POVISON 9200 User manual

MODEL NO. : 9200
CEILING FAN
User Manual
Simple Life , Better Home
Povison Official Povison
PovisonOfficial Povison Povisonpovisonofficial
[phone]
[email protected]

9200
Packing List:
1
Lighting
Light chassis Fan blade Expansion screws
Hanger bracket 10 inch downrod
Light hangerRemote controller
Balance package Blade screw
Canopy Translucent lampshadeDecorative cover
5 inch downrod

Product Care
1. Please read the manual before installation.
2. Do not use this product in humid environment or high temperature.
3. If the ceiling fan is defective or breaks down, please stop using it and
contact us with documented photos or short videos via customerser-
[email protected].
9200
2
Specification
Material
Color
Weight
Motor Power
Number Of Blades
Metal + ABS
White/Black
8.1KG
35W
5
Light Source Power 18W
Size 60*60*21.7”/60*60*26.6”in
Color Temperature 3000k-4500k-6500k
Luminous flux 1500lm

3
9200
Installation
philips screwdriver / Blade screwdiver / Adjustable pliers or wrench
Step ladder / Wire cutter / Electical tape / Lmpact drill
(1)
To use wood screws to fix bracket for
wooden or false ceiling.
(2)
To use expansion screws to fin bracket
for concrete ceiling before that will need
to drill dia.8mmexpansion bolts.
Note: Before installing the ceiling fan, make sure that the power has
been turned off.
1. Tools ready
2. Installation of bracket
Wood screws
Beam
Expansion screw
Fixed seat Lift the ball
（1）
Install the boom safety pin to the
junction of the boom and the
hanger.(Figure 1)

4
9200
1) Connect the corresponding wires at the
bottom of the lamp and the motor.
2) Tighten the three screws on the edge of
the switch cover
3) Take out the decorative nuts,nuts,iron
washers and plastic washers pre-locked on
the lamp tube
4)Install glass, tighten plastic washer, iron
washer and nut in turn
5) Install the decorative frame and fasten
the decorative nut
（2）
Install the fan blades to the motor in
order and screw on the fan
blade screws in turn.(Figure 2)
3. Install the blades
4. Lamp installation
Hex nuts Light source
chassis
light source
lampshade
（1）
Install the boom safety pin to the
junction of the boom and the
hanger.(Figure 1)

5
9200
（1） （2） （3）
1) To select the correct downrod,either 5 inch or 10 inch according to the
ceiling height.Put the canopy and decorative cover through the downrod;
2) Remove the locking pin and the long pin. then remove the two downrod set screws;
3) Fix the downrod set into the fan body,lock the downrod to the fan body with set screws.
4) Mount the bracket onto outlet box by the screws,spring washers and flat washers.
5) Hang the ball joint and the fan onto the bracket,make sure the guide pin of the
bracket is fitted into slot of ball joint.
6) Insert the remote control receiver between the bracket and the downrod.
7) Connect wires from supply and the bracket to the wiring terminals.
8) Attached canopy to the bracket by aligning canopy holes with the bracket holes
.Fix the canopy to bracket with set screws.
9) Install the blade brackets and blades with screws.
5. Installation of downrod,canopy and decorative
cover Selection of downrod
Locking pin
Downrod
setscrew
Downrod
setscrew
Pin

6
9200
1) Place the lobes in the hanger and turn the pipe so that the groove on the
lobes engages thelugs on the dome(inside the hanger)
The lug grouve must engage the hanger lug.
6. Installation height
7. Hanging ceiling fan
Fan blades to the ground shall
note less than 2.3 meters
0.5M
2.3M
Lobed coneave groove
hanger lugs

7
9200
Fan is installed,if it shakes up and down,please check the screws in blades,
downrod,and the lamp kit if they are fix,if not,please fix it with screw driver.
lf it still shakes, please use the balancing kit stools and check the instruction
of balancing kit inside the carton.
8. Connect the power cord
9. The balance adjustment of the fan
Connect the remote control driver as shown in the picture (the driver is finally
placed in the mounting bracket).
Connect to 110V household wire
Red line (Live wire)
Montor lineU
Montor lineV
Montor lineW
red line
gray line
pink line
Black line (Neutral wire)
White line (light control wire)
Blue wire (light control wire)
Connect the same color
wire of the fan accordingly
Remote controller driver

1
2
3
4
9200
Instruction of the remote control
8
9
8
5
6
7
Turn offallloads.
Fan speed control.
LED indicator light.
Turn on the light / Color
Temperature Adjustment.
Fan off.
Fan positive and negative
rotation control.
Fan timing control.
The remote control USES
a pair of 1.5v batteries.
Natural Wind.
1
2
3
4
5
6
FAN/OFF
ALL OFF LIGHT
ON/OFF
FR
1H2H 4H
1
2
3
4
5
6
7
8
9
Tips:
1.The remote control and receiver are paired as learning codes. The remote control is turned to
receive the controller within one minute after the receiver is powered on; Long press the natura
wind buttonAbout 5 seconds, in the sound of a drop, that learningsuccess, can be used normal-
ly:(note: no learning is accepted if the power is energized for more than one minute)
2. When the remote control cannot control the controller, please check whether the battery is
loadet correctly;
3.Too low battery voltage will affect the remote control distance and may cause remote control
failure Please replace the battery in time
4.When not in use for a long time,please remove the battery of the remote control;
5.support the maximum 300VV lighting6. During installation, the ceiling cover of the fan shall not
compress all the wires, which may easily cause the wires to break and short circuit

9200
Function Description
9
Power Off
Turn On(Off)
The Ceiling Fan Short Press
Short Press
1
2
3
4
5
6
FAN/OFF
ALL OFF LIGHT
ON/OFF
FR
1H2H 4H
1
2
3
4
5
6
FAN/OFF
ALL OFF LIGHT
ON/OFF
FR
1H2H 4H
