PRODIS NT2BHLO-HC User manual

NT SERIES
BACK BAR REFRIGERATION
USER MANUAL
NT100818UM Rev 1.1
NT1SLIM-HC - NT1BH-HC - NT1BHSP-HC - NT1BHLO-HC - NT1ST-HC - NT2BH-HC - NT2BHLO-HC - NT2BS-HC
NT2BSLO-HC - NT2ST-HC - NT3BH-HC - NT3BS-HC - NT3ST-HC - NT10-HC - NT10ST-HC - NT20-HC - NT20ST-HC

PART I
03. PROPER INSTALLATION, USE AND MAINTENANCE OF
THIS MACHINE ARE ALL IMPORTANT FOR MAINTAINING
EFFICIENCY AND USER SAFETY. IN ORDER TO REDUCE
THE FAILURE RATE PLEASE READ THESE INSTRUCTIONS
CAREFULLY. IMPROPER USE COULD RESULT IN EQUIPMENT
DAMAGE, PERSONAL INJURY OR EVEN DEATH.
04. DO NOT LET CHILDREN PLAY WITH THE CABINET OR
ITS PACKAGING MATERIALS.
05. AT LEAST TWO PEOPLE ARE REQUIRED TO POSITION
AND UNPACK THE CABINET OR IT IS RECOMMENDED THAT
A LIFTING DEVICE IS USED TO AVOID INJURY.
06. A QUALIFIED ENGINEER MUST PERFORM THE
INSTALLATION AND ONGOING MAINTENANCE OF THE
REFRIGERATOR.
07. WHEN OPERATING ALL PROCEDURES MUST BE
FOLLOWED IN ACCORDANCE WITH THESE INSTRUCTIONS
TO ENSURE NO DAMAGE OCCURS TO THE REFRIGERATION
SYSTEM.
08. DO NOT OPERATE THE UNIT IF THERE ARE
ANY UNAUTHORISED CHANGES TO THE ORIGINAL
MANUFACTURERS SPECIFICATIONS OR IF THE MACHINE
HAS BEEN MISUSED, ABUSED OR NEGLECTED.
09. DO NOT COVER THE FRONT VENTS, THERE MUST BE
A MINIMUM CLEARANCE OF 200MM AT THE REAR OF THE
REFRIGERATOR AT ALL TIMES DURING OPERATION.
10. DO NOT STORE FLAMMABLE GASES OR LIQUIDS IN OR
NEAR TO THE REFRIGERATOR.
11. DO NOT USE HIGH-PRESSURE WATER CLEANING
DEVICES TO CLEAN THE REFRIGERATOR.
12. IT IS THE USERS RESPONSIBILITY TO TAKE
APPROPRIATE MEASURES TO ENSURE THE SAFETY OF STAFF
OPERATING REFRIGERATOR.
13. IT IS THE USERS RESPONSIBILITY TO ENSURE THE
ONGOING MAINTENANCE OF THE REFRIGERATOR IS
COMPLETED IN ACCORDANCE WITH THE MANUFACTURERS
INSTRUCTIONS LAID OUT IN THIS MANUAL.
14. TO PREVENT ACCIDENTAL INJURIES KEEP THE AREA
SURROUNDING THE REFRIGERATOR CLEAN AND TIDY AND
FREE FROM OBSTRUCTIONS.
15. ALWAYS USE A DEDICATED ELECTRICAL OUTLET
FOR INSTALLATION. DO NOT USE EXTENSION CABLES
OR MULTI-PLUG ADAPTORS AS THIS COULD CAUSE
ELECTRICAL SHOCK, OVERHEATING OR FIRE.
16. NEVER OPERATE THE REFRIGERATOR WITH A
DAMAGED POWER CABLE AS THIS COULD CAUSE
ELECTRICAL SHOCK, OVERHEATING OR FIRE.
17. NEVER TWIST, BUNDLE, STRAIN OR EXCESSIVELY BEND
THE POWER CABLE AS THIS COULD CAUSE ELECTRICAL
SHOCK, OVERHEATING OR FIRE.
18. THIS UNIT IS DESIGNED FOR USE INDOORS ONLY,
USING THE CABINET OUTSIDE OR IN AN AREA SUBJECT TO
MOISTURE COULD CAUSE DAMAGE, ELECTRICAL SHOCK,
OVERHEATING OR FIRE.
19. THIS UNIT MUST BE INSTALLED ON A LEVEL FLOOR
WHICH IS CAPABLE OF SUPPORTING THE WEIGHT OF
THE UNIT WHEN FULLY LOADED. INSTALLATION ON AN
UNEVEN SURFACE COULD CAUSE DAMAGE, INJURY AND
BREAKDOWNS.
20. NEVER INSERT FINGERS OR OBJECTS INTO THE FANS
AS THEY ROTATE AT HIGH SPEED.
21. NEVER PLACE HEAVY OBJECTS OR ITEMS CONTAINING
WATER ON TOP OF THE UNIT AS THIS COULD CAUSE INJURY,
OR DAMAGE TO THE CABINET.
22. THIS REFRIGERATOR MUST BE INSTALLED AWAY
FROM HEAT SOURCES AND OUT OF DIRECT SUNLIGHT.
INSTALLATION IN A HOT ENVIRONMENT OR IN DIRECT
SUNLIGHT COULD CAUSE BREAK DOWNS AND WILL
ADVERSELY AFFECT COOLING EFFICIENCY AND
PERFORMANCE.
23. ALWAYS TRANSPORT THIS COOLER IN AN UPRIGHT
POSITION AND NEVER TILT THE UNIT AT MORE THAN A 45°
ANGLE FROM VERTICAL.
1 NT100818UM Rev 1.1
01. THIS MANUAL IS AN INTEGRAL PART OF THE
REFRIGERATOR AND SHOULD BE KEPT AND PRESERVED
BY THE USER FOR FUTURE REFERENCE. PLEASE READ
THE INSTRUCTIONS CAREFULLY FOR THE CORRECT
INSTALLATION METHOD, SAFETY WARNINGS AND
MAINTENANCE INFORMATION FOR THIS REFRIGERATOR.
02. THIS REFRIGERATOR IS DESIGNED FOR COMMERCIAL
USE AND SHOULD BE USED FOR THE PURPOSE FOR WHICH
IT HAS BEEN EXPRESSLY DESIGNED. ANY OTHER USE
SHOULD BE CONSIDERED IMPROPER AND THEREFORE
DANGEROUS. THE MANUFACTURER WILL NOT BE LIABLE
OR RESPONSIBLE FOR ANY DAMAGE CAUSED BY IMPROPER,
INCORRECT OR UNREASONABLE USE.
IMPORTANT
WARNING: THE INSTALLATION OF THIS REFRIGERATOR
MUST BE CARRIED OUT BY QUALIFIED PERSONNEL IN
ACCORDANCE WITH CURRENT REGULATIONS AND AS
PER THE MANUFACTURERS INSTRUCTIONS. FAILURE TO
CORRECTLY INSTALL THIS REFRIGERATOR COULD RESULT
IN DAMAGE OR INJURY AND WILL VOID THE WARRANTY.
INSTALLATION
TABLE OF CONTENTS
PART I - WARNINGS PART II - INSTALLATION
PART III - OPERATING INSTRUCTIONS PART IV - MAINTENANCE AND CLEANING
PART V - TROUBLESHOOTING

PART II
iv. REMOVE THE PROTECTIVE PLASTIC FILM (IF
PRESENT) FROM THE EXTERIOR BEFORE INSTALLATION.
IF THE REFRIGERATOR HAS BEEN EXPOSED TO SUN
OR HEAT ALLOW THE REFRIGERATOR TO COOL
DOWN BEFORE REMOVING THE PROTECTIVE FILM.
iv. REMOVE THE ACCESSORY PACK AND CHECK THE
CONTENTS, IT SHOULD CONTAIN
1 x SET OF KEYS (IF LOCK FITTED)
1 x INSTRUCTION MANUAL
1 x DIGITAL CONTROLLER MANUAL
01. UNPACKING
WARNING
KEEP ALL PACKAGING MATERIALS INCLUDING BOXES,
PLASTIC BAGS AND POLYTHENE OUT OF REACH OF
CHILDREN
IMPORTANT
i. REMOVE ALL SHIPPING MATERIALS, TAPE AND
PACKAGING FROM THE BOTH OUTSIDE AND INSIDE THE
REFRIGERATOR. IF PACKAGING MATERIAL IS LEFT INSIDE
THE REFRIGERATOR IT WILL NOT FUNCTION CORRECTLY
ii. AFTER REMOVING THE PACKAGING MAKE SURE THE
REFRIGERATOR IS IN GOOD CONDITION. IF IN DOUBT
PLEASE DO NOT INSTALL OR USE THE REFRIGERATOR AND
CONTACT YOUR SUPPLIER IMMEDIATELY.
iii. REMOVE THE SHIPPING TAPE WHICH IS HOLDING THE
DOOR CLOSED.
WARNING
THIS REFRIGERATOR IS NOT INTENDED FOR OUTDOOR
USE. NORMAL OPERATING TEMPERATURES FOR THIS
REFRIGERATOR ARE BETWEEN 10°C AND 30°C. USE OF
THIS REFRIGERATOR OUTSIDE OF THE DEFINED OPERATING
PARAMETERS WILL AFFECT COOLING AND MAY DAMAGE
THE UNIT.
01. ENSURE THERE IS A FREE FLOW OF CLEAN
AIR AVAILABLE AT THE FRONT AND REAR OF THE
REFRIGERATOR.
02. THIS REFRIGERATOR SHOULD NOT BE INSTALLED
CLOSE TO A HEAT SOURCE (RADIATOR, STOVE OR HEATER)
OR EXPOSED TO DIRECT SUNLIGHT.
03. THE INSTALLATION LOCATION SHOULD BE FIRM AND
LEVEL AND ABLE TO SUPPORT THE FULL WEIGHT OF THE
REFRIGERATOR WHEN FULLY LOADED.
04. ALLOW AT LEAST 200MM CLEARANCE AT THE
REAR FOR PROPER AIR CIRCULATION AND EASE OF
MAINTENANCE.
05. THIS REFRIGERATOR IS NOT SUITABLE FOR
INSTALLATION IN AREAS WHERE WATER IS FREE FLOWING
OR HIGH PRESSURE WATER JETS ARE USED.
LOCATION
2
NT100818UM Rev 1.1
01. CARE SHOULD BE TAKEN TO ENSURE THE
REFRIGERATOR IS PERFECTLY LEVEL FOR CORRECT
OPERATION. A SPIRIT LEVEL SHOULD BE USED TO CHECK
THE UNIT IS PERFECTLY LEVEL, IF THE UNIT IS NOT LEVEL
WATER LEAKS MAY OCCUR.
LEVELLING THE REFRIGERATOR
WARNING
ALL WIRING AND ELECTRICAL CONNECTIONS MUST
CONFORM TO NATIONAL REGULATIONS. ALL ELECTRICAL
CONNECTIONS MUST BE UNDERTAKEN BY A COMPETENT
ENGINEER OR A QUALIFIED ELECTRICIAN.
ELECTRICAL CONNECTION
01. THIS REFRIGERATOR MUST BE PLUGGED IN TO AN
INDEPENDENT POWER SOURCE OR AN ELECTRICAL SOCKET
OF VOLTAGE AND FREQUENCY SPECIFIED. ELECTRICAL
RATING INFORMATION CAN BE FOUND ON THE DATA PLATE
OF THE REFRIGERATOR.
02. THIS REFRIGERATOR MUST BE CONNECTED TO AN
INDEPENDENT CIRCUIT BREAKER OR FUSE.
03. DUE TO POTENTIAL SAFETY HAZARDS THIS
REFRIGERATOR IS NOT RECOMMENDED FOR USE WITH AN
EXTENSION LEAD
ALL REFRIGERATORS HAVE BEEN FACTORY PRESET
BEFORE SHIPMENT. ADJUSTMENTS TO THE PROGRAM OR
SETTINGS ARE NOT REQUIRED FOR A NEW REFRIGERATOR
INSTALLATION. IN ORDER TO ENSURE NORMAL
OPERATION OF THE REFRIGERATOR PLEASE REFER TO
PART III OF THIS MANUAL. ALWAYS REMEMBER THAT
CHECKING AND MONITORING OF THE REFRIGERATOR IS THE
RESPONSIBILITY OF THE OPERATOR.
PRE-INSTALLATION CHECK LIST
IS THE REFRIGERATOR INSTALLED ON A SOLID AND
LEVEL FLOOR
HAS ALL OF THE INNER AND OUTER PACKAGING BEEN
REMOVED FROM THE UNIT?
IS THERE PROPER VENTILATION AT THE FRONT AND
REAR OF THE REFRIGERATOR?
HAS THE REFRIGERATOR BEEN CLEANED INSIDE AND
OUT?
IS THE MACHINE CORRECTLY EARTHED?
IS THE POWER TO THE MACHINE SWITCHED
ON?
IS THE REFRIGERATOR LOCATED IN A ROOM WITH AN
AMBIENT TEMPERATURE BETWEEN 10°C AND 30°C?
HAVE ALL USERS BEEN FULLY TRAINED IN THE
OPERATION OF THE REFRIGERATOR?
HAS THE REFRIGERATOR BEEN ALLOWED TO STAND
FOR A MINIMUM OF 2 HOURS?

PART III
NT100818UM Rev 1.13
WARNING
IF THE POWER SUPPLY CABLE IS DAMAGED, DO NOT
INSTALL OR OPERATE THE MACHINE UNTIL THE CABLE
HAS BEEN REPLACED BY AN AUTHORISED SERVICE
PARTNER OR A QUALIFIED ENGINEER.
WARNING
ALL ELECTRICAL CONNECTIONS MUST CONFORM
TO LOCAL REGULATIONS AND BE CARRIED OUT BY A
QUALIFIED ENGINEER
OPERATING INSTRUCTIONS
WARNING
AFTER TURNING OFF YOUR REFRIGERATOR YOU MUST
WAIT AT LEAST 5 MINUTES BEFORE RESTARTING TO
AVOID DAMAGE TO THE COMPRESSOR
ALTERING THE TEMPERATURE (COOLERS FITTED WITH AN
SF-101 CONTROLLER)
YOUR COOLER FEATURES A DIGITAL CONTROLLER. ALL
PARAMETERS ARE PRESET AT THE FACTORY FOR OPTIMUM
COOLING PERFORMANCE AND EFFICIENCY. ALTERING
THE PARAMETERS OF THE DIGITAL CONTROLLER WILL
ADVERSELY AFFECT THE COOLING EFFICIENCY AND
PERFORMANCE OF THE COOLER.
TO CHANGE THE SET POINT OF YOUR COOLER PRESS AND
HOLD THE SET BUTTON, THE DISPLAY WILL FLASH AND THE
CURRENT SET TEMPERATURE WILL BE DISPLAYED. USE THE
UP AND DOWN ARROWS TO ADJUST THE TEMPERATURE
ACCORDING TO YOUR NEEDS AND PRESS THE SET BUTTON
AGAIN TO STORE THE NEW SET POINT.
CHANGING THE SET POINT WILL AFFECT THE
PERFORMANCE AND EFFICIENCY OF THE COOLER
AND SHOULD ONLY BE UNDERTAKEN BY A QUALIFIED
REFRIGERATION ENGINEER.
ALTERING THE TEMPERATURE (COOLERS WITH ELITECH
ECS-16 DIGITAL TEMPERATURE CONTROL)
SF-101
SET
2.2
refulgence
YOUR COOLER FEATURES A DIGITAL CONTROLLER. ALL
PARAMETERS ARE PRESET AT THE FACTORY FOR OPTIMUM
COOLING PERFORMANCE AND EFFICIENCY. ALTERING
THE PARAMETERS OF THE DIGITAL CONTROLLER WILL
ADVERSELY AFFECT THE COOLING EFFICIENCY AND
PERFORMANCE OF THE COOLER.
TO CHANGE THE SET POINT OF YOUR COOLER PRESS THE
SET BUTTON FOR 3 SECONDS UNTIL ST IS DISPLAYED IN
THE DISPLAY. WITH ST SHOWING IN THE DISPLAY PRESS
THE SET KEY AGAIN, THE CURRENT SET POINT IS NOW
DISPLAYED ON THE CONTROLLER. TO ADJUST THE SET
POINT USE THE UP AND DOWN ARROWS TO SELECT THE
NEW TEMPERATURE AND THEN PRESS SET ONCE AGAIN TO
STORE THE NEW VALUE.
CHANGING THE SET POINT WILL AFFECT THE
PERFORMANCE AND EFFICIENCY OF THE REFRIGERATOR
AND SHOULD ONLY BE UNDERTAKEN BY A QUALIFIED
REFRIGERATION ENGINEER.
ADJUSTING THE SHELVES
YOUR COOLER IS FITTED WITH ADJUSTABLE SHELVES
WHICH CAN BE MOVED TO SUIT DIFFERENT SIZE
PRODUCTS. TO ADJUST THE SHELVES REMOVE THE SHELF
COMPLETELY FROM THE UNIT TO REVEAL THE SHELF CLIPS.
LIFT THE SHELF CLIPS UPWARDS TO REMOVE THEM FROM
THE SUPPORT LADDER.
TO REINSTALL THE SHELF INTO THE CORRECT LOCATION
REPLACE THE CLIP INTO THE SUPPORT LADDER ENSURING
ALL CLIPS ARE AT THE SAME LEVEL AND REPLACE THE
SHELF
DEFROSTING
THIS REFRIGERATOR IS FITTED WITH AN AUTOMATIC
DEFROST SYSTEM. MANUALLY DEFROSTING IS NOT
REQUIRED UNDER NORMAL CIRCUMSTANCES.
IN HUMID CONDITIONS MOISTURE IN THE AIR MAY CAUSE
AN EXCESS BUILD UP ON FROST ON THE INSIDE OF THE
UNIT.
TO DEFROST YOUR COOLER UNLOAD THE CABINET AND
TURN OFF UNTIL ALL FROST AND ICE BUILD UP HAS
NATURALLY MELTED. A TOWEL MAY NEED TO BE PLACED
UNDER THE CABINET TO SOAK UP ANY EXCESS MOISTURE
GENERATED DURING DEFROST. IF FROST BUILD UP
REOCCURS AND THE CABINET IS WITHIN ITS NORMAL
AMBIENT OPERATING TEMPERATURE THE THERMOSTAT
MAY BE SET TOO LOW, ADJUST THE SET POINT TO THE
FACTORY DEFAULT SETTING OF 2°c.
NEVER TOUCH THE EVAPORATOR SURFACE WHEN THE
MACHINE IS RUNNING AS THIS MAY CAUSE INJURY TO
THE USER
NEVER REMOVE FROST OR ICE BUILD UP WITH A
SHARP IMPLEMENT OR TOOL AS THIS WILL DAMAGE
THE REFRIGERATION SYSTEM AND WILL VOID YOUR
WARRANTY
WARNING
WARNING

NT100818UM Rev 1.1 4
PART IV
LOADING YOUR CABINET
ALLOW YOUR CABINET TO RUN FOR 2 HOURS AFTER
INSTALLATION BEFORE LOADING PRODUCTS INTO THE
REFRIGERATOR.
ALWAYS LOAD YOUR REFRIGERATOR IN BATCHES, FULLY
LOADING YOUR CABINET WITH WARM PRODUCT WILL
INCREASE THE CABINET TEMPERATURE AND MAY CAUSE
LOSS OF PRODUCT.
WHEN LOADING YOUR REFRIGERATOR ALWAYS ALLOW
ADEQUATE SPACE FOR FLOW OF AIR INSIDE THE CABINET.
NEVER LOAD PRODUCTS TOUCHING THE INTERIOR WALLS
OF THE UNIT. NEVER LOAD PRODUCTS SO THAT THEY ARE
OVERHANGING THE SHELVES. THE SPACE BETWEEN THE
FRONT OF THE SHELF AND THE DOOR IS DESIGNED TO
ASSIST AIR FLOW, NEVER BLOCK THIS SPACE.
ALWAYS LOAD YOUR REFRIGERATOR WITH CARE, NEVER
THROW OR DROP ITEMS ON TO THE SHELVES AS THIS
COULD CAUSE DAMAGE TO THE INSIDE OF THE CABINET OR
DISLOCATE THE SHELF CAUSING DAMAGE OR INJURY.
OPERATING THE INTERIOR LIGHTS
THE INTERIOR LIGHTING CAN BE SWITCHED OFF AT
NIGHT OR WHEN THE CABINET IS NOT IN USE TO SAVE
ELECTRICITY AND REDUCE RUNNING COSTS.
OPERATING THE LIGHT (COOLERS FITTED WITH ELITECH
ECS-16 CONTROLLER)
YOUR CABINET FEATURES A DIGITAL
TEMPERATURE CONTROLLER WHICH ALSO CONTROLS
THE LIGHTS. TO TURN THE LIGHTING ON AND OFF SIMPLY
PRESS THE BUTTON WITH THE LIGHT BULB ICON.
OPERATING THE LIGHT (COOLERS FITTED WITH SF-101
CONTROLLER)
YOUR CABINET FEATURES A DIGITAL
TEMPERATURE CONTROLLER WHICH ALSO CONTROLS
THE LIGHTS. TO TURN THE LIGHTING ON AND OFF SIMPLY
PRESS THE BUTTON WITH THE LIGHT BULB ICON.
EFFICIENT USE
TO PREVENT COLD AIR FROM ESCAPING OPEN AND CLOSE
THE DOOR QUICKLY.
ALWAYS LOAD YOUR CABINET TO ALLOW FOR SUFFICIENT
AIRFLOW BETWEEN PRODUCTS.
ALWAYS TRY TO KEEP YOUR CABINET AS FULLY LOADED
WITH COLD PRODUCE AS POSSIBLE.
INSTALL THE UNIT IN A WELL VENTILATED AREA WHERE THE
AMBIENT TEMPERATURE WILL NOT RISE ABOVE 30°C.
THE CABINET IS SUITABLE FOR USE IN CONDITIONS UP TO
55% RELATIVE HUMIDITY. CONDITIONS ABOVE THE RATED
VALUE WILL CAUSE EXCESS FROST AND ICE BUILD UP
WHICH WILL AFFECT THE PERFORMANCE AND EFFICIENCY
OR THE REFRIGERATION SYSTEM
DEFROST YOUR CABINET REGULARLY TO KEEP ICE BUILD UP
AND FROST TO A MINIMUM TO INCREASE EFFICIENCY
EFFICIENT USE
TO PREVENT COLD AIR FROM ESCAPING OPEN AND CLOSE
THE DOOR QUICKLY.
ALWAYS LOAD YOUR CABINET TO ALLOW FOR SUFFICIENT
AIRFLOW BETWEEN PRODUCTS.
ALWAYS TRY TO KEEP YOUR CABINET AS FULLY LOADED
WITH COLD PRODUCE AS POSSIBLE.
INSTALL THE UNIT IS A WELL VENTILATED AREA WHERE THE
AMBIENT TEMPERATURE WILL NOT RISE ABOVE 30°C.
THE CABINET IS SUITABLE FOR USE IN CONDITIONS UP TO
55% RELATIVE HUMIDITY. CONDITIONS ABOVE THE RATED
VALUE WILL CAUSE EXCESS FROST AND ICE BUILD UP
WHICH WILL AFFECT THE PERFORMANCE AND EFFICIENCY
OR THE REFRIGERATION SYSTEM
DEFROST YOUR CABINET REGULARLY TO KEEP ICE BUILD UP
AND FROST TO A MINIMUM TO INCREASE EFFICIENCY
EXTERIOR CLEANING
ALWAYS CLEAN THE EXTERIOR OF THE REFRIGERATOR WITH
A MICRO-FIBRE CLOTH AND OR A SPONGE.
DO NOT USE ABRASIVE OR METALLIC PRODUCTS (WIRE
WOOL) WHICH COULD SCRATCH AND DAMAGE THE FINISH
OF THE REFRIGERATOR PERMANENTLY.
GLASS CLEANING
CLEAN THE GLASS DOORS OF THE FRIDGE WITH GLASS
CLEANING CHEMICALS AND WIPE DRY WITH PAPER TOWELS
TO AVOID SMEARS.
INTERIOR CLEANING
CLEAN THE INTERIOR OF THE REFRIGERATOR AND ALL
REMOVABLE PARTS BY WASHING THEM WITH A SOLUTION
OF LUKEWARM WATER AND A SMALL AMOUNT OF DISH-
WASHING LIQUID. RINSE AND DRY IMMEDIATELY.
WARNING
ALTHOUGH THE REFRIGERATOR HAS BEEN TESTED AND
CLEANED AT THE FACTORY DIRT AND PARTICLES MAY OF
ENTERED THE CABINET DURING TRANSIT, UNPACKING
AND INSTALLATION. DUE TO THIS IT IS IMPORTANT THAT
YOUR REFRIGERATOR IS CLEANED INSIDE AND OUT
BEFORE OPERATION.
PART III

PART IV
NT100818UM Rev 1.1
5
WARNING
DISCONNECT THE MACHINE FROM THE MAINS
ELECTRICITY BEFORE PERFORMING ANY CLEANING OR
MAINTENANCE.
WARNING
NEVER CLEAN THE REFRIGERATOR WITH A PRESSURE
WASHER OR BY SPRAYING WATER.
WARNING
NEVER USE ACIDIC OR ABRASIVE DETERGENTS, THESE
TYPES OF CLEANERS MAY DAMAGE THE INTERIOR AND
EXTERIOR OF THE REFRIGERATOR AND MAY LEAD TO
DISCOLOURATION.
CONDENSER CLEANING
A DIRTY OR CLOGGED CONDENSER WILL PREVENT PROPER
AIR FLOW. THIS WILL LEAD TO REDUCED EFFICIENCY
AND AN INCREASE IN OPERATING TEMPERATURE WHICH
MAY LEAD TO COMPONENT FAILURE. WE RECOMMEND
THE CONDENSER IS CLEANED EVERY SIX MONTHS BY
A QUALIFIED ENGINEER. TO CLEAN THE CONDENSER
DISCONNECT THE REFRIGERATOR FROM THE
MAINS ELECTRICITY. REMOVE THE SCREWS FROM THE REAR
PANEL AND GENTLY REMOVE THE GRILL.
REMOVE DIRT AND DUST FROM THE CONDENSER FINS WITH
A SOFT BRUSH AND VACUUM CLEANER. REATTACH THE
GRILL AND RECONNECT POWER TO THE MACHINE.
WARNING
CONDENSER CLEANING SHOULD ONLY BE UNDERTAKEN
BY A QUALIFIED ENGINEER OR SERVICE PARTNER.
WARNING
FAILURE TO CLEAN YOUR CONDENSER COULD CAUSE
COMPONENT FAILURE AND WILL INVALIDATE YOUR
WARRANTY.
PREPARING YOUR REFRIGERATOR FOR LONG TERM
STORAGE OR MOVING
IF THE REFRIGERATOR NEEDS TO BE STORED FOR A LONG
PERIOD OF TIME OR IT NEEDS TO BE MOVED TO A NEW
LOCATION THE FOLLOWING STEPS MUST BE TAKEN
DISCONNECT THE UNIT FROM THE MAINS ELECTRICITY.
REMOVE ALL REMAINING PRODUCT FROM THE CABINET.
CLEAN THE INSIDE OF THE REFRIGERATOR AND
THOROUGHLY DRY THE INSIDE WITH PAPER TOWELS.
FOR TRANSPORTING TO A NEW LOCATION TAPE THE DOOR
SHUT WITH A LOW TACK TAPE (MASKING TAPE) OR LOCK
THE DOORS (WHERE LOCKS ARE FITTED)
FOR LONG TERM STORAGE LEAVE THE DOOR OPEN
AT LEAST 50MM TO ALLOW FOR AIR FLOW INTO THE
REFRIGERATOR. THIS WILL PREVENT MOLD AND MILDEW
FORMING.
NEVER STORE THE REFRIGERATOR IN AN AREA WHERE
CHILDREN COULD CLIMB INSIDE AND BECOME TRAPPED.
ALWAYS TRANSPORT YOUR CABINET IN AN UPRIGHT
POSITION AND NEVER TILT PAST A 45° ANGLE.
WARNING
AFTER LONG TERM STORAGE OR TRANSPORT YOU
NEED TO FOLLOW ALL INSTRUCTIONS IN PART II OF
THIS INSTRUCTION MANUAL WHEN REINSTALLING THE
MACHINE.
WARNING
ALWAYS TRANSPORT YOUR REFRIGERATOR IN AN
UPRIGHT POSITION AND NEVER TILT PAST A 45° ANGLE.

6
NT100818UM Rev 1.1
PART V
SYMPTOM POSSIBLE CAUSE SUGGESTED SOLUTION
UNIT WILL NOT SWITCH ON
UNIT IS NOT CONNECTED
TO MAINS ELECTRICITY
CORRECTLY
• CHECK POWER IS ON AT THE SOCKET
• CHECK CABLE IS CORRECTLY PLUGGED IN
MACHINE IS SWITCHED OFF • PRESS POWER ON/OFF BUTTON (WHERE FITTED)
FUSE BLOWN OR CIRCUIT
BREAKER TRIPPED
• CHECK FUSE IN MAIN 13AMP PLUG
• CHECK FUSE OR CIRCUIT BREAKER AT MAIN DISTRIBUTION BOARD
POWER CABLE IS DAMAGED • CHECK FOR DAMAGE ON POWER CABLE, USE A QUALIFIED ENGINEER TO
REPLACE IF NECESSARY
LOOSE CONNECTION OR
FAULTY CONTROLLER • CHECK FOR LOOSE CONNECTION, REPLACE IF NECESSARY
COMPRESSOR IS RUNNING BUT
REFRIGERATOR IS NOT COOLING
REFRIGERANT LEAK • CHECK FOR REFRIGERANT LEAK AND REPAIR, RECHARGE SYSTEM AS PER
THE DATA PLATE
SET POINT TOO HIGH • CHECK SET POINT OF THE CABINET, CHANGE IF NECESSARY
BLOCKAGE IN SYSTEM • CLEAR BLOCKAGE, REPLACE FILTER DRIER AND RECHARGE SYSTEM AS PER
THE DATA PLATE
COMPRESSOR WIRING LOOSE
OR DEFECTIVE • CHECK FOR LOOSE CONNECTION, REPLACE IF NECESSARY
LOOSE CONNECTION OR
FAULTY CONTROLLER • CHECK FOR LOOSE CONNECTION, REPLACE IF NECESSARY
REFRIGERATOR IS NOISY
UNIT IS NOT PROPERLY LEVEL • ENSURE UNIT IS INSTALLED ON A LEVEL AND SUITABLE FLOOR
CABINET IS TOUCHING
ANOTHER CABINET OR A WALL
• CHECK CORRECT VENTILATION GAP HAS BEEN ADHERED TO - 200MM AT
THE REAR
OBJECT IS FOULING
EVAPORATOR FAN
• CHECK FOR CORRECT LOADING OF PRODUCT AND ENSURE NOTHING IS
IN CONTACT WITH THE EVAPORATOR FAN OR FAN GUARD
REFRIGERATOR IS NOT GETTING COLD
ENOUGH
CONDENSER DIRTY • CLEAN CONDENSER AS NECESSARY
INADEQUATE AIR FLOW
AROUND REFRIGERATOR
• CHECK CORRECT VENTILATION GAP HAS BEEN ADHERED TO - 200MM AT
THE REAR
CONDENSER FAN NOT
WORKING • CHECK FOR LOOSE CONNECTION, REPLACE IF NECESSARY
EVAPORATOR FAN NOT
WORKING • CHECK FOR LOOSE CONNECTION, REPLACE IF NECESSARY
HIGH AMBIENT TEMPERATURE • WAIT UNTIL AMBIENT TEMPERATURE DROPS BELOW 30°C
FROST IS FORMING INSIDE THE UNIT
HUMIDITY ABOVE 55% • LOWER HUMIDITY OF THE ENVIRONMENT
DOOR OPENED TOO OFTEN • KEEP DOOR OPENINGS TO A MINIMUM
DOOR HAS BEEN LEFT OPEN • INITIATE MANUAL DEFROST AS LAID OUT IN THIS MANUAL
DOOR GASKET NOT SEALING
CORRECTLY • CHECK FOR DAMAGE/CRACKS, REPLACE IF NECESSARY
DEFROST NOT COMPLETING
CORRECTLY
• CHECK CONTROLLER PARAMETERS FOR DEFROST, ADJUST IF NECESSARY
(WHERE AVAILABLE)
WATER IS LEAKING FROM THE UNIT
CABINET IS NOT LEVEL • CHECK CABINET WITH SPIRIT LEVEL, ADJUST FEET AS NECESSARY
DEFROST WATER DRAIN HOLE
IS BLOCK
• CLEAR DRAIN HOLE AT THE REAR OF THE CABINET WITH A PIPE CLEANER
OR SIMILAR IMPLEMENT
TROUBLESHOOTING
WARNING
ALL MAINTENANCE AND SERVICE WORK
MUST BE UNDERTAKEN BY A QUALIFIED
REFRIGERATION ENGINEER OR AN
AUTHORISED SERVICE PARTNER.

PROJECT DISTRIBUTION LTD
UNIT 1 SUN STREET
STOKE-ON-TRENT
UNITED KINGDOM
ST1 4JW
TEL: [phone]
[e-mail]
WWW.PRODIS.CO.UK
NT100818UM Rev 1.1
