POK DN500 User manual

Page 1
Presentation
IMPORTANT: Please read this manual before putting the equipment into service
Construction
- Construction aluminium alloy AGS T5.
- Protection against mecanical and chimical attack by hardcoating anodization and PTFE or with a polyester paint.
- Handle in aluminium alloy.
- Body and injector in brass.
- Swivel and cap in delrin.
- Arm, fence and ring in stainless steel.
- Net in aluminium wire gauze and fireproof.
Characteristics
- Max working pressure 16 bar (235 PSI).
- Injectors rotate automatically with the jets pressure.
- Weight : 13,5 kg (30lb).
Stand
View without net
View with net
CODE
18020
Injector nozzle
Protection fence
Handle
Net
Inlet coupling
Id plate
