Powerplus POWX1710 User manual

POWX1710 EN
Copyright © 2022 VARO P a g e | 1www.varo.com
1APPLIANCE .....................................................................................2
2DESCRIPTION (FIG. A) ...................................................................2
3PACKAGE CONTENT LIST.............................................................2
4SYMBOLS ........................................................................................3
5GENERAL POWER TOOL SAFETY WARNINGS ..........................3
5.1 Work area ................................................................................................................3
5.2 Electrical safety.......................................................................................................3
5.3 Personal safety .......................................................................................................3
5.4 Power tool use and care.........................................................................................4
5.5 Service.....................................................................................................................4
6ADDITIONAL SAFETY INSTRUCTIONS ........................................4
7OPERATION.....................................................................................5
7.1 Charging the battery (Fig. A)..................................................................................5
7.2 Connecting the air pump (Fig. A)...........................................................................6
7.3 Setting up and starting the pump (Fig. A & B)......................................................6
8CLEANING AND MAINTENANCE...................................................6
8.1 Cleaning...................................................................................................................6
8.2Maintenance............................................................................................................6
9TECHNICAL DATA ..........................................................................7
10 NOISE...............................................................................................7
11 STORAGE ........................................................................................7
12 WARRANTY.....................................................................................8
13 ENVIRONMENT ...............................................................................8
14 DECLARATION OF CONFORMITY ................................................9

POWX1710 EN
Copyright © 2022 VARO P a g e | 2www.varo.com
AIR PRESSURE PUMP 8V
POWX1710
1 APPLIANCE
The appliance is intended for inflating car and bicycle tires, and inflatable items for
games, sport and leisure, but not for pumping up inflatable items with a large
volume, such as inflatable boats and very large air beds.
The appliance is not intended for professional use.
WARNING! Read this manual and general safety instructions carefully
before using the appliance, for your own safety. Your power tool should
only be passed on together with these instructions.
2 DESCRIPTION (FIG. A)
1. Air hose
2. Air hose connector
3. Power switch
4. Display
5. Keyboard
6. Charging indicator
7. LED light
8. USB C connector
9. USB C cable
10. Ball adapter
11. Inflatable toy adapter
12. Inflatable boat adapter
13. Bicycle adapter
Display & keyboard description (FIG. B)
14. Pressure
15. Pressure unit
16. Mode selection
17. Battery level
18. Increase pressure
19. Decrease pressure
20. LED light key
21. Multi function key
22. Mode key
3 PACKAGE CONTENT LIST
▪Remove all packing materials
▪Remove remaining packaging and transit supports (if existing)
▪Check the completeness of the packing content
▪Check the appliance, the power cord, the power plug and all accessories for transportation
damages.
▪Keep the packaging materials as far as possible till the end of the warranty period.
Dispose it into your local waste disposal system afterwards.
WARNING Packing materials are no toys! Children must not play with
plastic bags! Danger of suffocation!
1 Air pressure pump
1 Air hose
1 USB C cable
4 adapters
1 Manual
1 Carrying bag
When parts are missing or damaged, please contact your dealer.

POWX1710 EN
Copyright © 2022 VARO P a g e | 3www.varo.com
4 SYMBOLS
In this manual and/or on the machine the following symbols are used:
Warning / Danger!
Read manual before use.
In accordance with essential applicable safety standards of European
directives.
5 GENERAL POWER TOOL SAFETY WARNINGS
Read all safety warnings and all instructions. Failure to follow all warnings and instructions
may result in electric shock, fire and/or serious injury. Save all warnings and instructions for
future reference. The term "power tool" in the warnings refers to your mains operated (corded)
power tool or battery operated (cordless) power tool.
5.1 Work area
▪Keep work area clean and well lit. Cluttered and dark areas invite accidents.
▪Do not operate power tools in explosive atmospheres, such as in the presence of
flammable liquids, gases or dust. Power tools create sparks which may ignite the dust or
fumes.
▪Keep children and bystanders away while operating a power tool. Distractions can cause
you to lose control.
5.2 Electrical safety
Always check that the power supply corresponds to the voltage on the
rating plate.
▪Power tool plugs must match the outlet. Never modify the plug in any way. Do not use
any adapter plugs with earthed (grounded) power tools. Unmodified plugs and matching
outlets will reduce risk of electric shock.
▪Avoid body contact with earthed or grounded surfaces such as pipes, radiators, ranges
and refrigerators. There is an increased risk of electric shock if your body is earthed or
grounded.
▪Do not expose power tools to rain or wet conditions. Water entering a power tool will
increase the risk of electric shock.
▪Do not abuse the cord. Never use the cord for carrying, pulling or unplugging the power
tool. Keep cord away from heat, oil, sharp edges or moving parts. Damaged or entangled
cords increase the risk of electric shock.
▪When operating a power tool outdoors, use an extension cord suitable for outdoor use.
Use of a cord suitable for outdoor use reduces the risk of electric shock.
▪If operating a power tool in a damp location is unavoidable, use a residual current device
(RCD) protected supply. Use of an RCD reduces the risk of electric shock.
5.3 Personal safety
▪Stay alert, watch what you are doing and use common sense when operating a power
tool. Do not use a power tool while you are tired or under the influence of drugs, alcohol or
medication. A moment of inattention while operating power tools may result in serious
personal injury.

POWX1710 EN
Copyright © 2022 VARO P a g e | 4www.varo.com
▪Use safety equipment. Always wear eye protection. Safety equipment such as dust mask,
non-skid safety shoes, hard hat, or hearing protection used whenever conditions require
will reduce personal injuries.
▪Avoid accidental starting. Ensure the switch is in the off position before plugging in.
Carrying power tools with your finger on the switch or plugging in power tools that have
the switch on invites accidents.
▪Remove any adjusting key or wrench before turning the power tool on. A wrench or a key
left attached to a rotating part of the power tool may result in personal injury.
▪Do not overreach. Keep proper footing and balance at all times. This enables better
control of the power tool in unexpected situations.
▪Dress properly. Do not wear loose clothing or jewellery. Keep your hair, clothing and
gloves away from moving parts. Loose clothes, jewellery or long hair can be caught in
moving parts.
▪If devices are provided for the connection of dust extraction and collection facilities,
ensure these are connected and properly used. Use of these devices can reduce dust
related hazards.
5.4 Power tool use and care
▪Do not force the power tool. Use the correct power tool for your application. The correct
power tool will do the job better and safer at the rate for which it was designed.
▪Do not use the power tool if the switch does not turn it on and off. Any power tool that
cannot be controlled with the switch is dangerous and must be repaired.
▪Disconnect the plug from the power source before making any adjustments, changing
accessories, or storing power tools. Such preventive safety measures reduce the risk of
starting the power tool accidentally.
▪Store idle power tools out of the reach of children and do not allow persons unfamiliar with
the power tool or these instructions to operate the power tool. Power tools are dangerous
in the hands of untrained users.
▪Maintain power tools. Check for misalignment or sticking of moving parts, breakage of
parts and any other condition that may affect the power tool’s operation. If damaged, have
the power tool repaired before use. Many accidents are caused by poorly maintained
power tools.
▪Keep cutting tools sharp and clean. Properly maintained cutting tools with sharp cutting
edges are less likely to stick and are easier to control.
▪Use the power tool, accessories and tool bits etc., in accordance with these instructions
and in the manner intended for the particular type of power tool, taking into account the
working conditions and the work to be performed. Use of the power tool for operations
different from intended could lead to a hazardous situation.
5.5 Service
▪Have your power tool serviced by a qualified repair person using only identical
replacement parts. This will ensure that the safety of the power tool is maintained.
6 ADDITIONAL SAFETY INSTRUCTIONS
▪Know your inflator. Read operator’s manual carefully.
▪Learn its applications and limitations, as well as the specific potential hazards related to
this tool. Following this rule will reduce the risk of electric shock, fire, or serious injury.
▪Risk of bursting. Do not operate inflator to result in output pressure greater than marked
maximum pressure of item to be inflated. Do not use at pressure greater than 8 Bar.
▪To reduce the risk of electric shock, do not expose to rain. Store indoors.
▪Inspect unit for cracks, pin holes, or other imperfections that could cause inflator to
become unsafe.
▪Never cut or drill holes in the inflator.
▪Make sure the hose is free of obstructions or snags.

POWX1710 EN
Copyright © 2022 VARO P a g e | 5www.varo.com
▪Entangled or snarled hoses can cause loss of balance or footing and may become
damaged.
▪Use the inflator only for its intended use. Do not alter or modify the unit from the original
design or function.
▪Always be aware that misuse and improper handling of this inflator can cause injury to
yourself and others.
▪Never leave an inflator unattended with the air hose attached to the item being inflated.
▪Do not continue to use a inflator or hose that leaks air or does not function properly.
▪Always disconnect the air supply and power supply before making adjustments, servicing
an inflator, or when an inflator is not in use.
▪Do not attempt to pull or carry the inflator by the hoses.
▪Always follow all safety rules recommended by the manufacturer of your inflator, in
addition to all safety rules for the inflator. Following this rule will reduce the risk of serious
personal injury.
▪Household use only.
▪Do not use inflator as a breathing device.
▪Never direct a jet of compressed air toward people or animals. Take care not to blow dust
and dirt towards yourself or others. Following this rule will reduce the risk of serious injury.
▪Protect your lungs. Wear a face or dust mask if the operation is dusty. Following this rule
will reduce the risk of serious personal injury.
▪Do not use this inflator to spray chemicals. Your lungs can be damaged by inhaling toxic
fumes.
▪Check damaged parts. Before further use of the inflator or air tool, a guard or other part
that is damaged should be carefully checked to determine that it will operate properly and
perform its intended function.
▪Check for alignment of moving parts, binding of moving parts, breakage of parts,
mounting, and any other conditions that may affect its operation. A guard or other part that
is damaged should be properly repaired or replaced by an authorized service center.
Following this rule will reduce the risk of shock, fire, or serious injury.
▪Inspect tool cords periodically and, if damaged, have repaired at your nearest Authorized
Service Center.
▪Constantly stay aware of cord location. Following this rule will reduce the risk of electric
shock or fire.
▪Risk of bursting. Carefully monitor objects during inflation.
▪To reduce the risk of over inflation, use a reliable pressure gauge periodically during
inflation. The pressure guage on the inflator is for reference only and is therefore not
binding for exact values.
▪Never leave the inflator unattended during inflation.
▪Allow pump to cool for five (5) minutes after each five (5) minutes of continuous use.
Never block the inflating or deflating outlets while operating.
▪Save these instructions. Refer to them frequently and use them to instruct others who may
use this inflator.
▪If you loan someone this inflator, loan them these instructions also.
7 OPERATION
7.1 Charging the battery (Fig. A)
▪When the battery is almost depleted the battery logo (4) will start flashing.
▪Turn off the pump using the power switch (3).
▪Connect the USB C cable (9) connector to the USB C connector (8) of the pump.
▪Connect the regular USB cable (9) connector to any powered USB outlet, for example a
USB adapter, power bank, laptop etc.
▪The charging indicator (6) will light up red, when the battery is fully charged this indicator
will light up green.

POWX1710 EN
Copyright © 2022 VARO P a g e | 6www.varo.com
▪Disconnect the USB cable (9).
7.2 Connecting the air pump (Fig. A)
▪Make sure the battery is sufficiently charged.
▪Make sure the air hose (1) is screwed securely in to the top left side connector of the
pump. This is the largest of the two connectors (see figure A).
▪The small air hose connector (2) should be screwed in to right hand side of the pump for
storage and transport. Unscrew the air hose connector (2) for operation.
▪Look for the correct type of adapter according to your application. (consult Fig. A and
chapter 2 “DESCRIPTION”, the adapter types and applications are listed 10 to 13)
▪NOTE : the air hose connector (2) can be used for cars, motorcycles and some bicycles
directly without the use of an adapter.
▪Turn on the pump with the power switch (3). The display (4) will light up.
▪Screw or insert the air hose connector (2) to the nipple of your application.
7.3 Setting up and starting the pump (Fig. A & B)
▪Hold the “M” key (8) for 3 seconds, repeat until the desired measuring unit :
▪Bar - KPA - PSI - Kg/cm² is set as shown on the display.
▪It is possible to choose from 4 preset pressure values : car –motorcycle –bicycle –ball.
Press the preset key (9) until the corresponding logo is shown on the display :
▪Alternatively you can set or adjust the required pressure for your application by pressing
the “+” (5) and “-“ (6) keys.
▪Press the “M” key (8) to start inflation.
▪The pump will stop automatically at the set pressure, you can also stop manually by
pressing “M” key (8).
▪Turn off the pump with the power switch (3).
NOTE: When inflating items of 10 PSI or less, inflate in short bursts and
check after each burst by feel or with a calibrated measuring device to
determine accurate pressure.
NOTE: Pressure required for most sports balls is too low for accurate
reading on tool gauge.
8 CLEANING AND MAINTENANCE
8.1 Cleaning
▪Keep the ventilation slots of the machine clean to prevent overheating of the engine.
▪Regularly clean the machine housing with a soft cloth, preferably after each use.
▪Keep the ventilation slots free from dust and dirt.
▪If the dirt does not come off use a soft cloth moistened with soapy water.
Never use solvents such as petrol, alcohol, ammonia water, etc. These
solvents may damage the plastic parts.
8.2 Maintenance
Our machines have been designed to operate over a long period of time with a minimum of
maintenance. Continuous satisfactory operation depends upon proper machine care and
regular cleaning.

POWX1710 EN
Copyright © 2022 VARO P a g e | 7www.varo.com
9 TECHNICAL DATA
POWX1710
Motor voltage
8 V
battery
2 x 2000mAh
Max. Pressure
10,3 bar
Weight (including battery )
385 gr
Rated charging voltage
5 V
Rated voltage of chargeable battery
8 V
10 NOISE
Noise emission values measured according to relevant standard. (K=3)
Acoustic pressure level LpA
76 dB(A)
Acoustic power level LwA
83 dB(A)
ATTENTION! Wear hearing protection when sound pressure is over 85
dB(A).
11 STORAGE
▪Thoroughly clean the whole machine and its accessories.
▪Store it out of the reach of children, in a stable and secure position, in a cool and dry
place, avoid too high and too low temperatures.
▪Protect it from exposure to direct sunlight. Keep it in the dark, if possible.
▪Don’t keep it in plastic bags to avoid humidity build-up.

POWX1710 EN
Copyright © 2022 VARO P a g e | 8www.varo.com
12 WARRANTY
▪This product is warranted as provided by law for a 36 -month period effective from the
date of purchase by the first user.
▪This warranty covers all material or production flaws excluding: batteries, chargers,
defective parts subject to normal wear & tear such as bearings, brushes, cables, and
plugs, or accessories such as drills, drill bits, saw blades, etc. ; damage or defects
resulting from maltreatment, accidents or alterations; nor the cost of transportation.
▪Damage and/or defects resulting from inappropriate use also do not fall under the
warranty provisions.
▪We also disclaim all liability for any bodily injury resulting from inappropriate use of the
tool.
▪Repairs may only be carried out by an authorised customer service centre for Powerplus
tools.
▪You can always obtain more information at the number 00 32 3 292 92 90.
▪Any transportation costs shall always be borne by the customer, unless agreed otherwise
in writing.
▪At the same time, no claim can be made on the warranty if the damage of the device is the
result of negligent maintenance or overload.
▪Definitely excluded from the warranty is damage resulting from fluid permeation, excessive
dust penetration, intentional damage (on purpose or by gross carelessness), inappropriate
usage (use for purposes for which the device is not suitable), incompetent usage (e.g. not
following the instructions given in the manual), inexpert assembly, lightning strike,
erroneus net voltage. This list is not exhaustive.
▪Acceptance of claims under warranty can never lead to the prolongation of the warranty
period nor commencement of a new warranty period in case of a device replacement.
▪Devices or parts which are replaced under the warranty therefore remain the property of
Varo NV.
▪We reserve the right to reject a claim whenever the purchase cannot be verified or when it
is clear that the product has not been properly maintained. (Clean ventilation slots, carbon
brushes serviced regularly, etc.).
▪Your purchase receipt must be kept as proof of date of purchase.
▪Your appliance must be returned undismantled to your dealer in an acceptably clean state,
(in its original blow-moulded case if applicable to the unit), accompanied by proof of
purchase.
13 ENVIRONMENT
Should your appliance need replacement after extended use, do not discard it
with the household rubbish but dispose of it in an environmentally safe way.
Waste produced by electrical machine items should not be handled like normal
household rubbish. Please recycle where recycle facilities exist. Check with your
Local Authority or retailer for recycling advice.
This product contains Li-ion. To preserve natural resources, please recycle or
dispose of batteries properly. Local, state or federal laws may prohibit disposal of
Li-ion batteries in ordinary trash. Consult your local waste authority for information
regarding available recycling and/or disposal options.

POWX1710 EN
Copyright © 2022 VARO P a g e | 9www.varo.com
14 DECLARATION OF CONFORMITY
VARO N.V. - Vic. Van Rompuy N.V Joseph Van Instraat 9 - BE2500 Lier - BELGIUM,
solely responsible declares that,
product: Air pressure pump
trade mark: POWERplus
model: POWX1710
is in conformity with the essential requirements and other relevant provisions of the applicable
European Directives, based on the application of European harmonized standards. Any
unauthorized modification of the apparatus voids this declaration.
European Directives (including, if applicable, their amendments up to the date of signature);
2011/65/EU
2006/42/EC
2014/30/EC
European harmonized standards (including, if applicable, their amendments up to the date of
signature);
EN62841-1 : 2015
EN1012-1 : 2010
EN55014-1 : 2017
EN55014-2 : 2015
Keeper of the Technical Documentation : Philippe Vankerkhove, VARO –Vic. Van Rompuy
N.V.
The undersigned acts on behalf of the company CEO,
Ludo Mertens
Regulatory Affairs –Compliance Manager
04/01/2022, Lier - Belgium
