plumBOSS SSTP50 Installation and operating manual

Head Ofce: 53 Taylor St Bulimba | Ph: 1300 331 141 |Fax :[phone]
E: [email protected] | www.plumboss.com.au
The pump is usually maintenance
free as long as clean water is used.
As a consequence of pressure
release any dirty water from the
water installation can ow back into
the test pump.
Any particles in the water can impair
the performance of the pump.
It is therefore recommended to
unscrew valves and ush both
valves and seats.
At the same time the o-rings can
be checked and lubricated with
non-toxic lubricant or if necessary
replaced.
Dirt in the tank should be removed
and inlet lter should be unscrewed
and cleaned regularly with clean
water.
SERVICE AND REPAIR OF SSTP50
STAINLESS
STEEL TEST
PUMP
Easy service and repair
instructions
and operation manual

Head Ofce: 53 Taylor St Bulimba | Ph: 1300 331 141 |Fax :[phone]
E: [email protected] | www.plumboss.com.au
1. Place pump close to water installation you like to test.
2. Insert rubber washer (supplied) into hose tting and connect to water installation.
3. Fill pump tank with max. 12L of clean water.
4. Open both valves and operate pump until water runs back into tank under valve 1
(situated below gauge, this disperses the air in pump body).
5. Close valve 1.
6. Operate pump until required pressure is reached. Recommendation: because of air in
system and hose we recommend to increase testing pressure by 2-5 bar (1bar=100kpa)
7. As soon as testing pressure is reached close valve 2 (situated below hose), testing
pressure now rests on installation and gauge only not on pump.
8. When test is nished open both valves to release pressure.
9. In respect to connections, pressure and testing time, always follow testing procedures
from the water authorities.
OPERATION OF STAINLESS STEEL TEST PUMP (SSTP50)
Other plumBOSS products
RUFIN TEST KIT (RTK02)
The RTK02 allows you to hold the pressure for the time specied by the inspector and the
test bucket can be taken away so that it is not stolen or can be used on multiple jobs.
HOSE TEST KIT (HTK01/HTK01NSW)
2500kpa Water Pressure Gauge with 300mm of hose and standard tap ttings. These units
are useful when explaining difference between volume and pressure problems. Also required
for checking pressure when installing pressure sensitive ttings
GAUGES (GO100/GO2500)
A variety of dry and liquid lled gauges are
available through plumBOSS AUSTRALIA.
