ProAudio MC 9010 iP User manual

MC 9010 iP
BEDIENUNGSANLEITUNG
USER MANUAL
Micro Music System

SAFETY PRECAUTIONS
1
HAZARD WARNING: TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK,
DO NOT EXPOSE THIS PRODUCT TO RAIN OR MOISTURE.
ESD Remark:
In case of malfunction due to electrostatic discharge just reset the product (reconnect
of power source may be required) to resume normal operation
WARNINGS
To reduce the risk of fire or electric shock, do
not expose this appliance to rain or moisture
EXPLANATION OF GRAPHIC SYMBOLS
This product contains a low-power laser emitter
CAUTIONRISK OF ELECTRIC SHOCK
DO NOT OPEN
WARNING: TO REDUCE THE RISK OF ELECTRIC
SHOCK. DO NOT REMOVE COVER. NO USER
SERVICEABLE PARTS INSIDE. REFER SERVICING
TO QUALIFIED SERVICE PERSONNEL.
The exclamation point within an equilateral
triangle is intended to alert the user to the
presence of important operating and
vaintenance ( servicing) instruction in the
lliterature accompanying the appliance.
The lightning flash with arrowhead symbol, with in
an equilateral triangle, is intended to alert user to
the presence of uninsulated “dangerous voltage”
within the product enclosure that may be of
sufficient magnitude to constitute a risk of electric
shock to persons.
CLASS 1 LASER PRODUCT CAUTION
INVISIBLE LASER RADIATION WHEN
OPEN AND INTERLOCK FAILED OR
DEFEATED. AVOIDDIRECT IXPOSURE
TO LASER BEAM
ENGLISH

SAFETY PRECAUTIONS
2
ENGLISH
IMPORTANT SAFETY PRECAUTIONS
To ensure safe, appropriate use of your
personal CD player, please follow the advice
below:
Location
xDo not use the product in extremely hot, cold,
dusty or damp conditions.
xPlace the product on a smooth, flat surface.
xEnsure that air is free to circulate through the
product. Do not use it in a poorly ventilated
place, cover it with a cloth or place it on
carpet.
Power supply
xBefore using the product, check that its rated
voltage is suitable for your mains supply.
Safety precautions
xWhen you plug in or unplug the power cord,
always hold the plug rather than the cable.
Pulling the cord could damage it and create a
hazard.
xAlways unplug the product from the mains if
you do not intend to use it for an extended
period.
xThe STANDBY button does not disconnect the
product from the mains power supply. To
disconnect the product from the power supply,
you must unplug the power cord.
xThis product should only be used in a
horizontal position.
xThe rating label is located at the bottom of the
cabinet.
xIf the power cord is damaged it has to be repla-
ced by manufacturer or a service centre or a
qualified person to avoid danger.
Condensation
xWater droplets or condensation may form
inside the CD player if it is left in a warm,
damp atmosphere.
xThe product may not operate correctly if
condensation forms inside it.
xLeave the product in a warm, dry room for 1 to
2 hours to allow the condensation to
evaporate.
In the event of a problem, unplug the power cord
and contact a qualified repair technician.
Warning: Ventilation
Your personal CD player has ventilation holes,
which should never be obstructed.
Liquid warning:
Never allow liquids to splash or drip onto the
product. Never place a liquid-filled container
(e.g. vase, jar, etc.) above it.
xThe apparatus shall not be exposed to drip-
ping or splashing liquids, no objects filled with
liquids, such as vases, shall be placed on
theapparatus
xThe mains plug is used as the disconnect
device and it shall remain readily operable.
To be completely disconnect the power input,
the mains plug of apparatus shall be
disconnected from the mains.
xThe apparatus will be use in open area
xThe ventilation should not be impeded by
covering the ventilation openings with items
such as newspaper, table-cloths, curtains etc
xNo open flame sources such as lighted
candles should be placed on the apparatus;
xAttention should be drawn to the
environmental aspects of battery disposal;
xOnly use the apparatus in moderate climates.

USING THE USB AND SD/MMC CARD
MAINTENANCE
3
1-2
4-5
6
7
10
11
12
12
13
14
8-9
ENGLISH

LOCATION OF CONTROLS
CAUTION
Usage of controls, adjustments, performance or procedures other than those specified herein may result
in hazardous radiation exposure. This unit should not be adjusted or repaired by anyone except a qualified
service person.
IMPORTANT
Since movement of the CD mechanism and the sensitive circuitry may cause interference to the radio
tuner nearby, switch this unit off while operating other radio devices.
PRECAUTIONS FOR USE
INSTALLATION
Unpack all parts and remove protective material. Do not connect the unit to the power outlet before
checking the voltage and before all other connections have been made. Do not cover any vents and
make sure that there is a space of several inches/centimeters around the unit for ventilation.
CONNECTION
1. Connect the power cord to AC outlet.
2. When you first plug the unit into the power outlet, the unit will go into standby mode.
3. Turn on the power and select CD function. If the LCD display is on with backlighting, it means the
power supply is normal and your system is ready to play music.
1. STANDBY BUTTON 2. EQ BUTTON3. REMOTE SENSOR4. SNOOZE BUTTON5. LCD DISPLAY 6. BUTTON
7. (ST/MO), PLAY/ PAUSE BUTTON
8. BUTTON
9. BAND/STOP BUTTON
10.PLAY MODE BUTTON11.MEMORY/CLOCK B UTTON12. DOCKING STATIONiPod
13.FOLDER -/PRE- BUT TON14.FOLDER +/PRE+ BUTTON15.CD DOOR 16.VOLUME UP/DOWN17.STEREO H EADPHONE JACK 18.ALARM2 BUTTON19.SD/MMC CARD SLOT20.ALARM1 BUTTON
21.USB INTERFACE
22.FUNCTION BUTTON23.AC CORD 24.FM ANTEN NA
4
1236795
11
4
12
10
13
8
14
15
161718192420212223
FM ANT.
ENGLISH

LOCATION OF CONTROLS
1. MUTE: Press to activate/ de-activate MUTE function.2. STANDBY: Press to turn power on or standby.3. FUNCTION: Switch to CD/TUNER/iPod/USB/SD mode.4. CARD: Press to select the CARD mode.5. PROG/ADJ: In CD or Tuner mode, press to set CD or
Tuner memory. In Standby mode, press to set clock.
6. FOLDER-/PRE-: In Mp3 mode, step down the album number; In tuner mode, step down the pre-set station; In iPod mode, back to the previous menu.7. FOLDER+/PRE+: In MP3 mode, step up the album number; In tuner mode, step up the pre-set station; In iPod mode, press to choose a menu item.8. MENU: Press to show the iPod menu.9. ENTER: In iPod mode, as a ENTER key.10. /-10 : In iPod menu, item moving downward; In CD mode , skip down the track by 10 multiple. 11. /+10: In iPod Menu, item moving upward; In CD mode, skip up the track by 10 multip le. 12. DBBS: Enable / Disable bass boost. 13. VOLUME -: Press to reduce the volume.14. TUNER: Press to select the TUNER mode.15. USB: Press to select the USB mode.16. CD: Press to select the CD mode.17. iPod: Press to select the iPod mode.18. ALARM2: Activate or deactivate Alarm 219. A LARM1: Activate or deactivate Alar m 120. PLAY/MODE: Select to different play mode(Repeat 1, Repeat all, RANDOM and INTR Mode).21. ST/MONO: Select to enable Stereo or in FM mode.22. ID3: In MP3 mode,show the ID3 tag of the track.23. SLEEP: Press to activate sleep function.24. SNOOZE: Pressed the Alarm will switch off for 6 minutes after which time it will sound again. 25. STOP/BAND: Press to stop the play in CD/USB/SD/iPod mode; AM/ FM band select in Tuner mode.26. PLAY/PAUSE : Press once to start playback. Press once agai n to stop the disc play temporarily.27. : In CD mode, press once to skip to the next track, press & hold for search forward; InTuner mode, press for stepping up of frequenc y.28. : In CD mode, pres s once to skip to previous track, press & hold for search backward; InTuner mode, press for stepping down of frequen cy.29. EQ: Press to select the presets EQ mode.30. VOLUME +: Press to increa se the volume. Remote Control HandsetSNOOZE131652146781011121315302928272625242394171819202122
FITTING THE REMOTE CONTROL BATTERIES
Open the battery compartment door and place two AAA size batteries
(not included) in the compartment following to the battery polarity
(+ and -) symbol marked on the door. Close the door until "click" shut.
5
ENGLISH
ŸźMono

CLOCK SETTING(can only be set during standby mode)
1. Press MEMORY/ CLOCK for 3 seconds, to enter clock setting. 2. Choose 12/24 HRS by pressing button, then press MEMORY/ CLOCK button.3. Press or button for HOUR setting, then press MEMORY/CLOCK button to store.4. Press or button for MINUTES setting now, and press MEMORY/CLOCK butto n to store.TIMER & ALARM SET TING1. Press AL ARM 1 on remote control to enter setup mode.2. Press FUNCTION butt on to select the desired wake up source (iPod, TUNER, CD, SD or USB).3. Press VOL - or VOL + buttons to set the volume level when reach the Alarm.4. Press or buttons to set the hours. Press “ALARM 1” to store.5. or buttons to set the minutes. Press “ALARM 1” to store.6. Switch the system to standby mode. When reac hed the pr e-set time, the selected source will pla y.7. ALARM 2 setup is same as ALARM 1.* onlycanwakebybuzzer.NOTE:•The ALARM se tting will be automaticallycancelledifnobuttonisbeingpressedformorethan 10 seconds. •If the selected source is CD and the disc is not a vailable wh en activated by timer, BUZZER will be selected automatically instead.DEACTIVATE THE ALARM FUNCTION•Press ALARM 1 or 2 button to deactivate 1 or 2 alarm set. “ALARM ? ” will disa ppear on the display. To activate the ALARM again with the pre-set time, press the “ALARM ?” but ton again.•To cancel active ALARM press the STANDBY/ON button on unit or remote, or ALARM 1 button on remote control.•ALARM 1 and 2 is same setting.PMALARM1
PMALARM1PMALARM1
6
SLEEPPMCD
SLEEPFUNCTION•Sleepmodewillbeactivatedonce“SLEEP”buttonispressedonremotehandset,bypressingoneatatimethesleeptimerwillchangeto90,60,30,15minutesandOFF.•Theunitwillswitchoffatthetimeyouhaveset.•YoucanpressSLEEPbuttontocheckthetimeoffwhenSLEEPfunctionwasactive.SNOOZEFUNCTIONPresstheSNOOZEbuttononremotecontrol,theAlarmwillswitchofffor6minutesafterwhichtimeitwillsoundagain.YoumaythenpressAlarmbuttononremotecontroltocancelorpresstheSNOOZEbuttonagainifyouwish.
ENGLISH
CLOCK TIMER & SLEEP
Then press
ALARM2

TUNERFM
MONO
MHz
PM
MANUAL TUNING1. Press “FUNCTION” button or “TUNER” butto n on remote control to enter TUNER mode, then press /BAND” button to select desired BAND ( AM or FM ).2. Tune to the desired station by pressing the or butto n.3. Adjust volume level by pressing VOL+/ -.AUTO TUNING1. Press “FUNCTION“ button to enter TUNER mode then press “ /BAND” button to select the desired BAND ( AM or FM ).2. Press and hold the or button for 1 - 2 seconds and then release.3. The unit will start seeking automatically and stop until a radio station is reached.4. Repeat step 2 & 3 until the desired radio station is being reached.5. Adjust volume level by pressing VOL+/-.PRESET STATIONS BY REMOTE HANDSETYou can store up to total of 20 radio stations in the memory (10-FM / 10-AM).1. Set to TUNER mode.2. Turn to the desired radio station by “MANUAL“ or “ AUTO “ tuning method.3. Press button PROG/ADJ to enable programming state. 4. Press “ “ button to select the desired station memory for storage.5. Press PROG/ADJ to confirm the setting.6. Repeat step 2 to 5 to store other stations.7. Press “PRE- or PRE+ “ b uttontore-loadthepres etst ationsinorder.8. To return normal tuner mode, leave keys free.FM & FM-STEREO RECEPTION Press the ST/MO button on remote handset to select “MONO “or “STEREO “reception mode. If selected mono “MONO”, the indicator will show on display.HINTS FOR BEST RECEPTION:-AM: the receiver has a built - in AM bar antenna. If AM reception is weak, slightly rotate or re-positioning of the unit will usually improve the AM reception.-FM: the receiver has an attached FM wire antenna at the rear unit. This wire should be fully unwound and extended at full length for best reception. RADIO
LISTENINGTORADIO
ENGLISH
buttonPRE- or PRE+

3) This player can support following model num ber i PodA.iPod mini (4G & 6G)
B.iPod & U2 iPod (20G)
C.4G iPod (40G)
D.iPod photo & Color U2 iPod (20G & 30G)
E.iPod photo (40G & 60G)
F.iPod with color display (60G)
G.iPod nano (2G & 4G)
H.5G iPod and U2 iPod with video (30G)
I.5G iPod with video (60G & 80G)
J.iPod nano (2G & 4G & 8G)
K.iPod nano (4G & 8G)
L.iPod Touch
4) Playing music through the unit speakers: Using the iPod Do ck, y ou can pla y mus ic from iPod through the unit speakers and operated with remote control.a)PlaceiPodintheDock.b)Usetheremotecontrollerorunittoplay iPod with following steps.you can remove the Dock adapterwith your fingemall by using this slotDock adapterConnector wellREMOTEUNITEnter main menuThe top and bottom chooseTo choose an itemPlay or pause a song.Change the volumeSkip to the next songStart a song over or play To go back to the previous menuPress the MENU buttonPress the /-10 or / +10 button, Press the ENTER buttonPress the play/pause ( ) buttonPress the “VOL+” or “VOL- “ buttonPress the ( ) buttonPress the ( ) button once to start a song over, press it twice to play the previous song.Press the MENU buttonN/AN/AFOLDER + VOL- or VOL -FOLDER-a previous song
ENGLISH
iPod PLAYER
PM
iPod
TousetheDockwithyouriPod:1.SelecttheFUNCTIONtoiPodmode.Fig12.RemovetheiPodcoverfromtheunit.3.InstalltheiPodDockAdapterintoDock,andthenputyouriPodintheDockontheunit.(Dockadapterisa iPodaccessoriesavailablese paratelyandfitswithyouriPodproduct).Note:1)AfterplacingtheiPodintheDock,thesystemwillautoplayyouriPod.AlliPodfunctionscanbeoperatedbyremotecontroller,pleasedon'ttrytousetheiPodcontrolsbecausetheiPodconnectormaybedamagedwhilethedockisconnectedwithyouriPod.2)TheiPodbatteryisstillchargingwhentheunitisunderPowerstandbymode.8
źŸ

If your iPod does have a docking connector you must first fit the correct iPod adaptor to the iPod bay. There are 11
adaptors supplied, each has an adaptor number printed on the underside.FINDING THE COR RECT IPOD ADAPTORRefer to the table of compatible iPod models in the next column and the correct adaptors to match them. Onc e you have located the correct adaptor for your iPod, press it gently in go the iPod bay before attempting to connect your iPod.NOTE: If you connect an iPod without fitting the cor rect adaptor, y ou may damage the iPod and your music system.LIST OF COMPATIBLE IPOD MODELS
IPod mini (4G & 6G) Use adaptor No. 3
IPod and U2 IPod (20G) Use adaptor No. 4
4G IPod (40G) Use adaptor No. 5
IPod photo & Colour U2 iPod (20G & 30G) Use adaptor No. 6
IPod photo (40G & 60G)/iPod with color display (60G) Use adaptor No. 7
IPod nano (2G & 4G) Use adaptor No. 8
5G iPod and U2 iPod with video (30G) Use adaptor No. 9
5G iPod with video (60G & 80G) Use adaptor No. 10
IPod nano (2G & 4G & 8G) Use adaptor No. 11
IPod nano (4G & 8G) Use adaptor No. 13
IPod Touch Use adaptor No. 14
RECHARGETHEIPODWhen the iPo d is connected to this unit, the battery will start cha rging.Fig 1: This icon will sho w when the battery is charging.Fig 2: This icon will show whe n the battery is full charged.Fig 1 Fig 2
CONNECTINGWITHYOURIPod
BeforeconnectinganiPod,youm ustfirstcheckifyouriPodhasa dockingconnectorasearl yiPodmodelsdonothaveoneandcannotbedockedtoyourunit.IfyouriPoddoeshavea dockingconnectoritwillbelocatedonthebuttonoftheiPodasshowninthediagram.Docking connectoriPod PLAYER
9
ENGLISH

PMMP3CDID3CDMP3
PM
LOADING AND PLAYING CD DISCS
1. Press “FUNCTION” or “CD” button on remote control to enter CD mode.2. Place a music disc with the printed side facing up inside the tray3. Close the CD door.4. Focus search is performing; the display will show the total number of tracks & playing time. See Fig 1
PLAY/ PAUSE ( ) MODE 1. Press the “ “ button to start playback, the first track will be played and the TRACK NO. will appear on the LCD display. 2. To interrupt, Press the “ “ button once, the current playing time will flash on the LCD display, press again to release & resume playback.STOP MODE1. If “ /BAND “ button is pressed during play or pause mode, CD play will go to stop mode.SKIP / SEARCH MODE ( SKIP UP / SKIP DOWN )1 .During play or pause mode, If button is pressed, it will go to next track and display the track NO. and remain in the PLAY or PAUSE mode.2 .During PLAY or PAUSE mode, if button is pressed, it will go back to the beginning of the track, original track NO. is display and remain the PLAY or PAUSE mode.3. After step 2, press button again will go to the previous track and remain the PLAY or PAUSE mode.Note: press and hold the or button to activate the search function.FOR MP3 DISC1. Press “ FOLDER -” or “ FOLDER + “ button to select the FOLDER NO.2. Press or button to select the track NO.Press -10 button to select previous
10 tracks; Press +10 button to select next 10 tracks.
3. When the desired track is being selected, press the “ “ button to start playback.Notice for CDR/CDRW MP3 users:Depending on the type of CD burner, on the disc brand, the burning speed and the MP3 compression level, some reading problems may occur.ID3-TAG (TITLE/ ARTIST/ ALBUM) FUNCTIONID3-TAG (TITLE/ARTIST/ ALBUM) will display atomically during playback if ID3 button is pressed on remote control. REMARK:-In that case of no name in the disc, “NO TAG “ or “ UN_ KNOWN” will be displayed.-The LCD display support English language only for MP3 format.
ENGLISH
CD PLAYER
CD PLAYER
10

PMCDMEMORYCDMP3PMINTROCDMP3PMRANDOMCDMP3REPEATPMCDMP3REPEATPMPMCDREPEAT
REQUIREMENT:-Bit rate: 32 kbps ~320kbps, Sampling rate: 32KHz, 44.1KHz and 48KHhz decode format.-The performance of playing MP3 disc is varied from the quality of recordi ng disc and the method of recording furthermore , the searching lead time for MP3 - CD is longer than normal CD due to difference format.PLAY-MODEEach press to switch the different play mode as follow:1.REPEATRepeat single or current track2.REPEATRepeat single folder (MP3 only)3.REPEATREPEAT ALL TREACK4.RANDOMRandom play, all tracks will be starting playback in random order automatically.5.INTROPreview playing, to play first sever al seconds of each track on the current disc.CD/MP3 PROGRAMMINGUp to 20 tracks can be programmed for disc play in any sequence. Before use, be sure to press the STOP button to stop the playing
1. Switch to CD mode.2. Press the “MEMORY/CLOCK“ bu tton, “MEMORY“ will appear on the LCD display and flash. Moreover, It will indicate progr am NO. and digits for track and Folder (MP3) NO. To be pro grammed. Fig 1.3. (MP3 only) Press Folder +/- button to select the desired folder and press MEMORY/ CLOCK to store the Folder NO. into memory.4. Select the desired track by pressing or buttons. Press the “MEMORY/ CLOCK“ button to store the track into memory. 5. Repeat steps 3 and 4 to ent er ad ditional tracks into the memory if necessary.6. When all the desired tracks have been programmed, press “ ” button to play the music in the order whi ch yo u have programmed.7. Press “ /BAND“ button to terminate pro grammed play. - To clear the programming press “ /BAND” button in twice or open the CD door.MUTE FUNCTION Press “MUTE“ button to temporarily shut off the sound from the speakers.Press “MUTE“ button again to cancel Mute and restore the sound. PRE-SET EQ FUNC TIONThis unit provides 5 differences sou nd mode to enhance your listening quality, you can select the desired effect by pressing the “EQ” button repeatedly to following sequence FLAT CLASSIC ROCK PO P JAZZ11
CD PLAYER
BASSFUNCTIONPress“DBBS”buttononremotecontroltoenhancethebassboost.
ENGLISH

MP3PM
USB
OPERATING MEMORY CARD 1. Press “FUNCTION” to sel ec in SD mode or “CARD” button on remote.2. Display will s how “CARD” .3. Slot in the memory card “SD/MMC only” with label facing up.4. Display will show tot al folders andtracknumbers.5. Press “ ” butto n to start playingmusic.6. You can press the “FOLDER+” or “FOLDER “ to sel ect t he folder. Press or to select the track.7. Press “ /BAND” button to stop playing.OPERATING USB DEVICE1. Press “FUNCTION” on unit to select in USB mode or “USB” button on remote control.2. Display will show "USB".3. Plug in your USB device into USB port.4. Display show the total foldersandtracknumbers.5. Press" " buttontostartmusicplaying.6. You can press the “FOLDER+” or “FOLDER“ to selec t the folder. Press or select the track.7. Press “ /BAND” but ton to stop playing.CARE AND MAINTENANCE
CARE OF THE COMPACT DISCTo remove a disc from its storage case, press down on the center of the case and lift the disc ou t, holding it carefully by the edges.Fingerprints and dust should be carefully wiped off the disc's recorded surface wit h a soft cloth. Unlike conventional records, compact discs have no grooves to collect dust and microsco pic d ebris, so gently wiping with a soft cloth sho uld r emove most particles. Wipe in a straight line from the inside to the outside of the disc. Small dust particles and ligh t stains will have absolutely no effect on reproduction quality.•••Clean the disc periodically with soft, lint - free, dry cloth. Never use detergents or abrasive cleaners to clean the disc. If necessary, use a CD cleaning kit. •Never write on or affix labels to the surface of compact discs.CARE OF THE CABINETIf the cabinet becomes dusty wipe it with a soft dry dust cloth. Do not use any wax, polish sprays, or abrasive cleaners on the cabinet.CAUTION
MP3PM
Never allow any water or other liquids to get inside the unit while cleaning.
CARD
12
ENGLISH
FLASH MEMORY / MAINTENANCE

TROUBLESHOOTING
If a fault occurs, first check the points listed below before taking the set for repair. Do not open the set as
there is a risk of electric shock.
Problem Cause Solution
No sound / power
Volume not adjusted Adjust the Volume
Connect the AC cord properly
Display does not function properly / No
reaction to operation of any of the controls Electrostatic discharge Switch off and unplug the set. Reconnect after a
few seconds
The CD skips tracks CD damaged or dirty Replace or clean CD
Program is active Quit program mode
No disc indication
No CD inserted Insert a CD, CD-R or CD-RW
CD badly scratched or dirty Replace or clean CD
Laser lens has steamed up Wait until lens has cleared
CD-R is blank or the disc is not finalized Use a finalized CD-R
CD Playback does not work CD badly scratched or dirty Replace or clean CD
Laser lens steamed up Wait until lens has adjusted to room temperature
USB / Memory card failure
USB / Memoy Card connecting error Unplug and reinsert memory card or USB stick
USB / Memory Card does not contain playable
files
Use a USB / Memory Card containing MP3 or
WMA files
Power cord not securely connected
ENGLISH
f this product should be defective, despite our high standard quality control,
please contact the service & support hotline.
The hotline is available Monday through Friday from 10am to 6pm at this number:
0180 5 - 22 17 84
¼0LQ*HUPDQ\RQO\n case your product needs to be sent to our service centre, please use the provided return sticker.
f the return sticker is missing, please contact the service & support hotline

SPECIFICATIONS
14
GENERAL
Power Supply: AC 230V~50Hz
Power consumption: 52 W
Dimensions of unit: 400(w) x 185(h) x 240(d) mm
Frequency range: AM 522 - 1622 kHz
FM 87,5 - 108 MHz
Antenna: FM: PIG TALL ANTENNA
AM: FERRITE BAR ANTENNA
Remote Control: 2 batteries x 1.5V ; LR03(batteries not supplied)
COMPACT DISC
Disc Drive Top Loading CD Player
Laser Type CLASS 1 LASER
Disc Compatibility CD-R / CD-RW
SPEAKER SYSTEM
Speaker 2.1 ch Speaker System
MP3 PLAYER
Format: ISO9660 / JOLIET
Bitrate: 8 - 320 kBit/s CBR/VBR
Sampling Rate: 32, 44 & 48 kHz
SPECIFICATIONS SUBJECT TO CHANGE WITHOUT NOTICE
ENGLISH
Disposal of old electrical appliances
Dispose of the packaging in the proper manner.
The European Directive 2002/96/EC on Waste Electrical and Electronic
Equipment (WEEE), requires that old household electrical appliances
must not be disposed of in the normal unsorted municipal waste stream.
Old appliances must be collected separately in order to optimise the
recovery and recycling of the materials they contain and reduce the
impact on human health and the environment.
The crossed out ‘wheeled bin’ symbol on the product reminds you of
your obligation, that when you dispose of the appliance it must be
collected separately.
Consumers should contact their local authority or retailer for information
concerning the correct disposal of their old appliance.

SICHERHEITSHINWEIS
15
EUTSCH
WARNUNG: ZUR VERMEIDUNG VONFEUER ODER ELEKTRISCHENSCHLA-
GES DAS GERÄT NIEMALS REGENODER FEUCHTIGKEIT AUSSETZEN.
Bei Fehlfunktion des Gerätes durch elektrostatische Entladungen kann ein Reset durchgeführt
werden. Dazu muß eventuell die Stromversorgung kurz unterbrochen werden.
WARNUNG
Zur Vermeidung von Feuer oder elektrischen Schlages,
das Gerät niemals Regen oder Feuchtigkeit aussetzen Erklärung der Warnsymbole
Dieses Gerät verwendet einen Klasse 1 Laser mit niedriger Strahlleistung

SICHERHEITSHINWEIS
16
EUTSCH
WICHTIGE SICHERHEITSHINWEISE
Wichtige Sicherheitshinweise
Zum sicheren Gebrauch Ihres Gerätes sollten sie
die folgenden Hinweise beachten:
Aufstellen und Gebrauch
xVerwenden Sie das Gerät nicht in Umgebungen
mit extremer Hitze oder Kälte oder in staubiger
oder feuchter Umgebung.
xStellen Sie das Gerät nur auf einer flachen,
ebenen Unterlage auf.
xStellen Sie sicher, daß ausreichende
Luftzirkulation vorhanden ist. Decken Sie die
Lüftungsöffnungen nicht ab, stellen Sie das
Gerät nicht auf weichen Untergrund.
Stromversorgung
xPrüfen Sie vor Gerbrauch des Gerätes ob die
vorhandene Stromversorgung mit der auf dem
Gerät angegebenen übereinstimmt.
Sichere Verwendung
xFassen Sie die Netzzuleitung beim Aus– oder
Einstecken immer nur am Stecker an, niemals
am Kabel ziehen. Ziehen am Kabel kann die
Zuleitung beschädigen.
xTrennen Sie das Gerät von der Netzsteckdose,
wenn das Gerät für längere Zeit nicht verwendet
wird.
xDer Ausschalter am Gerät trennt das Gerät
NICHT vom Netz. Um das Gerät komplett vom
Netz zu trennen, ziehen Sie bitte den Netz-
Stecker.
xVerwenden Sie das Gerät nur in aufrechter
Position.
xWenn das Netzkabel dieses Gerätes beschädigt
wird, muss es durch den Hersteller oder seinen
Kundendienst oder eine ähnlich qualifizierte
Person ersetzt werden, um Gefährdung zu ver-
meiden.
Kondensation
xIn warmer, feuchter Umgebung kann im Gerät
Kondensation entstehen.
xBei Kondensation im Gerät wird die Funktion
stark beeinträchtigt.
xDie Kondensation kann verdunsten, wenn das
Gerät für 1 bis 2 Stunden in einer warmen,
trockenen Umgebung plaziert wird.
Sollte ein Problem auftreten, Ziehen Sie den Netz-
stecker und setzen Sie sich mit dem Kundendienst
inVerbindung.
Belüftung
Dieses Gerät verfügt über Belüftungsöffnungen,
welche nicht abgedeckt werden dürfen.
Wichtige Sicherheitshinweise
xSetzen Sie das Gerät niemals Flüssigkeiten aus,
stellen Sie keine Flüssigkeitsbehälter, z.B.
Vasen auf das Gerät.
xDer Netzstecker dient dazu, das Gerät vom Netz
zu trennen und sollte immer frei zugänglich
sein.
xVerwenden Sie das Gerät nicht im Freien
xDie Luftzirkulation des Gerätes sollte nicht
durch Gegenstände behindert werden.
xStellen Sie keine Kerzen auf das Gerät.
xBeachten Sie die Umweltbestimmungen bei
der Entsorgung von Batterien.
xVerwenden Sie das Gerät nur in normaler
Umgebungstemperatur.

1
INHALT
SICHERHEITSHINWEISE………………………………………………………15 -16
BEDIENELEMENTE…………………………………………………………….18-19
UHREINSTELLUNG UND SCHLAFFUNKTION…………………………………….20
RADIO………………………………………………………………………. .21
iPOD PLAYER…………………………………………………………………22
CD PLAYER……………………………………………………………….…..24
KLANGEINSTELLUNG (SOUND CONTROL)………………………………………25
BENUTZUNG VON USB UND SD/MMC KARTE…………………………………...26
WARTUNG……………………………………………….….….….….….…...26
FEHLERBEHEBUNG……………………………………………….….….….…27
TECHNISCHE SPEZIFIKATION…………………………………….….….….…..28
EUTSCH

18
BEDIENELEMENTE
1. STANDBY TASTE
2. EQ TASTE
3. IR EMPFÄNGER
4. SNOOZE TASTE
5. LCD DISPLAY
6. TASTE
7. (ST/MO),WIEDERGABE,PAUSE TASTE
8. TASTE
9. BAND / STOP TASTE
10. PLAY MODUS TASTE
11. MEMORY / CLOCK TASTE
12. iPOD DOCKING STATION
13. FOLDER-/PRE- TASTE
14. FOLDER+/PRE+ TASTE
15. CD FACH
16. LAUTSTÄRKE +/-
17. STEREO KOPFHÖRER BUCHSE
18. ALARM 2 TASTE
19. SD/MMC CARD SLOT
20. ALARM 1 TASTE
21. USB SCHNITTSTELLE
22. FUNCTION TASTE
23. NETZKABEL
24. FM ANTENNE
ACHTUNG: Handhabung und Verwendung des Gerätes und seiner Bedienelemente anders als hier
angegeben kann zum Austreten von Laserstrahlung führen. Überlassen Sie Reparaturen
einem qualifizierten Servicetechniker.
INSTALLATION
Entnehmen Sie das Gerät vorsichtig aus der Verpackung und stellen es auf eine feste und gerade
Oberfläche. Installieren Sie das Gerät nicht in Heizungsnähe oder an einer Stelle, die direkter
Sonneneinstrahlung ausgesetzt ist. Stellen Sie sicher, daß eine gute Luftzirkulation möglich ist
ANSCHLIESSEN
• Den Netzstecker einstecken.
• Wenn Sie das Gerät zum ersten Mal an das Netz anschließend, geht das Gerät in den Standby Modus.
• Schalten Sie ein und wählen Sie die CD Funktion. Wenn das LCD Display angeht, bedeutet dies,
daß die Stromversorgung normal ist und das Gerät bereit zur Musikwiedergabe ist.
EUTSCH

19
BEDIENELEMENTE
FERNBED ENUNG
1. MUTE: Drücken, um MUTE Funktion zu aktivieren/deaktivieren.
2. STANDBY: Drücken, um E N zu schalten oder auf Standby Modus zu gehen.
3. FUNCT ON: Um CD/TUNER/iPod/USB/SD Modus auszuwählen.
4. CARD: Drücken, um CARD Modus auszuwählen
5. PROG/ADJ: m CD oder TUNER Modus drücken, um im CD oder TUNER
Einstellungen zu speichern. m Standby Modus drücken, um die Uhrzeit
einzustellen.
6. FOLDER -/PRE-: Um im MP3 Modus innerhalb der Albumnummer
zurückzugehen; um im Tuner Modus innerhalb der eingestellten Radiosender
zurückzugehen; im iPOD Modus drücken, um zum vorherigen Menüpunkt
zurückzukehren.
7. FOLDER+/PRE+: Um im MP3 Modus innerhalb der Albumnummer vorwärts
zu gehen.; um im Tuner Modus innerhalb der eingestellten Radiosender
vorwärts zu gehen; im iPOD Modus drücken, um einen Menüpunkt
auszuwählen.
8. MENU: Drücken, um das iPOD Menü zu wählen.
9. ENTER: Dient im iPOD Modus als Enter-Taste.
10. / -10: m iPOD Menü, um absteigend durch die Punkte zu gehen;
im CD Modus, um um 10 Tracks zurückzuspringen.
11. / +10: m iPOD Menü, um aufsteigend durch die Punkte zu gehen;
im CD Modus, um um 10 Tracks vorzuspringen.
12. DBBS: Bass Boost aktivieren/deaktivieren
13. VOLUME -: Drücken, um Lautstärke zu senken
14. TUNER: Drücken, um Tuner Modus zu wählen.
15. USB: Drücken, um USB Modus zu wählen.
16. CD: Drücken, um CD Modus zu wählen
17. iPOD: Drücken, um iPOD Modus zu wählen
18. ALARM2: Alarm 2 aktivieren oder deaktivieren.
19. ALARM1: Alarm 1 aktivieren oder deaktivieren
20. PLAY/MODE: Unterschiedliche Wiedergabemöglichkeiten auswählen(Repeat 1, Repeat all, Random, ntro Modus)
21. ST/MONO: Auswählen, um Stereo oder Mono im FM Modus zu aktivieren.
22. D3: Um im MP3 Modus die D3 Tag des Tracks anzuzeigen.
23. SLEEP: Drücken, um Sleep Funktion zu aktivieren.
24. SNOOZE: Durch Drücken wird der Alarm für 6 Minuten abgeschaltet. Danach ertönt er wieder.
25. STOP/BAND: Drücken, um Wiedergabe im CD/USB/SD/iPOD Modus zu stoppen. Auswahl des AM/FM Bandes
im Tuner Modus.
26. PLAY/PAUSE: Einmal drücken, um Wiedergabe zu starten. Erneut drücken, um Disk Wiedergabe vorübergehend
zu unterbrechen.
27 : m CD Modus einmal drücken, um zum nächsten Track zu springen. Drücken & gedrückt halten, um vorwärts zu
suchen. m Tuner Modus drücken, um im Frequenzbereich aufwärts zu gehen.
28. : m CD Modus einmal drücken, um zum vorherigen Track zu springen. Drücken & gedrückt halten, um rückwärts
zu suchen. m TUNER Modus drücken, um im Frequenzbereich abwärts zu gehen
29. EQ: Drücken, um den voreingestellten EQ Modus auszuwählen
30. VOLUME +: Drücken, um Lautstärke zu erhöhen.
BATTERIEN IN DIE FERNBEDIENUNG EINSETZEN
Öffnen Sie das Batteriefach und setzen Sie 2 AAA Batterien (nicht enthalten)
entsprechend der auf dem Deckel angegebenen Polarität (+ und – Symbol) ein.
Schließen Sie das Fach, so daß es einrastet.
EUTSCH
