Prodigy Athletics CTE2000E User manual

Owner’s Manual
Model CTE2000E
Children’s Circuit Training & Spinning Combo Bike
Revised 4.12.04

2
Know your heart rate and / or pulse, and your physician recommended target heart rate training
zone.
Proper medical clearance is recommended for anyone beginning an exercise program especially if
you are over 35 years of age or suffer from heart/respiratory problems.
Warm up before any exercise program with 8 minutes of aerobic activity. This can be on your bike.
Wear comfortable clothes that allow freedom of movement and that are not tight or restricting.
Wear comfortable shoes made of good support with nonslip soles. (Tennis shoes are recommended).
Breathe naturally, never holding your breath during an exercise.
Perform exercises consistently with proper technique and pass through a full range of motion.
Avoid over training. You should be able to carry on a conversation while exercising.
After an exercise session, cool down by stretching.
Handicapped or disabled people must have medical approval before using this machine and should
be under close supervision when using any exercise equipment.
Use this machine only for its intended use as described in this manual. Do not use attachments not
recommended by the manufacturer.
Only one person at a time should use this machine.
Do not put hands, feet, or any foreign objects on or near this machine when in use by others.
Always use this machine on a level surface.
Never operate the machine if the machine is not functioning properly,
Start exercise slowly and gradually increase the amount of resistance.
If the user experiences dizziness, nausea, chest pain, or any other abnormal symptoms, stop
exercise at once and consult a physician immediately.
Use caution not to pinch ngers or hands in moving parts when using the unit.
The Prodigy bike should be checked for wear before each use.
Care should be taken when getting on or off this bike.
IMPORTANT SAFETY INSTRUCTIONS
Read all instructions before using this machine. If you are in a class setting you must inquire about
complete instructions prior to use.
1.
2.
3.
4.
5.
6.
7.
8.
9.
10.
11.
12.
13.
14.
15.
16.
17.
18.
19.
20.
Exercise of a strenuous nature, as is customarily done on this equipment, should not
be undertaken without rst consulting a physician. You could die or suffer debilitating
injuries from the use of this bike. No specic health claims are made or implied as
they relate to the equipment.
WARNING:
Model CTE2000E Children’s Circuit Training & Spinning Combo Bike

3
BENEFITS OF EXERCISE
Regular exercise improves both the quality and quantity of life.
The benets of regular participation in a well balanced tness program include:
1. Weight loss
2. Improved body shape and denition
3. Increased muscle mass, strength, endurance, power, and denition.
4. Enhanced exibility
5. Increased metabolism
6. Injury prevention
7. Improved self-esteem
8. Improved aerobic tness
9. Improved coordination and agility
A regular exercise program will improve the quality of your life, give you more energy.
Fifteen to thirty minutes, three times a week, or only one and a half hours a week is a small price to pay
for huge benets of a regular exercise program.
Daily Maintenance
At the end of the last class for the day release the brake tension until the brake pad no longer contacts
the ywheel. This will help prevent brake squeal. Wipe the perspiration off the bike at the end of each
class.
Inspect the bike for loose parts such as bolts, screws, nuts etc. Please check the brake assembly and
the seat and handlebar pop pins and knobs. Check to be certain that the bike is stable and not rocking.
If the bike is unstable adjust pads under front and rear stabilizers.
Weekly Maintenance
Inspect bike for loose parts such as bolts, screws, nuts etc. Please check the brake assembly, and the
seat and handlebar pop pins and knobs. Check the pedals to be certain they are in good condition,
they are on the crank properly and the the pedal spins easily. Apply lubrication to all pop pins, seat and
handlebar posts. Lubricate moving parts with grease. Check to be certain that the bike is stable. If the
bike is unstable adjust the pads under the front and rear stabilizers.
If the belt slips during pedaling follow these steps:
a. Loosen the nuts on each side of the ywheel.
b. Slowly tighten the nuts on the eyebolts equally on both sides.
c. Make sure the ywheel is aligned correctly and tighten the nuts on each side of the ywheel.
Monthly Maintenance
Check the belt to be certain that it is property adjusted.
Inspect all nuts, bolts, knobs, pop pins to be certain that they are tight and work properly, Clean the
dust off of the bike and use Windex or a low PH Cleaner. Never use abrasive cleaners on the bike.
Check to be certain that the bike is stable. If the bike is unstable adjust the pads under the front and rear
stabilizers. Check warning label and if torn or unreadable call Prodigy for a new warning label. Check
the pedals to be certain they are in good condition, they are on the crank properly and that the pedal
spins easily.
Model CTE2000E Children’s Circuit Training & Spinning Combo Bike

4
TRAINING GUIDELINES
Exercise
Exercise is one of the most important factors in
the overall health of an individual. Listed among
its benets are:
• Increased capacity for physical work (strength
endurance).
• Increased cardiovascular (heart and arteries/
veins) and respiratory efciency.
• Decreased risk of coronary heart disease.
• Changes in body metabolism, e.g. losing
weight.
• Delaying the physiological effects of age.
• Psychological effects, e.g. reduction in stress,
increase in self-condence, etc.
Your Prodigy Bike provides an excellent
opportunity for a high level of overall tness.
Basic Components of Physical Fitness
There are four all encompassing components
of physical tness and we need to briey dene
each and clarify Its role.
Strength is the capacity of a muscle to exert a
force against rseistance. Strength contributes to
power and speed and Is of great importance to a
majority of sports people.
Muscular Endurance is the capacity to exert a
force repeatedly over a period of time, e.g. It
is the capacity of your legs to carry you 10 Km
without stopping.
Flexibility is the range of motion about a joint.
Improving exibility involves the stretching of
muscles and tendons to maintain or increase
suppleness, and provides increased resistance
to muscle injury or soreness.
Cardio-Respiratory Endurance is the most
essential component of physical tness. It is the
efcient functioning of the heart and lungs.
Aerobic Fitness
The largest amount of oxygen that you can
use per minute during exercise is called your
maximum oxygen uptake (MV02), This Is often
referred to as your aerobic capacity.
The effort that you can exert over a prolonged
period of time is limited by your ability to deliver
oxygen to the working muscles. Regular vigorous
exercise produces a training effect that can
increase your aerobic capacity by as much as 20
to 30%. An Increased MV02 indicates an
increased ability of the heart to pump blood, of
the lungs to ventilate oxygen and of the muscles
to take up oxygen.
Anaerobic Training
This means “without oxygen” and is the output of
energy when the oxygen supply is insufcient to
meet the body’s long term energy demands (For
example, 100 meter sprint).
The Training Threshold
This is the minimum level of exercise which is
required to produce signicant improvements in
any physical tness parameter.
Progression
As you become tter, a higher Intensity of exercise
is required to create an overload and therefore
provide continued improvement.
Overload
This is where you exercise at a level above
that which can be carried out comfortably. The
intensity, duration and frequency of exercise
should be above the training threshold and
should be gradually increased as the body
adapts to the increasing demands. As your
tness level improves, so the training threshold
should be raised. Working through your program
and gradually increasing the overload factor is
important.
Model CTE2000E Children’s Circuit Training & Spinning Combo Bike

5
Specicity
Different forms of exercise produce different
results. The type of exercise that is carried out
is specic both to the muscle groups being used
and to the energy source involved. There is
little transfer of the effects of exercise, e.g. from
strength training to cardiovascular tness. That is
why it is important to have an exercise program
tailored to your specic needs.
Reversibility
If you stop exercising or do not do your program
often enough, you will lose the benets you
have gained. Regular workouts are the key to
success.
Warm Up
Every exercise program should start with a warm
up where the body is prepared for the effort to
come. It should be gentle and preferably use the
muscles to be involved later. Stretching should be
included in both your warm up and cool down,
and should be performed after 3-5 minutes of
low intensity aerobic activity or calisthenic type
exercise.
Warm Down or Cool Down
This involves a gradual decrease in the intensity
of the exercise session. Following exercise, a
large supply of blood remains in the working
muscles. If It is not returned promptly to the
central circulation, pooling of blood may occur in
the muscles.
Heart Rate
As you exercise, so the rate at which your heart
beat also increases. This is often used as a
measure of the required intensity of exercise.
You need to exercise hard enough increase your
pulse rate, bid not enough to strain your heart.
Your initial level of tness is important in
developing an exercise program for you. If you
are starting off, you can get a good training effect
with a heart rate of 110-120 beats per minute
(BPM). If you are tter, you will need a higher
threshold of stimulation.
Pulse Count
The pulse count (on your wrist or carotid artery in
the neck, taken with two index ngers) is done for
ten seconds, taken a few seconds after you stop
exercising. This is for two reasons: (a) 10 Seconds
is long enough for accuracy, (b) the pulse count is
to approximate your BPM rate at the time you are
exercising. Since heart rate slows as you recover,
a longer count isn’t as accurate.
The target is not a magic number, but a general
guide. If you’re above average tness, you
may work quite comfortably a little above that
suggested for your age group.
The following table is a guide to those who are
keeping t. Here we are working at about 80% of
maximum. Formula (220 - age x 80%)
To begin with, you should exercise at a level that
elevates your heart rate to about 65 to 70% of
your maximum. If you nd this is too easy, you
may want to increase it but it is better to lean on
the conservative side.
As a rule of thumb, the maximum heart rate Is
220 minus your age. As you increase in age, so
your heart, like other muscles, loses some of its
efciency. Some of its natural loss is won back as
tness improves. Formula (220 - age x 70%)
The following table is a guide to those who are
“starting tness”.
Age
8 15 20 25 30 35 40 45 50 55 60
Target Heart Rate
10 Second Count
24 23 23 22 22 21 20 19 19 18 18
Beats per Minute
144 140 138 132 132 128 120 114 114 108 108
Model CTE2000E Children’s Circuit Training & Spinning Combo Bike

6
Age
8 15 20 25 30 35 40 45 50 60
Target Heart Rate
10 Second Count
27 27 26 26 25 24 23 22 22 21 20
Beats per Minute
164 160 156 150 144 130 132 132 126 120
Don’t push yourself too hard to reach the gures
on this table. It can be very uncomfortable if you
overdo it. Let it happen naturally as you work
through your program. Remember, the target is
a guide, not a rule, a little above or below is just
ne.
Two nal comments: (1) don’t be concerned with
day to clay variations in your pulse rate, being
under pressure or not enough sleep can affect
it; (2) your pulse rate is a guide, don’t become a
slave to it.
Endurance Circuit Training
Cardiovascular endurance, muscle strength,
exibility and coordination are all necessary for
maximum tness. The principle behind circuit
training is to give a person all the essentials
at one time by going through your exercise
program moving as fast as possible between
each exercise. This increases the heart rate
and sustains it, which improves the tness level.
Do not introduce this circuit training effect until
you have reached an advanced program stage.
Circuit training can combine strength and cardio
for the best results.
Body Building
Is often used synonymously with strength training.
The fundamental principal here is OVERLOAD.
Here, the muscle works against greater loads than
usual. This can be done by increasing the load
you are working against. You may also increase
the intensity by increasing the repetitions.
Rest Periods
Once you start your exercise program, you
should continue through to the end. Do not break
off halfway through and then restart at the same
place later on without going through the warm-up
stage again. The rest period required between
strength training exercises may vary from person
to person. This will depend mostly on your level
of tness and the program you have chosen. Rest
between exercises by all means, but do not allow
this to exceed two minutes. Most people manage
half minute to one minute rest periods.
If you are involved in an aerobic curcuit traing
program you may only have 10 - 15 seconds
to change stations.
Muscle Soreness
For the rst week or so, this may be the only
indication you have that you are on an exercise
program. This, of course, does depend on your
overall tness level. A conrmation that you are
on the correct program is a very slight soreness
in most major muscle groups, This is quite normal
and will disappear in a matter of days.
It you experience major discomfort, you may be
on a Program that is too advanced or you have
increased your program too rapidly.
If you experience PAIN during or after exercise,
your body is telling you something. Stop
exercising and consult your doctor.
Periodization
This is the term used to vary your exercise
program for both physiological and psychological
benets In your overall program, you should
vary the workload, frequency and intensity. The
body responds better to variety and so do you.
In addition, when you feel yourself getting “stale,
bring in periods of lighter exercise to allow your
body to recuperate and restore its reserves. You
will enjoy your program more and feel better for
it.
Model CTE2000E Children’s Circuit Training & Spinning Combo Bike

7
PROGRAMS
The program you follow should be determined
by your tness level, available time and goals.
It is highly recommended that you review the
heart rate and pulse count within this manual and
obtain a better understanding of your capabilities
and the intensity that best suite you and your
goals.
First time exercisers should follow Program #1
and gradually build up both the time and intensity
of your workout. If you are already a regular
exerciser, you may wish to follow Program #2.
Always remember to warm up and cool down
and never try to over do it, moderation and
consistency is the secret to long term results.
PROGRAM 1. Initial Conditioning Program
Frequency: 3-4 times per week
Duration: 20-30 minutes
Intensity: 60-70% of age predicted
maximum heart rate
When rst starting an exercise program, the
emphasis should be placed on gradually building
up to 20-30 minutes of continuous activity, not
PROGRAM 2: Intermediate Conditioning
Program
Frequency: 3-5 times per week
Duration: 20-45 minutes
Intensity: 70-80% of age predicted
maximum heart rate
In most cases, this program will produce results
consistent with the tness goals for the majority of
the general tness population. Training at higher
levels of frequency, duration and intensity than
these is normally reserved for the competitive
athlete.
PROGRAM 3: Advanced Conditioning
Program
Frequency: 4-6 times per week
Duration: 30-60 minutes
Intensity: 80-90% of age predicted
Maximum heart rate
This program should be undertaken only by
those individuals having a need to develop and
maintain the highest levels of cardiovascular
tness. As an alternative to continuous high
intensity exercise, an interval training format
can be followed during which short bouts (30-60
seconds) of high intensity exercise (faster pedal
speed) are alternated with longer bouts (1-2
minutes) of tower intensity exercise.
If you should ever stop your exercise program for
a peroid of time upon your return you should start
program one and progress to program three.
on achieving and maintaining a specic exercise
intensity. Once 20-30 minutes of continuous
activity can be performed, the emphasis can be
moved to gradually building up the time for which
you exercise at the recommended intensity level.
This program should be followed for the rst 6-8
weeks of training.
What to Wear
Wear clothing that will not restrict your movement
in any way while exercising. Clothes should be
light enough to allow the body to coal. Excessive
clothing that causes you to perspire more than
you normally would while exercising, gives you
no advantage. The extra weight you lose is body
uid and will be replaced with the next glass of
water you drink. It is advisable to wear a pair of
gym or running shoes or “sneakers”
Breathing During Exercise
Do not hold your breath while exercising, Breathe
normally as much as possible. Remember,
breathing Involves the intake and distribution of
oxygen, which feeds the working muscles.
Model CTE2000E Children’s Circuit Training & Spinning Combo Bike

8
LIMITED WARRANTY
This is warranted to the original purchaser to be free from defects in workmanship and/or materials
under normal use or service. If at any time a component part is defective, it shall be repaired or
replace it within ONE year of purchase. This warranty does not cover cost of removal, transportation
or reinstallation. This warranty shall not apply if defect was caused by misuse, neglect or normal wear
and tear. Starting from the original date of purchase, normal wear and tear shall be considered as the
following:
COMMERICAL USE; All malfunctions of upholstery grips, paint and chrome that occur after one year;
all malfunctions of electronic components, belts, cables, or upholstery after one year, all malfunctions
of bearings or bushings that occur after one year, the frame and all welded components are warranted
for the fe of the product.
HOME USE; All malfunctions of grips, paint, and chrome that occur after rst year, all malfunctions
of electronic components, belts, cables, or upholstery that occur after rst year; all malfunctions of
bearings or bushings that occur after rst year, the frame and all welded components are warranted for
the life of the product.
WHAT IS NOT COVERED BY THIS WARRANTY; The sole obligation under this warranty is limited to
either repair or replacement of parts, subject to the additions below. This warranty neither assumes
nor authorizes any person to assume obligations other than expressly covered by this warranty. NO
CONSEQUENTIAL DAMAGES. No responsibility for economic loss, prot loss; or special, indirect, or
consequential damages.
WARRANTY IS NOT TRANSFERABLE; This warranty is not assignable and applies only in favor of the
original purchaser/user to whom delivered. Any such assignments or transfer shall void the warranties
herein made and shall void all warranties, expressed, implied or statutory, except the rst described
above. These warranties are exclusive and in lieu of all other warranties, including implied warranty and
merchantability of tness for a particular purpose, There are no warranties, which extend beyond the
description on the face hereof.
ALTERATION, NEGLECT, ABUSE, MISUSE, NORMAL WEAR & TEAR,ACCIDENT. DAMAGE DURING
TRANSIT OR INSTALLATION, FIRE, FLOOD. ACTS OF GOD. The warranty is not responsible for the
repair or replacement of any parts that Prodigy Athletics and Fitness determines have been subjected
after the date of manufacture to alteration, neglect, abuse, misuse normal wear & tear, accident,
damage during transit or installation, re, ood, or ACT OF GOD.
TRANSPORTATION COSTS. WARRANTY CLAIMS. All claims should include; model number, the
serial number, proof of purchase, date of installation, and all pertinent information supporting the
existence of the alleged defect.
PLEASE KEEP THIS FOR YOUR RECORDS
Model CTE2000E Children’s Circuit Training & Spinning Combo Bike

9
Step 1.
Step 2.
Step 3.
Step 4.
FIGURE 1
1
28
26
4
NUT
WASHER
8
RIGHT
7
RIGHT
3
31
2
2
40
37
Attach FRONT STABILIZER (2), with CASTERS (45) and
REAR STABILIZER (3) to FRAME (1) with M8 x 73mm
CARRIAGE BOLTS (31), M8 WAVE WASHERS (37) and
M8 CAP NUTS (40).
NOTE: One PEDAL (7) has RIGHTHAND threads and the
other has LEFTHAND threads.
Thread RIGHTHAND threads into RIGHT CRANK ARM
(8) and LEFTHAND threads into LEFT CRANK ARM (8).
Thghten securely.
Remove NUTS and WASHERS from SADDLE (28) and
attach SADDLE to SEAT POST (4) with NUTS and WASH-
ERS.
Insert SEAT POST (4) into FRAME (1), with adjustment
holes facing to the rear, and lock at desired height by
threading LOCKING LEVER HANDLE (26) into FRAME
until tight.
IMPORTANT: Make sure SEAT POST is locked before
exercising.
IMPORTANT
PLEASE READ ALL INSTRUCTIONS CAREFULLY BEFORE ASSEMBLING
FIGURE 1 - ASSEMBLY
Tools needed for assembly: Hammer, Adjustable Wrench
Model CTE2000E Children’s Circuit Training & Spinning Combo Bike

10
Step 5.
Step 6.
Step 7.
Tie a piece of string onto the REED
SWITCH WIRE (49), see Detail, and in-
sert string up through the HANDLEBAR
POST (5).
Holding the string, slide the HANDLE-
BAR POST (5) into FRAME (1), with
adjustment holes facing front, and lock
at desired height by threading LOCK-
ING LEVER HANDLE (26) into FRAME
(1) until tight.
Pull plug of REED SWITCH WIRE (49)
through hole at top of HANDLEBAR
POST (5).
FIGURE 2 - ASSEMBLY
49
FIGURE 2
DETAIL
126
Step 8.
Step 9.
Attach HANDLEBAR (6) to HANDLE-
BAR POST (5) with M8 x 15mm BOLTS
(33) and M8 SPRING WASHERS (39).
Plug EXTENSION WIRE (48) into REED
SWITCH WIRE (49), see Detail.
FIGURE 3 - ASSEMBLY
33
DETAIL
39
56
FIGURE 3
48
49
5
Model CTE2000E Children’s Circuit Training & Spinning Combo Bike

11
Directions for Use
- Adjust the adjust pads under the front & rear stabilizer.
- Adjust the saddle and the handlebar to desired height and lock with adjust knobs.
- Get on the bike, resistance can be adjusted with the tension knob.
Precautions
- Before starting the training consult a physician.
- If you feel faint or dizzy during the training stop immediately.
- The bike must be used under the supervision of an instructor.
- Do not use the bike for acrobatic exercises.
- Before beginning the exercising, set the knobs to their correct settings.
FIGURE 4
Step 10.
Step 11.
Step 12.
Remove the four SCREWS form the CONSOLE (30) and attach CONSOLE to HANDLEBAR
(6).
Plug CONSOLE WIRE into EXTENSION WIRE (48), see Detail “A”.
Carefully plug HAND PULSE WIRE into CONSOLE PULSE WIRE, see Detail “B”.
FIGURE 4 - ASSEMBLY
DETAIL “A” DETAIL “B”
30
6
SCREWS
CONSOLE
WIRE
48
CONSOLE
PULSE
WIRE
HAND
PULSE
WIRE
Model CTE2000E Children’s Circuit Training & Spinning Combo Bike

12
Monitor Operation
AUTO POWER ON/OFF
The monitor will be turned on automatically by pressing any
key or start exercising. The monitor will turn off automatically
if it does not detect any signals for 4 minutes.\
AUTO START/STOP
When you start exercising the monitor will display the prog-
ress of the exercise. When you stop exercising all functions
will remain displayed untill monitor turns off or you continue
exercising.
TIME
Time is displayed at the top left of the monitor and will count
up in one second increments.
TO PRESET TIME
1. Press MODE key until the TIME window is ashing.
2. Press SET key to increase and stop when it reach-
es the desired time.
3. When you start exercising the time will count down.
4. It will beep for 12 seconds to indicate the comple
tion of the workout. Press any key to stop beeping.
NOTES
1. To preset DISTANCE, CALORIE & MAXIMUM PULSE RATE, please refer to above proce
dure for preset TIME.
2. It is recomended to preset one function only at a time. If setting more that one function,
monitor will beep when reaching any of the default values.
3. The PULSE display will not beep after reaching the preset value. The display will ash con
tinuously while actual heartrate detected is over the preset value.
4. Press MODE key and setting will start for TIME, DISTANCE, CAL0RIES & PULSE. To skip a
function, do not press MODE again untill display stops ashing.
ACCUMLATED DISTANCE
Press and hold RESET key, TIME window will show accumlated distance. After releasing key all dis-
plays will reset to zero.
SPEED
Current speed will display in the left 2nd window.
DISTANCE
The distance will display in the left 4th window.
CALORIE
The calories burned will display in the 3rd window.
Model CTE2000E Children’s Circuit Training & Spinning Combo Bike

13
PULSE (Perfect pulse system)
Your current heart rate will display on the lower right LCD in beats per minute (BPM). Place the palms
of your hands on both contact pads and the monitor will display heart rate. (See diagram below.)
NOTE
1. If pulse value is not preset, the monitor will display the default value at 90 BPM.
2. If no pulse signal input within 16 seconds, the display will indicate “P”. It is a power saving function.
Press the up & down keys to restart pulse function.
RESET
Simply press RESET key and all
displays will zero except accum-
lated distance.
SPECIFICATIONS
FUNCTIONS
Current Speed 0.0 - 99.9 MPH or KPH
Calorie Consumption 0.0 - 99.0 - 100 - 999
Elapsed Time 00:00 - 99:59 (Minute:Second)
Trip Distance 0.00 - 999.9 MPH or KPH
Pulse Rate 40 - 240 BPH
DISPLAY Liquid Crystal Type
CONTROLLER 4 bit, 1 chip microprocessor
SENSOR Magnetic, non-contact
POWER SOURCE Requires 2 “AA” batteries
OPERATING TEMPERATURE 00C - +400C (320F - 1040F)
STORAGE TEMPERATURE -100C - +600C (140F - 1400F)
BATTERY REPLACEMENT
Note: Removing batteries will erase all stored
function readings.
1. Remove battery door from monitor.
2. Carefully remove old batteries.
3. Replace with 2 “AA” batteries and close battery
door.
BATTERY
DOOR
2 “AA”
BATTERIES
Model CTE2000E Children’s Circuit Training & Spinning Combo Bike

14
Parts List
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
Item Qty. Part Name
1
1
1
1
1
1
1 Set
1 Set
1 Set
1
1
1
- -
1
1
1
1
1
1
1
1
4
4
2
1
2
2
1
1
1
1
6
4
2
6
1 set
4
2 sets
4
4
L/R
2
2
1
2
2
10
1
1
2
Frame
Front Stabilizer
Rear Stabilizer
Seat Post
Handlebar Post
Handlebar
Pedal
Crank Arm
Bottom Bracket Set
Drive Pulley
Belt
Idler Pulley Section
- - - - -
Axle of Center Pulley
Single Row Ball Bearing
Center Pulley
Belt
Axle of Inertia Pulley
Inertia Pulley
Alloy Plate
Brake Shoe
Adjust Pads
End Plate
Caster
Shroud
Locking Lever Handle
Sleeve
Saddle
Tension Knob w/Spring & 2
Nuts
Monitor
M8 x 73mm Carriage Bolt
M6 x 10mm Bolt
M8 x 15mm Bolt
M8 x 25mm Bolt
M8 x 10mm Bolt
M6 Eye Bolt with Nylon Nut
M8 Wave Washer
M8 x 28mm Screw
M8 Spring Washer
M8 Cap Nut
Hand Pulse
3/8” Flange Nut
Ball Bearing
Freewheel
Ball Bearing
3/8” Nut
M4 x 20mm Screw
Extension Wire
Reed Switch Wire
Allen Wrench
If this problem occurs:
Problem: The bike becomes uneven or it is
wobbling.
Fix: Adjust the rubber adjustment pads on
the front and rear stabilizers until the
bike stops wobbling.
Problem: While pedaling the belt slips and you
don’t have a smooth pedaling action.
Fix: Adjust the belt tightness.
Problem. The seat wobbles.
Fix: Tighten the nuts under the seat if they
are loose- Check the knob and plunger
to be certain plunger is engaged and
knob is tightened down.
Problem: The seat or handlebar is hard to adjust.
Fix: Lubricate pop pins, handlebar and seat
posts.
Troubleshooting Guide
Model CTE2000E Children’s Circuit Training & Spinning Combo Bike

15
47
25
42
30
48
41
49
28
4
6
39
33
18
36
14
43
32
45
87
34
20
46
15
44
45
17 43
19
9
42
34
7
9
238
24
31
27
26
21
16
22
40 37
23
24
38
36
1
12
42
3
11
10
8
25
31
22
22
23
37
40
26
47
47
29
41
41
41
5
Model CTE2000E Children’s Circuit Training & Spinning Combo Bike

Instructions for Belt Adjustment
Step 1. Use wrench and crank extractor, remove
CRANK ARMS (8)
CRANK
EXTRACTOR
WRENCH
8
Step 2. Remove SCREWS (47) and both SHROUDS
(25).
Step 3. Loosen 3/8 FLANGE NUTS (42) on each side.
Step 4. Tighten NUT of EYE BOLTS (36), the same
amount on each side, until slack is removed
from BELT (17).
Step 5. Make sure CENTER PULLEY (16) is properly
aligned and tighten 3/8 FLANGE NUTS (42)
on each side.
36
47
17
25
16
42
25
Prodigy Athletics and Fitness
Model CTE2000E Children’s Circuit Training & Spinning Combo Bike
