P. 1User Guide
TWO-WAY MANUAL TRANSMISSION REMOTE
STARTER SYSTEM WITH FULL ALARM
PS-7080 TW
UserGuide
A note concerning the battery inside the transmitter:
Depending on your usage of the transmitter, the battery can last anywhere
between 3 to 6 months. When the battery is low, the transmitter will
produce two beeps in a repetitive cycle. At that point you should
replace your battery with a new one. That is why we recommend that
you keep a spare battery somewhere handy such as the glove
compartment.

User Guide P. 2
Table of Contents
Table of Contents.................................2
Introduction............................................2
Using the Remote Control...................2
LCD Remote Functions.......................3
LCD Transmitter Operation (First
Car Control)...........................................3
Basic Vehicle Operation......................3
Transmitter Mode Selection................3
Time or Alarm Clock Adjustments .....4
Cold Weather Mode.............................4
Home ValetTM........................................5
Countdown Timer.................................5
Parking Countdown..............................5
Safe Start Mode....................................5
*Runtime Options (once the car has
been remote started)............................6
LCD Transmitter Operation
(Second Car Control)...........................6
Basic Vehicle Operation......................6
Start and Stop While in Safe Start
Mode.......................................................6
Remote-Starting Your Vehicle............6
Setting Your Vehicle into Ready
Mode.......................................................6
Remaining In Ready Mode.................7
Remote-starting....................................7
Vehicle Presets.....................................7
Driving Off..............................................7
Using the System .................................8
Arming and Disarming the System....8
Idle Mode...............................................8
Turbo Mode...........................................8
Valet Mode with the Valet Switch......9
Ignition Valet..........................................9
Start Attempts Indicator (Valet
Mode).....................................................9
“Home ValetTM” Mode..........................9
Remote ValetMode...........................10
Panic Mode..........................................10
Quick LockoutTM.................................10
Cold Weather Mode...........................10
Temporary chirp delete......................11
Advanced Features: Installation-
programmable Options......................11
Remote Door Locks ...........................11
Priority Door Access..........................11
Active or Passive Arming..................11
The Starter Kill and the Anti-grind
Feature.................................................11
Shock Sense, Warn-away Sense....12
Disarmed Notification.........................12
Siren Chirps or Horn Honks..............12
Car Finder............................................12
Siren or Horn Chirp Timing...............12
Safe Start.............................................12
Home Valet TM.....................................12
Ignition-controlled Door Locks..........13
Ignition Re-lock...................................13
Secure Lock........................................13
Turbo Mode.........................................13
Remote Trunk Release......................13
Engine Run Time................................13
Multi-car Operation.............................13
L.E.D. Intrusion Codes ......................13
Troubleshooting Poor Transmitting
Range...................................................14
Diagnostics –Chirps Table ............... 14
Diagnostics –Parking Light Flash
Table.................................................. 15
Introduction
This system is a state-of-the-art remote car starter and alarm combo system. the system is packed
with advanced features such as priority access to the driver’s door and car finder (commodity
features), last armed state memory in case of power failure (which ensures that the vehicle
remains protected after a power failure recovery) and the safe start children safety feature. With
many an advanced function, this product will satisfy any one your expectations from high-end
commodity and security systems, without neglecting any standard feature commonly offered by
entry-level starters.
Using the Remote Control
Your system is equipped with a 5-button multi-channel remote control. It can operate two
independent vehicles equipped with identical systems (see multi-car operation section, later in
this guide, for second-car transmitter functions).

P. 3User Guide
The functions of the transmitter are as follows:
LCD Remote Functions
The transmitter offers several command-confirmation and timer features. This section explains
some of the key functions available on the remote control. Next section gives a summary of the
button combinations used to access the functions (see LCD remote operation tables).
Note:
If you wish to exit a function while still in the process of accessing it, simply stop and wait for at
least 10 seconds: the transmitter will return to its normal state.
LCD Transmitter Operation (First Car Control)
Basic Vehicle Operation
FUNCTION BUTTON PRESSED ICON BUZZER INSTRUCTIONS /DESCRIPTION
LOCK 1 Beep
Locks the doors
and arms the Starter Kill (if
installed) and the alarm.
UNLOCK 2 Beep
Unlocks the doors and disarms
the Starter Kill (if installed) and
the alarm.
TRUNK or AUX 3 1 Beep Trunk output
START *
(see Runtime
Options below) + Melody Starts the engine
STOP None Melody Stops the engine
Light ON ON for 10 seconds Press the button once.
Transmitter Mode Selection
FUNCTION BUTTON PRESSED ICON BUZZER INSTRUCTIONS /DESCRIPTION
POWER-SAVING
MODE + Melody
VIBRATION MODE
+ Vibrates twice

User Guide P. 4
ALARM CLOCK
MODE ON/OFF + Melody
Press once to switch the Alarm
Clock ON
Press twice to switch the Alarm
Clock OFF
Time or Alarm Clock Adjustments
User Transmitter
1. Press and hold the FUNCTION button until a
beep is heard
The backlight will turn on the moment the
FUNCTION button is pressed.
2. Upon hearing the beep, release the
FUNCTIONbutton, ........................... is displayed
3. Press and hold the FUNCTION button once
more
4. Release the FUNCTION button when a beep
is heard, ........................... is displayed
5. Press and hold the FUNCTION button once
more until a beep is heard,
6. Release the FUNCTION button ........................... is displayed
7. At that point, press and hold the FUNCTION
button until 2 beeps are heard. ...........The hour setting will start to flash.
Pressing the FUNCTION button
1X...............................Adjust hour (current time)
2X..........................Adjust minutes (current time)
3X........................................Adjust hour (Alarm)
4X...................................Adjust minutes (Alarm)
5X.... Melody selection for the ringing of the alarm
6X...........Activate (ON) / Deactivate (OFF) Alarm
7X................................ Adjust hour (countdown)
8X........................... Adjust minutes (countdown)
9X................ Melody selection for the countdown
10X.Activate (ON) / Deactivate (OFF) countdown
a. Press the button to increase the
value or to activate or deactivate a
function or to toggle through the
melodies.
b. Press the to decrease the value or to
activate or deactivate a function or to
toggle through the melodies.
c. To save modifications, do not touch any
buttons for approx 5 to 10 seconds.
There will be a beep and the display will
return to the time.
Cold Weather Mode
FUNCTION BUTTON PRESSED ICON BUZZER INSTRUCTIONS /DESCRIPTION
TO ENTER COLD
WEATHER MODE
BEEP Press and hold for 3 seconds.
TO EXIT COLD
WEATHER MODE
None NONE Press and hold for 3 seconds
TO ENTER COLD
WEATHER MODE
IN SAFE START
MODE
X 2
BEEP
Press twice within 3 seconds.
Or: press and hold for 1 second
(melody) then press and hold for
3seconds.
TO EXIT COLD
WEATHER MODE
IN SAFE START
MODE
X 2 None NONE
Press twice within 3 seconds.
Or: press and hold for 1 second
(melody) then press and hold for
3seconds.

P. 5User Guide
Home ValetTM
FUNCTION BY PRESSING ICON BUZZER INSTRUCTIONS / DESCRIPTION
TO ENTER HOME
VALET ™ MODE
Step 1 :or
Step 2: +
simultaneously
within 5
seconds
1 BEEP
Press or ; within 5 seconds,
press + :The
icon w ill be
displayed and there will be 1 beep.
TO EXIT HOME
VALET ™ MODE NONE NONE NONE
Insert the key in the ignition switch
and turn it to the IGNITION ON / RUN
position. The icon will disappearafter
pressing the LOCK or ULOCK button.
Countdown Timer
FUNCTION BY PRESSING ICON BUZZER INSTRUCTIONS /
DESCRIPTION
COUNTDOWN
TIMER ADJUST
MODE (HOUR) 6 times
COUNTDOWN
TIMER ADJUST
MODE (MIN) 7 times
COUNTDOWN
TIMER ENDING
MELODY
SELECTION 1
8 times
5 Selections
1,2,3,4,5
COUNTDOWN
TIMER MODE
(ON / OFF) 9 times /
button: press for upward
adjustment or for switching the
function ON.
button: press for downward
adjustment or for switching the
function OFF.
Parking Countdown
FUNCTION BY PRESSING ICON BUZZER INSTRUCTIONS /
DESCRIPTION
1 time Melody 10 MIN COUNT DOWN
2 times Melody 20 MIN COUNT DOWN
3 times Melody 30 MIN COUNT DOWN
4 times Melody 60 MIN COUNT DOWN
5 times Melody 90 MIN COUNT DOWN
6 times Melody 120 MIN COUNT DOWN
FOR
PARKING
COUNTDOWN:
PRESS AND HOLD
THEN PRESS:
7 times Melody PARKING COUNT DOWN OFF
Safe Start Mode
FUNCTION BY PRESSING ICON BUZZER INSTRUCTIONS /
DESCRIPTION
START ON SAFE
START MODE X 2 + Melody
Press the button twice within
3seconds. Or:
Press for 1 second (melody) then
press again for 1 second.
STOP ON SAFE
START MODE None Melody

User Guide P. 6
*Runtime Options (once the car has been remote started)
FUNCTION BY PRESSING ICON GAS DIESEL
4 minutes 9 minutes
ENGINE RUNTIME
15 minutes 20 minutes
25 minutes 30 minutes
LCD Transmitter Operation (Second Car Control)
Basic Vehicle Operation
FUNCTION BUTTON PRESS ICON BUZZER DESCRIPTION
LOCK + 1 Beep
Locks the doors
and arms the Starter Kill (if
installed) and the alarm.
UNLOCK + 2Beep
Unlocks the doors and disarms
the Starter Kill (if installed) and
the alarm.
START + + Melody Starts the engine
STOP + None Melody Stops the engine
Start and Stop While in Safe Start Mode
FUNCTION BUTTON PRESS ICON BUZZER DESCRIPTION
START ON SAFE
START MODE + X 2 + Melody
Press the and buttons
simultaneously twice within
3seconds.
Press for 1 second (a melody
will be heard) then press 1sec
and a melody will be heard
again.
STOP ON SAFE
START MODE + None Melody
Remote-Starting Your Vehicle
Setting Your Vehicle into Ready Mode
This product is designed for vehicles with a manual transmission only. In order to start the vehicle
by remote, the unit must first be set to ready mode. If the unit is not set to ready mode, it cannot
remote-start the vehicle. Once the system is set to ready mode, the vehicle can be remote-started
and stopped at wish. The system will exit ready mode if a door or the hood is opened, if the brake
pedal is pres sed, if the parking brake is disengaged or if the ignition key is turned to the IGNITION ON
(RUN) position.
To set the system to ready mode:
1. Ensure that all the doors are closed and that the shifter is in the neutral position.
2. With the engine already running, apply the parking brake and release the brake pedal.
Make sure to release the brake pedal.
3. Within 20 sec. press LOCK, or UNLOCK.
The parking lights will flash 3 times quickly and remain lit.
4. Remove the key: the engine will go on running.
5. Exit the vehicle and close the door.

P. 7User Guide
6. Press and hold either:
a. LOCK to lock the doors and shut down the engine;
b. UNLOCK to unlock the doors and shut down the engine;
c. START/STOP to shut down the engine without affecting the doors.
Remaining In Ready Mode
Once the vehicle is in ready mode you can start and stop the vehicle at wish. However, should any
of the following occur, the vehicle will exit ready mode –thus eliminating the remote start option
until ready mode is restored:
•Door opened;
•Hood opened;
•Brake pedal pressed;
•Parking brake disengaged;
•Ignition key turned to the IGNITION ON (RUN) position.
Should any of the above occur, ready mode will be cancelled.
Note: The unit will notify the user that it has exited ready mode by giving 3 slow flashes
(parking lights).
Remote-starting
Press the START/STOP button for approx. 1 second. The parking lights will come ON and the remote
control will play a melody to inform you that the system has received your signal. Approximately 5
seconds later, the engine will start the parking lights will remain on during the pre-programmed
run time of the engine. The remote control will play a second melody to confirm that the engine has
started. If the vehicle does not start at the first attempt, the system will shut down.
WARNING!
It may require as much as 10 seconds before receiving the second confirmation signal;
therefore, pressing any buttons before receiving that confirmation will abort the
confirmation process.
Vehicle Presets
Heater & Heated Seat
When leaving the vehicle it is recommended to preset the accessory controls in preparation for the
next remote start. Settings for the blower motor (fan), front and rear, as well as heated seats (if
equipped) should not be left on HIGH. It is recommended to leave the settings on LOW or MEDIUM
instead.
Windshield Wipers & Radio & Headlights
Certain vehicles require the radio and / or windshield wiper and / or headlight circuits to become
energized while running under remote start. When leaving the vehicle you must ensure that the
windshield wiper and headlight switches are OFF. Leaving the headlight switch ON on certain types
of vehicles could cause them to remain ON even after remote starter shut down, resulting in a dead
battery.
Driving Off
With the vehicle running under remote control, press the UNLOCK button to disarm and unlock the
doors. Enter the vehicle and do the following:
•Turn the ignition key to the IGNITION ON (RUN) position. (Do not turn the key to the CRANK
position while the engine is running. This would cause the starter motor to re-engage.)
•Press the brake pedal to disengage the remote starter unit.
You are now ready to drive off.

User Guide P. 8
Using the System
Arming and Disarming the System
To disarm the alarm and starter kill (if installed) and unlock the doors (if
installed):
1. Press and hold the UNLOCK button for approx imately 1second.
There will be two chirps if the siren or horn is so configured.
2. The icon will appear, the parking lights will flash twice and the L.E.D. will go out to
confirm that the doors have been unlocked and that the starter kill (if installed) and the alarm
are disarmed.
In passive mode, the system will rearm automatically 30 seconds after unlocking unless the key is
meanwhile inserted in the ignition switch (see description of passive mode later in this guide).
To arm the alarm and starter kill (if installed) and lock the doors (if installed):
1. Press and hold the LOCK button for approx imately 1second.
You will hear one chirp if the siren or horn is so configured.
2. The icon will appear, the parking lights will flash once and the L.E.D. will flash slowly to
confirm that the doors have been locked and that the starter kill feature (if installed) and the
alarm are armed.
Idle Mode
Convenience feature: Idle mode allows you to keep the engine running and the doors
locked while you stop, for example, at a convenience store or for a short delivery.
This feature allows you to let the remote starter take over control of the vehicle (i.e. no key in the
ignition switch) while the engine is running. For example, if you stop for a delivery or at a conveni-
ence store, lock your vehicle and leave it running for the length of a run cycle while you are away.
Idle mode can be activated through the same routine as that used for ready mode; at the last step,
the TRUNK button is pressed instead of the other buttons:
1. Ensure that all the doors are closed and that the shifter is in the neutral position.
2. With the engine already running, apply the parking brake and release the brake pedal.
Make sure to release the brake pedal.
3. Within 20 sec. push LOCK, UNLOCK or START/STOP on the transmitter.
The parking lights will flash 3 times quickly and remain lit.
4. Remove the key: the engine will go on running.
5. Exit the vehicle and close the door.
6. Press the TRUNK button until the system is armed (the doors will be locked if remote door lock is
installed).
If the pre-programmed run-time ex pires or if the user shuts down the engine by remote control, the
vehicle will get in ready mode.
Caution!!! Do not leave children or pets unattended in a vehicle standing in idle mode.
Turbo Mode
If turbo mode is configured at installation, it will allow a turbocharger to idle down after the user
leaves the vehicle: the unit will take over the vehicle and keep it running for 60 seconds (or until it
is shut down by remote control), then shut down the engine and set the system to ready mode.
To activate turbo mode, follow all steps of the ready mode routine:
1. Ensure that all the doors are closed and that the shifter is in the neutral position.
2. With the engine already running, apply the parking brake and release the brake pedal.
Make sure to release the brake pedal.
3. Within 20 sec. press LOCK, UNLOCK or START/STOP on the transmitter.
The parking lights will flash 3 times quickly and remain lit.
4. Remove the key: the engine will go on running.

P. 9User Guide
5. Exit the vehicle and close the door.
6. Press and hold either:
a. LOCK to lock the doors and shut down the engine after 60 sec.;
b. UNLOCK to unlock the doors and shut down the engine after 60 sec.;
c. START/STOP to shut down the engine immediately, without affecting the doors
(This will by -pass turbo mode).
Valet Mode with the Valet Switch
When your vehicle is in valet mode, the remote starter functionalities are disabled. If the vehicle
needs to be serviced, or if you park it indoors, the valet mode will prevent the engine from being
remote-started accidentally.
To put the system into valet mode:
1. Turn the ignition key to the IGNITION ON (RUN)position.
2. Within 3 sec onds, press the valet button. The parking lights will flash three times and the L.E.D.
will turn itself on.
To take the system out of valet mode:
1. Turn the ignition key to the IGNITION ON (RUN) position.
2. Within 3 sec onds, press and release the valet button. The parking lights will flash twice and the
L.E.D. will turn itself off.
Note: Once valet mode is activated, the remote starter and alarm functions will be disabled.
Ignition Valet
This feature will allow you to remotely put your system into valet mode by using the ignition key
instead of the valet button as above. Ignition valet can be used without a valet button installed.
To put the system into valet mode:
•Insert the ignition key into the ignition switch; within 10 sec onds, turn the key 5times
successively into the IGNITION ON / RUN and OFF positions.
•The parking lights will flash three times to indicate that the vehicle is now in valet mode and the
L.E.D. will turn itself on.
To take the system out of Valet Mode:
•Insert the igniti on key into the ignition switch; within 10 seconds, turn the key 5times
successively into the IGNITION ON / RUN and OFF positions.
•The parking lights will flash twice to indicate that the vehicle is now in valet mode and the L.E.D.
will turn itself off.
Note: With the remote valet activated, the remote starter and alarm functions will be disabled.
Start Attempts Indicator (Valet Mode)
This reveals start attempts made while the vehicle was in valet mode. The parking lights will:
•Come ON, go OUT; then
•Flash twice.
“Home ValetTM” Mode
If configured at installation, this feature will remotely set the vehicle to a no-remote-start mode: if
the vehicle is parked indoors there is no danger of it starting accidentally by remote control.
Note: Once the Home Valet Mode is activated, the vehicle will not start by remote.
To take the system into home valet mode:
•Press the LOCK or UNLOCK button.
•Within 5 seconds, press the LOCK and START/STOP button simultaneously.
The transmitter will beep once and the home valet icon will start flashing. The icon will flash
until the vehicle exits home valet mode.

User Guide P. 10
To take the system out of home valet mode:
•Turn the ignition key to the IGNITION ON (RUN) position.
The system will warn you if someone attempts to start your vehicle while it stands in Home Valet
Mode. The parking lights will:
•Go ON then OFF; then
•Flash twice, pause; then
•Flash twice again.
Remote Valet Mode
This feature will allow you to remotely put your system into valet mode by using the transmitter
instead of the valet button as above.
Getting into valet mode
•Hold the UNLOCK and START/STOP buttons simultaneously for 3seconds.
•The parking lights will flash 3 times.
The transmitter will beep once and will display the icon; the LED will remain on solid.
Getting out of valet mode
•Hold the UNLOCK and START/STOP buttons simultaneously for 3 seconds.
•The parking lights will flash 2 times.
The transmitter will beep once and the icon will disappear after pressing the LOCK or UNLOCK
button and the LED will turn off.
Note: With the remote valet activated, the remote starter function will be disabled.
Panic Mode
In an emergency situation, you can activate panic mode using the LOCK or UNLOCK button. This will:
•shut down the engine,
•unlock the doors (with the UNLOCK button)
•or lock the doors (with the LOCK button),
•disarm the starter kill and
•activate the activate the siren for 1 minute.
Note: See the description of the starter kill option later in this guide.
To activate panic mode:
•Press and hold the UNLOCK button for approximately 3 seconds until the sound signal starts and
the parking lights flash: this will unlock the doors before the sound signal starts.
•Or press and hold the LOCK button for approximately 3 seconds until the sound signal starts and
the parking lights flash: this will lock the doors before the sound signal starts.
Panic mode will automatically shut down after 1 minute.
Note: To stop panic mode before the end of its delay, press the LOCK or UNLOCK button until
the sound signal stops.
Quick LockoutTM
(Also called secure panic.) For fast protection in emergency situations, the system will lock all
doors when you press the brake pedal while you hear the sound signal. (quick lockout is only
available when panic mode has been set off.)
Cold Weather Mode
When cold weather mode is active, the engine starts every 2 hours and runs for 4 minutes (or for 9
or 20 minutes with diesel engines). The system must be in ready mode in order to enter cold
weather mode. Cold weather mode automatically ends after 24 hours.
To enter cold weather mode:
•Press and hold the START/STOP button for 3 seconds until the parking lights flash three times.
The remote control will play a melody and the icon will appear on the display.

P. 11 User Guide
To exit cold weather mode, do any one of the following actions:
•Open the hood.
•Start the engine by remote.
•Turn the ignition key to the IGNITION ON (RUN) position.
•Press the brake pedal.
•Press and hold the START/STOP button for 3 seconds (the parking lights will flash once).
When the system exits cold weather mode, the icon will disappear after pressing the LOCK or
ULOCK buttons.
Temporary chirp delete
To temporarily disable the chirp confirmations of the siren upon arming and disarming (e.g. in a
quiet neighbourhood):
1. Press the TRUNK button.
2. Within 3 seconds, press the LOCK or UNLOCK button to arm or disarm without any chirps.
Advanced Features: Installation-programmable Options
The system was designed with flexibility and OEM integration in mind. With its programmable
options, this unit can single-handedly control nearly any electrical system in your vehicle.
Caution: The programming of your system should be left to a professional. Changing any
one of the settings may affect the operation of your system.
The installation-programmable options are as follows:
•Remote Door Locks
•Priority Door Access
•Passive or Active Arming
•Starter Kill / Anti-grind feature
•Shock Sense and Warn-away
•Disarmed Notification
•Siren / Horn Chirps
•Car Finder
•Siren / Horn Chirp Timing
•Safe Start
•Ignition-controlled Door Locks
•Ignition Re-lock
•Secure Lock
•Turbo Mode
•Remote Trunk Release
•Engine Run Time
•Multi-car Operation
Remote Door Locks
If your system was installed with the remote door locks option, you will have the convenience of
remote keyless entry. See section arming and disarming the system, earlier in this guide, for further
instructions on remote door locking and unlocking.
Priority Door Access
If the Remote Door Locks option is installed on your vehicle, this safety feature allows you unlock
solely the driver’s door with a single press of the UNLOCK button on the transmitter; upon a second
press of the UNLOCK button, all the other doors will unlock.
Active or Passive Arming
The alarm and starter kill can be configured either to passive mode (so as to arm automatically) or
active mode (so as to require user intervention for arming). By default, your system is configured to
passive mode. In passive mode, the alarm and starter kill will automatically arm 30 seconds after
the last door is closed. The system will not arm if a door is left open, or if you re-open a door within
the 30-second delay.
Important: When the system re-arms automatically or if there is an alarm condition, you can
disarm the system by simply pressing the UNLOCK button.
The Starter Kill and the Anti-grind Feature
With this added security feature, the system will prevent your vehicle from starting with the ignition
key when the starter kill is armed. If your system was installed with the starter kill option, one will

User Guide P. 12
not be able to start your vehicle with the key unless the system has been unlocked and disarmed
first, or put into valet mode.
Note: If the starter kill is installed, your vehicle will benefit from a protection against starter
motor damage that could occur after remote-starting the engine should the user, by force of
habit, turn the ignition key to the CRANK position.
Shock Sense, Warn-away Sense
Your system will react to a full shock by triggering the alarm; it can also respond to a lighter shock
(30 % of the strength of a full shock) by giving a warn-away (without triggering an alarm condition).
When the engine is running after a remote start, however, the system will prevent any alarm
condition to be triggered; it will still give a warn-away if this feature has not been disabled at
installation.
Note: After a remote start, although the shock sensor is disabled, all the other alarm-
triggering zones, such as the doors or the hood, may still trigger an alarm.
Disarmed Notification
This feature will notify the user when the vehicle was left disarmed: after the engine is shut down
(with the key removed) and all doors are closed, the siren will chirp once after a 10-seconds
notification delay to warn the user that the vehicle was left unprotected. The notification can be
avoided by pressing the LOCK or UNLOCK button on the transmitter.
The user will likewise be notified after the system is disarmed using the transmitter.
Siren Chirps or Horn Honks
The siren will chirp to confirm basic operations on the System:
•By default, upon locking the doors the siren will give one chirp if no protection zone is active.
•If a zone is active as the doors are being locked, the siren will give three chirps.
•When the doors are being unlocked, the siren will give two chirps if no intrusion was detected.
•If an intrusion was detected, as the doors are being unlocked the siren will give four chirps.
The system can alternatively be set to:
Warning Mode:no chirp during lock/unlock…
•unless a zone is active when locking, in which case there will be 3 chirp upon locking
•or unless the alarm was triggered, in which case there will be 4chirps when unlocking);
Open Zone Notification Mode: 3 warning chirps if a door is left open 10 sec. after arming.
No Chirp: the siren will not chirp under any circumstance.
Car Finder
When enabled, the Car Finder option will help you locate your vehicle by generating a pulsating
signal through the horn or the siren. To hear the signal, press the LOCK and UNLOCK buttons
simultaneously. This will cause a pulsating signal lasting for the time you keep the buttons pressed.
Siren or Horn Chirp Timing
The duration of the chirps can be adjusted at installation (from 5 to 200 ms).
Safe Start
If this feature is enabled, the user must press the START/STOP button 2 times within 3seconds to
remote-start the vehicle. This will eliminate accidental remote starts, e.g. when children are playing
with the transmitter. If swap start mode is selected, to remote-start your vehicle press LOCK and
UNLOCK simultaneously. The AUX 2output can be activated by pressing the START/STOP button.
Home Valet TM
If this feature is installed, the user will have the possibility to remotely set the vehicle to a no-
remote-start mode. See home valet section, earlier in this guide, for full instructions.

P. 13 User Guide
Ignition-controlled Door Locks
This is an added security feature. If your system was installed with the ignition-controlled door
locks option, the doors will automatically be locked as soon as the ignition key is turned to the
IGNITION ON (RUN) position while the brakes are pressed. When the key is turned to the OFF position,
the doors will automatically be unlocked.
Ignition Re-lock
On systems of this series, when ignition-controlled door locks are enabled and the ignition key is in
the IGNITION ON (RUN) position, should any door be unlocked and opened, all doors will be relocked
next time the brake pedal is pressed.
Secure Lock
Before it can remote-start your vehicle, the system must first disarm the factory security system.
The secure lock feature may be required on certain vehicle models with factory security systems
that automatically unlock the doors when the security system is disarmed.
To keep your vehicle protected when the factory security system is disarmed for a remote start,
secure lock will relock your doors as soon as the vehicle has started. Once the engine run cycle
ends, secure lock will rearm your factory security system.
Turbo Mode
When left in turbo mode, the system will keep the engine running for 60 seconds before shutting it
down. This is to allow a turbocharger to idle down after the user leaves the vehicle. See turbo
mode section earlier in this guide.
Remote Trunk Release
If your system was installed with the remote trunk release option, you can open your trunk by
pressing the TRUNK button for 3seconds on the remote transmitter or by pressing the TRUNK button
twice within 3seconds.
Engine Run Time
(15/20 minutes by default.) If you have a gas engine, your System can be programmed to run the
engine for 4, 15, or 25 minutes (15 minutes by default). If you have a diesel engine, the System
can be programmed to run the engine for 9, 20, or 30 minutes (20 minutes default).
Multi-car Operation
This option allows the owner of two vehicles, both equipped with System systems, to control both
systems with a single remote control. To control the second vehicle, simultaneously press the
TRUNK button and the button of the function you wish to use. See the transmitter operation table
earlier in this Guide. for full instructions on second car operation.
Note: Your remote control must be configured for second car operation by the installer.
L.E.D. Intrusion Codes
If an intrusion took place while your vehicle was locked and the system was armed, the L.E.D. will
provide feedback on the intrusion. The L.E.D. intrusion codes are flashed by the L.E.D. in
continuous loops and are as follows:
1 flash = power-up reset: battery
disconnected and reconnected, or dead
battery.
2 flash = doors intrusion
3 flash = shock sense
4 flash = hood intrusion
5 flash = panic
6 flash = ignition

User Guide P. 14
Troubleshooting Poor Transmitting Range
Many factors may affect the operating range of the transmitter. Some of these are:
•The condition of the battery in the transmitter.
•The operating environment (for example: downtown radio-frequency noise, airports, cellular
phone towers…)
•Metal: any type of metal will affect operating range. This includes the metal in the car.
•The shape of the vehicle can affect range as well; vans in general have an especially poor
range.
•The shape of the roof and A-pillars brings about considerable radio-frequency deflection (in
this case the signal from the remote control). As a result, the direction in which the vehicle is
facing in relation to the remote control can affect the range. Straight on –standing in front of
the vehicle –generally gives you the greatest range; the second best performance is from the
back. Using the remote control from either side of the vehicle will usually give the lowest
range.
•The range will be significantly lower in a crowded parking lot than in open space.
•Always hold the transmitter high, approximately at shoulder height. Holding the transmitter
against your chin will also increase your range: your head acts as an antenna.
•The operating range will be somewhat lower on vehicles equipped with an aftermarket or
factory alarm.
Diagnostics –Chirps Table
Chirps Description
1
•Doors locked, alarm and starter kill armed.
•Lock confirmation.
•Entering mode 1 in the programming centre.
•Disarmed notification
2•Doors unlocked, alarm and starter kill disarmed.
•Transmitter programmed.
•Entering mode 2 in the programming centre.
3•LOCK and arm while a zone is left unprotected.
•Entering mode 3 in the programming centre.
•Door zone left unprotected.
4•Unlock and disarm: an intrusion was detected (in warning chirps mode or full
chirps mode).
•Entering tach-programming mode.
5•Siren or horn chirp timing adjustment
Constant up
to 30 seconds •In horn mode: alarm condition generated by an intrusion, by panic mode or
when the system is powered up. the horn will sound for 30 sec.
Constant up
to 60 seconds •In siren mode: alarm condition generated by an intrusion, by panic mode or
when the system is powered up. the siren will sound for 60 sec.

P. 15 User Guide
Diagnostics –Parking Light Flash Table
Flashes Description
1
•Doors locked, alarm and starter kill armed.
•End of run time.
•TRUNK button pressed
•Start signal received by the system.
•Cold weather mode cancelled.
•Cannot start after maximum number of attempts is reached.
2
•Doors unlocked, alarm and starter kill disarmed.
•Run time cancelled.
•Exit remote valet.
•Exit ignition valet
•Remote start attempt cancelled by remote.
3•Entering cold weather mode.
•Entering remote valet.
•Entering ignition valet
4•+12 V where detected on the brake line and cranking was cancelled.
•Entering tach-programming mode
5•New transmitter programmed.
•Tach programmed.
6•A remote start was attempted while a tach or a vacuum signal was detected
before cranking.
8•Unit reset: occurs when the unit is reset to the factory defaults.
10 •The hood switch line went to ground during cranking or run time.
1 –pause –2 •There was an attempt to start the vehicle while the system was in valet mode.
2 –pause –2 •There was an attempt to start the vehicle while the system was in home valet
mode.
ON solid •Cold weather mode: the brake pedal is being held down.
ON 2 sec. •The hood is up and the hood switch line went to ground. this is step one of
the programming centre procedure.
ON 3 sec. •First press of the START/STOP button under safe start.
ON 4 sec. •Locking or unlocking a door (with door pulses configured to 4 sec.)
ON 25 sec.
•The hood pin-switch has been pressed twice: the unit went into step 1 of the
programming centre procedure, and no transmitter activity was detected for
20 seconds.
•Or the unit went into step 1 of the transmitter programming procedure and no
activity was detected for a few seconds. The unit has exited the transmitter
programming procedure.
Irregular •If the unit gives irregular signals (1 to 10 flashes followed by a pause,
followed by further flashes), the system is playing back start failure codes.
This occurs when the hood pin-switch is pressed three times.
Constant
flashes up to
30 sec.
•In horn mode: alarm condition generated by an intrusion, by panic mode or
when the system is powered up.
Constant
flashes up to
60 sec.
•In siren mode: alarm condition generated by an intrusion, by panic mode or
when the system is powered up.
