Process Technology Lufran LUF Series User manual

LUF-Series
LufranTM Fluoropolymer Inline Water Heater
www.processtechnology.com
38809 Mentor Ave., Willoughby, Ohio 44094 Phone: [phone] Fax: [phone] USA/CN: 800-621-1998
Optional features shown.
Photo may vary from actual product

M-43-25 LUF-series Lufran Manual
Revision - Date: 03-01/04/18 Single outlet, Standard Interface
1
TABLE OF CONTENTS:
RELATED DOCUMENTS...............................................................................................2
INTRODUCTION.............................................................................................................2
ENGINEERING INFORMATION.....................................................................................4
SYSTEM SPECIFICATIONS.............................................................................................................................6
MODEL NUMBER..........................................................................................................................................7
FACILITY REQUIREMENTS...........................................................................................................................11
SPACE REQUIREMENTS..............................................................................................................................11
WATER PLUMBING REQUIREMENTS.............................................................................................................12
ELECTRICAL REQUIREMENTS......................................................................................................................12
PURGE GAS REQUIREMENTS......................................................................................................................12
-OPTIONAL COMMUNICATIONS....................................................................................................................13
OPERATOR INTERFACE...............................................................................................................................15
Operator Interface Buttons..................................................................................................................................15
Operator Interface Panel (OIP) ..........................................................................................................................15
Main Menu .........................................................................................................................................................16
Alarms Menu........................................................................................................................................................18
Trend Graph........................................................................................................................................................19
Alarm Summary...................................................................................................................................................20
ADAM Setup Menu..............................................................................................................................................21
SLC Setup Menu ..................................................................................................................................................22
Secure Menu........................................................................................................................................................23
Secure Menu........................................................................................................................................................24
TC1 Setup Menu ..................................................................................................................................................25
Heater Calibration Menu ....................................................................................................................................26
Flow Calibration Menu .......................................................................................................................................27
HEATER CALIBRATION PROCEDURE............................................................................................................28
FLOW METER CALIBRATION PROCEDURE....................................................................................................29
ALARMS ....................................................................................................................................................30
INSTALLATION............................................................................................................32
INSPECTION AND UNCRATING .....................................................................................................................32
POSITIONING THE UNIT...............................................................................................................................33
PLUMBING .................................................................................................................................................34
WIRING .....................................................................................................................................................39
OPERATION.................................................................................................................41
STARTUP PROCEDURE...............................................................................................................................41
SHUTDOWN ...............................................................................................................................................42
DRAINING THE UNIT ...................................................................................................................................42
MAINTENANCE............................................................................................................43
SPARE PARTS............................................................................................................. 58
CLEANING ...................................................................................................................59
WARRANTY ................................................................................................................. 60
APPENDIX.......................................................................................................................I

2
M-43-25 LUF-Series Lufran Manual
Revision - Date 03-01-04-18 Standard outlet, Standard Interface
Related Documents:
The following documents are to be used in conjunction with this manual:
ANSI/NFPA70 – National Electric Code→, latest edition. To be used to determine appropriate electrical
service, wire sizing, routing and protection.
SEMI S2 – Semiconductor Equipment Safety Guidelines, latest edition. To be used in conjunction with
safe operation, access and decommissioning procedures.
ANY – State or local building codes that would cover the electrical, mechanical, or physical installation of
electrical heating equipment.
National Electric Code→
NFPA 1999 Copyright
National Fire Protection Association
Quincy, Mass. 02269
Introduction:
The LUF-series LufranTM fluoropolymer inline water heater is designed to heat DI water with very stringent
cleanliness requirements. All wetted surfaces in this unit are fluoropolymer and PVDF material. There
are no metallic wetted surfaces. The cleanliness of these units has been confirmed by independent third
party testing. The cleanliness report is available upon request.
The Lufran fluoropolymer inline water heaters are available in wattages from 24kW to 312kW. These
units consist of one or more heating columns combined with a control system and all necessary power
distribution circuitry in a freestanding enclosure. The table on page 10 shows the various wattages with
the corresponding number of heating columns. The photo on the cover shows a typical Lufran unit with
two heating columns.
CE certification is available as an optional feature.

3
M-43-25 LUF-Series Lufran Manual
Revision - Date 03-01-04-18 Standard outlet, Standard Interface
Introduction (Continued):
The following symbols and warning labels appear on the unit and in the instruction manual. The table
below provides an explanation of each one.
DESCRIPTION
PICTORAL
DESCRIPTION
DESCRIPTION
DANGER
indique une situation
dangereuse imminente qui menera à
un décès ou des blessures graves si
elle n'est pas évitée. Ce mot clé sera
limité aux situations les plus extrêmes.
DANGER
indicates an imminently
hazardous situation which, if not
avoided, will result in death or serious
injury. This signal word is to be limited
to the most extreme situations.
WARNING
indique une situation
dangereuse imminente qui menera à
un décès ou des blessures graves si
elle n'est pas évitée.
WARNING
indicates a potentially
hazardous situation which, if not
avoided, could result in death or serious
injury.
ATTENTION indique une situation
potentiellem
ent dangereuse qui
pourrait mener à blessure bénine ou
modérée. ATTENTION peut
également être utilisé pour avertir les
pratiques dangereux.
CAUTION
indicates a potentially
hazardous situation which, if not
avoided, may result in minor or
moderate injury. It may also be used to
alert against unsafe practices.
DANGER: TENSION DANGEREUSE
CI-JOINTE
Tension ou danger de courrant
suffisant pour causer choc, brûlure, ou
mort. Couper le courrant et mettre une
déconsignation avant de réparer.
DANGER:
HAZARDOUS VOLTAGE
ENCLOSED
Voltage or current hazard sufficient to
cause shock, burn or death.
Disconnect and lock out power before
servicing.
ATTENTION: TENSION
DANGEREUSE
Toucher peut causer un choc
électrique ou une brûlure.
Cette machine devrait
être réparée
uniquement par personnel qualifié.
WARNING: HAZARDOUS VOLTAGE
Contact may cause electric shock or
burn.
This unit to be serviced by trained
personnel only
ATTENTION
: SURFACE CHAUDE.
NE PAS TOUCHER.
La colonne du peut être chaude.
Laisser refroidir avant l'entretien.
CAUTION: HOT SURFACE. DO NOT
TOUCH
Heater column may be hot. Allow unit
to cool before servicing.
EIP:
Electronic Information Product
Pollution Control Logo.
MISE À TERRE PROTECTIVE EARTH (GROUND)

4
M-43-25 LUF-Series Lufran Manual
Revision - Date 03-01-04-18 Standard outlet, Standard Interface
Engineering Information:
This system features the patented DACTM control system operating from a PLC with a touch-screen
operator interface. The DAC control system provides superior temperature control and faster response to
changes in conditions versus a typical PID temperature control system.
Figure 1: DAC Performance Graph

5
M-43-25 LUF-Series Lufran Manual
Revision - Date 03-01-04-18 Standard outlet, Standard Interface
Engineering Information (Continued):
The maximum possible temperature rise through the heater is dependent upon the wattage of the unit
and the water flow rate through the unit. The following table illustrates the maximum temperature rise of
various models based upon the water flow rate through the unit.
The Lufran fluoropolymer inline water heaters include a comprehensive system of safety controls and
devices to insure safe and long-lasting operation. The list of safety devices includes but is not limited to
the following:
•EMO pushbutton
•Circuit breaker
•Ground fault (earth leakage) protection
•Pressure relief valve
•Liquid level sensor
•Leak detector (optional)
•High process temperature sensor
•High element temperature sensor
•Purge gas flow switch
•Moisture sensor in the purge gas exhaust line
•Sensor failure (open sensor) detection
Heater Power (Kilowatts)
Flow Rate
24
52
72
105
130
144
156
210
260
288
312
L/min
Maximum Theoretical Temperature Rise (°C)
5
68.6
-
-
-
-
-
-
-
-
-
-
10
34.3
74.3
-
-
-
-
-
-
-
-
-
15
22.9
49.5
68.6
-
-
-
-
-
-
-
-
20
17.1
37.1
51.4
75.0
-
-
-
-
-
-
-
25
13.7
29.7
41.1
60.0
74.3
82.3
-
-
-
-
-
30
11.4
24.8
34.3
50.0
61.9
68.6
74.3
-
-
-
-
35
9.8
21.2
29.4
42.9
53.1
58.8
63.7
85.7
-
-
-
40
8.6
18.6
25.7
37.5
46.4
51.4
55.7
75.0
-
-
-
45
7.6
16.5
22.9
33.3
41.3
45.7
49.5
66.7
82.5
-
-
50
6.9
14.9
20.6
30.0
37.1
41.1
44.6
60.0
74.3
82.3
-
55
6.2
13.5
18.7
27.3
33.8
37.4
40.5
54.5
67.5
74.8
81.0
60
5.7
12.4
17.1
25.0
31.0
34.3
37.1
50.0
61.9
68.6
74.3
65
5.3
11.4
15.8
23.1
28.6
31.6
34.3
46.2
57.1
63.3
68.6
70
4.9
10.6
14.7
21.4
26.5
29.4
31.8
42.9
53.1
58.8
63.7
75
4.6
9.9
13.7
20.0
24.8
27.4
29.7
40.0
49.5
54.9
59.4
80
4.3
9.3
12.9
18.8
23.2
25.7
27.9
37.5
46.4
51.4
55.7

6
M-43-25 LUF-Series Lufran Manual
Revision - Date 03-01-04-18 Standard outlet, Standard Interface
Engineering Information (Continued):
System Specifications:
Product
LUF-series, Lufran fluoropolymer inline water heater
Available Wattages
24kW – 312kW
Refer to model number label for the wattage of any specific unit
Available Voltages
380V – 600V, 50/60Hz, 3 phase only
(Lower voltages available with special construction, consult factory for
details)
Cabinet dimensions and
unit weight:
Width Depth Height Weight
24kW – 72kW 508mm (20-in) 769mm (30.25-in) 2123mm
(83.57-in) 270 kg (595 lbs)
105kW – 156kW 712mm (28-in) 769mm (30.25-in) 2123mm
(83.57-in) 340 kg (750 lbs)
195kW – 312kW 1220mm (48-in) 769mm (30.25-in) 2123mm
(83.57-in) 682 kg (1500 lbs)
Wetted surfaces:
Heating elements
PTFE fluoropolymer
Columns and plumbing
PVDF
o-rings
Chemraz®
Operating temperatures:
Process inlet
50°C maximum
Process outlet Up to 95°C, depending upon operating conditions
Temperature accuracy
+/- 3°C, depending upon operating conditions
Ambient air temperature
30°C maximum
Water flow rate range
1 l/min (0.25 gpm) to 200 l/min (50 gpm)
Water pressure range
Minimum 69 kPa (0.69 bar, 10 psi)
Maximum 690 kPa (6.9 bar, 100 psi)
Purge gas flow rate
required (minimum):
24kW – 72kW 141 l/hr (5 scfh)
105kW – 144kW
282 l/hr (10 scfh)
210kW – 288kW
564 l/hr (20 scfh)
Purge gas pressure range
Minimum 175 kPa (1.75 bar, 25 psi)
Maximum 690 kPa (6.9 bar, 100 psi)

7
M-43-25 LUF-Series Lufran Manual
Revision - Date 03-01-04-18 Standard outlet, Standard Interface
Engineering Information (Continued):
System Specifications (Continued):
RoHS (3) Compliance Table
•Lead (Pb): < 1000 ppm
•Mercury (Hg): < 100 ppm
•Cadmium (Cd): < 100 ppm
•Hexavalent Chromium (Cr VI): <
1000 ppm
•Polybrominated Biphenyls
(PPB): < 1000 ppm
•Polybrominated Diphenyl Ethers
(PBDE): < 1000 ppm
•Bis (2-Ethylhexyl) Phthalate
(DEHP): < 1000 ppm
•Benzyl Butyl Phthalate (BBP): <
1000 ppm
•Dibutyl Phthalate (DBP): < 1000
ppm
•Diisobutyl Phthalate (DIBP): <
1000 ppm
Model Number:
Process Technology model numbers are designed to offer some description of the heater construction,
including features and options. The model number can be found on the model/serial number label located
directly above the operator interface screen. Refer to figure 33 (page 41) to see the location of this label.
Assembly
Control
Circuit
Power
Circuit
Enclosure
Fasteners
Lead
O
O
O
O
O
Mercury
O
O
O
O
O
Cadmium
O
O
O
O
O
Hexavalent
Chromium
O
O
O
O
O
Polybroinated
Biphenyis
O
O
O
O
O
Polybrominated
Diphenyl Ethers
O
O
O
O
O
Bis (2-
Ethylhexyl)
Phthalate
O
O
O
O
O
Benzyl Butyl
Phthalate
O
O
O
O
O
Dibutyl
Phthalate
O
O
O
O
O
Diisobutyl
Phthalate
O
O
O
O
O
O indicates that this toxic or hazardous substance contained in the omogenous material for
this part, according to the EIP-A, EIP-B,-EIP-C is below the limit requirement listed in
SJ/T11363 2006.
X indicates that this toxic or hazardous substance contained in the omogenous material for this
part, according to the EIP-A, EIP-B,-EIP-C is above the limit requirement listed in SJ/T11363
2006.

8
M-43-25 LUF-Series Lufran Manual
Revision - Date 03-01-04-18 Standard outlet, Standard Interface
Figure 2: Model/Serial Number Label
Engineering Information (Continued):
Model Number (Continued):
Provided below is an example of a typical model number along with an explanation of each part. This key
will help you understand your model number.
Model number example:
LUF-130-3LL6-SK

Heater kilowattage rating. The table provided below identifies the standard available wattage
ratings and the number of heater columns needed to provide that amount of Wattage.
Heater
Model
Number
Heater
Wattage
(W)
Number Of
Heater
Columns
Wattage
Per Heater
Column
(W)
Heater
Model
Number
Heater
Wattage
(W)
Number Of
Heater
Columns
Wattage
Per Heater
Column
(W)
024 24,000 1 24,000 144 144,000 2 72,000
036 36,000 1 36,000 156 156,000 2 78,000
052 52,500 1 52,500 195 195,000 3 65,000
065 65,000 1 65,000 210 210,000 4 52,500
072 72,000 1 72,000 260 260,000 4 65,000
078 78,000 1 78,000 288 288,000 4 72,000
105 105,000 2 52,500 312 312,000 4 78,000
130 130,000 2 65,000
Heater Voltage. The first character following the heater Wattage will describe the rated Voltage of
the heater. Please note that all heaters are rated for Three-Phase power.
Heater
Model
Number
Rated
Voltage
(V)
Heater
Model
Number
Rated
Voltage
(V)
1 208 6 480
2 240 7 440
3 380 8 575
4 400 9 220
5 415 10 200

9
M-43-25 LUF-Series Lufran Manual
Revision - Date 03-01-04-18 Standard outlet, Standard Interface
Engineering Information (Continued):
Model Number (Continued):
LUF-130-3LL6-SK

Heater Inlet, Outlet Plumbing Connections.
The heater inlet and outlet plumbing connections are usually the same. However, it is possible to have
different plumbing connections for the inlet and outlet. The characters to describe the plumbing
connections have the same designation for both the inlet and outlet connections. Please refer to the table
below to see the specific plumbing connections provided with the heater:
Heater Model
Number
Plumbing Connection Type
Plumbing Connection Size: mm (in)
A
Flared Tube Fitting
13mm (1/2-inch)
B
Flared Tube Fitting
19mm (3/4-inch)
C
Flared Tube Fitting
25mm (1-inch)
D
Union manifold Connector
32mm (1 ¼-inch)
E
Flange
19mm (3/4-inch)
F
NPT Pipe Threads, Female
13mm (1/2-inch)
G
NPT Pipe Threads, Female
19mm (3/4-inch)
H
NPT Pipe Threads, Female
25mm (1-inch)
I
NPT Pipe Threads, Male
13mm (1/2-inch)
J
NPT Pipe Threads, Male
19mm (3/4-inch)
K
NPT Pipe Threads, Male
25mm (1-inch)
L
Butt Fusion Union
25mm (1-inch)
M
BCF Union
32mm (1 ¼-inch)
N
Socket Fusion Union
32mm (1 ¼-inch)
P
Pillar Tube Fitting
13mm (1/2-inch)
Q
Pillar Tube Fitting
19mm (3/4-inch)
R
Pillar Tube Fitting
25mm (1-inch)
U
Socket Fusion Union (Standard)
25mm (1-inch)
Flow Meter Device. The ultrasonic flow meter device is part of the DAC temperature control system.
The flow meter is selected based upon total wattage of the heater and operating flow rate range. This
device does not require routine maintenance or re-calibration.
Heater Model
Number
Device
Brand
Water Flow
Range
Process Technology
Part Number
0-4
5
Thornton
2-20 LPM
8136
6
Thornton
10-70 LPM
8137
7
Honda
0.5-20 LPM
9238
8
Honda
1-50 LPM
09-6820
9
Thronton
15-150 LPM
9964

10
M-43-25 LUF-Series Lufran Manual
Revision - Date 03-01-04-18 Standard outlet, Standard Interface
Engineering Information (Continued):
Model Number (Continued):
Options: There are several options available with the LUF-series Lufran fluoropolymer inline water
heater. Some of these options are described in greater detail in the OPERATION section of this
manual. More than one option may be included in an individual heater. Please refer to the table
below for a brief listing of the available options.
Heater
Model
Number
Description
C1
Ethernet communications
C2
Devicenet communications
C3
RS232 communications
C4
RS485 communications
C5
Modbus communications
C#
Custom communications option. Contact the Process
Technology technical service department for assistance.
CE
CE certification
LK
Cabinet leak detector
R#
Customer-defined remote interface option. Contact the
Process Technology technical service department for
assistance.
SK
Stack light
##
Customer specific design/construction (Which may or may
not include some of the above options)

11
M-43-25 LUF-Series Lufran Manual
Revision - Date 03-01-04-18 Standard outlet, Standard Interface
Engineering Information (Continued):
Facility Requirements:
Before installing the Lufran fluoropolymer inline water heater confirm the facility requirements listed
below.
Space Requirements:
The Lufran fluoropolymer inline water heater is constructed in a freestanding enclosure. This cabinet
includes the common framework for the heating column(s) as well as the electrical components. No
additional support is required.
The dimensions of the specific model are based upon the unit wattage. The cabinet assembly requires
ventilation. Locate equipment so that ventilation fans on the top and bottom of the enclosure and louvers
on the sides are not obstructed. The ventilation fan exhausts through these openings, preventing
overheating of the unit. Be sure to provide adequate clearance for normal operation and maintenance of
this heater.
Typical Cabinet Dimensions
Heater Wattage
(kW) Number of Heating Columns Width Depth Height
24-78 1 508mm (20-in) 769mm (30.25-in) 2123mm (83.57-in)
105-156 2 712mm (28-in) 769mm (30.25-in) 2123mm (83.57-in)
195-312 3-4 1220mm (48-in) 769mm (30.25-in) 2123mm (83.57-in)
Figure 3: Clearance Dimensions (24-78kW units shown)

12
M-43-25 LUF-Series Lufran Manual
Revision - Date 03-01-04-18 Standard outlet, Standard Interface
Engineering Information (Continued):
Facility Requirements (Continued):
Water Plumbing Requirements:
This unit is typically supplied with a single inlet and outlet water connection located just inside the rear of
the cabinet. The connections are arranged vertically and do not offset from the horizontal center of the
unit. The inlet plumbing should also include a means to drain the unit for service. There are also
connections for the PRV valve and the leak pan drain. Reference the unit’s model number and the model
number key to identify the specific plumbing connections provided with your unit.
Electrical Requirements:
Reference the unit’s model number and model number key or the Electrical Specifications Table inside
the front door to identify the electrical power requirements of this unit. In addition, the model number tag
on the front of the unit includes the unit’s Wattage, Voltage, Amperage draw and Phase. Verify that the
incoming electrical service is rated and fused for the required amperage draw.
Ne pas dépasser la tension nominale. Des
dommages irréparables à l'appareil de chauffage
entraînera.
Do not exceed the rated voltage. Irreparable
damage to the heater will result.
NOTE: Ensure electrical power fusing and disconnects meet local jurisdictional
requirements. Fuse ratings noted in this document are for reference only.
Purge Gas Requirements:
A source of purge gas, nitrogen (N2) or clean dry air (CDA) is required for the heater element purge
system. All Lufran fluoropolymer inline water heaters use 6.4-mm (0.25-inch) compression fittings as the
purge gas inlet connection.
The purge gas supply must be regulated between 1.75 – 6.9 bar (25 – 100 psig) gas pressure. Each
heating column inside the unit will use approximately 141 l/hr (5 SCFH) of purge gas.
If the gas pressure is supplied lower than 1.75 bar (25 psi), the control’s safety circuitry will disable the
heater and indicate a safety alarm. If the gas pressure exceeds 6.9 bar (100 psi) equipment damage will
result.
Ne pas dépasser la pression de gaz pur de 6.9
bar (10
0 PSI). Des dommages irréparables à
l'élément de chauffage peut entraîner.
Do not exceed pure gas pressure of 6.9 bar (100
PSI). Irreparable damage to the heater may result.

13
M-43-25 LUF-Series Lufran Manual
Revision - Date 03-01-04-18 Standard outlet, Standard Interface
Engineering Information (Continued):
Optional Communications:
-C1 Option: Ethernet:
The –C1 communications option adds
Ethernet communications to the PLC
controller. The network can interface with
the Lufran heater through the RJ45
connector included with the unit.
The Lufran heater is provided with the
following default IP Address: 128.1.105.100.
The Ethernet card has a default module ID
of 14. Once connected to the network, the
customer may wish to change the IP
address. Adjusting the IP Address or
performing other networking tasks with the
Lufran heater will require the use of NetEdit
software (3.5 or later), available from Host
Engineering. This software along with the
instruction manual is available as a free
download through their website:
http://hosteng.com
-C2 Option: DeviceNet:
The –C2 communications option adds DeviceNet communications to the PLC controller. The network can
interface with the Lufran heater through the DeviceNet mini male connector included with the unit.
The Lufran heater is provided with the following default node assignment: 63. Once connected to the
network, the customer may assign a new node to the Lufran heater.
If necessary, the EDS file can be downloaded from this address:
http://support.automationdirect.com/downloads.html
When one of the communications options are included with the heater, the main menu screen will be
modified to include a button to select this communication as the method for control of the unit.
Figure 5: Main Menu, with Communications Option Included
Figure 4: Communications connector plug
Remote
Interface
Connection
Ethernet RJ45 or
DeviceNet mini male
Connector

14
M-43-25 LUF-Series Lufran Manual
Revision - Date 03-01-04-18 Standard outlet, Standard Interface
Engineering Information (Continued):
Optional Communications (Continued):
The following table describes the network addresses of the Lufran water heater.
Network
Address
Data Signal
type
Description
V3200 Inlet water temperature
(°C)
Heater
output The value provided is the measured inlet water temperature.
V3202 Outlet water temperature
(°C)
Heater
output
The value provided is the measured outlet water temperature.
This address may be used to monitor the outlet temperature of
the heater through the network.
V3204 Flow rate
(liters/min) Heater output The value provided is the measured water flow rate through the heater.
V3206 Heater output
(%) Heater output The value provided is the current percentage (%) output of the heating column(s).
V3210 Set point (°C) Heater
output
The value provided is the outlet set point of the heater. When
the system is in NETWORK control mode, this value should
match address V3102.
V3212 Remote
control Heater output
0 = System is in LOCAL control mode
1 = System is in MANUAL control mode
2 = System is in REMOTE control mode
3 = System is in NETWORK control mode
This setting is adjusted in the control access menu, through
the operator interface touch screen.
V3214 System
enabled Heater output 0 = System disabled
1 = System enabled
V3216 System
operating Heater output 0 = Not operating
1 = Operating
V3220 System at
temperature Heater output
0 = Outlet temperature is not within the process deviation
setting
1 = Outlet temperature is within the process deviation setting
V3222 System fault Heater
output 0 = No system fault detected
1 = System fault detected
V3100 Remote
start/stop Heater input 0 = Stop heater operation
1 = Start heater operation
V3102 Heater set
point (°C) Heater input
The value provided from the network to the heater will be
the desired outlet set point of the heater. When the
system is in NETWORK control mode, this value should
be matched by address V3210.

15
M-43-25 LUF-Series Lufran Manual
Revision - Date 03-01-04-18 Standard outlet, Standard Interface
Engineering Information (Continued):
Operator Interface:
Operator Interface Buttons:
There are two push buttons are located on the front panel of the unit.
Power On Button: When depressed, this button enables the main power safety contactor (1CON) and
readies the system for operation. It illuminates to indicate the system is in an operational mode.
Power Off Button: When depressed this button disables heater operation by disengaging the main
power safety contactor (1CON). It illuminates to indicate the main power is off.
Operator Interface Panel (OIP):
The operator interface panel is an intelligent flat panel display. It is designed to interchange and display
graphical data from a PLC by merely viewing or touching the screen. To ensure the effectiveness of the
panel, it is important to take the following precautions:
Do not press sharp objects against the screen.
Do not strike the panel with hard objects.
Do not press the screen with excessive force.
Many fields in the various displays can be adjusted by pressing the field value. This will
bring-up a keypad which will allow the operator to change the value.
Figure 7: OIP Keypad
Figure 6: Operator Interface Buttons
POWER ON
GREEN BUTTON
POWER OFF
RED BUTTON

16
M-43-25 LUF-Series Lufran Manual
Revision - Date 03-01-04-18 Standard outlet, Standard Interface
Engineering Information (Continued):
Operator Interface Panel (OIP) (Continued):
Main Menu:
Figure 8: Main Menu
Main Menu Information
Panel
Description
TREND GRAPH This button will go directly to the TREND GRAPH screen.
PROCESS SETPOINT
Displays the process setpoint. The value appears when the unit is in
LOCAL control mode.
Press this button to bring up a keypad to change the process
setpoint.
MANUAL SETPOINT
This value is the manual output of the heater. This value will only
appear when the unit is in MANUAL control mode.
REMOTE SETPOINT
This value is the process setpoint. The value appears when the unit
is in REMOTE control mode.
LOCAL,
MANUAL,
REMOTE
These buttons will switch control of the various settings between
local mode, remote mode, or manual adjustments of the DAC control
values. The selected control mode will be highlighted.
LOCAL: The heater is controlled from the touch-
screen on the
front of the unit.
MANUAL
: The heater output is set manually. The DAC control
system is not active.
REMOTE
: The setting of this unit are controlled by a remote
device.
Une fois en mode de contrôle manuel, le contrôle
automatisé est plus active et peut entraîner un
comportement erratique ou de surchauffe
conditions. Pour cette raison, la commande
manuelle ne doit être utilisé par du personnel
qualifié comme un outil de maintenance.
Once in manual control m
ode the automated
control is no longer active and may result in erratic
behavior or over-temperature conditions. For this
reason, manual control should only be used by
qualified personnel as a maintenance tool.

17
M-43-25 LUF-Series Lufran Manual
Revision - Date 03-01-04-18 Standard outlet, Standard Interface
Engineering Information (Continued):
Operator Interface Panel (OIP) (Continued):
Main Menu (Continued):
Main Menu Information
Panel
Description
OUTLET TEMPERATURE
Displays the temperature measured from the process sensor located
at the outlet of the heater.
HEATER OUTPUT
Displays the output load of the heating elements needed to provide
the desired outlet temperature.
HEAT ON/OFF
This button will start or stop heater operation. The field directly
above this button displays the current status of this selection.
ALM. LOG
This button will display the ALARMS SUMMARY screen.
CONFIG
This button will display the CONFIGURATION MENU screen.
ALARMS
This button will display the ALARMS MENU screen.

18
M-43-25 LUF-Series Lufran Manual
Revision - Date 03-01-04-18 Standard outlet, Standard Interface
Engineering Information (Continued):
Operator Interface Panel (OIP) (Continued):
Alarms Menu:
The ALARMS MENU displays the status of the various alarm settings for the LUF heater. All of the alarm
fields in this menu are read-only. Any alarm that has been activated will be indicated by a blinking red
light. Refer to the Alarms section of this manual for a detailed description of each alarm setting.
Figure 9: Alarms Menu (2 Screens)
Fault Log Information
Panel
Description
MAIN
This button will display the MAIN MENU screen.
CONFIG
This button will display the CONFIGURATION MENU screen.
ALM. LOG
This button will display the ALARMS SUMMARY screen.
NEXT
This button will display screen 2 of the ALARMS MENU
BACK
This button will display screen 1 of the ALARMS MENU
FAULT RESET
This button will reset all alarm settings.

19
M-43-25 LUF-Series Lufran Manual
Revision - Date 03-01-04-18 Standard outlet, Standard Interface
Engineering Information (Continued):
Operator Interface Panel (OIP) (Continued):
Trend Graph:
The TREND GRAPH displays the graph of current datalog values. This display includes the fields to
adjust the sampling rate and the switch to stop or start datalogging.
Figure 10: Trend Graph
Trend Graph Information
Panel
Description
OFF- LOG
This button turns on or off the data logging function. When off is
selected, there is no trend graph data to view.
Pressing the LOG side of this button will activate the data logging
function and will then display the trend graph lines.
SAMPLE RATE
This field displays the sampling rate for the trend graph. Press this
button to bring up a keypad to change the sampling rate. The range
for data sampling is 2-60 seconds.
BACK
This button will return to the previous screen.
