Playtex Embrace User manual

Getting
Started
Guide
Keep this guide with your Playtex™Embrace™Breast Pump
TM
DOUBLE ELECTRIC, FOR LONG-TERM DAILY USE
TM

1
READ ALL INSTRUCTIONS BEFORE USING THIS BREAST PUMP
DANGER – To reduce the risk of electrocution:
1. Always unplug this product immediately after using.
2. Do not use while bathing.
3. Do not place or store product where it can fall or be pulled into a tub or sink.
4. Do not place in or drop into water or other liquids
5. Do not reach for this product if it has fallen into water. Unplug immediately.
WARNING – To reduce the risk of burns,
electrocution, fire or injury to persons:
1. This product should never be left unattended when plugged in.
2. Close supervision is necessary when this product is used near children or invalids.
3. Use the pump only for its intended use as described in this manual. Do not use
accessories or attachments not recommended by the manufacturer.
4. Never operate this product if it has a damaged cord or plug, if it is not working
properly, if it has been dropped or damaged, or if it has been dropped into water.
5. Keep the cord away from heated surfaces.
6. Never operate while sleeping or drowsy, or while driving.
7. Do not operate outdoors, where aerosol products are being used, or where
oxygen is being administered.
8. Use only the AC/DC Adapter or Car Adapter provided with the Playtex™Embrace™Breast Pump.
9. Do not unplug by pulling on the cord.
10. When pump is not in use, be sure all tubing, parts and accessories are stored
safely, away from children.
11. Plug the AC/DC Adapter into the Pump unit first, then plug into wall socket.
12. Plug the Car Adapter into the Pump unit first, then plug into the car's auxiliary power outlet.
SAVE THESE INSTRUCTIONS.
The Playtex™Embrace™Breast Pump is intended for household use.
Important
Safeguards
When using electrical products, especially when children are present, basic safety precautions
should always be followed, including the following:

2
Congratulations
on your purchase of the
Playtex
™
Embrace
™
Breast Pump
A Double-Electric, Long-Term Daily Use Pump that combines Ultimate Comfort with
State-of-the-Art Efficiency.
The Playtex™Embrace™Breast Pump System offers top-of-the-line features and important
benefits to moms who pump daily and/or over a long period of time.
Ultra Comfortable Breast Cups
• Soft Comfort™Breast Cups gently plump nipples and surrounding milk ducts, minimizing
pulling or stretching nipples.
State-of-the-Art Efficiency
• The Playtex™Embrace™Breast Pump provides
massage AND wide-ranging suction, to express milk
most efficiently.
Total Control at Your Fingertips
• You control your own comfort level with 5 levels of speed
and 5 levels of suction.
Exceptional Style & Convenience
• The Tote Bag is high-quality, stylish and discreet – no one
will ever know there is a breast pump inside.
• The unique inner bag system allows you to stay
completely organized.
Unsurpassed Hygiene
• The Playtex™Embrace™Breast Pump has a unique closed
system that protects against contamination from
bacteria and germs.
- Milk cannot back up into system.
- Prevents collected milk from being exposed to ambient air.
• Wide openings on breast cups are easy to thoroughly clean
in the dishwasher or by hand.
✔
✔
✔
✔
✔
Save These Instructions
CALL US FIRST!
The Playtex™Embrace™Breast Pump is a personal care item and
cannot be returned once opened.
At Playtex, we understand that sometimes breastfeeding and
breast pumping can be challenging. Our Customer Care Represen-
tatives are here to help make it more successful for you. Call us at
1-800-222-0453 Monday through Friday from 8:00am to 8:00pm,
or visit www.playtexbaby.com.
Table of Contents
Quick Start
Important Safeguards 1
How to Maintain and
Clean your Playtex™
Embrace™Breast Pump 3
Getting to Know
your Playtex™Embrace™
Breast Pump 4
How to Use
your Tote Bag 5
How to Assemble
your Playtex™Soft Comfort™
Breast Cup 6
How to Connect
your Playtex™Embrace™
Breast Pump 7
How to Operate
your Playtex™Embrace™
Breast Pump 8
How to Disassemble
your Playtex™Air-Cushion™
Breast Cup 9
Troubleshooting Tips 10, 11
How to Store
Breast Milk 12
How to Order
Replacement Parts 13
Limited Warranty Back

3
with your Playtex™Embrace™Breast Pump, call Playtex Customer Care at 1-800-222-0453
Monday through Friday from 8 am to 8 pm, or visit www.playtexbaby.com.
For help
Pump, Tubing and “Y” Connector Care
• CAUTION – Do not attempt to remove back of Pump housing due to risk of electric shock.
If Pump requires servicing, call Playtex Customer Care at 1-800-222-0453 Monday through Friday
8:00am to 8:00pm.
• DO NOT Sterilize or WASH the Pump, Tubing or “Y” Connector. The Playtex™Embrace™Breast
Pump has been designed so that no breast milk will ever contact these components, and no air from
these components will contact your breast milk. Therefore, there is no need to wash or sterilize
these parts.
• Clean the Pump with a soft cloth. DO NOT put the Pump in the dishwasher or allow the Pump
to get wet. The Pump is an electrical appliance and must be kept away from liquids.
• Be sure all tubing is stored safely, away from children.
• If the tubing or “Y” Connector is lost, worn or damaged, call 1-800-667-4860 to purchase
replacement parts. See the list of replacement parts on page 13.
Cleaning the Breast Cup and Breast Milk Storage Components
• Prior to first use, and after each use, disassemble and wash all Breast Cup and Breast Milk Storage
components in the dishwasher (top rack only) or hand wash in hot, soapy water for about one minute
and rinse thoroughly.
• As with all infant feeding products, clean as soon as possible after each use.
• Discard Drop-Ins®Pre-formed Soft Bottle Liners or standard liners after each use.
• If any parts are lost or damaged, call 1-800-667-4860 to purchase replacement parts. See the list of
replacement parts on page 13.
AC/DC Adapter and Cord Care
• Plug the AC/DC Adapter into the Pump first, then plug into wall socket.
• Unplug AC/DC Adapter when not in use.
• Keep cord stored inside bag or safely away from children.
• Do not unplug by pulling on the cord. Pull on the plug to remove from socket.
Car Adapter and Cord Care
• Plug the Car Adapter into the Pump first, then plug the adapter into the car's auxiliary power outlet.
• Unplug the Car Adapter when not in use.
• Keep cord stored inside bag or safely away from children.
• Do not unplug by pulling on the cord. Pull on the adapter to remove from outlet.
• Never operate the Pump while driving.
Tote Bag Care
• Clean the Tote Bag with a damp cloth.
How to Maintain
and Clean
your Playtex
™
Embrace
™
Breast Pump

4
is for Cups.
Keeps Breast Cups separate from
other Pump components before
pumping, and stores wet Breast
Cups after they have been used.
C
(2) Breast Cup
Soft Shields
(2) Breast Cup Bases
(2) Breast Cup Holders
(2) Breast Cup
White Valves
Note the “C” on the bag
with your Playtex™Embrace™Breast Pump, call Playtex Customer Care at 1-800-222-0453
Monday through Friday from 8 am to 8 pm, or visit www.playtexbaby.com.
For help
Getting to Know
your Playtex
™
Embrace
™
Breast Pump
is for Accessories.
To keep track of small and
extra parts.
ANote the “A” on the bag
(2)
Additional
Breast Cup
White Valves
(2)
Additional
Sealing
Disks
(1)
Additional
"Y"
Connector
(2)
Liner
Rings
(2)
Additional
Nipple
Rings
is for Breast Milk
Storage.
Insulated bag with cooling
pack keeps milk fresh for
up to 8 hours.
BNote the “B” on the bag
(1) Cooling Pack
(2) Reusable Breast Milk
Storage Containers
with Nipple Rings
and Sealing Disks
(2) Premium Nursers
with Nipple Rings
and Sealing Disks
Tote Bag
The discreet and stylish Tote
Bag holds your Pump securely in
its own special protective pocket.
The Tote Bag also contains 3 inner
bags that keep your accessories
organized and clean.
(1) AC/DC Adapter
(1) Car Adapter
(1) "Y" Connector
(1) Pump
(3) Tubing Pieces
(1 Long and 2 Short)
NOTE: Actual product may appear slightly
different than photograph.
(15) Drop-Ins®Liners

Use the Pump from
within the Tote Bag…
There’s no need to remove the Pump
from the Tote Bag:
•Handy front pouch allows easy
access to the Pump.
•Plug the AC/DC Adapter into any
outlet or the Car Adapter into the
car's auxiliary power outlet.
•Feed the AC/DC Adapter or Car Adapter
through the hole in the top of the front
pocket. When the Adapter is not in use,
you can keep it plugged into the Pump,
but stored inside the Bag.
…or, remove the Pump
from the Tote Bag.
•The Pump is stylish, small and discreet,
so you can leave it out if you prefer.
5
How to Use
your Tote Bag
The Playtex™Embrace™Breast Pump Tote
Bag combines both style and convenience.
This elegant, fashionable bag provides discreet
portability – no one will know you are carrying
a breast pump.
with your Playtex™Embrace™Breast Pump, call Playtex Customer Care at 1-800-222-0453
Monday through Friday from 8 am to 8 pm, or visit www.playtexbaby.com.
For help
Packing
your Tote Bag
The Tote Bag has been designed to
neatly fit the smaller storage bags as
shown, so you are perfectly organized
and have extra room for storage.

6
with your Playtex™Embrace™Breast Pump, call Playtex Customer Care at 1-800-222-0453
Monday through Friday from 8 am to 8 pm, or visit www.playtexbaby.com.
For help
4
Insert the Soft Shield.
Insert the Breast Cup Soft Shield into the front of the
Breast Cup Holder. Be sure to pull the Soft Shield all the
way through the Holder so the edges are seated firmly
around both the front and back of the Holder.
How to Assemble
your Playtex
™
Soft Comfort
™
Breast Cup
The Breast Cup components
are located in the Cups Bag
labeled with a “C”.
1
Attach a bottle or liner.
Screw a Premium Nurser with a disposable liner
or a Reusable Breast Milk Storage Container into
the bottom of the Breast Cup Base.
Attach the White Valve.
Press the Breast Cup White Valve onto the round
opening on the bottom of the Breast Cup Base.
3
Attach the Holder to
the Base.
Snap the Breast Cup Holder into the front of the Breast
Cup Base. You should hear a distinct “click” sound.
2
✔Check that the Breast Cup
Soft Shield is pulled all the way
through the Breast Cup Holder
so the edges are seated firmly
around both the front and back
of the Breast Cup Holder.
✔Check that the Breast
Cup Holder is securely
snapped onto the front
of the Breast Cup Base
(you should hear a
distinct “click” sound).
✔ Check that the Breast
Cup White Valve is
securely attached onto
the round opening on
the bottom of the
Breast Cup Base.
Troubleshooting
Tips
Breast Cup
Soft Shield
Breast Cup
Holder
Breast Cup
Base
Thumb Tab
Breast Cup
White Valve

7
with your Playtex™Embrace™Breast Pump, call Playtex Customer Care at 1-800-222-0453
Monday through Friday from 8 am to 8 pm, or visit www.playtexbaby.com.
For help
After you assemble the
Breast Cup, connect it
to the Pump using the
tubing. The tubing is
located in the Tubing
Storage Compartment
in the Pump.
Connect tubing to
the Pump.
On the Pump, press the button to open
the Tubing Storage Compartment.
Connect the long tubing piece to the air
supply nozzle inside the Compartment.
1
Attach the bottom of the “Y”
Connector to the other end
of the long tubing piece.
Connect tubing to
the Breast Cup.
Attach the open end of the
tubing securely onto the post
on the side of the Breast Cup.
If you are double pumping,
attach both short tubing pieces
to the Breast Cups.
Connect the Adapter.
If you are using the AC/DC Adapter,
connect the AC/DC Adapter to the bottom
of the Pump first and then plug it into the
wall outlet. If you are using the Car
Adapter, connect the Car Adapter to the
bottom of the Pump first and then plug it
into the car's auxiliary power outlet. The
lights will illuminate indicating that the
Pump is ready to use.
If you are operating the Pump from the
front pocket of your Tote Bag, you can feed
the AC/DC Adapter or Car Adapter wire
through the hole at the side of the pocket
for easy access.
2
3
If you are single pumping,
attach a short tubing piece to
one hole on the “Y” Connector.
Insert the attached plug into the
open hole on the “Y” Connector.
SINGLE
If you are double pumping,
attach a short tubing piece to
each hole on the “Y” Connector.
DOUBLE
How to Connect
your Playtex
™
Embrace
™
Breast Pump
✔ Make sure all tubing
connections are
secured properly.
✔ Check the connections
to the “Y” Connector.
✔ Check the connections
inside the Tubing
Storage Compartment.
✔ Check the connection(s)
to the Breast Cup(s).
✔ If single pumping, be
sure that the open hole
on the “Y” Connector is
sealed with the
attached plug.
Troubleshooting
Tips

8
How to Operate
your Playtex
™
Embrace
™
Breast Pump
Before you operate your Playtex™Embrace™
Breast Pump, be sure you have assembled
correctly the Breast Cups and connected
them to the Pump. For proper suction
levels and function, there must be no air
leaks or opening between the Pump and
the Breast Cups. Check that the tubing and
Breast Cups are fully sealed.
If Double Pumping…
If double pumping, try holding both cups
with one arm as shown. This method allows
you to keep one hand free while you begin
pumping. Be sure to position each Breast
Cup with your nipple centered on the cup.
1If Single Pumping…
If single pumping, position the
Breast Cup on your breast with
your nipple centered in the cup.
Begin Pumping.
Press the On/Off button on the Pump
to begin pumping. We recommend that
you start with the speed and suction
levels on their lowest settings.
Adjust Speed and
Suction levels.
Using the arrow buttons, increase/
decrease the speed and suction
levels until you find the levels that
are comfortable for you.
Stop Pumping.
When you have finished pumping, press the On/Off button on the Pump. The Pump will remember
your speed and suction levels while it is still plugged in.
2
3
4
with your Playtex™Embrace™Breast Pump, call Playtex Customer Care at 1-800-222-0453
Monday through Friday from 8 am to 8 pm, or visit www.playtexbaby.com.
For help
DOUBLE
SINGLE
