POS-X XP8200 User manual

Table of Contents
Chapter 1 Introduction………………………………………………………2
1.1 Features……………………………………………………………. …2
1.2 Outline……………………………………………………………… …3
Chapter 2 General Specification…………………………………..... …4
2.1 Tube Display………………………………………………………..…4
2.2 Electricity…………………………………………………………...…5
2.3 Overall Dimensions……………………………………………….…5
2.4 Environment………………………………………………………..…5
2.5 Driver Interface…………………………………………………….…5
2.6 User Settings……………………………………………………… …6
2.6.1FuctionSetting……………………………………………..………6
Chapter 3 Interface………………………………….... ...............8
3.1 Interface……………………………………………………………. …8
3.2 Interface Conversion Adapter………………………………….. …9
Chapter 4 Command Description……………………………….9
4.1 XP8200 Command Set…………………………………………...11
4.1.1 LD220 Command Mode……………………………………….11
4.1.2 EPSON Command Mode…………………………………......12
4.1.3 UTC Standard Command Mode…………………………….15
4.1.4 UTC Enhance Command Mode…………………………......16
4.1.5 AEDEX Command Mode………………………………….......16
4.1.6 ADM788 Command Mode…………………………….………17
4.1.7 DSP800 Command Mode……………………………………..18
4.1.8 CD5220 Command Mode……………………………………..19
4.1.9 EMAX Command Mode………………………………………..21
4.1.10 LOGIC Command Mode……………………………………..22
Chapter 5 Character Set…………………………………..........23
5.1 U.S.A. / Standard Character Set ( 20h - 7Eh)………………… .23
5.2 International Character Selection……………………………….23
5.3 Character Code Table……………………………………………..24
5.3.1 Page 0 (PC437: U.S.A., Standard Europe)………………24
5.3.2 Page 1 (PC863: Canadian-French)…………………….....26
5.3.3 Page 2 (Japanese Katakana)…………………………………27
Chapter 6 Setup XP8200 AP Guide …………………………………28
Chapter 7 Installation Guide…………………………………………....29
V2.5

Chapter 1 Introduction
1.1 Features
The XP8200 is Vacuum Fluorescent Displays which display 20 columns
and 2 lines, each columns is 5x7 dots.
Blue-green fluorescent color is easy on the eyes.
The display panel is movable so that it can be adjusted for the best viewing
angle.
The customer display have different height by adjusting the support.
The interface of XP8200 is RS-232, with baud rates select from 9600 or
19200 bps.
The customer display have provided the pass through function to reduce
the cable connection.
The user defined and international character sets are the standard of
customer display.
Supports 10 command modes, with EPSON command mode set as default
Supports power from 5V to 12V, it prevents any mindless use of improper
power input to cause malfunction
Easy configure & various settings through its free powerful set up software
i.e. Welcome message and plenty of code pages setting and others setting.
Control boards design in top panel to prevent water or wet counter surface
may damage from the bottom.
2
nd Choice round-shape mini base for space-saving, stable and ingenious
Panel is structured to easy-detachable and available for wall mounting
install and OEM
Attention
1. This specification shall apply only to the product(s) coming
along with this manual inside.
2. This manual may not apply to the previous or later product(s).
3. This specification may be modified without any notice. If it is
necessary for “customers” to have a latest manual about
specification, please inquire your suppliers.

1.2 Outline
The customer display outline has included of three parts: the panel, the
support, and the interface adapter
The standard VFD customer display should include following accessories:
Item Description Dimension (mm) Q’ty
1 Panel of XP8200 220(L)*87(W)*50(H) 1
2 Support 130 (H), 33 (Diameter) 2
3 Disk Including Manual and
setup AP 1
4 D-SUB 9 PIN RS-232 Cable 1600(Length) 1
5
<XP8200>
+5V PC 4P Plug Power Kit or
PS/2 Power Kit or
USB Power Kit or
100V~240V Universal Adapter (5V/2A) or
110V US or 230V Europe 2P Adapter
(5V/2A)
100(W) x 59(D) x 33(H)
76(W) x 51(D) x 31(H)
1
Above accessories may be different due to customers’ requirement ※
when delivery.

Chapter 2 General Specification
2.1 Tube Display
( I ) XP8200
Customer
Display
Vacuum Fluorescent Display
Blue Green
Display Pattern 5 x 7 Dot Matrix
Brightness 350~700 cd/m²
Character Type 95 Alphanumeric & 32 International Characters
Character Size 5.25 mm (W) x 9.03 mm (H)
Character Number 40 (20 columns x 2 lines)
Character Pitch Refer the figure 2.1

2.2 Electricity
Central Control Unit CPU : SM5964
ROM : 64K ROM
RAM : 32K SRAM
Speed CPU : 33 MHz
Connector 16 PIN Phone Jack Connector
9 PIN D-SUB Connector
25 PIN (Female) D-SUB Connector
Power Source DC + 5V~12V
Power Consumption 3 Watts Average (Maximum 15 Watts)
2.3 Overall Dimensions
Dimension of Panel
XP8200 : 220(L)* 87(W)* 50(H) mm
Dimension of Support
One Support: 217* 106* 248 mm
Two Support: 217* 106* 378 mm
Dimension of Base 217(L)* 106(W)* 33(H) mm
Viewing Angle 0°~60°
Horizontal Rotation 180°
Weight 980g
2.4 Environment
Operating
Temperature
+10 to +40℃℃
Storage Temperature -10 to +50℃℃
Relative Humidity 0% to 90% RH
2.5 Interface
Interface RS232 or USB
2.6 User Setting
The default protocol is 9600 bps, non-parity, 8 data bits, 1 stop bit
and with DTR/DSR control.

2.6.1 Function Setting
No switch, all user setting is set up by Application Program
(AP). Please find more illustration on Chapter 6.
( I ) Baud Rate Select
Function Description Baud Rate (bps)
9600
19200
( II ) Command Type Select
Function Description Software Defined
Command Type Hex Code
LD220 00
EPSON POS D101(default) 01
UTC Standard 02
UTC Enhance 03
AEDEX 04
ADM788 05
DSP800 06
CD5220 07
EMAX 08
LOGIC CONTEOL 09

( III ) International Character Set
Function Description
International Character
Set (Code 20H-7FH)
Code Table
(Code 80H-FFH)
U.S.A. PC-437 (USA)
(Standard European)
FRANCE PC-850 (Multilingual)
GERMANY PC-850 (Multilingual)
U.K. PC-850 (Multilingual)
DENMARK I PC-850 (Multilingual)
SWEDEN PC-850 (Multilingual)
ITALY PC-850 (Multilingual)
SPAIN PC-850 (Multilingual)
JAPAN Katakana
NORWAY PC-865 (Nordic)
DENMARK II PC-850 (Multilingual)
SLAVONIC/RUSSIAN PC-437 (USA)
(Standard European)
RUSSIAN PC-866
GREEK PC-737
CZECH PC-852
LATIVAIN PC-1257

Chapter 3 Interface
3.1 Interface
Specifications
Data Transmission Method : Asynchronous Serial.
Handshaking : DTR/DSR Control
Default Protocol : 9600/19200 bps, non-parity, 8 data bits, 1 stop bit.
Communication Protocol
1. Receive Data.
The DTR signal is as follows:
[HIGH] This indicates that the display isn't ready to receive data.
It depend on the following conditions:
The period from when the power is turned on to when the printer
first becomes ready to receive data.
When the remaining space in the receiving buffer becomes 128
bytes or less.
When the DTR signal of the printer is HIGH when the printer is
selected using the command.
[LOW] This indicates that the display is ready to receive data.
It depends on the following conditions:
When the printer first becomes ready to receive data after power-on.
When the remaining space in the receiving buffer becomes 128 bytes
or more.
When the DTR signal of the printer is LOW when the printer is
selected using the command.
2. Transmit Data.
After confirming the DSR is LOW, data is transmitted to printer.

3.2 Connector
(I) Connector for Host Computer
145
9876
32
PIN Assignment
Pin No. Signal I/O Description
1 NC No Connection
2 TXD- OUTPUT Transmit Data
3 RXD INPUT Receive Data
4 DSR INPUT Data Set Ready
5 GND Power GND
6 DTR OUTPUT Data Terminal Ready
7 CTS Clear To Send
8 RTS Request to Send
9 By Selection N.C. or +5V ~ +12V
(II) Passthru Mode
XP8200-PASS 1
For the printer with ESC/POS command

XP8200-PASS2
For the printer without ESC/POS command

Chapter 4 Command Description
4.1 XP8200 Command Set
4.1.1 LD220 Command Mode
Command Hex Function Description
HT 09 Move cursor right (Only valid in overwrite
mode)
BS 08 Move cursor left (Only valid in overwrite
mode)
CR 0D Move cursor to left-most position
(Only valid in overwrite mode)
ESC @ 1B 40 Initialize customer display to initial state,
clears display buffer, set display mode to shift
and sets current display row to upper row
ESC U 1B 55 Select upper row as current row (Initial
default)
ESC D 1B 44 Select lower row as current row
ESC A n 1B 41 n Sets customer display disable or enable
n=D, Disable ; n=E, Enable
ESC C r c 1B 43 r c Move cursor to specified position
(Only valid in overwrite mode)
r=U, upper row ; r=D, lower row
1 c 20 (column number)≦≦
ESC E r n 1B 45 r n Set special effect or display mode of specified
row
ESC R n 1B 52 n Set international font sets
( Please refer International Font Set Table )
ESC = n 1B 3D n Select peripheral
n=1, printer ; n=2, display ; n=3, printer &
display
ESC % n 1B 25 n Set font pattern
n=0, selected ; n=1, canceled
ESC & n s
[p]
1B 26 n s data Define user font pattern
n=code for first character
s=code for last character
data=5 bytes required for each character
(REMARK)*Using commands “ESC E r n”, the value (Hex) of parameter
r 58h=all rows
55h=upper row
44h=lower row
n special function, the value is one of
30h=shift mode (Default display mode)
31h=rotation mode
32h=blink mode
33h=clear this row and switch to shift mode
34h=overwrite mode
35h=vertical mode
* International Font Set Table
n (Hex) International Font Set n (Hex) International Font Set
30h
31h
U.S.A
GERMANY
32h
33h
FRANCE
JAPAN

4.1.2 EPSON Command Mode
Command Hex Function Description
HT 09 Move cursor right
BS 08 Move cursor left
US LF 1F 0A Move cursor up
LF 0A Move cursor down
US CR 1F 0D Move cursor to right-most position
CR 0D Move cursor to left-most position
HOM 0B Move cursor to home position
US B 1F 42 Move cursor to bottom position
US $ x y 1F 24 x y Move cursor to specified position
1 x(column) 20 ; 1 y(row) 2≦≦≦≦
US C n 1F 43 n Select/cancel cursor display
n=0, canceled ; n=1, selected
CLR 0C Clear display screen
CAN 18 Clear cursor line
US X n 1F 58 n Brightness adjustment
1n4≦≦
US E n 1F 45 n Blink display screen
0 n 255 (n*50msec) ON / (n*50msec)≦≦
OFF
n= 0, blinking is canceled
n=255, display is turned off
ESC @ 1B 40 Initialize display
ESC t n 1B 74 n Select character code table
0 n 5 ( Please refer≦≦ “Chapter 5” )
ESC R n 1B 52 n Select international character set
( Please refer International Font Set Table )
US r n 1F 72 n Select/cancel reverse character
n=0, canceled ; n=1, selected
US MD1 1F 01 Specify overwrite mode
US MD2 1F 02 Specify vertical scroll mode
US MD3 1F 03 Specify horizontal scroll mode
US . n 1F 2E n Specify period display
n= display character code
US , n 1F 2C n Specify comma display
n= display character code
US ; n 1F 3B n Specify semicolon (period+comma) display
n= display character code
US # n m 1F 23 n m Specify display annunciator,, turn the
annunciator at “m” column on or off
n=0,1 (Off, On) ; 0 m 20≦≦
ESC & s n m
[a(pl..p5)]
(m-n+1)
1B 26 s n m
[a(pl..p5)](m-n+1)
Define download characters
s=1 ; 32 n m 126 ; a=5≦≦ ≦
( p1..p5 = pattern1..pattern5 )
ESC ? n 1B 3F n Cancel user-defined characters
32 n 126 (n=character code)≦≦

ESC % n 1B 25 n Select/cancel download character set
n=0, canceled ; n=1, selected
ESC W n s
(x1 y1 x2 y2)
1B 57 n s (x1 y1
x2 y2)
Specify/cancel the window range
n=1,2,3,4 (four windows) ; s=0,1 (disable,
enable)
1 x1 x2 20 (column) ; 1 y1 y2 2 (row)≦≦≦ ≦≦≦
ESC = n 1B 3D n Select peripheral device
n=1, printer ; n=2, display ; n=3, printer &
display
US : 1F 3A Set starting/ending position of macro
definition
US ^ n m 1F 5E n m Execute and quit macro
0 (n,m) 255≦≦
n: specifies the time interval for display of
characters in units of [n* 50msec]
m: specifies the interval of macro execution
every [m*50msec]
US @ 1F 40 Execute self-test
US T h m 1F 54 h m Display time :0 h 23 ; 0 m 59≦≦ ≦ ≦
US U 1F 55 Display of time counter
* International Font Set Table
n (Hex) International Font Set n (Hex) International Font Set
00h
01h
02h
03h
04h
05h
U.S.A.
FRANCE
GERMANY
U.K.
DENMARK I
SWEDEN
06h
07h
08h
09h
0Ah
ITALY
SPAIN
JAPAN
NORWAY
DENMARK II
SLAVONIC/RUSSIA
Specify decimal point, comma, semicolon, annunciator*※
(1) US . n (Decimal Point) / US , n (Comma) / US ; n (Semicolon):
The displayed character codes are form 32(20h) to 127(7Eh), and
128(80h) to 255(FFh) in the character code table. The
period/comma/semicolon displayed only for n. The period is not displayed for
the subsequent display characters.
(2) US # n m (annunciator):
[ range ] n = 0(00h) or 1(01h) / m = 0(00h)~20(14h)
[ notes ] When n= 0, the annunciator at column m is turned off.
When n= 1, the annunciator at column m is turned on.
”m” specify column number (the most left column is column 1) at
which annunciator to be turned on/off is placed.
When m = 0, all annunciators are turned on or off.
Once an annuciator(s) is turned on, it remains on until turned off by this
command, the ESC@ or US@ command is executed, or the power is turned
off. [example]: To turn on the annunciator at the third column:
[n = 01h ], [ m = 03h ]
To turn off all the annunciators:
[n = 00h ], [ m = 00h ]
Above commands relating decimal point, comma, semicolon, and ※
annunciator may not be available due to hardware limit of display tube.

ESC % n 1B 25 n Select/cancel download character set
n=0, canceled ; n=1, selected
ESC W n s
(x1 y1 x2 y2)
1B 57 n s (x1 y1
x2 y2)
Specify/cancel the window range
n=1,2,3,4 (four windows) ; s=0,1 (disable,
enable)
1 x1 x2 20 (column) ; 1 y1 y2 2≦≦≦ ≦≦≦
(row)
ESC = n 1B 3D n Select peripheral device
n=1, printer ; n=2, display ; n=3, printer &
display
US : 1F 3A Set starting/ending position of macro
definition
US ^ n m 1F 5E n m Execute and quit macro
0 (n,m) 255≦≦
n: specifies the time interval for display of
characters in units of [n* 50msec]
m: specifies the interval of macro execution
every
[m*50msec]
US @ 1F 40 Execute self-test
US T h m 1F 54 h m Display time
0 h 23 ; 0 m 59≦≦ ≦ ≦
US U 1F 55 Display of time counter
* International Font Set Table
n (Hex) International Font Set n (Hex) International Font Set
00h
01h
02h
03h
04h
05h
U.S.A.
FRANCE
GERMANY
U.K.
DENMARK I
SWEDEN
06h
07h
08h
09h
0Ah
ITALY
SPAIN
JAPAN
NORWAY
DENMARK II
SLAVONIC/RUSSIA
Specify decimal point, comma, semicolon, annunciator*※
(3) US . n (Decimal Point) / US , n (Comma) / US ; n (Semicolon):
The displayed character codes are form 32(20h) to 127(7Eh), and
128(80h) to 255(FFh) in the character code table. The
period/comma/semicolon displayed only for n. The period is not displayed for
the subsequent display characters.
(4) US # n m (annunciator):
[ range ] n = 0(00h) or 1(01h) / m = 0(00h)~20(14h)
[ notes ] When n= 0, the annunciator at column m is turned off.
When n= 1, the annunciator at column m is turned on.
”m” specify column number (the most left column is column 1) at
which annunciator to be turned on/off is placed.
When m = 0, all annunciators are turned on or off.
Once an annuciator(s) is turned on, it remains on until turned off by this
command, the ESC@ or US@ command is executed,
or the power is turned off.
[example]: To turn on the annunciator at the third column:

[n = 01h ], [ m = 03h ]
To turn off all the annunciators:
[n = 00h ], [ m = 00h ]
Above commands relating decimal point, comma, semicolon, and
※
annunciator may not be available due to hardware limit of display tube.
4.1.3 UTC Standard Command Mode
Command Hex Function Description
BS 08 Back space
HT 09 Horizontal tab
LF 0A Line feed
CR 0D Carriage return
DC0 p 10 p Move cursor to specified position,
0p39≦≦
(Please refer Row Character Position
Chart )
DC1 11 Over write display mode
DC2 12 Vertical scroll mode
DC3 13 Cursor on
DC4 14 Cursor off
ESC d 1B 64 Change to UTC enhanced mode
US 1F Clear display
Row Character Position Chart (Decimal)
Row1 012345678910111213141516171819
Row2 20 21 22 23 24 25 26 27 28 29 30 31 32 33 34 35 36 37 38 39
Row Character Position Chart (Hex)
Row1 00 01 02 03 04 05 06 07 08 09 0A 0B 0C 0D 0E 0F 10 11 12 13
Row2 14 15 16 17 18 19 1A 1B 1C 1D 1E 1F 20 21 22 23 24 25 26 27

4.1.4 UTC Enhance Command Mode
Command Hex Function Description
ESC u
A..CR
1B 75 41 [data x
20] 0D
Upper line display
ESC u
B..CR
1B 75 42 [data x
20] 0D
Bottom line display
ESC u
D..CR
1B 75 44 [data x
45] 0D
Upper line message scroll continuously
ESC u
E..CR
1B 75 45 hh ‘:’ mm
0D
Set and display 24 hour time
0 h ,m 9≦≦
ESC u F..CR 1B 75 46 [data x
45] 0D
Upper line message scroll once pass
ESC u
H..CR
1B 75 48 n m 0D Change attention code
32 n ,m≦
( Default attention code n=1Bh, m=75h )
ESC u 1..CR 1B 75 49 [data x
40] 0D
Two line display
ESC RS..CR 1B 0F 0D Change to UTC standard mode
4.1.5 AEDEX Command Mode
Command Hex Function Description
! # 1..CR 21 23 31 [data x
20] 0D
Upper line display
! # 2..CR 21 23 32 [data x
20] 0D
Bottom line display
! # 4..CR 21 23 34 [data x
45] 0D
Upper line message scroll continuously
! # 5..CR 21 23 35 hh ‘:’ mm
0D
Set and display 24 hour time
0 h ,m 9≦≦
! # 5 CR 21 23 35 0D Display 24 hour time
! # 6..CR 21 23 36 [data x
45] 0D
Upper line message scroll once pass
! # 8..CR 21 23 38 n m 0D Change attention code
32 n ,m≦
( Default attention code n=”!”, m=”#” )
! # 9..CR 21 23 39 [data x
40] 0D
Two line display

4.1.6 ADM788 Command Mode
Command Hex Function Description
CLR 0C Clear display
CR 0D Carriage return
SLE1 0E Clear up line and move cursor to upper line
left most end
SLE2 0F Clear low line and move cursor to lower line
left most end
DC0 10 n Set period to upper line last n position
1n7≦≦
DC1 11 n Set line blinking
n=1, upper line
n=2, lower line
DC2 12 n Clear line blinking
n=1, upper line
n=2, lower line
SF1 1E Clear field 1 and move cursor to field 1 fast
position
SF2 1F Clear field 2 and move cursor to field 2 fast
position

4.1.7 DSP800 Command Mode
Command Hex Function Description
EOT SOH I
n ETB
04 01 49 n 17 Select international character set
( Please refer International Font Set Table )
EOT SOH P
n ETB
04 01 50 n 17 Move cursor to specified position
49n88≦≦
EOT SOH C
n m ETB
04 01 43 n m 17 Clear display range from n position to m
position and move cursor to n position
49nm88≦≦ ≦
EOT SOH S
n ETB
04 01 53 n 17 Save the current displaying data (40
characters) to n’th layer for demo display
1n3≦≦ ( n specify the layer 1, 2, or 3 )
EOT SOH D
n m ETB
04 01 44 n m 17 Display the saved data
1 n 3 ( n specify the layer 1, 2, or 3 )≦≦
“m” can be ignored
EOT SOH A
n ETB
04 01 41 n 17 Brightness adjustment
1n4≦≦
EOT SOH =
n ETB
04 01 3D n 17 Select peripheral device
n=1, printer ; n=2, display
EOT SOH %
ETB
04 01 25 17 Initialize display
* International Font Set Table
n (Hex) International Font Set
30h
31h
32h
33h
34h
35h
36h
37h
38h
39h
3Ah
XXh
U.S.A.
FRANCE
GERMANY
U.K.
DENMARK I
SWEDEN
ITALY
SPAIN
JAPAN
NORWAY
DENMARK II
SLAVONIC/RUSSIA
RUSSIAN
GREEK
CZECH
LATIVAIN

4.1.8 CD5220 Command Mode
Command Hex Function Description
ESC DC1 1B 11 Overwrite mode
ESC DC2 1B 12 Vertical scroll mode
ESC DC3 1B 13 Horizontal scroll mode
ESC Q A CR 1B 51 41 [N]20
0D
Set string display mode, write string to upper line
ESC Q B CR 1B 51 42 [N]20
0D
Set string display mode, write string to lower line
ESC Q D CR 1B 51 44 [N]m20
0D
Upper line message scroll continuously m<40
ESC [ D 1B 5B 44 Move cursor left
BS 08 Move cursor left
ESC [ C 1B 5B 43 Move cursor right
HT 09 Move cursor right
ESC [ A 1B 5B 41 Move cursor up
ESC [ B 1B 5B 42 Move cursor down
LF 0A Move cursor down
ESD [ H 1B 5B 48 Move cursor to home position
HOM 0B Move cursor to home position
ESC [ L 1B 5B 4C Move cursor to left-most position
CR 0D Move cursor to left-most position
ESC [ R 1B 5B 52 Move cursor to right-most position
ESC [ K 1B 5B 4B Move cursor to bottom position
ESC l x y 1B 6C x y Move cursor to specified position
1 x 20 (column) ; y=1,2 (row)≦≦
ESC @ 1B 40 Initialize display
ESC W s x1
x2 y
1B 57 s x1 x2 y Enable or disable the window range at horizontal
scroll mode
s=0,1 (disable, enable)
1 x1 x2 20 (column) ; y=1,2 (row)≦≦≦
CLR 0C Clear display screen, and clear string mode
CAN 18 Clear cursor line, and clear string mode
ESC * n 1B 2A n Brightness adjustment
1n4≦≦
ESC & s n m
[a(pl..p5)]
(m-n+1)
1B 26 s n m
[a(pl..p5)]
(m-n+1)
Define download characters
s=1 ; 32 n m 126 ; a=5≦≦ ≦
( p1..p5 = pattern1..pattern5 )
ESC ? n 1B 3F n Delete download characters
32 n 126 (n=character code)≦≦
ESC % n 1B 25 n Select / cancel download character set.
n=0, canceled ; n=1, selected
ESC _ n 1B 5F n Set cursor ON/OFF
n=0,1 (Off,On)
ESC f n 1B 66 n Select international fonts set
ESC c n 1B 63 n Select fonts, ASCII code or JIS code
ESC = n 1B 3D n Select peripheral device
n=1, printer ; n=2, display ; n=3, printer & display

(REMARK)
* While using command “ESC Q A” or “ESC Q B”, these two commands could
be used combining with terminal printer - TP 2688 or TP3688
* If using command “ESC Q A” or “ESC Q B”, others commands can’t be used
except using command “CLR” or “CAN” to change operating mode.
* If using command “ESC Q D”, message on upper line will move continuously
till receiving a new command, clearing upper line, and moving cursor to most left
position on upper line.
* International Font Set Table
n
( Decimal )
International Font Set
A
G
I
J
U
F
S
N
W
D
E
L
R
U.S.A
GERMANY
ITALY
JAPAN
U.K.
FRANCE
SPAIN
NORWAY
SWEDEN
DENMARK I
DENMARK II
SLAVONIC
RUSSIA
Reserved
* Select Code Table
n
( Decimal )
International Code
A
J
R
L
compliance with ASCII code
compliance with JIS code
compliance with RUSSIA code
compliance with SLAVONIC code
