Polaris CDMC-1000 User manual

CDMC-1000 Color Camera
Vandalproof IR Dome Camera
Specification
Packing List
No Name Model Number
2.
User Guide CDMC-1000
1
1.
Vandalproof IR Dome Camera CDMC-1000 1
Franchiser：
Notes:Before providing power for the
camera, please read this User Guide in
detail!
Do not attempt to disassemble the camera.
If the camera can not work, please contact
local franchiser or our company.
Model CDMC-1000
Pick up Element 1/3” SONY CMOS
Effective Picture Elements
(H×V) 1280×720
Horizontal Resolution 720P
0.01 Lux
0Lux (with IR LED ON)
S/N Ratio 52dB
Scanning System 2:1 interface
Synchronous System Internal, Negative sync.
Auto Electronic Shutter NTSC: 1/60s~1/100,000s, PAL: 1/50s~1/100,000s
Gama Characteristic 0.45
IR Distance 20 Meters (with ￠5X24PCS Infrared LED)
IR Status Under 10Lux by CDS
IR Power On CDS AUTO Control
Video Output 1Vpp, 75Ω
Auto Gain Control Auto
Power/Current DC12V(+/-10%)/550mA
Lens Board Lens 3.6mm/F2.0
Dimension (mm) ￠94 x 69(H) mm
Weight (g) 450
Storage Temperature -30~+60℃ RH95% MAX
Operating Temperature -10~+45℃ RH95% MAX
Minimum Illumination

INTRODUCTION
Congratulations on your purchase of this product.
This User Guide suits CDMC-1000 series product. We
adopt the latest SONY technical of sensor and driver. The
most attractive characteristics are small and easy hidden,
suits the elevator and corridor. In addition, it owns the
characters of high definition and stability, strong anti-
jamming, rich and real color. Fixing and using this model
are convenient too. It is very good for you to apply to your
CCTV system.
Please read this instruction manual carefully to en-
sure proper use of the product.
CONNECTING
BRIEF OF PRODUCT
* Sensor (COMS )
Adopt SONY 1/3"CMOS Sensor.
* Auto Gain Control (AGC)
Built-in auto gain control (AGC) circuit. The color camera
can get high definition picture in low Lux condition.
* Scanning Mode
NTSC or PAL mode.
* OSD SETTING
DC12V Power Supply
Monitor
CDMC-1000
TROUBLE AND SOLUTION
Link wire rule：
Power
Video
Note:
● Please note the camera’s operating temperature and its using
environment requirement. Avoid using the camera at too high or
too low temperatures. The operating temperature is -30~+60℃.
(Recommendatory operating temperature is -10~+45℃.)
● Never make the camera face the sun or bright object. Other-
wise, it will damage the CCD.
● Do not mount the camera near by the radiator or heater.
1. No Picture after providing power
. May be the power supply voltage abnormity, please check the power
supply voltage and pole whether exactitude.
. Please check all the connecting cable and monitors whether be connected
correctly or not.
2. The picture level direction have flowing interference ripples
. May be caused by the power supply AC ripples, it need filter the wave of the
power supply.
. Check the monitor and peripheral equipments used.
3. The picture background color changes continuously
. The fluorescent lamp’s electromagnetic field cause color roll. This is proper
phenomenon of the cameras.
. Reduce the fluorescent lamp numbers or increase the distance between the
camera and the fluorescent lamps can improve it.
. Use power supply external sync. camera can solve it.
4. The picture smear too mass
. The power supply’s voltage unstable.
. Connecting cables not connect correctly or have high impedance.
The symbol is intended to alert the user to the presence of
The symbol is intended to alert the user to the presence of
important operating and maintenance (servicing)
Instructions in the literature accompanying the appliance.
uninsulated ‘dangerous voltage’ within the product’s
enclosure that may be of sufficient Magnitude to constitute
a risk of electric shock to persons.
Video
DC12V
CAUTION:
CAUTION: TO REDUCE THE RISK OF ELECTRIC
SHOCK
DO NOT REMOVE COVER OR BACK NO USER
SERVICEABLE PARTS INSIDE. REFER SERVICING
RISK OF ELECTRIC. DO NOT OPEN
CAUTION: TO PREVENT ELECTRIC SHOCKS AND RISK OF
FIRE HAZARDS, DO NOT USE OTHER THAN
SPECIFIED POWER SOURCE.
Notes：
●The power supply must through safe attestation. Its output voltage,
current, voltage polarity and operating temperature must match the
camera’s requirement.
●When using the camera in the thunderbolt condition,please note to
mount Anti-thunder device or put off the power supply plug and cable.
●In order to capture high quality pictures, the power supply’s cable and
video output cable should not be too long.
MENU
UP
DOWN
RIGHT
LEFT
PRESS
KEY BOARD
3D-NR ON/OFF
AE MODE
GLOBAL
CENTER
CENTER WEIGHT
BLACK LIGHT
FRONT LIGHT
DISTINGUISH
IMAGE ENHANCE
SHARPNESS DETAIL AUTO
MANUAL VALUE (0-15)
EDGE AUTO
MANUAL VALUE (0-15)
CONTRAST AUTO MANUAL VALUE(0-255)
GAIN MAP
SATURATION AUTO
MANUAL VALUE(0-15)
MIRROR ON
OFF
FLIP ON
OFF
BRIGHTNESS 0.10.20......250
ZOOM IN 50. 60. 70. 80. 90.
DAY&NIGHT AUTO
IR-CUT
WB
AWB-PRO
AWB-TEMPORAL
AWB-AI
AWB-SZ
AWB-GW
AWB-CCT
ZONE MASKING
COLOR MO-
AREA NO.0
STATUS ON/OFF
HORIZON SIZE 0
VERTICAL SIZE 0
HORIZON MOVE 0
VERTICAL MOVE 0
AREA NO.1
AREA NO.2
AREA NO.3
AREA NO.4
AREA NO.5
AREA NO.6
AREA NO.7
DIRECTION
SENSITIVITY
WEAK
LOW
MIDDLE
HIGH
AREA NO.0
STATUS ON/OFF
COLOR BLACK\ WHITE\YELL
HORIZON SIZE
VERTICAL SIZE
HORIZON MOVE
VERTICAL MOVE
AREA NO.1
AREA NO.2
AREA NO.3
LANGUAGE ENGLISH
CHINESE
LOAD DEFAULT
SOFT VERION
SAVE&EXIT
