PNJ AllRoad User manual

1
EN
User manual
English
AllRoad
Ultra HD
4K
4k 25fps / 1080p 60fps
720p 90fps
resolution:
8m
Wi Function Wide angle
Thank you for choosing a PNJ product. This manual describes how to prepare and use your product. It’s also providing information about the
utilization and safety precautions, the regulations, compliance and technical specications of the device. Please read completely, carefully and
regularly before use, become familiar with all the feature of the device and ensure safety use of your drone to fully enjoy with it. Keep this manual
for future use. The manual is also available on our website www.pnj.fr under the heading «User manuals».
www.pnj.FR

1
EN
1 ATTENTION / WARNING / WAARSCHUWING ........................................................................................ 3
2.Battery ....................................................................................................................................................4
3.Precaution of use ...................................................................................................................................6
4.Warning ...................................................................................................................................................7
5.Download the App ..................................................................................................................................8
6.Included in the pack ...............................................................................................................................9
7.Camera parts name .............................................................................................................................10
8.Specications .......................................................................................................................................11
9.Camera conguration ..........................................................................................................................13
Charging the battery ......................................................................................................................13
Waterproof camera .........................................................................................................................14
Inserting the memory card.............................................................................................................14
10.Camera operation ...............................................................................................................................16
Turning On And Off The Camera. ...................................................................................................16
System Setup..................................................................................................................................16
Function conguration ...................................................................................................................17
Changing the mode of camera.......................................................................................................19
CONTENTS

2
EN
Recording videos ............................................................................................................................19
Taking Still Photos..........................................................................................................................21
Playback..........................................................................................................................................22
Connect the camera to a PC...........................................................................................................23
Using a card reader.........................................................................................................................23
Connecting the camera to a PC via USB cable..............................................................................23
Connecting the camera to a HD TV ...............................................................................................24
11.Maintenance........................................................................................................................................26
12.Warranty ..............................................................................................................................................27
13.Recycling .............................................................................................................................................29
14.Declaration of conformity...................................................................................................................30
15.Trademarks .........................................................................................................................................31
16.Modications ......................................................................................................................................31

3
EN
1.ATTENTION / WARNING / WAARSCHUWING
Veuillez lire ce mode d'emploi entièrement et attentivement avant toute utilisation. Retrouvez le manuel mis à jour
sur notre site web dans la rubrique "Mode d'emplois": www.pnj.fr/modes-demploi/
ATTENTION: Toutes les précautions d'utilisation concernant les batteries doivent être suivies rigoureusement. Une
mauvaise manipulation de la batterie peut provoquer un incendie, une explosion, des blessures personnelles ou des
dégâts matériels.
Please read the operation manual carefully before using the product. The english User Manual can be downloaded
on our website: www.pnj.fr/en/user-manuals/
WARNING : Batteries are dangerous, please follow the instructions to avoid injuries or damages.
Lees de instructies in de bedieningshandleiding zorgvuldig door voordat u onze producten gebruikt
De bedieningshandeleiding kunt u downloaden vanaf onze website: www.pnj.fr/en/user-manuals/
WAARSCHUWING : Baterijen zijn gevarlijk, het niet opvolgen van de gebruikshandekeiding kan blessures en schaden
veroorzaken.
nl
en
fr

4
EN
2.BATTERY
- By owning, charging or using the Li-battery, you assume all risks associated with the use of lithium
batteries.
- Always keep out of reach of children.
- Never leave the battery unattended while charging.
- Never leave the battery charged for more than 1 hour.
- Use only the USB charger provided in the pack. Never use a non-adaptable charger.
- Before charging the battery, check that it is not damaged. Check that the battery has not swollen or
that the battery compartment is not punctured. If you notice any of these situations: DO NOT CHARGE
THE BATTERY!
- A used battery must be removed from the unit and replaced.
- If you notice that the battery starts to swell during charging, disconnect the battery immediately
and do not use it again. Continued use of an inflated or deteriorated battery may cause an explosion.
- Make sure that the output voltage of the charger matches the battery voltage. Do not charge at a
higher current than recommended. Use only the charger provided in the pack.
- Disconnect the battery from the charger if it becomes too hot (Never exceed 49 ° C / 120 ° F) or swells.
If the battery becomes hot, disconnect the charger immediately.
- Charge only on non-flammable surfaces. Never charge inside a vehicle!
- Do not expose the battery to any source of heat or high temperature.
- Never put the battery in contact with water or immerse it in any other liquid.

5
EN
- Improper use of the battery may cause re, explosion or other hazards.
- In case of re caused by the battery, do not use water to extinguish the re (sand is recommended).
- Do not carry unwrapped batteries in your pocket or bag, as the shock of the batteries against each
other could cause a short circuit.
- Store the battery in a dry place at room temperature.
ATTENTION ATTENTION ATTENTION ATTENTION ATTENTION ATTENTION
Always use a charger
suitable for Li-Po
Always charging
away from ammable
materials
Never leave the
battery unattended
while charging
Never change or
transform a battery Never use a hot battery
Never charge a
damaged battery

6
EN
When using your drone, be sure to observe the following precautions:
- Not suitable for persons under 3 years of age.
- Caution: risk of ingestion of small parts.
- Be sure to use this product in a safe and responsible manner to avoid personal injury and / or
property damage.
- Make sure that your use is in accordance with the legal provisions of the country where you are
located.
- Avoid contact with sand, dust, water, liquid substances or heat, it could cause irreversible damage.
- Not suitable for people with epilepsy.
- Observe the safety instructions in this manual.
- Use only the accessories supplied by PNJ.
- Before each utilization, check that the batteries are fully charged.
3.PRECAUTION OF USE

7
EN
The law required to use this action cam in prudent and responsible manners to avoid all human or material damage.
In case for unauthorized use or for illicit purposes, you will be fully responsible for any damage causes. Be sure
to respect laws, without violating the privacy of other people. PNJ assumes no responsibility in case of damage
resulting directly or indirectly from the use of this device, any parts of this device or the manual. PNJ is not
responsible for any accident, injury, death, loss or other claim of any kind related or resulting the use of this product.
4.WARNING

8
EN
5.DOWNLOAD THE APP
Scan the QR code bellow, to have the access to our website www.pnj.fr and download the application for free. You
can also search ''Allroad App'' in Google Play Store or Apple Store to download the application for being able to
control the action cam in distance via your smartphone.

9
EN
6.INCLUDED IN THE PACK
Pole mount Mount Helmet mount Quick release
USB CableExtension supportFixation screw
Switch supportHelmet pedestal

10
EN
1. Power/ Shutter/ Ok button
2. Mode button
3. Lens
4. Working/ Charging indicator light
5. Wi/ Down button
6. Voice cover
7. LCD Screen
8. HDMI jack
9. Reset
10. USB jack
11. TF Card slot
12. Tripod slot
7.CAMERA PARTS NAME

11
EN
Image Sensor Sony 8 Mega Pixels CMOS
LCD display 2.0", 960*240 TFT
Resolution Image: 2M/ 5M/ 8M/ 12M/ 16M
Video: 720P 30FPS/ 720P 60FPS/ 720P 90FPS/
1080P 30FPS/ 1080P 60FPS/ 2.7K 30FPS/ 3.2K 30FPS/ 4K 25FPS
Aperture F2.2, f=2.65mm
Lens feature 6G Wide lens, FOV 130
Focus 1.5m~innity
White balance Auto/ Sunny/ Cloudy/ Incandescent light/ Fluorescent light
Exposure +3.0 EV ~ -3.0 EV in 1.0EV increment
Webcam Yes ( by using a USB cable )
8.SPECIFICATIONS

12
EN
Video out HDMI
PC interface Micro USB 2.0
Microphone Built-in
Speaker Built-in
Storage Micro SD card, up to 64GB
Power source Built-in Li-ion rechargeable battery 1000mAh
Supported O/S Microsoft Windows XP, Vista, 7 ou Mac 10.5 (Or above)
Dimensions 68 x 49.5 x 37.8mm

13
EN
9.CAMERA CONFIGURATION
• Charging the battery
The camera has an internal lithium battery. Please follow bellow steps to charge the battery when in
rst use or in low power.
1. Long press the power button to turn off the camera.
2. Open the cover on the side of the camera and nd the USB slot.
3. Connect the camera to the computer or a charger through the USB cable for battery charging.
4. When charging, the indicator light will turn red and flicker.
5. Once the charging completed, the indicator light will keep red.
Please unplug the USB cable.
Notice : The camera body may get warner after using for long time, this is normal.

14
EN
• Waterproof camera
The Allroad camera is waterproof itself. If the cover is well closed, you can use it underwater without a
waterproof case. For a better outdoor utilization, we are providing accessories to mount your camera.
• Inserting the memory card
This camera is not equipped with an internal memory card. For normal operation, please prepare a TF
card (at least class 4) rst and follow below steps to insert the card.
1. Turn off the camera
2. Open the cover on the side of the camera and nd the TF card slot. Then insert the card in the
correct direction. You will hear a ''click'' sound if the memory card has been inserted into camera
successfully.

15
EN
Notice
1. Must use Class 4(at least) or higher speed rate TF card slot. Then insert the
card in correct direction. you will hear a ''click'' sound if the memory card has been
inserted into the camera successfully.
2. Please format the TF card before using. make sure the camera is turned off before
inserting or removing the card.
3. Using poor quality or counterfeit memory card will lead to many problems such
as crashing, can not taking photo or video, damaging the les and so on. Suggest
to use brand memory card for improving the stability of camera. It has higher
requirement for TF card when in moving or long-time continuous shooting.
4. It is important to keep TF card clean. Do not adhere any liquid, dust and particles
on the surface of card.

16
EN
10.CAMERA OPERATION
• Turning On and Off the camera
1. Press the Power/ Shutter button to turn on the camera.
2. Long press the Power/Shutter button to turn off the camera.
Tips: The working indicator light will turn blue after turning on the camera.
• System setup
1. Turn on the action camera.
2. Press Mode button to switch to the setting screen.
3. Press OK button to enter the function setting screen.
4. Then press Mode button to chose the system setting menu screen as below.
5. Press Down button to scan all menu options.
6. Press OK button to chose and conrm the target menu.
7. Press Mode button to switch to icon, the screen will show “ Press OK To Exit ”.Then press the OK
button to exit.

17
EN
Menu Function
Exposure Set the exposure value to compensate light. Solve the problems of shooting
under poor or strong light.
Options:-3/ -2/ -1/ 0/ 1/ 2/ 3
White
balance
Set the white balance to adapt to different light sources. Options: Auto/ Sunny/
Cloudy/ Incandescent Light/ Fluorescent Light
rotation
The content on display screen will be inverted.You can invert the camera to
shoot. Press the OK button to select or cancel.
Driving mode Open/Close the function of driving recorder. Press the OK button to select or
cancel.
Wi-Fi Open/ Close WiFI. Press the OK button to select or cancel.
System setup menu list as below:

18
EN
Light Source
Frequency
Set the light source frequency according to your region. Options: Auto/ 50Hz/
60Hz.
LED Indicator
Light
Open/Close the LED indicator light. Press the OK button to select or cancel.
Screensaver Options : Close/ 10s/ 20s/ 30s.
Auto
Shutdown
For saving power, the camera will close automatically after a preriod of time if
not using.
Options : Close/ 1 minute/ 3 minutes/ 5 minutes
Time
Watermark
The date and time will be on the photos and videos les if this option is choosen.
Press the OK button to select or cancel.

19
EN
• Changing the mode of camera
The camera has 4 differents modes : capture mode, video mode, sport video mode, playback mode.
Press repeatedly the Mode button to select one mode.
Video Mode For recording video
Capture Mode For taking still photos
Sport Video Mode For recording slow motion video.
Playback Mode For playing the recorded les.
• Recording Videos
1. Turn on the camera, press the Mode button to switch to video mode.
2. Start to record video.
- Use the LCD screen to view your subject.
- Press the Shutter button to start recording.
- The record duration will be shown on the LCD display.
- If using a low speed card, the video size will be adjusted to 720P automatically.
3. Finish recording.
- Press the Shutter button again to stop recording.
- The camera will stop recording automatically once capacity of the memory card is
full.
