PRIMARE
T23 DAB / FM Tuner
Service Manual

1. Schematics and Pcb.
2. Technical Specifications.
Confidential !
This document is not allowed to show for third part without written permission
from Primare Systems AB.
This document is subject to change without notice.
Author:
Bjorn Holmqvist
Primare Systems AB
[email protected]

DVD26FI1.job - Tue Dec 07 16:06:01 2004

T23 Performance Data
FM
Stereo tuner, 87.5-108Mhz
RDS decoding
Number of Presets: 40
Usable sensitivity: FM Mono 10dBuV
FM Stereo 20dBuV
DAB
Band III (174-240Mhz) and L (1452-1492Mhz).
Usable Sensitivity: 29dBuV band III
30dBuV band L
Number of Presets 10
Outputs / inputs
1 Line inputs (RCA)
1 75R SPDIF (RCA)
1 TOSlink
1 IR input
1 RS232 input
50R Antenna Input (F-connector) combined for DAB / FM.
