PondMAX 04PL686 User manual

3W WARM WHITE
POND & GARDEN LIGHT
INSTRUCTION MANUAL
DATE
OCT 2021 v1.1
MODEL
04PL686
HOTLINE [phone]
www.pondmax.com.au
PMAX 3W Warm White Light Instructions.indd 1PMAX 3W Warm White Light Instructions.indd 1 29/10/21 5:59 am29/10/21 5:59 am

FOR GARDENS THAT GO THE EXTRA YARDPONDMAX.COM.AU
WELCOME TO THE WORLD OF PONDMAX™.
YOU MADE THE RIGHT CHOICE INVESTING IN THIS
QUALITY PRODUCT. THANK YOU AND ENJOY.
TECHNICAL SPECIFICATIONS
DESCRIPTION 3W WARM
VOLTAGE (V)
12
POWER (W)
3
CABLE LENGTH (m)
5
LUMENS
250
BEFORE USING THIS PRODUCT, PLEASE READ THESE INSTRUCTIONS CAREFULLY AND MAKE
YOURSELF FULLY FAMILIAR WITH THE UNIT. PLEASE KEEP THESE INSTRUCTIONS IN A SAFE PLACE
FOR FUTURE REFERENCE.
DESIGN HIGHLIGHTS
Your PondMAX 3W Warm Pond/garden Light has been manufactured with advanced
technology and quality materials to ideally integrate into any pond and garden scene,
thanks to their compact design.
• The PondMAX light has a glass lens and is
suitable for use in or out of water.
• The high power energy ecient LED
emits a natural warm light providing years
of maintenance free satisfaction.
• The 240V transformer (not included)
converts the power supply to a safe 12
volts for peace of mind in your pond or
garden.
INSTALLATION
If required, have a qualified electrician install a weather proof power point near to the
pond or garden, within reach of the transformer and light.
• Mount the transformer in a dry and protected
location making sure that it can’t be wet by
either rain or reticulation. It is not waterproof
and do not submerge.
• For pond installation slide the weighted base
into the circular recess on the underside of
the light body. Position the light in the desired
location taking care not to wet the 2 pin female
plug at the end of the cable.
• For garden installation slide the garden spike
into the circular recess on the underside of the
light body. Holding the light body firmly, push
the light with attached spike into the desired
location taking care not to penetrate any
hidden services.
• Adjust the light until facing in the general
direction of the feature you wish to illuminate.
We recommend final adjustments be carried
PMAX 3W Warm White Light Instructions.indd 2PMAX 3W Warm White Light Instructions.indd 2 29/10/21 5:59 am29/10/21 5:59 am

FOR GARDENS THAT GO THE EXTRA YARDPONDMAX.COM.AU
3W WARM WHITE
POND & GARDEN LIGHT
1
2
46
7
3
5
out at night. For single light installations plug
the Transformer Adaptor (5) into the end of the
light cable and into the transformer tightening
both locking collars firmly. The transformer can
now be turned on.
• Once in the correct position lock the light by
tightening the thumb screws, taking care not to
over tighten.
• Multiple lights can be connected together to
the same transformer using the 2 Pin Male
Connection (4) on the side of the light body.
• A maxiumum of 33 lights can be connected in
a single chain (a larger transformer is required),
see table below.
• There is minimal maintenance required with
PondMAX pond lights. The light should be
inspected on a regular basis to ensure the light
or cable is not damaged in any way. Clean
the lens on the light regularly for maximum
eciency.
EXPLODED VIEW
1
2
3
4
5
6
7
Light Body
Weighted Base
Garden Spike
2 Pin Piggyback Connection*
Transformer Adaptor
Screw Cap
Thumb Screw
* For additional lights
NOTE: Parts and features dier from model to model. All images
used are for illustrative purposes only. Not all features depicted
apply to all models in the range and these are subject to change.
IMPORTANT
These accessories and attachments are recommended for use with your
PondMAX product specified in this manual. The use of any other accessories or
attachments might present a risk of injury to persons. Only use the accessory or
attachment for its stated purpose.
EXPANDABLE LIGHTING
SYSTEM
TRANSFORMER
REQUIRED
PRODUCT
CODE
4 LIGHTS 20VA 04ST016
6 LIGHTS 30VA 04ST017
10 LIGHTS 50VA 04ST018
21 LIGHTS 96VA 04ST036
33 LIGHTS 150VA 04ST019
PMAX 3W Warm White Light Instructions.indd 3PMAX 3W Warm White Light Instructions.indd 3 29/10/21 5:59 am29/10/21 5:59 am

PONDMAX.COM.AU
Please consult your retailer for quality original PondMAX replacement parts.
Visit www.pondmax.com.au for your nearest stockists.
E.&O.E.
IMPORTANT SAFEGUARDS
LIMITED WARRANTY
• The light should only be used in clean water. Do not use
the light in any solvent or flammable liquids. Do not use in
chlorinated or salt water.
• Do not operate the light if the light or any of the
components of the light such as the power cable or
transformer have been damaged.
• If the 240V plug supplying the transformer gets wet, do
not unplug the cord. Disconnect the circuit breaker that
supplies power to the power outlet. Then unplug and
examine the plug and power outlet for presence of water.
If the power outlet has become wet, you should consult an
electrician before using the again.
• Always use a properly grounded power supply
that is connected to an RCD with a rated residual
operating current not exceeding 30mA as per AS/
NZS8350.2.41:1997.
• Always unplug the light from the power supply when not
in use or before performing any maintenance.
• Never pull the transformer cord to disconnect the plug
from the power supply. Grasp the plug and pull to
disconnect.
• Do not install or store the light where it will be exposed to
extreme hot or cold temperatures.
• Keep out of reach of children or pets. This appliance
should not be used by children or interim persons without
supervision.
• Do not cut the cord as this will result in voiding your
warranty. Care should be taken to arrange the power cord
so that it cannot be accidentally tripped over or pulled.
• Do not attempt to repair the light yourself. Return to an
authorised service centre or place of purchase if a fault
occurs.
• Do not use in water above 35°C.
• To guard against injury, basic safety precautions should
be observed including but not limited to the following;
• This product comes with a warranty against detects
(Warranty). The benefits provided in this Warranty are
in addition to other rights and remedies available to
you under the Australia Consumer Law. The Warranty is
provided to the original purchaser of the product on the
following terms:
• The Warranty is given by Aquatec Equipment Pty Ltd
trading as Aquatec Equipment,
37 Edison Circuit, ForrestdaleWA 6112. Contactable by
phone [phone] or email
[email protected].
• To make a claim under the Warranty you must return
the faulty product to the place of purchase with a valid
receipt or proof of purchase.
• A Warranty claim must be made within 2 years of the date
of purchase.
• If your claim complies with the above terms and the
product is not an Exhaustible Item and no Voiding Events
have occurred, we will (at our sole discretion):
- repair the product, if possible; or
- provide a replacement product; or
- if a replacement product is not available, provide a
refund for the purchase price paid.
• You will bear the cost associated with claiming under the
Warranty such as the cost of transportation and delivery
of the product to and from the place of purchase.
• The Warranty will be void it any of the following events
occur, as determined by us, at our sole discretion (Voiding
Events):
- any tampering/removal of warranty/identification
labels or electrical components is evident;
- the detect has arisen due to: an accident, incorrect or
inadequate installation, misuse or abuse of the
product (including improper maintenance and
service}, excessive wear and tear, not following
manufacturer’s guidelines instructions, or the product
has been used in a manner contrary to the purpose
of suitability of the product;
- the product has been modified without our authority;
- the detect is caused by power surges/spikes
brownouts.
• Loss of livestock, damage of property or personal injury
caused by the improper use or abuse of the product will
not be covered and the manufacturer excludes all liability
for such events, of the extent permitted by law.
• In addition to the Warranty set out above, our goods
come with guarantees that cannot be excluded under
the Australian Consumer Law. You are entitled to
a replacement or refund for a major failure and for
compensation for any other reasonably foreseeable
loss or damage. You are also entitled to have the goods
repaired or replaced if the goods fail to be of acceptable
quality and the failure does not amount to a major failure.
