Polycom EagleEye Director II Manual

www.polycom.com
© 2019, Polycom, Inc. All rights reserved. POLYCOM® and the names and marks associated with Polycom’s products are trademarks and/or
service marks of Polycom, Inc. and are registered and/or common law marks in the United States and various other countries
For information about the Taiwan RoHS Matrix, refer to http://support.polycom.com.
November 2019
Polycom EagleEye Director II
SETUP SHEET
1725-69477-001K
(2) M3 x 10
Screw
(4) M3 x 4
Screw
(Non-Standard)
(2) M2 x 40
Screw
12
3 4

2Polycom EagleEye Director II Setup Sheet
Mount on a Wall
Total weight:
4.7 kg (10.36 lbs)
(4) Wafer Head
Phillips Self-
Drilling Screw
(4) Plastic Insert
for Concrete Wall
546 mm (21.5 in.)
159.78 mm
(6.3 in.) 50.8 mm
(2 in.)
1.7-2.1 m (5.5-7 ft.)
≥0.3 m
(12 in.)
≥0.3 m
(12 in.)
≥0.3 m
(12 in.)
5
HDMI In
HDMI Out
USB 2.0
Type A
USB 2.0
Type B
Power
3.5 mm
Audio In
HDCI Out
LAN
420 mm (16.5 in.)
139 mm
(5.47 in.)
143 mm
(5.63 in.)
138 mm
(5.43 in.)

Polycom EagleEye Director II Setup Sheet 3
Using Polycom EagleEye Director II
with Polycom RealPresence Group Series
6 a
c
e
b
d

Polycom EagleEye Director II Setup Sheet 4
12V 6.25A
2
1
Using Polycom EagleEye Director II with
Polycom RealPresence Group Series 300/310/500
f1
4
1 2 3
3
1 2
100-240VAC 50/60Hz 2.3A
Using Polycom EagleEye Director II with
Polycom RealPresence Group Series 700
f2

Polycom EagleEye Director II Setup Sheet 5
Using Polycom EagleEye Director II
with Poly G7500
f3

Polycom EagleEye Director II Setup Sheet 6
Using Polycom EagleEye Director II as a USB Camera
Optional
PN: 2215-69444-001
Optional
PN: 2215-69443-001
USB
2.0
USB
2.0
7
a
c
e
b
d

Polycom EagleEye Director II Setup Sheet 7
f1 Using Polycom EagleEye Director II
with a Laptop Running Skype for Business
Far End Echo
Cancellation

Polycom EagleEye Director II Setup Sheet 8
f2
Far End Echo
Cancellation PoE | PoE+
Network
Using Polycom EagleEye Director II and Poly Trio with
Microsoft Surface Hub, Microsoft Teams Room, Zoom, or PC

Intranet
Polycom EagleEye Director II Setup Sheet 9
8
Mode: Polycom RealPresence Group Series/
Poly G7500
Primary
Mode: Polycom RealPresence Group Series/
Poly G7500
Secondary
4
1 2 3
3
1 2
100-240VAC 50/60Hz 2.3A
Polycom EagleEye Director II Cascading Cabling

Polycom EagleEye Director II Setup Sheet 10
Mode: Connect Your Own Device
Primary
Mode: Connect Your Own Device
Secondary
Intranet
8Polycom EagleEye Director II Cascading Cabling

11Polycom EagleEye Director II Setup Sheet
9
10 a
c
b
d


12Polycom EagleEye Director II Setup Sheet
548 mm (21.57 in.)
283 mm (11.14 in.)
140.5 mm
(5.5 in.)
~5º
-15º
0.9 m
(3 ft.)
<10 m (33 ft.)
<10 m (33 ft.)
~
8
0
º
~
1
5
0
º
F
r
a
m
i
n
g
S
p
e
a
k
e
r
R
a
n
g
e
A
n
a
l
y
t
i
c
s
C
a
m
e
r
a
H
o
r
i
z
o
n
t
a
l
F
i
e
l
d
o
f
V
i
e
w
