POWERBOR PB100FRV User manual

PB50 Low Profile Manual Original instructions 2019
1
POWERBOR –PB100FRV
Magnetic drilling machine
Model Number
18N110, 18N230
This machine is CE approved.
Burgess Road
Sheffield, South Yorkshire
United Kingdom
S9 3WD
Tel: [phone] Fax: [phone]
Email: [email protected] Website: www.Powerbor.co.uk

PB50 Low Profile Manual Original instructions 2019
2
CONTENTS OF THE MANUAL
Page
1)
2)
3)
4)
5)
6)
7)
8)
9)
10)
11)
12)
13)
14)
15)
16)
17)
18)
19)
Intended use
General safety rules
Information plate symbols
Specification
Operational safety procedures
Operating instructions
Extension cable selection
Mounting of cutters
Fitting the Chuck
Remedies for hole making problems
Wiring diagram
Machine Layout
Exploded view of the Machine
Motor Breakdown
Control panel and parts list
Maintenance
Trouble shooting
Cutter selection, speeds and feeds
Warranty
3
3
4
5
6
6
7
7
7
8
9
10
11
14
17
18
19
20
21
Part
Description
Quantity
W18XC533
RATCHET STRAP / HOOK ASSEMBLY
1
W18XC535
HOOK / STRAP PLAIN
1
RD23603
OIL BOTTLE ASSEMBLY
1
W18XC527
ALLEN KEY SET
1

PB50 Low Profile Manual Original instructions 2019
3
1) INTENDED USE
The intended use of this magnetic drill is to drill holes in ferrous metals. The magnet is used to hold the drill in
place whilst the drill is functioning. It is designed for use in fabrication, construction, railways, petrochemical
and any other applications when drilling ferrous metal.
Any deviation from its intended use will not be covered by warranty.
2) GENERAL SAFETY RULES
WARNING! When using electric tools basic safety precautions should always be followed to reduce the risk of fire, electric
shock and personal injury, including the following.
Read all these instructions before attempting to operate the machine.
Remove the power supply before carrying out any adjustment, servicing or maintenance.
1. Keep work area clear - cluttered areas and benches invite injuries.
2. Consider work area environment;
•Do not expose tools to rain.
•Do not use tools in damp or wet locations.
•Keep work area well lit (500 Lux recommended).
•Do not use tools in the presence of flammable liquid or gases.
•Ensure there is adequate space to gain access to the plug, mains and motor on/off switches.
3. Guard against electric shock:
Avoid body contact with earthed or ground surfaces (e.g. pipes, radiators, cookers and refrigerators). Electric safety
can be further improved by using a high-sensitivity (30 m A/0.1s) residual current device (RCD).
4. Keep other persons away! DO NOT let untrained persons, especially children, touch the tool or the extension cord and
keep them away from the work area.
5. Store idle tools when not in use. All tools should be stored in a dry locked-up place, out of reach of children.
6. Do not force the machine. It will do the job better and safer at the rate for which it was intended.
7. Use the right tool;
•Do not force small tools to do the job of a heavy duty tool.
•Do not use this tool for purposes not intended: e.g. do not use the magnetic drill to cut tree logs.
8. Dress properly;
•Do not wear loose clothing or jewellery; they can be caught in moving parts.
•Non-skid footwear is recommended when working outdoors.
•Wear a protective hair covering to contain long hair. This will reduce the risk of entanglement.
9. Use protective equipment when using this machine;
•Use safety glasses to prevent debris from damaging eyes.
•Use ear defenders or ear plugs for hearing protection.
•Use face or dust masks if cutting operations create dust.
•Use protective gloves to prevent swarf or debris cutting the skin.
10. When using the drill, always ensure a safe operating distance from any swarf and do not reach into the cutting area,
or near the cutter, when the machine is running.
11. Connect dust extraction and collecting equipment, if devices are provided, ensuring these are properly connected and
used.
12. Do not abuse the cord; never pull the cord to disconnect it from the socket. Keep the cord away from heat, oil and
sharp edges.
13. Secure work where possible, use clamps or a vice to hold the work. It is safer than using your hand.
14. Do not overreach! Keep proper footing and balance at all times.
15. Maintain tools with care;
•Keep cutting tools sharp and clean for better and safer performance.
•Regularly check the machine for any wear or damage.

PB50 Low Profile Manual Original instructions 2019
4
•Ensure the machine is clean and free from debris prior to use.
•Remove from the mains prior to any maintenance.
•Follow instructions for lubricating and changing accessories.
•Inspect tool cords periodically and if damaged have them repaired by an authorized Powerbor service facility.
•Inspect extension cords periodically and replace if damaged.
•Keep handles dry, clean and free from oil and grease.
16. Disconnect tools when not in use, before servicing and when changing accessories such as cutters, disconnect tools
from the power supply.
17. Form the habit of checking to see that keys and adjusting wrenches are removed from the tool before turning it on.
18. Avoid unintentional starting. Ensure the magnet is OFF before plugging the machine in.
19. Use extension leads only intended for outdoor use when the tool is used outdoors.
20. WARNING! The vibration emissions during actual use can differ from the declared total value depending on the ways
in which the tool is being used.
21. Stay alert! Watch what you are doing, use common sense and do not operate the tool when you are tired. DO NOT
operate the machine when under the influence of alcohol or ANY illegal substances.
22. Check for damaged or missing parts before use of the tool; it should be carefully checked to determine that it will
operate properly for its intended function.
23. Warning! The use of any accessory or attachment, other than ones recommended in this instruction manual, may
present a risk of personal injury.
24. Have your machine repaired by a qualified Powerbor technician.
This electric tool complies with the relevant safety rules. Qualified persons using original spare parts should only carry
out repairs, otherwise this may result in considerable danger to the user.
25. Never operate the machine if parts are missing or damaged.
26. Never direct jets of water or flammable liquids over the drill.
27. Operator must be physically able to handle the weight of the machine.
28. Operator should be trained in the use of the machine.
3) INFORMATION PLATE SYMBOLS
1 2 3 4
1. Refer to the user manual for operational and safety issues with regard to this machine.
2. Dispose of the machine and electrical components correctly.
3. Eye protection must be worn when operating the machine.
4. Ear defenders must be worn when operating the machine.

PB50 Low Profile Manual Original instructions 2019
5
4) SPECIFICATION
Maximum hole cutting capacity in .2/.3C steel = 100mm dia. x 50mm deep
Arbor bore = 19.05mm (3/4") dia.
Motor Unit
Voltages
110V 50-60Hz
230V 50-60Hz
Normal full load
15.5 A
1700 W
7.9 A
1700 W
Electro Magnet
0.86 A
95W
0.41 A
95W
Size
220 mm long
110 mm wide
Holding Force at 20°C with 25mm
minimum plate thickness
The use on any material less than 25mm thick will progressively
reduce the magnetic performance. If possible, substitute
material should be positioned under the magnet and work
piece to equate to a suitable material thickness. If this is not
possible, an alternative secure method of restraining the
machine MUST be used.
20000N
Total Load (magnet + motor)
1795W
1795W
Overall Dimensions
Height - minimum
455mm
Width (Without Capstan fitting)
160mm
Length Overall (including Guard)
Nett Weight
25 kgs
Vibration total values (triax vector sum) in accordance with
EN61029-1:
Vibration emission value
2.5 m/s²
Level of sound pressure in accordance with EN61029-1:
86 dBA
Ear and eye defenders must be worn when operating this machine. Wear gloves to protect hands when
operating the machine.
These tools are UK designed and manufactured with globally sourced components and conform to the
requirements of EEC Document HD.400.1 and BS.2769/84
Suitable only for a single phase 50-60Hz A.C. power supply
DO NOT USE ON D.C. SUPPLY
Do not use your magnetic drill on the same structure when arc welding is in progress.
D.C. current will earth back through the magnet and cause irreparable damage.
WARNING: THIS APPLIANCE MUST BE EARTHED!
NB: ANY MODIFICATIONS TO THIS MACHINE WILL INVALIDATE THE GUARANTEE

PB50 Low Profile Manual Original instructions 2019
6
5) OPERATIONAL SAFETY PROCEDURES
READ BEFORE USING THE MACHINE
•When using electrical tools, basic safety precautions should always be followed to reduce the risk of electric shock, fire, and personal
injury.
•Ensure the magnet is OFF before plugging in the machine.
•Do NOT use in wet or damp conditions. Failure to do so may result in personal injury.
•Do NOT use in the presence of flammable liquids, gases or in high risk environments. Failure to do so may result in personal injury.
•BEFORE activating the machine, inspect all electrical supply cables (including extension leads), and replace if damaged. DO NOT use if
there are any signs of damage.
•Only use extension cables approved for site conditions.
•BEFORE activating the machine, ALWAYS check the correct function of all operational systems, switches, magnet etc.
•BEFORE operating, the machine MUST be securely restrained to a fixed independent feature (by using safety strap RD4329B, or other
means) to reduce the potential free movement, should the magnet become detached from the work piece. Failure to do so may
result in personal injury.
•ALWAYS wear approved eye protectors, ear defenders and recommended PPE at ALL times when operating the machine.
•Disconnect from power source when changing cutters or working on the machine.
•Cutters and swarf are sharp, ALWAYS ensure that hands are adequately protected when changing cutters or removing swarf. Use a
tool or brush where necessary to remove any swarf or the cutter from the arbor.
•Before operating the machine, ALWAYS ensure cutter-retaining screws are secured tightly.
•Regularly clear the work area and machine of swarf and dirt, paying particular attention to the underside of the magnet base.
•ALWAYS remove tie, rings, watches and any loose adornments that might entangle with the rotating machinery before operating.
•ALWAYS ensure that long hair is securely enclosed by an approved restraint before operating the machine.
•Should the cutter become stuck in the work piece, stop the motor immediately to prevent personal injury. Disconnect from power
source and turn arbor to and fro. DO NOT ATTEMPT TO FREE THE CUTTER BY SWITCHING THE MOTOR ON AND OFF. Wear safety
gloves to remove the cutter from the arbor.
•If the machine is accidentally dropped, ALWAYS thoroughly examine the machine for signs of damage and check that it functions
correctly BEFORE resuming drilling.
•Regularly inspect the machine and check for any damaged or loose parts.
•ALWAYS ensure when using the machine in an inverted position that only the minimum amount of coolant is used and that care is
taken to ensure that coolant does not enter the motor unit.
•Cutting tools may shatter, ALWAYS position the guard over the cutter before activating the machine. Failure to do so may result in
personal injury.
•On completion of the cut, a slug will be ejected. DO NOT operate the machine as the ejected slug may cause injury.
•When not in use ALWAYS store the machine in a safe and secure location.
•ALWAYS ensure that approved POWERBOR™ agents conduct repairs.
6) OPERATING INSTRUCTIONS
•Keep the inside of the cutter clear of swarf. It restricts the operating depth of the cutter.
•Ensure that the coolant bottle contains sufficient cutting oil to complete the required operating duration. Refill as required.
•Occasionally depress the pilot to ensure cutting fluid is being correctly metered.
•To start the machine, follow the control panel operation instructions.
•ALWAYS switch off the motor by depressing the MOTOR stop button. DO NOT switch off the motor by depressing the MAGNET
switch.
•Apply light pressure when commencing the cut of a hole until the cutter is introduced into the work surface. Pressure can then be
increased sufficiently to load the motor. Excessive pressure is undesirable, it does not increase the speed of penetration and will
cause the safety overload protection device to stop the motor, (the motor can be restarted by operating the motor start button), and
may cause excessive heat which may result in inconsistent slug ejection
•Always ensure that the slug has been ejected from the previous hole before commencing to cut the next.
•If the slug sticks in the cutter, move the machine to a flat surface, switch on the magnet and gently bring the cutter down to make
contact with the surface. This will usually straighten a cocked slug and allow it to eject normally.
•Apply a small amount of light oil lubricant regularly to the slide and arbor support bearing.
•Cutter breakage is usually caused by insecure anchorage, a loosely fitting slide or a worn bearing in the arbor support. (Refer to
routine maintenance instructions).
•Only use approved cutting fluid.

PB50 Low Profile Manual Original instructions 2019
7
7) EXTENSION CABLE SELECTION
The machines are factory fitted with a 2 metre length of cable having three conductors 1.5mm²
LIVE, NEUTRAL and EARTH. If it becomes necessary to fit an extension cable from the power source, care
must be taken in using a cable of adequate capacity. Failure to do so will result in a loss of traction by the
magnet and a reduction of power from the motor.
Assuming a normal AC supply of the correct voltage, it is recommended that the following extension lengths
shall not be exceeded:
For 110v supply: 3.5 yards of 3 core x 1.5mm²
For230v supply: 26 yards of 3 core x 1.5mm²
ALWAYS DISCONNECT THE MACHINE FROM THE POWER SOURCE BEFORE CHANGING CUTTERS.
8) MOUNTING OF CUTTERS
•The machine has been made to accept cutters having 19.05mm (3/4”) dia. Weldon shanks.
The following procedure is to be used when mounting cutters:
•Lay the machine on its side with feed handles uppermost, ensuring arbor is wound down to its lowest
point to enable access to socket screws RD4066.
•Take appropriate pilot and place through the hole in cutter shank. Insert shank of cutter into bore of
arbor, ensuring alignment of two drive flats with socket screws.
•Tighten both screws using hexagon key.
STAN OPERATION
10) REMEDIES FOR HOLE MAKING PROBLEMS
Problem
Cause
Remedy
1) Magnetic base
won’t hold
effectively
Material being cut may be too thin for efficient
holding.
Swarf or dirt under magnet.
Irregularity on magnet contact or work-piece.
Insufficient current going to magnet during drilling
cycles.
Attach an additional piece of metal under the
magnet, or mechanically clamp magnetic base to
work-piece.
Clean magnet.
Use extreme care; file any imperfections flush to
surface.
Confirm power supply and output from control unit,
check supply cable.
2) Cutter skips
out of centre-
punch mark at
initiation of cut
Magnetic base is not holding effectively.
Worn arbor bushing and/or ejector collar.
Too much feed pressure at start of cut.
Cutter is dull, worn, chipped or incorrectly
sharpened.
Poor centre-punch mark; weak pilot spring; pilot not
centred in centre-punch mark.
Worn or bent pilot, worn pilot hole.
See causes and remedies above.
New arbor bushing is needed.
Light pressure only is needed until a groove is cut.
The groove then serves as a stabilizer.
Replace or re-sharpen. Sharpening service is
available.
Improve centre-punch and/or replace worn parts
Replace part or parts
3) Excessive
drilling pressure
Incorrectly re-sharpened, worn or chipped cutter.
Re-sharpen or replace.

PB50 Low Profile Manual Original instructions 2019
8
required
Coming down on swarf lying on surface of work-
piece.
Swarf accumulated (packed) inside cutter.
Take care not to start a cut on swarf.
Clear cutter.
4) Excessive
cutter breakage
Steel swarf or dirt under cutter.
Incorrectly re-sharpened or worn cutter.
Cutter skipping.
Cutter not attached tightly to arbor.
Insufficient use of cutting oil or unsuitable type of
oil.
Incorrect speed
Remove cutter, clean part thoroughly and replace.
Always have a new cutter on hand to refer to for
correct tooth geometry, together with instruction
sheet.
See causes and remedies (2).
Retighten.
Inject oil of light viscosity into the coolant-inducing
ring and check that oil is being metered into cutter
when pilot is depressed. If not, check pilot groove
and arbor internally for dirt or apply oil externally.
(Even a small amount of oil is very effective).
Ensure correct speed is use for the cutter.
5) Excessive
cutter wear
See cause and remedy above
Incorrectly re-sharpened cutter.
Insufficient or spasmodic cutting pressure.
Refer to instructions and a new cutter for proper
tooth geometry.
Use sufficient steady pressure to slow the drill down.
This will result in optimum cutting speed and chip
load.

PB50 Low Profile Manual Original instructions 2019
9
11) WIRING DIAGRAM

PB50 Low Profile Manual Original instructions 2019
10
12) MACHINE LAYOUT
PB100E LOWERED
PB100E RAISED
ILLUSTRATED DESCRIPTION OF FUNCTIONS

PB50 Low Profile Manual Original instructions 2019
11
13) EXPLODED VIEW OF MACHINE

PB50 Low Profile Manual Original instructions 2019
12
No.
Part
Description
Qty
1
RD23603
OIL BOTTLE ASSEMBLY
1
2
W18XC202
M6 X 25 CAPHEAD SCREW
1
3
RD4414
M4 X 10 SKT HEAD CAP SCREW
2
4
RD33338
FIXED RATCHET WHEEL
1
5
18Y3008
POWERBOR COOLANT BRACKET
1
6
W18XC209
M5 X 12 CAPHEAD SCREW
2
7
W18XC723
GLAND AL16/M16/A
2
8
18Y177
CONDUIT ASSEMBLY
1
9
W18Y150
MAIN BODY CASTING
1
10
W18XC612
LASER PROFILE
1
11
W18XC345
SHIM STRIP 379MM X 11MM X 0.7MM
1
12
W18XC502
20 X 20 X 15 BUSH
2
13
W18XC614
PB100 PINION
1
14
W18Y156
LARGE HANDLE & KNOB ASSEMBLY
3
15
W18XC525
PANEL SCREWS M3 X 10
8
16
W18XC220
M5 X 25 GRUB SCREW
7
17
W18XC219
M5 STEEL NUT
7
18
18Y3017/CS
CONTROL PANEL ASSEMBLY 110V
1
18
18Y3018/CS
CONTROL PANEL ASSEMBLY 230V
1
19
W18XC613
BRASS GUIDE
2
20
W18XC201
M6 X 20 CAPHEAD SCREW
3
21
18Y3006
NOSE BRACKET
1
22
W18XC201
M6 X 20 CAPHEAD SCREW
4
23
W18Y102
NO.3 MT ARBOR ASSEMBLY
1
24
RDA3032
GUARD SUPPORT
1
25
W18XC214
M6 SCHNORR WASHER
2
26
RD4347
M5 X 15 C/SNK SKT HEAD SCREW
2
27
18Y3002
SLIDE CHANNEL
1
28
RDA4021
M4 X 14 BUTTON HEAD SCREW
2
29
18Y3003
GUARD
1
30
W18XC717
DOVETAIL SLIDE
1
31
W18XC212
M6 X 10 CAPHEAD SCREW
1
32
W18XC625
LARGE RACK
1
33
W18Y135
MAGNET BASE ASSEMBLY
1
34
W18XC1083
PB100E FRV FABRICATED SIDE BRACKET
1
35
W18XC6231
SIDE BRACKET
1
36
18X722
SPEED POTENTIOMETER (100K/C4)
1
37
18X730
POWER / POTENTIOMETER (220R/W2)
1
38
18X731
SPEED / POWER CONTROL WHEEL
2
39
W18XC723
GLAND AL16/M16/A
1

PB50 Low Profile Manual Original instructions 2019
13
40
W18XC1082
SPEED CONTROL GRP MOULDED HOUSING
1
41
18X5620
D5/25 TIP SCREW
4
42
W18XC532
D RING STRAP
1
45
W18XC227
M6 STEEL WASHER
4
46
W18XC202
M6 X 25 CAP HEAD SCREW
4
47
W18XC1025
PB100E REAR PANEL
1
49
W18XC221
M5 X 16 SOCKET CAP SCREW
1
50
W18XC524
PINION END CAP
1
51
W18XC239
M4 INT. S/PROOF WASHER
1
52
W18XC240
M4X20 CSK SLOT MC SCREW
1
53
W18XC430
CABLE GLAND, SPIRAL TAIL, M16
1
54
W18Y181
LEAD & PLUG ASSEMBLY 110V
1
W18XC503
MAINS CABLE UK PLUG 230V
1
W18XC503/EU
MAINS CABLE EURO PLUG 230V
1
W18XC503/AU
MAINS CABLE AUSTRALIAN PLUG 230V
1

PB50 Low Profile Manual Original instructions 2019
14
14) MOTOR BREAK DOWN
Item No. Part Number Description Item No. Part Number Description
1 18ZJ01 ARMATURE - 110V 74329100 42 18ZD42 WASHER 71540517
1a 18ZJ01A ARMATURE - 230V 74326100 43 18ZD43 DEEP GROOVE BEARING 6205-2RS
2 18ZJ02 FIELD COIL - 110V 74329150 44 18ZD44 INT CIRCLIP 47x1.75
2a 18ZJ02A FIELD COIL - 230V 74326150 45 18ZD45 DEEP GROOVE BEARING 6006-2RS
3 18ZJ03 MOTOR HOUSING 80900042 46 18ZD46 WASHER 71540426
4 18ZJ04 AIR GUIDE RING 71540144 47 18ZD47 INT CIRCLIP 55x2
5 18ZD05 BRUSH HOLDER 80201199 48 18ZE63 INTERMEDIATE SHAFT 1 71540490
7 18ZJ07 PAIR BRUSHES (110V) 80700040 49 18ZD49 CLUTCH GEAR 74326550
7 18ZD07 PAIR BRUSHES (230V) 80700021 50 18ZD50 CLUTCH HALF 71540560
8 18ZJ08 WASHER 80200998 51 18ZD54 PRESSURE WASHER 71540607
9 18ZD09 B4 SPRING WASHER 80201385 52 18ZJ52 KEY 5 x 5 x 10 80200600
10 18ZD10 CM4 x 12 SCREW 80201180 53 18ZD71 PRESSURE WASHER 71540606
11 18ZD11 DEEP GROOVE BEARING 6000-2Z 54 18ZE48 WASHER 12 / 18 x 0.5 80200503
12 18ZJ12 RING MAGNET 80701004 55 18ZD55 EXTERNAL CIRCLIP 80201361
13 18ZJ13 BEARING CAP 83000031 56 18ZD56 DISHED WASHER 29/12.2x1.0 80200713
14 18ZD14 CIRCUIT BOARD - 110V 80601138 57 18ZJ57 GEAR COUPLING ASSY 7454C493
14a 18ZD14A CIRCUIT BOARD - 230V 80601137 58 18ZE67 INTERMEDIATE SHAFT 2 71540500
16 18ZJ16 PCB SCREW HC 4.2 x 9.5 80201269 59 18ZD59 KEY A5 x 5 x 10 80200602
17 18ZD17 MOTOR HOUSING CAP 80900189 60 18ZE51 GEAR CLUSTER 71540440
18 18ZD18 CAP SCREW HC 4.8 x 45 80201267 61 18ZE61 GEAR SELECTOR 71540520
31 18ZJ31 GEARBOX END SHIELD 7154C610 62 18ZJ62 GEAR SELECTOR ASSY (GREEN) 7154A545
32 18ZD32 INT CIRCLIP 28 x 1.2 80201333 63 18ZE58 INTERMEDIATE SHAFT 3 71540510
33 18ZD33 DEEP GROOVE BEARING 6001-2RS 64 18ZE57 GEAR CLUSTER 2 71540450
34 18ZD34 EXT CIRCLIP 11 x 1 80201320 65 18ZJ65 WORK SPINDLE 74527420
35 18ZD35 HOUSING SCREW HC 5.5 X 38 80201292 66 18ZD66 SPINDLE GEAR 71540430
36 18ZD36 NEEDLE BEARING HK0810 67 18ZJ67 WASHER 25 X 0.1 80200512
37 18ZJ37 GEAR BOX SEAL 82000509 68 18ZJ68 KEY B6 x 6 x 20 80200606
38 18ZD38 PIN 80200280 69 18ZJ69 EXTERNAL CIRCLIP 24 x 1.2 80201326
39 18ZJ39 GEAR BOX HOUSING (BLACK) 7154C400 72 18ZE08 GREASE BARRIER 80900110
40 18ZD40 DEEP GROOVE BEARING 6000 76 18ZE52 KEY A6 x 6 x 40 80200608
41 18ZD41 NEEDLE BEARING RNA 4900 77 18ZE24 GEAR SELECTOR 2 71540530

PB50 Low Profile Manual Original instructions 2019
15
15)CONTROL PANEL AND PARTS LIST
No.
Part Number
Description
Qty
1
W18XC656
MOTOR SWITCH 110V
1
1
W18XC657
MOTOR SWITCH 230V
1
2
W18XC456
MAGNET SWITCH
1
3+ 9
W18XC511
FUSE HOLDER
1
4
W18XC650
FWD/REV SWITCH
1
5
W18XC512
FUSE
1
6
W18XC262
M3 X 12 POZI PAN SCREWS
4
7
W18XC922
FACIA PLATE
1
8
W18XC1085
M5 X 20 BUTTON HEAD SCREW
1
10
W18XC515
SILICON BRIDGE RECT.
1
11
W18XC219
M5 STEEL NUT
1

PB50 Low Profile Manual Original instructions 2019
16
17) MAINTENANCE
In order to ‘get the best life’ out of your Powerbor machine always keep it in good working
order.
A number of items must always be checked on Powerbor machines.
Always before starting any job make sure the machine is in good working order and that there
are no damaged or loose parts. Any loose parts must be tightened.
Before proceeding with any maintenance work be certain that the power supply is
disconnected.
Description
Every operation
1 week
1 Month
Visual check of
machine for damage
X
Operation of machine
X
Check brush wear
X
Check magnetic base
X
Check grease
X
Check armature
X
Visually check the machine for damage.
The machine must be checked before operation for any signs of damage that will affect the
operation of the machine. Particular notice must be taken to the mains cable, if the machine
appears to be damaged it should not be used, failure to do so may cause injury or death.
Check operation of the machine.
The machines operation must be checked to ensure that all components are working correctly.
Machine Brushes - should be checked to make sure there is no abnormal wear present (this
should be checked at least once a week if used frequently). If the brush has worn more than 2/3
the original length the brushes should be changed. Failure to do so may cause damage to the
machine.
Magnetic base –before every operation the magnetic base should be checked to make sure
that the base is flat and there is no damage present. An uneven magnet base will cause the
magnet not to hold as efficiently and may cause injury to the operator.
Check machines grease.
The gearbox grease should be checked once a month to ensure all moving components are
covered to prevent wear. The grease should be changed at least once a year to ensure you gain
the best from your machine.
Check Armature of the machine.
This should be checked at least once a month to check that there are no visual signs of damage
to the body or to the commutator. Some signs of wear will be seen on the commutator over a
period of time, but this is normal (this is the part that comes into contact with the brushes)
however, if there are any signs of abnormal damage the part should be replaced.

PB50 Low Profile Manual Original instructions 2019
17
18) TROUBLE SHOOTING
Magnet and motor do not function
- The magnet switch is not connected to the power supply
- Damaged or defective wiring
- Defective magnet switch
- Defective control unit
- Defective power supply
Magnet does function, the motor does not
- Damaged or defective wiring
- Carbon brushes are stuck or worn out
- Defective magnet switch
- Defective on / off switch
- Defective control unit
- Defective armature and/or field
Magnet does not function, the motor does
- Defective magnet
- Defective control unit
Hole cutters break quickly, holes are bigger
than the hole cutter
- Play in the guide
- Bent spindle
- Shaft extending from the motor is bent
- Pilot bent
Motor running roughly and/or seizing up
- Bent spindle
- Shaft extending from the motor is bent
- Triangular guide not mounted straight
Motor making a rattling sound
- Gear ring (bottom of the armature) worn out
- Gear(s) worn out
- No grease in gear box
Motor humming, big sparks and motor has no
force
- Armature damaged
- Field burned
- Carbon brushes worn out
Motor does not start or fails.
- Damaged or defective wiring
- Damage to armature or field coil
- Damaged or defective brushes
Insufficient magnetic force
- Damaged or defective wiring
- Bottom of magnet not clean and dry
- Bottom of magnet not flat
- Work piece is not bare metal
- Work piece is not flat
- Work piece is too thin less than 10mm
- Defective control unit
- Defective magnet
Frame under voltage
- Damaged / defective wiring
- Defective magnet
- Motor seriously dirty
Fuse blows when magnet switch is turned on
- Damaged or defective wiring
- Wrong value fuse
- Defective magnet switch
- Defective control unit
- Defective magnet
Fuse blows when motor is started up
- Damaged or defective wiring
- Motor running roughly
- Defective armature and / or field
- Carbon brushes worn out
- Defective control unit
Rotation system free stroke too long
- Loose or defective gear-rack
- Defective rotation system

PB50 Low Profile Manual Original instructions 2019
18
19) CUTTER SELECTION
Material
Material Hardness
Cutter
Mild and free cutting steels
<700N/mm²
M2
Mild and free cutting steels
<850N/mm²
M42
Steel angle and joists
<700N/mm²
M2
Steel angle and joists
<850N/mm²
M42
Plate and sheet steel
<700N/mm²
M2
Plate and sheet steel
<850N/mm²
M42
Aluminium
<750Nmm²
M2
Aluminium
<850N/mm²
M42
Brass
<700N/mm²
M2
Brass
<850N/mm²
M42
Cast iron
<700N/mm²
M2
Cast iron
<850N/mm²
M42
Stainless steel
<700N/mm²
M2
Stainless steel
<850N/mm²
M42
Stainless steel
>850N/mm²
TCT
Rail track
>850N/mm²
M42
Tool steel
>850N/mm²
TCT
Die Steel
>850N/mm²
TCT

PB50 Low Profile Manual Original instructions 2019
19
20) WARRANTY AND CE STATEMENTS
Powerbor™warrants its machines to be free from faulty materials, under normal usage of machines, for a
period of 12 months from initial date of purchase. All other parts (excluding cutters) are under warranty for
90 days, provided that the warranty registration card (or online registration) has been completed and
returned to Powerbor™or its designated distributor within a period of (30) days from the purchase date.
Failure to do so will void the warranty. If the stated is adhered to Powerbor™ will repair or replace (at its
option) without charge any faulty items returned.
This Warranty does not cover:
1. Components that are subject to natural wear and tear caused by the use not in accordance with the
operators instructions
2. Defects in the tool caused by non-compliance with the operating instructions, improper use, abnormal
environment conditions, inappropriate operating conditions overload or insufficient servicing or
maintenance.
3. Defects caused by using accessories, components or spare parts other than original Powerbor™parts.
4. Tools to which changes or additions have been made.
5. Electrical components are subject to manufacturer’s warranty.
The warranty claim must be logged within the warranty period. This requires the submission or sending of
the complete tool in question with the original sales receipt which must indicate the purchase date of the
product. A complaint form must also be submitted prior to the return.
All goods returned defective must be returned pre-paid to Powerbor™, in no event shall Powerbor® be
liable for subsequent direct, or indirect loss or damage.
THIS WARRANTY IS IN LIEU OF ANY OTHER WARRANTY, (EXPRESSED OR IMPLIED) INCLUDING ANY
WARRANTY OF MERCHANTABLITY OR FITNESS FOR A PARTICULAR PURPOSE. POWERBOR™RESERVE THE
RIGHT TO MAKE IMPROVEMENTS AND MODIFICATIONS TO DESIGN WITHOUT PRIOR NOTICE
Known and Trusted Worldwide for Quality, Performance and Reliability
