Prismasonic Cinomorph P-100R Manual

Anamorphic Lens
Cinomorph P-100R
INSTALLATION INSTRUCTIONS
Carefully remove and unwrap all the
contents of box. Referring to the parts
list, make sure you have everything
needed to proceed with the installation
of the lens. If any parts are missing,
contact Prismasonic immediately.
Inspect the lens to make sure there are
no shipping defects. If you notice a
problem with the lens itself, or the lens’
mechanical system, contact Prismasonic
immediately.
Parts list:
Lens Unit
Table Stand
Power Cord
Power Converter
Remote Controller
L-Wrench, 3 mm
L-Wrench, 4 mm
Instruction Manual
Bringing the lens into the use:
STEP 1
Lift the lens up and flip it upside down in a
stand. By using the L-wrench, 3 mm remove
the delivery lock screws of prisms from bottom
plate (Fig 1-a). After this carefully remove the
front element by releasing the four cap screws
(Fig 1-b). Put the front element in a safe place
waiting for the further use. After this remove the
bottom plate of housing by releasing the four
screws on the bottom plate (Fig 1-c).
STEP 2
Now carefully take off the plastic cover sheets
from both sides of both lenses (Fig 2). Remove
also the cover coats from both IR windows of
motor box.
Fig 1
b)
b)
c)
b)
b)
c)
c)
c)
a)
a)
Fig 2
Fig 3
STEP 3
Insert the bottom plate back to the housing and
prepare to affix the four screws (Fig 3) with L-
wrench, 3mm. Tighten the screws securely.
At this point, do not yet insert the front
element back to its place, since it has to be
unassembled while setting up the system.
Flip the lens back upright in a stand. Your lens is
now ready for the setting up!
Setup Instructions Anamorphic Lens
Cinomorph P-100R
A Picture to
Remember

Anamorphic Lens
Cinomorph P-100R
Setup Instructions Setup Instructions
Setting up the system:
STEP 4
Make sure the projector is turned on. It is helpful
to have a picture that fills the entire panel of 16:9
projector. With a 2.40:1 source material the
vertical expand is good to be performed to the
picture at this step. (Fig 4)
Now carefully adjust the focus of projector. Also
make sure the image is symmetrically in the
center of the 2.40:1 screen.
STEP 5
First move the prisms to the ‘pass’ mode using
the supplied remote controller until the prisms
stop. Carefully position the lens with a stand in
front of the projector, with the small opening
closest to the projector lens and the large
opening pointing towards the screen.
Now manually adjust the lens in a stand. Make
sure the entire beam fits centered within the
two lenses (Fig 5). Lower, raise and tilt the lens
until the desired height and angle is reached.
Make sure the image is now rectangular and still
symmetrically in the center of the screen.
NOTE: The optimum symmetry for the projected
picture can only be found by tilting the lens to the
direction of the beam
Fig 4
Fig 5
STEP 9
In case the friction based lens height (Fig 9-a) or
the tilt (Fig 9-b) adjusting mechanism become too
loose, it is possible to get them tightened with the
set screws of stand drums on both sides of lens.
Use the L-wrench, 4 mm for tightening the
screws.
You’re done. Enjoy your new 2.40:1 picture!
STEP 6
Using the remote control, press ‘wide’ until the
prisms stop again. The tuning of picture width can
be accomplished manually by adjusting the cap
screws inside the lens to match your screen
perfectly on both sides.
NOTE: Tuning is done with the cap screws to where the
prisms stop after turning the prisms to the ‘wide’
position (Fig 6)
Fig 6
rear view
front view
STEP 8
Take the front element, remove the cover sheets
and secure it to the lens body using the four
screws (Fig 8).
You slightly have to zoom in the picture after
front element installation. Also now adjust the
focus and picture in a ‘wide’ mode to achieve
the optimum settings, and note these settings
as for future reference.
Fig 8
Fig 9
a) b)
Only use optically safe lens cleaning solutions and a clean,
lint-free cloth certified for cleaning of lens materials. In
order to clean the optics from both sides, the bottom plate
can be temporarily removed.
Fig 7 rear view
front view
STEP 7
If the sides of picture are not opening/closing synchronously to each other when switching the modes, tune
the terminal screws to where the prisms stop after pressing the ‘pass’ button (Fig 7). Open the cap screw of
the prism which had a shorter travel, and close the cap screw of that prism, which had a longer travel until
both sides of picture are opening and closing synchronously to each other.
Cleaning the optics:
Maintenance:
Your Cinomorph lens was designed to require very minimal cleaning. It is best to only wipe the lens housing
with a clean, damp, soft cloth when needed.
