRQ%HVXUHWRLQVSHFWWKHUHJXODWRUKRVH
EHIRUHHDFKXVH,IWKHKRVHLVFXWRUIUD\HGUHSODFHLW
ZLWKWKHPDQXIDFWXUHUVXJJHVWHGDVVHPEO\
:$51,1*7KLVKHDWHULVQRWLQWHQGHGIRUUHVLGHQWLDOXVH
3DJH 3LQQDFOH3URGXFWV,QWHUQDWLRQDO,QF3URSDQH&DELQHW+HDWHU 8VHU¶V0DQXDO

Ventilation
Caution: Always provide a fresh air opening in the
heated space of at least three square feet (2,800 sq. cm)
for each 100,000 BTU/Hr. of heater output. Provide a
larger opening if more heaters are being used. As an
example, an PT-16-PCH-A heater will require:
- a two-car garage door open 2 inches, or
- a single car garage open 3 inches, or
- two thirty two inch wide windows open 4 inches.
Connecting to Gas Supply
IMPORTANT! Always use a propane (LP) cylinder that has
a connection device that is compatible with the hose and
regulator assembly supplied.
- Remove the Back Cover by sliding the cover straight up
and away from the Heater Body. Place the LP cylinder
on the Bottom Plate and replace the Back Cover. (see
Figure 2).
-To connect LP cylinder, insert regulator end fitting into
cylinder valve, rotate coupling nut clockwise and tighten
firmly (see Figure 3).
-Open valve on propane cylinder slowly. If the valve is
not opened slowly, the excess flow check valve in the
regulator will stop the flow of gas. If this should happen,
close the valve, wait one minute (or until you hear the
valve click), and re-open, slowly.
- Be sure to inspect all connections for leaks, by using a
50/50 mixture of dish soap and water on all connection.
Any bubbles forming indicate a leak.
Lighting Instructions
1. Turn the knob on the LP cylinder valve counterclockwise
to the ON position.
2. Turn the Gas Valve Knob on heater to the OFF position.
3. Wait five (5) minutes for any gas to clear. Smell for gas.
If none is evident, proceed to the next step.
4. Push in the Gas Valve Knob on the heater and rotate
knob to PILOT/IGN position. (Note: If operating the
heater for the first time, or after a replacing the cylinder,
hold the control knob down for 30 seconds, then rotate
to PILOT/IGN, to allow any air to bleed from the sys-
tem.) Rotating the Gas Valve Knob to the PILOT/IGN
position will cause the piezo igniter to spark and light
the pilot. It may be necessary to rotate the Gas Valve
Knob (from OFF to PILOT/IGN) several times to ignite
the heater.
5. Keep the Gas Valve Knob depressed for at least 30
seconds after the pilot is lit. This will heat the thermo-
couple. After 30 seconds, release the Gas Valve Knob.
6. If heater fails to light, or does not stay lit, repeat Steps 2
through 6.
7. When burner stays lit, turn Gas Valve Knob to desired
setting.
Test Firing Heater
It is always a good idea to test fire your heater in a safe
and controlled environment, in an area with adequate ven-
tilation, and away from any combustibles to be sure that all
functions of the heater and gas supply system are operat-
ing properly.
Leak test all gas connections with a 50/50 solution of dish
soap and water. DO NOT use a flame to test for leaks!
Propane
Cabinet Heaters
Figure 2. Removing/Replacing Back Cover
NEVER LEAVE HEATER
UNATTENDED WHILE BURNING,
OR WHILE CONNECTED TO A
FUEL SOURCE
Figure 3. Connecting Hose/Regulator to LP cylinder
WARNING! This heater is not intended for residential use.
Pinnacle Products International, Inc. Propane Cabinet Heater User’s Manual Page 5

Moving and Positioning the Heater
There is a brake in each of the front wheels of your heater
that helps keep it in place when in use. To engage the
brakes, push the lever down on each wheel.
To move the heater, release the brakes, simply by flipping
the levers on both brakes up (See Figure 5).
Shutdown Instructions
1. Turn the Gas Valve Knob to the “PILOT/IGN” position.
2. Turn the Gas Valve Knob to the “OFF” position.
3. Turn the knob at the LP cylinder clockwise to the OFF
position.
4. Disconnect Regulator Hose from the LP cylinder.
Storage
Always disconnect the LP cylinder from the regulator assy
and remove the LP cylinder from the heater before putting
the heater into storage.If for any reason the heater is to be
stored indoors, the heater MUST be disconnected from the
LP cylinder, and the cylinder stored outdoors in a well-ven-
tilated area, out of the reach of children, and in accor-
dance with the Standard for Storage and Handling of
Liquefied Gases, ANSI/NFPA 59 - latest edition. The plas-
tic valve plug or valve cover supplied with the LP cylinder
must be reinstalled on the valve to protect the fitting from
damage.
NOTE: Repair of this heater should be done by a quali-
fied service person.
It is recommended that you save all of the packaging
materials that came with your heater, and re-package the
heater using these materials for safe storage.
Debris, dust and dirt inside of the heater body can affect
the performance of your heater. This debris can impair the
heaters ability to draw air for ventilation and combustion.
Spiderwebs can also appear during periods of inactivity.
Be sure to inspect the heater before each use to look for
any such obstructions. Be sure to keep the air passage-
ways, burner and combustion areas clean. Wipe with a
damp cloth or use a vacuum cleaner to clean these areas.
It is suggested that you perform a thorough cleaning at
least once every 30 days of operation. You may need to
clean the heater more often if conditions are naturally dirty.
A yellow tipping of the pilot flame indicates that the burner
area may be in need of cleaning.
Propane
Cabinet Heaters
NEVER LEAVE HEATER
UNATTENDED WHILE BURNING,
OR WHILE CONNECTED TO A
FUEL SOURCE
21
2
))
Figure 5. Casters and Brakes
WARNING: Never store an LP cylinder inside of a
building, or near any other gas or oil burning appli-
ances.
CAUTION: Always be sure that the heater has
been allowed to cool for at least 30 minutes before
attempting to store, service, or maintenance.
WARNING! This heater is not intended for residential use.
Figure 4. Gas Valve Knob Position/Burner Pattern
Page 6 Pinnacle Products International, Inc. Propane Cabinet Heater User’s Manual
Off
Pilot / IGN
Low
Med
High

Troubleshooting Guide
Propane
Cabinet Heaters
NEVER LEAVE HEATER
UNATTENDED WHILE BURNING,
OR WHILE CONNECTED TO A
FUEL SOURCE
Problem Possible Cause Solution
Burner does not light 1. Air in gas line
2. Gas pressure from cylinder too low
3. LP cylinder valve turned off
4. Obstruction in air passageway
5 Dirt in pilot orifice
6. Gas valve knob not fully depressed in
Pilot/Ign position
7. Safety switch in cylinder valve engaged
8. Tipover switch engaged
9. Out of fuel
1. Keep depressing the gas control knob for at
least 30 seconds to remove any air in line.
2. Check LP cylinder pressure
3. Open LP cylinder valve
4. Inspect and clean heater housing
5. Blow out, or otherwise clean the pilot orifice
6. Be sure to fully depress gas valve knob
7. Close LP cylinder valve. Wait one minute for
switch to click off. Reopen LP cylinder valve
slowly
8. Move heater to a level surface
9. Replace LP cylinder
No spark is created when
ignited
1. Incorrect igniter electrode position
2. Electrode damaged or broken
3. Loose or disconnected igniter wire
4. Broken igniter wire
1. Properly position electrode
2. Replace the electrode
3. Tighten or reconnect loose wire
4. Replace igniter wire
Heater stops running by
itself
1. Thermocouple damaged
2. Gas control valve damaged
3. Gas valve knob not pressed down long
enough
4. Gas leak
5. Thermocouple not in contact with pilot
flame
6. Tipover switch damaged, or loose con-
nection at tipswitch
7. Out of fuel
1. Replace thermocouple
2. Replace gas control valve
3. Keep gas valve knob depressed for 30 sec-
onds after pilot is ignited
4. Check all connections for leaks using 50/50
solution of dishsoap and water. Repair any
leaks found
5. Clean inside of heater housing
6.Inspect tipover switch and connections.
Replace if necessary
7. Replace LP cylinder
WARNING! This heater is not intended for residential use.
Pinnacle Products International, Inc. Propane Cabinet Heater User’s Manual Page 7

([SORGHG'UDZLQJ3DUW%UHDNGRZQ
3URSDQH
&DELQHW+HDWHUV
1(9(5/($9(+($7(5
81$77(1'(':+,/(%851,1*
25:+,/(&211(&7('72$
)8(/ 6285&(
)LJXUH ([SORGHG9LHZ373&+$
:$51,1*7KLVKHDWHULVQRWLQWHQGHGIRUUHVLGHQWLDOXVH
3DJH 3LQQDFOH3URGXFWV,QWHUQDWLRQDO,QF3URSDQH&DELQHW+HDWHU 8VHU¶V0DQXDO

3URSDQH
&DELQHW+HDWHUV
1(9(5/($9(+($7(5
81$77(1'(':+,/(%851,1*
25:+,/(&211(&7('72$
)8(/ 6285&(
:$51,1*7KLVKHDWHULVQRWLQWHQGHGIRUUHVLGHQWLDOXVH
3LQQDFOH3URGXFWV,QWHUQDWLRQDO,QF3URSDQH&DELQHW+HDWHU 8VHU¶V0DQXDO 3DJH
 %RG\)UDPH$VVHPEO\ 
 *DV9DOYH.QRE 
 5HJXODWRU+RVH$VVHPEO\ 
 %DFN&RYHU 
 8SSHU5HDU6XSSRUW 
 +HDW3ODWH 
 ,QOHW&RQQHFWRU 
 9DOYH$VVHPEO\ 
 038 /HDG:LUH 
 7LS2YHU6ZLWFK 
 1R]]OH 
 25LQJ 
 7XEHµ5¶ $VVHPEO\ 
 2'6 7XEH$VVHPEO\ 
 7XEHµ/¶ $VVHPEO\ 
 7XEHµ0¶ $VVHPEO\ 
 )URQW&DVWRU 
 &DVWRU1XW 
 5HDU&DVWRU 
 8SSHU)URQW3DQHO 
 )URQW3DQHO 
 &HUDPLF+ROGHU 
 %XUQHU$VVHPEO\ 
 &HUDPLF3ODWH 
 &HUDPLF*DVNHW 
 5HIOHFWRU 
 :LQG&RYHU$ 
 6DIHW\*XDUG 
 :LQG&RYHU% 
 2'6$VVHPEO\ 
 2'6 %UDFNHW 
5HI 3DUW 3DUW1XPEHUVIRU0RGHO
1R 'HVFULSWLRQ 373&+$
5HSODFHPHQW3DUWV

Propane
Cabinet Heaters
NEVER LEAVE HEATER
UNATTENDED WHILE BURNING,
OR WHILE CONNECTED TO A
FUEL SOURCE
WARNING! This heater is not intended for residential use.
Page 10 Pinnacle Products International, Inc. Propane Cabinet Heater User’s Manual

Pinnacle Products International, Inc. Propane Cabinet Heater User’s Manual Page 11
WARNING! This heater is not intended for residential use.
Propane
Cabinet Heaters
NEVER LEAVE HEATER
UNATTENDED WHILE BURNING,
OR WHILE CONNECTED TO A
FUEL SOURCE

LIMITED WARRANTY
Pinnacle Products International, Inc. warrants this
heater to the original retail purchaser only, to be free from
defects in material and workmanship for a period of one
(1) year from the date of initial purchase. This product
must be properly installed, maintained and operated in
accordance with the instructions provided.
Pinnacle Products International, Inc. requires reason-
able proof of your date of purchase from an authorized
retailer or distributor. Therefore, you should keep your
sales slip, invoice, or cancelled check from the original
purchase. This Limited Warranty shall be limited to the
repair or replacement of parts, which prove defective
under normal use and service within the warranty period,
and which Pinnacle Products International, Inc. shall
determine at its reasonable discretion.
This warranty does not apply to products purchased for
rental use.
This Limited Warranty does not cover any failures or oper-
ating difficulties due to normal wear and tear, accident,
abuse, misuse, alteration, misapplication, improper instal-
lation or improper maintenance and service by you or any
third party. Failure to perform normal and routine mainte-
nance on the heater, shipping damage, damage related to
insects, birds, or animals of any kind, and damage due to
weather conditions are also not covered. In addition, the
Limited Warranty does not cover damage to the finish,
such as scratches, dents, discoloration, rust or other
weather damage, after purchase.
All transportation costs for the return of the damaged
product or parts will be the responsibility of the purchaser.
Upon receipt of damaged item, Pinnacle Products
International, Inc. will examine the item and determine if
defective. Pinnacle Products International, Inc. will
repair or replace and return the item, freight pre-paid. If
Pinnacle Products International, Inc. finds the item to be
in normal operating condition, or not defective, the
item will be returned freight collect.This Limited Warranty
is in lieu of all other express warranties. Pinnacle
Products International, Inc. disclaims all warranties for
products that are purchased from sellers other than
authorized retailers or distributors.
AFTER THE PERIOD OF THE ONE (1) YEAR EXPRESS
WARRANTY EXPIRES, Pinnacle Products International,
Inc. DISCLAIMS ANY AND ALL IMPLIED WARRANTIES,
INCLUDING WITHOUT LIMITATION THE IMPLIED WAR-
RANTIES OF MERCHANTABILITY AND FITNESS FOR A
PARTICULAR APPLICATION. FURTHER, Pinnacle
Products International, Inc. SHALL HAVE NO LIABILITY
WHATSOEVER TO PURCHASER OR ANY THIRD PARTY
FOR ANY SPECIAL, INDIRECT, PUNITIVE, INCIDENTAL,
OR CONSEQUENTIAL DAMAGES. Pinnacle Products
International, Inc. assumes no responsibility for any
defects caused by third parties. This Limited Warranty
gives the purchaser specific legal rights; a purchaser may
have other rights depending upon where he or she lives.
Some states do not allow the exclusion or limitation of
special, incidental or consequential damages, or limitations
on how long a warranty lasts, so the above exclusion and
limitations may not apply to you.
Pinnacle Products International, Inc. does not authorize
any person or company to assume for it any other
obligation or liability in connection with the sale,
installation, use, removal, return, or replacement of its
equipment, and no such representations are binding on
Pinnacle Products International, Inc.
Always be sure to specify model number and serial
number when making any claim with Pinnacle Products
International, Inc. For your convenience use the space
provided below to list this information:
Model #: ____________________
Serial #: _________________________
Date of Purchase: _________________
Propane
Cabinet Heaters
NEVER LEAVE HEATER
UNATTENDED WHILE BURNING,
OR WHILE CONNECTED TO A
FUEL SOURCE
