PARAMOUNT PARTS LIST
R
WEED EATER PARTS LIST
R
R
POULAN PARTS LIST
R
Replaces
1
Note: Illustration may differ from actual model due to design changes
PARTS L IST NO.
PAGE NO.
CHAIN SAW MODEL(s)
530165403 P3416
DATE
7/03/08
PARTS LIST
530165403 --- 6/06/08
r
1. 530057893 Knob--Choke
2. 530057908 Spring--Ign. Switch
3. 530057891 Lever--Ign. Switch
4. 530016080 Screw
5. 530071888 Kit--Trigger/Lockout
6. 530069216 Kit--Fuel Line (Large)
7. 530069247 Kit--Fuel Line (Small)
8. 530095649 Assy--Fuel Pick Up
9. 530023877 Fitting--Fuel line
10. 530071945 Kit--Clutch Washer
11. 530057905 Assy--Clutch Drum 3/8”
12. 530071945 Kit--Clutch Washer
13. 530057907 Assy--Clutch
14. 530016419 Washer--Large Clutch
15. 530047192 Assy--Fuel Cap w/ret
16. 530016064 Screw
17. 530015922 Nut--”U” type speed
18. 530057937 Assy--Flywheel
19. 530057911 Shield--Heat
20. 530015127 Washer--Flywheel
21. 530016134 Nut--Flywheel
All repairs, adjustments and maintenance
not described in the Operator’s Manual
must be performed by qualified service
personnel.
WARNING
Ref. Part No. Description Ref. Part No. Description Ref. Part No. Description
44
45
22. 530015920 Screw
23. 530057890 Pulley--Starter
24. 530042095 Spring--Starter
25. 530058810 Housing--Fan
26. 530056402 Handle--Starter
27. 530069232 Kit--Rope
28. 530016432 Screw
29. 530016080 Screw
30. 530058786 Assy--Oil Vent
31. 530057236 Assy--Oil Cap w/ret.
32. 530057897 Handguard
33. 530016416 Spring--Handguard
3 4 . -- -- -- A s s y -- C h a s s i s
(Incl. 5,6,7,8,9,15,16,
17,19,31,33,37)
530058863 Green
530058870 Black
35. 530071893 Kit--Chainbrake
36. 530016432 Screw
37. 530016133 Bolt--Bar
38. 530057910 Plate--Bar
39. 530015917 Nut--Bar
40. 530058933 Assy--Clutch Cover
(Incl. # 41)
41. 530069611 Kit--Bar Adjust
(Incl. 42,43)
42. 530015826 Pin--Bar Adjust
43. 530038593 Retainer--Bar Adjust
44. 952051211 Accy--16” Chain
45. 952044370 Accy--16” Bar
46. 530071945 Kit--Clutch Washer
(Incl. 10,12)
47. 530016432 Screw
48. 530057888 Handle--Front
49. 530071891 Kit--Oil Pump
(Incl. 51,52,53)
50. 530057924 Assy--Oil Pick Up
51. 530016064 Screw
52. 530057931 Assy--Oil Pump
53. 530037820 Gear--Worm
=NEW PART NUMBER FOR THIS IPLn=REFER TO THE SERVICE REFERENCE INDICATED FOR MORE INFORMATION. (LOCATED AT END OF IPL) K
515
16
19
11
10
12
13
14
18
20 21 22 23
24
25
17
40
48
47
49
38
37
34
31
30
28
32
35
36
33
27
26
51 52
50
53
42 43
41
2
34
1
8
6
9
39
29
Clutch
Washer
Kit
46
7
TYPE 1,2

PARAMOUNT PARTS LIST
R
WEED EATER PARTS LIST
R
R
POULAN PARTS LIST
R
Replaces
2
Note: Illustration may differ from actual model due to design changes
PARTS L IST NO.
PAGE NO.
CHAIN SAW MODEL(s)
530165403 P3416
DATE
7/03/08
PARTS LIST
530165403 --- 6/06/08
r
1. 530058837 Shield--Cylinder
(incl. #3)
2. 530016153 Screw
3. 530059006 Reflector--Tape
4. 530039198 Module -- Ignition
5. 530016432 Screw
6. 530047442 Strap--Ground
7. 530057943 Assy--Wire Harness
8. 530058687 Cover--Air Filter
9. 530057925 Filter--Air
10. 530016425 Screw
11. 530057892 Housing--Air Filter
12. ------ Carburetor
530035590 Zama W--26
13. 530069247 Kit--Fuel Line (Small)
14. 530047721 Bulb--Purge “snap--in”
15. 530071889 Kit--Carb. Adaptor
( Incl. # 16,34,37)
16. 530071894 Gasket--cyl. o--ring (kit)
17. 952030150 Accy--Spark Plug (RCJ--7Y)
18. 530071884 Kit--Cylinder (Incl. 25,33)
19. 530016136 Clip--High Tension Lead
20. 530071887 Kit--Muffler (Incl .21--23,24)
21. 530057942 Backplate--Muffler
22. 530071894 Gasket--Muffler (kit)
23. 530071886 Kit--Spark Arrestor
24. 530016338 Bolt--Muffler
25. 530057885 Insert--Left (black) Cyl.
26. 530012537 Assy--Crankshaft/Rod
27. 530016417 Bolt
28. 530057941 Cap--Crankcase
29. 530056363 Assy--Bearing/Seal
30. 530071883 Kit--Piston (Incl. 31,32)
31. 530015697 Retainer--Piston Pin
32. 530038729 Ring--Piston
33. 530057886 Insert--Right (gray) Cyl.
Ref. Part No. Description Ref. Part No. Description Ref. Part No. Description
34. 530071894 Seal--Adaptor (kit)
35. 530016426 Screw
36. 530071894 Gasket--Carb. (kit)
37. 530057926 Tube--Intake
38. 530057909 Wire--Throttle
39. 530016101 Nut--Carb.
40. 530071894 Kit--Gasket
(Incl . 16,22,34,36)
41. 530031163 Wrench--Bar
545047535 Manual--Operator
530059107 Decal--Warning
530058840 Decal--Start/Stop Inst.
Engine
Gasket
Kit
=NEW PART NUMBER FOR THIS IPLn=REFER TO THE SERVICE REFERENCE INDICATED FOR MORE INFORMATION. (LOCATED AT END OF IPL)K
40
Not Shown
41
All repairs, adjustments and maintenance not
described in the Operator’s Manual must be
performed by qualified service personnel.
WARNING
8
9
10
11
12
13
14 15
16
17
18
19
21
22 20
1
2
3
4
5
7
6
39
38 37
36
35
34
33
25
31
32
29
27
26
28
24
30
23
TYPE 1

PARAMOUNT PARTS LIST
R
WEED EATER PARTS LIST
R
R
POULAN PARTS LIST
R
Replaces
3
Note: Illustration may differ from actual model due to design changes
PARTS L IST NO.
PAGE NO.
CHAIN SAW MODEL(s)
530165403 P3416
DATE
7/03/08
PARTS LIST
530165403 --- 6/06/08
r
1. 530058837 Shield--Cylinder
(incl. #2 & 3)
2. 530016153 Screw
3. 530059006 Reflector--Tape
4. 530039198 Module -- Ignition
5. 530016432 Screw
6. 530047442 Strap--Ground
7. 530057943 Assy--Wire Harness
8. 530058687 Cover--Air Filter
9. 530057925 Filter--Air
10. 530016425 Screw
11. 530057892 Housing--Air Filter
12. ------ Carburetor
545070601 Zama W--26B
(Incl. 14)
13. 530069247 Kit--Fuel Line (Small)
14. 530047721 Bulb--Purge “snap--in”
15. 530071889 Kit--Carb. Adaptor
( Incl. # 16,34,37)
16. 530071894 Gasket--cyl. o--ring (kit)
17. 952030150 Accy--Spark Plug (RCJ--7Y)
18. 530071884 Kit--Cylinder (Incl. 25,33)
19. 530016136 Clip--High Tension Lead
20. 545006007 Kit--Muffler
(Incl .21,22,23,24)
21. 530057942 Backplate--Muffler
22. 530071894 Gasket--Muffler (kit)
23. 545006056 Kit--Spark Arrestor
24. 530016338 Bolt--Muffler
25. 545015301 Insert--Left (black) Cyl.
26. 530012537 Assy--Crankshaft/Rod
27. 530016417 Bolt
28. 530057941 Cap--Crankcase
29. 530056363 Assy--Bearing/Seal
30. 530071883 Kit--Piston (Incl. 31,32)
31. 530015697 Retainer--Piston Pin
32. 530038729 Ring--Piston
33. 545015401 Insert--Right (gray) Cyl.
Ref. Part No. Description Ref. Part No. Description Ref. Part No. Description
34. 530071894 Seal--Adaptor (kit)
35. 530016426 Screw
36. 530071894 Gasket--Carb. (kit)
37. 530057926 Tube--Intake
38. 530057909 Wire--Throttle
39. 530016101 Nut--Carb.
40. 530071894 Kit--Gasket
(Incl . 16,22,34,36)
41. 530031163 Wrench--Bar
545186804 Manual--Operator
530059107 Decal--Warning
Engine
Gasket
Kit
=NEW PART NUMBER FOR THIS IPLn=REFER TO THE SERVICE REFERENCE INDICATED FOR MORE INFORMATION. (LOCATED AT END OF IPL)K
40
Not Shown
41
All repairs, adjustments and maintenance not
described in the Operator’s Manual must be
performed by qualified service personnel.
WARNING
8
9
10
11
12
13
14 15
16
17
18
19
21
22 20
1
2
3
4
5
7
6
39
38 37
36
35
34
33
25
31
32
29
27
26
28
24
30
23
TYPE 2
