E111/F111 IntelliTec Models
OWNER'S MANUAL
Manual No. 513532-5 Jan. 2006, Rev. 0

We stock the parts you need.

Our Technicians are factory
trained and are certified in the
Stoelting Technicare program.
Model No.: _______________________
Serial No.: _______________________
Purchase Date: ____________________
Start-Up Date:____________________
CALL
Distributor: _________________________
Phone No.: _________________________
(fill in or affix label)
Need Parts or Service?

This manual provides basic information about the freezer. Instructions and suggestions are given
covering its operation and care.
The illustrations and specifications are not binding in detail. We reserve the right to make changes
to the freezer without notice, and without incurrring any obligation to modify or provide new parts
for freezers built prior to date of change.
DO NOTATTEMPT to operate the freezer until instructions and safety precautions in this manual
are read completely and are thoroughly understood. If problems develop or questions arise in
connection with installation, operation, or servicing of the freezer, contact the company at the
following location:
STOELTING, LLC Ph: 800-558-5807
502 Hwy. 67
Kiel, WI 53042 Fax: [phone]
Owner's Manual
For Endura E111 and Futura F1 11
Stoelting Counter Model Gravity Freezer
Soft Serve

Safety Alert Symbol:
This symbol Indicates danger, warning or caution.
Attention is required in order to avoid serious personal
injury. The message that follows the symbol contains
important information about safety.
Signal Word:
Signal words are distinctive words used throughout
this manual that alert the reader to the existence and
relative degree of a hazard.
CAUTION
The signal word “CAUTION” indicates a potentially
hazardous situation, which, if not avoided, may result
in minor or moderate injury and equipment/property
damage.
A Few Words About Safety
Safety Information
Read and understand the entire manual before
operating or maintaining Stoelting equipment.
This Owner's Manual provides the operator with
information for the safe operation and maintenance of
Stoelting equipment. As with any machine, there are
hazards associated with their operation. For this
reason safety is emphasized throughout the manual.
To highlight specific safety information, the following
safety definitions are provided to assist the reader.
The purpose of safety symbols is to attract your
attention to possible dangers. The safety symbols,
and their explanations, deserve your careful attention
and understanding. The safety warnings do not by
themselves eliminate any danger. The instructions or
warnings they give are not substitutes for proper
accident prevention measures.
If you need to replace a part, use genuine Stoelting
parts with the correct part number or an equivalent
part. We strongly recommend that you do not use
replacement parts of inferior quality.
WARNING
The signal word “WARNING” indicates a potentially
hazardous situation, which, if not avoided, may result
in death or serious injury and equipment/property
damage.
CAUTION
The signal word “CAUTION” not preceded by the safety
alert symbol indicates a potentially hazardous situa-
tion, which, if not avoided, may result in equipment/
property damage.
NOTICE
The signal word “NOTICE” indicates information or
procedures that relate directly or indirectly to the
safety or personnel or equipment/property.

SECTION DESCRIPTION PAGE
1. INTRODUCTION
1.1 Description............................................................................................................. 1
1.2 Specifications ........................................................................................................ 1
2. INSTALLATION INSTRUCTIONS
2.1 Safety Precautions ................................................................................................. 3
2.2 Shipment and Transit.............................................................................................. 4
2.3 FreezerInstallation ................................................................................................. 4
3. INITIAL SET-UP AND OPERATION
3.1 Operator's Safety Precautions ................................................................................ 5
3.2 Operating Controls and Indicators........................................................................... 5
3.3 Sanitizing ............................................................................................................... 7
3.4 Freeze Down and Operation................................................................................... 8
3.5 MixInformation ....................................................................................................... 9
3.6 Removing Mix From Freezer .................................................................................. 9
3.7 Cleaning The Freezer ............................................................................................. 9
3.8 Disassembly of Freezer Parts ................................................................................ 9
3.9 Cleaning The Freezer Parts.................................................................................... 11
3.10 Sanitize Freezer and Freezer Parts ....................................................................... 11
3.11 Assembly of Freezer ............................................................................................. 11
3.12RoutineCleaning................................................................................................... 12
3.13PreventiveMaintenance ........................................................................................ 12
3.14 Extended Storage ................................................................................................. 14
3.15ProductConsistencyAdjustment ........................................................................... 15
3.16 Locking Out Control Panel..................................................................................... 15
4. TROUBLESHOOTING CHARTS
4.1 Error Codes ............................................................................................................ 17
4.2 Troubleshooting Error Codes .................................................................................. 17
4.3TroubleshootingCharts ........................................................................................... 19
5. REPLACEMENT PARTS ........................................................................................... 21
TABLE OF CONTENTS

LIST OF ILLUSTRATIONS
FIGURE TITLE PAGE
1-1 Model E111 & F111 Freezer .................................................................................. 1
1-2 FreezerSpecifications ........................................................................................... 1
2-1 WarningLabelLocations ....................................................................................... 3
2-2 Leveling ................................................................................................................. 4
2-3 SpaceandVentilationRequirements ..................................................................... 4
2-4 Electrical Plug ....................................................................................................... 4
3-1 FreezerControls .................................................................................................... 5
3-2 IntelliTecControl .................................................................................................... 7
3-3 MixInletRegulator ................................................................................................. 7
3-4 SanitizingHopper .................................................................................................. 8
3-5 DrainingSolution ................................................................................................... 8
3-6 DispensingProduct ............................................................................................... 8
3-7 Auger Flight Wear..................................................................................................10
3-8 RemovingAugerSupport .......................................................................................10
3-9 RemovingAugerShaft andFlights .........................................................................10
3-10 RemovingO-Ring ...................................................................................................10
3-11 CleaningFreezerBarrel .........................................................................................11
3-12 Auger Parts ...........................................................................................................11
3-13 Front Door Parts ....................................................................................................12
3-14 ProductConsistency Control .................................................................................15
3-15 Locked ControlDisplay (In ServeMode) .................................................................15

1
SECTION 1
DESCRIPTION AND SPECIFICATIONS
1.1 DESCRIPTION
The Stoelting Endura/Futura 111 counter freezers are
gravityfed.Thefreezersareequipped with fully automatic
controls to provide a uniform product. The freezers are
designed to operate with almost any type of commercial
softserveornon-dairymixavailable,includingicemilk,ice
cream,yogurt,andfrozendietarydesserts.Thismanualis
designed to assist qualified service personnel and opera-
tors in the installation, operation and maintenance of the
StoeltingE111 and F111 gravity freezers.
Figure 1-1 Model E111 & F111 Freezer
Figure 1-2 Freezer Specifications

2
MODELENDURA/FUTURA111
COUNTERMODEL
GRAVITYFREEZER
DIMENSIONS:
Freezer: 15" (38 cm) wide x 28.6" (72 cm) deep x 35.6" (90 cm) high
Crated: 19.5" (50 cm) wide x 33" (84 cm) deep x 40" (102 cm) high
WEIGHT:
Freezer: 230 lbs. (140 kg) Crated: 275 lbs. (125 kg)
ELECTRICAL:
Description Endura111-37I Futura111-38I
Voltage AC 1 PH 115V 1 PH 208/230
Total Run Amps 14.00 10.00
DriveMotor 3/4 HP 3/4 HP
Use 20 amp HACR circuit breaker.
Automatic safeguard circuit built into electronic control-protects major
freezercomponentsunderabnormaloperatingconditions.
COOLING:
Air cooled requires minimum 3" (7.6 cm) air clearance on right and left hand side.
No clearance needed in the rear. (See Fig.5).
HOPPER:
3 Gallons (11.5 liters) refrigerated and insulated.

3
2.1 SAFETY PRECAUTIONS
Do not attempt to operate the freezer until the safety
precautions and operating instructions in this manual are
readcompletelyand are thoroughlyunderstood.
Takenoticeofallwarninglabels on thefreezer.Thelabels
have been put there to help maintain a safe working
environment.Thelabelshavebeendesignedtowithstand
washingandcleaning.Alllabelsmustremainlegibleforthe
lifeofthefreezer.Labelsshouldbecheckedperiodicallyto
be sure they can be recognized as warning labels.
If danger, warning or caution labels are needed, indicate
thepartnumber,typeoflabel,locationoflabel,andquantity
required along with your address and mail to:
STOELTING, INC.
ATTENTION: Customer Service
502 Hwy. 67
Kiel, Wisconsin 53042
SECTION 2
INSTALLATION INSTRUCTIONS
Figure 2-1 Warning Label Locations

4
2.2 SHIPMENT AND TRANSIT
Thefreezerhasbeenassembled,operatedandinspected
at the factory. Upon arrival at the final destination, the
complete freezer must be checked for any damage which
mayhave occurred during transit.
With the method of packaging used, the freezer should
arrivein excellentcondition.THE CARRIERIS RESPON-
SIBLEFORALLDAMAGEINTRANSIT,WHETHERVIS-
IBLEORCONCEALED.Donotpay the freightbilluntilthe
freezerhasbeencheckedfordamage.Havethecarriernote
anyvisibledamageonthefreightbill.Ifconcealeddamage
and/or shortage is found later, advise the carrier within 10
days and request inspection. The customer must place
claim for damages and/or shortages in shipment with the
carrier.Stoelting,Inc.cannotmakeany claims against the
carrier.
2.3 FREEZER INSTALLATION
Installationofthefreezerinvolvesmovingthefreezerclose
to its permanent location, removing all crating, setting in
place, assembling parts, and cleaning.
A. Uncratethefreezer.
B. Accuratelevelingisnecessaryforcorrectdrainage
of freezer barrel and to insure correct overrun.
Place a bubble level on top of the freezer at each
cornertocheckforlevelcondition.Ifadjustmentis
necessary,levelthefreezer byturningthebottom
part of each leg in or out. Then separate freezer
basegasketand installwithseam totheback and
angle to the top. (Fig. 4).
C. Thefreezerisequippedwithanaircooledcondenser
and requires correct ventilation. The right side of
thefreezeristheairintakeandleftsidedischarge.
Bothsidesmusthave3"clearancethetoprequires
10" of clearance. (Fig. 5).
CAUTION
Failure to provide adequate ventilation will void war-
ranty.
D. Place the OFF-ON switch in the OFF position.
(Fig.10).
E. Connect the power cord to the proper power
supply.Theplugisdesignedfor208or230volt/20
ampduty.Checkthenameplateonyourfreezerfor
proper supply. The unit must be connected to a
properlygroundedreceptacle.Theelectricalcord
furnished as part of the freezer has a three prong
groundingtypeplug(Fig.6).Theuseofanextension
cord is not recommended, if necessary use one
withasize12gaugeorheavierwithgroundwire.Do
not use an adapter to get around grounding
requirement.
WARNING
Do not alter or deform electrical plug in any way.
Altering the plug to fit into an outlet of different con-
figuration may cause fire, risk of electrical shock,
product damage and will void warranty.
F. Install the drip tray, drain tray, hopper cover and
other miscellaneous parts on the freezer.
Figure 2-3. Space and Ventilation Requirements
115V
20 Amp
Figure 2-4. Electrical Plug
208/230V
20 Amp
Figure 2-2 - Leveling

5
Figure 3-1 Freezer Controls
3.1 OPERATOR’S SAFETY PRECAUTIONS
SAFE OPERATION IS NO ACCIDENT; observe these
rules:
A. Know the freezer. Read and understand the
Operating Instructions.
B. Notice all warning labels on the freezer.
C. Wearproperclothing.Avoidloosefittinggarments,
andremovewatches,ringsorjewelrywhichcould
cause a serious accident.
D. Maintain a clean work area. Avoid accidents by
cleaning up the area and keeping it clean.
E. Stay alert at all times. Know which switch, push
button or control you are about to use and what
effect it is going to have.
F. Disconnectelectricalcordformaintenance.Never
attempt to repair or perform maintenance on the
freezer until the main electrical power has been
disconnected.
G. Donotoperateunderunsafeoperatingconditions.
Neveroperate the freezer if unusualor excessive
noise or vibration occurs.
3.2 OPERATING CONTROLS AND INDICATORS
Beforeoperatingthefreezer,itisrequiredthattheoperator
know the function of each operating control. Refer to
Figure 3-1 for the location of the operating controls on the
freezer.
WARNING
High voltage will shock, burn or cause death. The
OFF-ON switch must be placed in the OFF position
prior to disassembling for cleaning or servicing. Do
not operate machine with cabinet panels removed.
SECTION 3
INITIAL SETUP AND OPERATION
Dispense RateAdjustor
Main Power OFF-ON
IntelliTec Control
(See Figure 3-2)

6
A. Spigot Switch
The spigot switch will automatically actuate the
auger drive and refrigeration systems when the
spigot is opened to dispense product. When the
spigot is closed, the drive motor and compressor
will remain “on” until the product in the barrel
reaches the proper consistency.
B. Main Freezer Power OFF-ON Switch
The Main Freezer Power OFF-ON switch is a two
positiontoggleswitchusedtosupplypowertothe
control circuit. When the switch is in the OFF
position, power will not be supplied to the control
board or refrigeration system. When the switch is
in the ON position, the freezer will operate in the
freezing mode or cleaning mode. The freezer will
be in the sleep mode until a switch is activated.
C. PUSH TO FREEZE Switch
The PUSH TO FREEZE button is used to initiate
the serve mode. To start the freezer, place the
Main Freezer Power OFF-ON switch in the ON
positionandpressthePUSHTOFREEZEbutton.
NOTE
After the drive motor starts, there is a 3 second de-
lay before the compressor starts.
D. LEDs
Themembraneswitchfeaturestwolights;agreen
LED and an amber LED. The green LED is lit
duringservemode.Duringfreezedown,thegreen
LED is not lit. When product consistency
approaches 90% in the freezing cylinder, the
greenLEDflashes.The amberLEDislitduringall
other modes. In the event of an error or when the
freezingcylinderisoff,bothLEDswillalternatively
flash.
NOTE
If the freezer shut s off and alternating green and
amber lights flash on the control panel, the freezer
is running in the "hopper only" mode or the freezer
is in an error condition. Note the display on the LCD
screen. If the screen displays an error, turn the Main
Freezer Power OFF-ON switch to the OFF posi-
tion, correct the problem (Refer to Troubleshooting
in Section 4) and turn the freezer back on.
E. CLEAN Switch
The CLEAN button will stop all refrigeration and
start the auger rotatating. A CLEAN message will
display on the LCD screen and a 5 minute
countdown begins. To exit the CLEAN mode,
presstheCLEANbuttonagain.Ifthefreezerisleft
in CLEAN for more than 30 minutes, it will go into
anerrortopreventdamagetothefreezingcylinder.
When this error occurs, refrigeration will start to
prevent mix spoilage. To reset, place the Main
FreezerPowerOFF-ONswitchintheOFFposition
and back in the ON position.
F. Mix Low Light Indicator
The MIX LOW message will appear on the LCD
displaytoalerttheoperatortoalowmixcondition.
The message will display when there is
approximatelyonegallonofmixleftinthehopper.
When the MIX LOW message is displayed, refill
hopper immediately.
NOTE
Failure to refill hopper immediately may result in
operational problems.
G. DISPENSE RATE ADJUSTERS
The dispense rate adjuster limits the opening of
the spigot. To adjust product dispense rate, turn
the adjusting know clockwise for slower flow and
counterclockwise for faster flow. It takes at least
five complete turns of the adjusting knob to make
a noticeable difference in the dispense rate.
H. FRONT DOOR SAFETY SWITCH
The front door safety switch prevents the auger
from turning when the front door is removed. The
switch is open when the door is not in place and
closed when the door is properly installed.

7
I. MENU NAVIGATION BUTTONS
The Menu Navigation Buttons allow the user to
display information regarding the freezer's status
ofoperationaswellasadjustproductconsistency.
Selection Button (SEL) The SEL button is not
functional in the normal operation mode. This
button is only used by service technicians for
freezer calibration.
Set Button (SET) Pressingthis button will save a
change made to the product consistency setting.
Refer to Section 3-15 for consistency adjustment
procedures.
Left Arrow Button (Õ)Pressing any button on
the control panel will automatically illuminate the
display.Thebacklightwillturnoffseveralseconds
after use. To keep the display constantly light,
pressandholdtheleft(Õ)buttonforfiveseconds.
The backlight function can be reset to normal
operation in the same manner.
Up Arrow Button (×)Pressing this button will
change the value of the product consistency.
Refer to Section 3-15 for consistency adjustment
procedures.
3.3 SANITIZING
Sanitizing must be done after the freezer is cleaned and
justbeforethehopperisfilledwithmix.Sanitizingthenight
before is not effective. However, you should always clean
the freezer and parts after each use.
THE UNITED STATES DEPARTMENT OF AGRI-
CULTURE AND THE FOOD AND DRUG ADMIN-
ISTRATION REQUIRE THATALL CLEANINGAND
SANITIZING SOLUTIONS USED WITH FOOD
PROCESSING EQUIPMENT BE CERTIFIED FOR
THIS USE.
When sanitizing the freezer, refer to local sanitary regula-
tions for applicable codes and recommended sanitizing
products and procedures. The frequency of sanitizing
must comply with local health regulations.
Mix sanitizer according to manufacturer’s instructions to
provide a 100 parts per million strength solution. Mix
sanitizer in quantities of no less than 2 gallons (7.5 liters)
of 120°F water. Allow sanitizer to contact the surfaces to
besanitizedfor5minutes.Anysanitizermustbeusedonly
in accordance with the manufacturer’s instructions.
CAUTION
Do not allow sanitizer to remain in contact with stain-
less steel freezer parts for prolonged periods. Pro-
longed contact of sanitizer with freezer may cause
corrosion of stainless steel parts.
In general, sanitizing may be conducted as follows:
A. Push the mix inlet regulator into hopper with air
inlet (long) tube toward the front of the freezer
(Fig. 3-3).
B. Prepare2gallons(7.5 liters) ofsanitizing solution
following manufacturer’s instructions. Pour into
hopper with mix inlet regulator in place.
C. Place the Main Freezer Power OFF-ON toggle
switch in the ON position and press the CLEAN
switch. Check for leaks.
Figure 3-2 IntelliTec Control
Push to Freeze
Green Light
Amber Light
SEL Button
SET Button
Clean Switch
Up Arrow Button
Left Arrow Button
Figure 3-3 Mix Inlet Regulator

8
D. Clean sides of hopper, mix inlet regulator and
underside of hopper cover using a sanitized soft
bristlebrushdippedinthesanitizingsolution.(Fig.
3-4).
E. Afterfiveminutes,placeabucketunderthespigot
andopenspigottodrainsanitizingsolution.When
solution has drained, press the CLEAN button to
stop the auger. Allow the freezer barrel to drain
completely (Fig. 3-5).
3.4 FREEZE DOWN AND OPERATION
This section covers the recommended operating proce-
dures to be followed for the safe operation of the freezer.
A. Sanitize just prior to use.
B. Place the Main Freezer Power OFF-ON switch in
the OFF position.
NOTE
Make sure the mix inlet regulator is in place before
adding mix.
C. With spigot open, pour approximately 1 gallon
(3.8 liters) of fully thawed mix into the hopper.
Allow the mix to flush out about 8 ounces (0.23
liters) of sanitizing solution and liquid mix. Close
the spigot.
D. Fill hopper with approximately 3 gallons (11.4
liters) of pre-chilled (40°F or 4°C) mix.
NOTE
Do not overfill the hopper . Mix level must not be
higher than the air inlet tube on the mix inlet regula-
tor.
E. The freezer barrel will automatically fill until it is
about 1/2 full. If freezer barrel does not fill, check
for obstruction in the mix inlet regulator. If freezer
barrel fills over 1/2 full, indicated by low overrun,
check for leaks at the mix inlet regulator o-ring or
check if the mix inlet regulator was installed
correctly or that the freezer is level.
F. Place the Main Freezer Power OFF-ON switch in
theONposition,thenpressthePUSHTOFREEZE
switch.
NOTE
After the drive motor starts, there is a 3 second de-
lay before the compressor starts.
G. After about 6 to 10 minutes the product will be at
consistency and the LCD screen will display
"SERVE". The product is ready to serve. Freeze
down time may be longer for some frozen diet
dessert mixes. High ambient temperatures may
extend freeze down time.
H. For normal dispensing, pull the spigot handle
down to fully open the spigot (Fig. 3-6).
Figure 3-4 Sanitizing Hopper
Figure 3-5 Draining Solution
Figure 3-6 Dispensing Product

9
NOTE
Refrigeration is automatically activated when the
spigot is opened. Close the spigot completely after
dispensing.
I. Thefreezerisdesignedtodispensetheproductat
areasonabledrawrate.Ifthefreezerisoverdrawn,
theresultisasoft product oraproductthat will not
dispense at all. If this should occur, wait until the
bars fill the lower section of the display (Fig. 3-7).
J. Do not operate the freezer when the MIX LOW
light is on or with less than 1-3/4 inches (4.4 cm)
ofmixinthehopper.Refillthehopperimmediately.
NOTE
The freezer has standby and sleep modes. When
the freezer is not used, after a preset number of
freezing cycles, it will enter the standby mode (fol-
lowed by sleep mode) and remain there until some-
one draws a product or pushes the PUSH T O
FREEZE switch. In the sleep mode, the freezer will
keep the product below 41°F (5°C). Sleep modes
are not to be used in place of cleaning and sanitiz-
ing. Frequency of cleaning and sanitizing is deter-
mined by Federal, State, and local regulatory agen-
cies.
3.5 MIX INFORMATION
Mix can vary considerably from one manufacturer to
another. Differences in the amount of butterfat content
and quantity and quality of other ingredients have a direct
bearingonthefinishedfrozenproduct.Achangeinfreezer
performance that cannot be explained by a technical
problem may be related to the mix.
Proper product serving temperature varies from one
manufacturer’smixtoanother. Softservemixesgenerally
providesatisfactoryproductfrom18°to20°F(-7°to-6°C),
shake mixes 24° to 28°F (-4° to -2°C).
When checking the temperature, stir the thermometer in
the frozen product to read the true temperature.
Old mix or mix that has been stored at elevated tempera-
tureswillproducepoor-qualityproductwithabadtasteand
unacceptable appearance. To retard bacteria growth in
dairy based mixes, the best storage temperature range is
between 36° to 40°F (2.2° to 4.4°C).
Some products tend to foam more than others. If foam
appearsinthehopper,skimoffwithasanitizedutensiland
discard. Periodically, stir the mix in the hopper with a
sanitized utensil to help prevent excess foam.
3.6 REMOVING MIX FROM FREEZER
To remove the mix from the freezer, refer to the following
steps:
A. Removethemixinletregulatorfromthehopperby
pulling straight up.
B. Place the Main Freezer Power OFF-ON rocker
switch in the ON position and push the CLEAN
switchtorotate theauger.Allow themixto agitate
infreezerbarrel untilthe mix hasbecome aliquid,
about 5 minutes.
C. Drain the liquid mix by opening the spigot. A
bucket or container should be placed under the
spigot to catch the liquid mix.
D. Place the Main Freezer Power OFF-ON switch in
the OFF position.
3.7 CLEANING THE FREEZER
NOTE
The frequency of cleaning the freezer and freezer
parts must comply with local health regulations.
After the mix has been removed from the freezer, the
freezer must be cleaned. To clean the freezer, refer to the
following steps:
A. Close the spigot and fill the hopper with 2 gallons
(7.5 liters) of cold tap water.
B. Place the Main Freezer Power OFF-ON switch in
theONpositionandpresstheCLEANswitch.The
auger will start to rotate.
C. Allow the water to agitate for approximately 5
minutes.
NOTE
If freezer is left in CLEAN for more than 20 minutes,
the display will show an error code. To reset, place
the Main Freezer Power OFF-ON switch in the OFF
position and back in the ON position.
Figure 3-7. During Freezing Cycle

10
D. Open the spigot to drain the water. Remember to
place a bucket or container under the spigot to
catchthewater.Whenthewaterhasdrained,turn
theOFF-ONswitch totheOFF position.Allowthe
freezer barrel to drain completely.
E. Repeat Steps A through D using a mild detergent
solution and warm water.
3.8 DISASSEMBLY OF FREEZER PARTS
CAUTION
Hazardous Moving Parts
Revolving auger shaft can grab and cause injury.
Place the Main Freezer Power OFF-ON switch in
the OFF position before disassembling for cleaning
or servicing.
Inspection for worn or broken parts should be made each
time the freezer is disassembled. All worn or broken parts
should be replaced to ensure safety to both the operator
and the customer and to maintain good freezer perfor-
mance and a quality product. Check the wear line on the
auger flights on a regular basis (Fig. 3-8) and replace as
needed.Frequencyofcleaningmustcomplywiththelocal
health regulations.
To disassemble the freezer, refer to the following steps:
A. Remove hopper cover and drain tray.
B. Removethemixinletregulatorfromthehopperby
pulling straight up.
C. Remove the front door by turning the circular
knobsandthenpullingthefrontdooroffthestuds.
D. Remove the rosette caps from the front door.
Push the spigot body through the bottom of the
front door and remove.
E. Removethefrontaugersupportandbushing(Fig.
3-9).
F. Remove the auger assembly from the freezer
(Fig.3-10). Pullthe augerout ofthe freezer barrel
slowly. As the auger is being pulled out, carefully
remove each of the plastic flights with springs.
G. Keep the rear of the auger shaft tipped up once it
is clear of the freezer to avoid dropping rear seal.
H. Remove the rear seal.
I. Wipe socket lubricant from the drive end (rear) of
the auger with a cloth or paper towel.
J. Remove all o-rings from parts by first wiping off
the lubricant using a clean paper towel. Then
squeezetheo-ringupwardwithadrycloth(Fig.3-
11). When a loop is formed, roll out of the o-ring
groove.
CAUTION
Do not use any type of sharp object to remove the
o-rings.
Figure 3-8 Auger Flight Wear
Figure 3-9 Removing Auger Support
Figure 3-10 Removing Auger Shaft and Flights

11
3.9 CLEANING THE FREEZER PARTS
Place all loose parts in a pan or container and take to the
wash sink for cleaning. To clean freezer parts refer to the
following steps:
A. Place all parts in warm mild detergent water and
clean with brushes provided. Rinse all parts with
clean hot water.
B. Wash the hopper and freezer barrel with warm
detergentwaterandbrushesprovided.(Fig.3-12)
C. Cleantherearsealsurfacesfromtheinside of the
freezer barrel with warm detergent water.
D. Cleanthedrip trayandinsertwithasoapsolution.
Rinse with clean hot water.
3.10 SANITIZE FREEZER AND FREEZER
PARTS
A. Use a sanitizing solution mixed according to
manufacturer's instructions to provide 100 parts
per million strength solution. Mix sanitizer in
quantities of no less than 2 gallons (7.5 liters) of
120°F water. Allow the sanitizer to contact the
surfacestobesanitizedfor5minutes.Anysanitizer
must be used only in accordance with the
manufacturer's instructions.
B. Place all parts in the sanitizing solution, then
remove and let air dry.
C. Using this sanitizing solution and the large barrel
brush provided, sanitize the rear of the barrel by
dipping the brush in the sanitizing solution and
brushing the rear of the barrel.
3.11 ASSEMBLY OF FREEZER
Toassemblethefreezerparts,refertothefollowingsteps:
NOTE
Petrol Gel sanitary lubricant or equivalent must be
used when lubrication of parts is specified.
NOTE
The United States Department of Agriculture and
the Food and Drug Administration require that lu-
bricants used on food processing equipment be cer-
tified for this use. Use lubricants only in accordance
with the manufacturer’s instructions.
A. Assemble all o-rings onto parts dry, without
lubrication. Then apply a thin film of sanitary
lubrication to exposed surfaces of the o-rings.
Apply a thin film of sanitary lubricant to metal part
of rear seal. Also apply a thin film of sanitary
lubricant inside and outside of the front auger
support bushing.
B. Assemble the rear seal onto the auger with the
largeend tothe rear. Be sure theo-ring isin place
before installing the rear seal.
C. Lubricate the auger drive (rear) with a small
amountofwhitesocketlubricant.Asmallcontainer
of socket lubricant is shipped with the freezer.
D. Screw the springs onto the studs in plastic flights.
Springsmustbescrewedintotheflightscompletely
to provide proper compression (Fig. 3-13).
Figure 3-12 Cleaning Freezer Barrel
Figure 3-11 Removing O-Ring

12
CAUTION
Do not place the mix inlet regulator into the hopper
before installing the auger. Attempting to install the
auger with the mix inlet regulator in place will dam-
age the mix inlet regulator.
E. Installthe two plastic flights onto rearof the auger
and insert part way into freezer barrel.
F. Installtheremainingplasticflights,pushtheauger
into the freezer barrel and rotate slowly until the
auger engages the drive shaft.
G. Installthebushingandaugersupportintothefront
of the auger with one leg of the support pointing
straight up.
H. Install the spigot body with o-ring into the front
door from bottom (Fig. 3-14). Push straight up
until the spigot is in place.
I. Install the front door on the freezer.
J. Install the circular knobs on the freezer studs.
CAUTION
Overtightening or uneven tensioning of circular
knobs may cause damage to front door and cause
leaking. Hand tighten circular knobs evenly.
K. Look for the proper seal between the freezer
barrel, o-ring, and front door.
L. Install the mix inlet regulator into the freezer with
the air tube to the front of the freezer.
M. Install hopper cover and drain tray.
3.12 ROUTINE CLEANING
To remove spilled or dried mix from the freezer exterior,
simply wash in the direction of the finish with warm soapy
water and wipe dry. Do not use highly abrasive materials
as they will mar the finish.
3.13 PREVENTIVE MAINTENANCE
It is recommended that a maintenance schedule be fol-
lowed to keep the freezer clean and operating properly.
Cleaning and Sanitizing Information
Soft serve freezers require special consideration when it
comes to food safety and proper cleaning and sanitizing.
The following information has been compiled by Purdy
Products Company, makers of Stera-Sheen Green Label
Cleaner/Sanitizerandspecificallycoversissuesforclean-
ing and sanitizing frozen dessert machines. This informa-
tion is meant to supplement a comprehensive food safety
program.
Soil Materials Associated with Frozen Dessert
Machines
MILKFAT/BUTTERFAT – As components of ice-cream/
frozen custard mix, these soils will accumulate on the
interior surfaces of the machine and its parts. Fats are
difficulttoremove and helpattributeto milkstone build-up.
MILKSTONE – Is a white/gray film that forms on equip-
mentandutensilsthatcomeincontactwithdairyproducts.
Thesefilmswillaccumulateslowlyonsurfacesbecauseof
ineffective cleaning, use of hard water, or both. Milkstone
is usually a porous deposit, which will harbor microbial
contaminants and eventually defy sanitizing efforts.
Once milkstone has formed, it is very difficult to remove.
Without using the correct product and procedure, it is
nearly impossible to remove a thick layer of milkstone.
(NOTE: general-purpose cleaners DO NOT remove
milkstone.) This can lead to high bacteria counts and a
food safety dilemma.
IT IS BEST TO CONTROL MILKSTONE ON A DAILY
BASISBEFOREITCANBECOMEASIGNIFICANTFOOD
SAFETY PROBLEM.
Figure 3-14 Front Door Parts
Figure 3-13 Auger Parts
