Operator’s Manual and Parts List
TDR-30
Rotary Finish Mowers
Serial No. 14301009 and up
PROGRESSIVE TURF EQUIPMENT INC.
137 WEST WILLIAM STREET
SEAFORTH, ONTARIO
CANADA N0K 1WO
TOLL FREE: 800 668-8873
ISSUE DATE: May 2017
P.N. 120537 www.progressiveturfequip.com

TDR-30 Operator’s Manual
1
TABLE OF CONTENTS PAGE
INTRODUCTION..............................................................................................................................3
FOREWORD ....................................................................................................................................3
ITEMS INCLUDED WITH TDR-30 MOWERS........................................................................4
SERIAL NUMBER LOCATION...............................................................................................4
REPLACEMENT PARTS INFORMATION.............................................................................4
UNAUTHORIZED MODIFICATION........................................................................................4
MISUSE OF EQUIPMENT .....................................................................................................5
NOTIFICATION OF UNAUTHORIZED MODIFICATION OR MISUSE..................................5
PRODUCT DESIGN...............................................................................................................5
SPECIFICATIONS ...........................................................................................................................6
COMPONENT IDENTIFICATION ....................................................................................................7
SAFETY RULES..............................................................................................................................8
SAFETY ALERT SYMBOL.....................................................................................................8
HAZARD SERIOUSNESS LEVEL .........................................................................................8
GENERAL SAFETY PRECAUTIONS ....................................................................................9
POWER UNIT SAFETY..........................................................................................................9
OPERATING EQUIPMENT SAFELY...................................................................................10
MAINTENANCE SAFETY PRECAUTIONS.........................................................................11
SAFETY DECALS .........................................................................................................................14
DECAL LOCATIONS............................................................................................................14
DECAL LISTING..................................................................................................................15
ASSEMBLY INSTRUCTIONS .......................................................................................................17
SET-UP ................................................................................................................................17
WING DECKS ......................................................................................................................17
OUTER WING DECK INSTALLATION ................................................................................20
DECK PTO SHAFTS............................................................................................................26
INPUT SHAFT......................................................................................................................27
TRANSPORT TIRES............................................................................................................27
BLADE INSTALLATION.......................................................................................................27
MOWER SETUP FOR OPERATION .............................................................................................28
HITCH ADJUSTMENT .........................................................................................................28
HITCHING THE MOWER TO THE TRACTOR....................................................................29
CONNECTING THE PTO DRIVELINE.................................................................................29
CONNECTING THE HYDRAULICS.....................................................................................30
CONNECTING THE PULL ROPE........................................................................................30
MOWER SAFETY LOCKS...................................................................................................30
CHECK PTO DRIVELINE DURING MANEUVERS .............................................................31
CHECK TIRE CONTACT DURING TURNS.........................................................................31
DISCONNECTING THE MOWER........................................................................................32
LONG-TERM STORAGE .....................................................................................................32
OPERATING THE MOWER...........................................................................................................33
DAILY CHECK LIST.............................................................................................................33
DECK LOCK SYSTEM.........................................................................................................33
RAISING AND LOWERING THE DECKS............................................................................35
ADJUSTING THE CUTTING HEIGHT .................................................................................36
ENGAGING THE MOWER...................................................................................................36
MOWING..............................................................................................................................37
PRO LIFT-N-TURNTM OPERATION.....................................................................................37
TRANSPORTING THE MOWER...................................................................................................38

TDR-30 Operator’s Manual
2
MAINTENANCE.............................................................................................................................39
LUBRICATION .....................................................................................................................39
“V” BELT DRIVE...................................................................................................................43
FASTENER INSTALLATION TORQUE...............................................................................44
BLADE SERVICING.............................................................................................................45
SPINDLE SERVICE .............................................................................................................48
HYDRAULICS ......................................................................................................................50
SUPPORTING MACHINE FOR SERVICE...........................................................................50
TRANSPORT TIRES............................................................................................................51
LONG-TERM STORAGE .....................................................................................................51
TROUBLESHOOTING .........................................................................................................52

TDR-30 Operator’s Manual
3
INTRODUCTION
Thank you for purchasing a TDR-30 mower. This product is designed and manufactured to allow safe
and productive mowing of large areas. A well-maintained machine will provide years of reliable service.
FOREWORD
This is the Operator’s Manual for the TDR-30 mower. Keep it with the mower at all times. This manual
is intended as a guide to the safe use and maintenance of the machine, so before you operate this
machine, study this manual carefully.
Replace this manual immediately if it becomes lost.
This manual is not considered all-inclusive, so for further information on specific components, e.g. PTO
shafts etc refer to the respective documents included with the manual set for this machine.
The TDR-30 series are production turf grass finishing rotary mowers with a 30 foot cutting width, and is
designed to be pulled by a 85-105 PTO horsepower tractor. High blade tip speed gives this versatile
mower the ability to mow both slightly contoured and flat terrain that requires a high quality after-cut
appearance. Full-width steel rollers reduce deck bounce during mowing and allow for higher mowing
speeds.Features:
Five independent, fully floating decks
Low power input per cutting width
Cut height can be set on each deck between 1/2 inch and 4 inches
Full-width steel rollers on front and rear deck allow increased mowing speed
Automatic mechanical deck locks for transport
Optional galvanized steel deck skins for increased service life
Applications:
Turf grass farms
Park lands and recreational areas
Grass runways

TDR-30 Operator’s Manual
4
OSHA Training Requirements (USA)
The following training requirements have been taken from Title 29, Code of Federal Regulations Part
1928.57 (a)(6). www.osha.gov
Operator Instructions: At the time of initial assignment and at least annually thereafter, the employer
shall instruct every employee in the safe operation and servicing of all covered equipment with which he
is or will be involved, including at least the following safe operating practices.
In other jurisdictions
It is good practice, following the initial instruction and at least annually thereafter, the employer shall
instruct every employee in the safe operation and servicing of all covered equipment with which he is or
will be involved, including at least the following safe operating practices.
ITEMS INCLUDED WITH TDR-30 MOWERS
TDR-30 Operator’s Manual & Parts List
Service instructions for PTO drive shafts and safety clutches
Cutting Height Adjustment Wrenches
Blade balancer tool
SERIAL NUMBER LOCATION
The serial number plate for the machine is located on the left-hand front
frame.
For quick reference, record the following information:
Model: TDR-30 ______________
Serial Number: ___________________________
Date purchased: ___________________________
REPLACEMENT PARTS INFORMATION
Use only Genuine Original Equipment Manufacturers (O.E.M.)
replacement parts. The use of “will fit” parts may reduce machine
performance, void machine warranties and present a safety hazard. Use
Genuine OEM parts.
UNAUTHORIZED MODIFICATION
Modifications to the original design of the TDR-30 mower, including the use of unauthorized
accessories or non-genuine OEM parts, may affect the reliability of the machine or make it unstable or
unsafe to operate and perform as originally designed and intended. Persons or organizations that make
unapproved modifications (including operation without provided guards and shields) assume all liability
arising from or related to the modification including any adverse effect on the machine.
No modification can be made to the original design or assembly of the TDR-30 mower (including any
and all attachments, safety or control devices) without the prior written consent of the Progressive Turf
Equipment Inc.’s Engineering Manager (see contact information below). Progressive Turf Equipment
Inc. retains the right to reject all claims which arise from or are related to unauthorized modifications.

TDR-30 Operator’s Manual
5
Modifications are officially approved if at least one of the following conditions is met:
i. The attachment, accessory or part is distributed by Progressive Turf Equipment Inc. and is
intended for a TDR-30 mower application and installed in an approved manner as
described in Progressive Turf Equipment Inc.’s provided instructions; or
ii. The modification has been approved in writing by the Progressive Turf Equipment Inc.’s
Engineering Manager.
No other entity is authorized by Progressive Turf Equipment Inc. to provide such approval.
MISUSE OF EQUIPMENT
It is incumbent upon the owner and selling dealer along with their respective employees to warn and
discourage users about the misuse of the equipment whenever knowledge of misuse becomes known,
whether the act has, is or could occur. Such acts include, but not limited to: riding upon, use of non-
OEM parts, operation on unstable or steeper slopes than specified, operating in explosive or fire-hazard
areas, modifications that alter the original machine specifications or use other than originally intended,
etc.
NOTIFICATION OF UNAUTHORIZED MODIFICATION OR MISUSE
If any person, employee, agent, dealer or distributor becomes aware of any Unauthorized Modification
or Misuse of a TDR-30 mower, either past or intended, it is the responsibility of that person to ensure
that Progressive Turf Equipment Inc.’s Engineering Manager is notified of the occurrence promptly.
That person shall provide; the facts of the occurrence, location, machine serial number, name and
contact information of the persons involved.
Send correspondence regarding Unauthorized Modification or Misuse to:
Progressive Turf Equipment Inc.
Box 940, 137 West William St.
Seaforth, Ontario, N0K 1W0
Canada
Attn: Engineering Manager
PRODUCT DESIGN
The TDR-30 mower has been designed and produced using generally acceptable manufacturing
processes as is standard in the industry for the type of equipment that is similar to the machine. As
such, the useful life of the machine is ten (10) years from the date of manufacture.
The official language of the manufacturer is English.
No responsibility is assumed for translations in other languages, which do not correspond to the original
meaning.
Under our policy of continuous improvement, we reserve the right to change specifications and designs
without prior notice. The illustrations shown do not necessarily represent the standard version of
product offered by Progressive Turf Equipment Inc.
*For clarity, some illustrations used in this manual show depictions with certain components removed.
Never operate the machine with any component or guard removed.

TDR-30 Operator’s Manual
6
SPECIFICATIONS
TDR-30
Tractor Requirement
Size (hp) ........................85-130.......................
PTO Input Speed (rpm) ...........................540 .........................
Hydraulic System Requirement ... (1) double-acting circuit with float..
Max. Hydraulic Pressure (psi) ..........................2500 ........................
Machine Specifications
Cutting Width (ft) ............................30 ..........................
No. of Blades ............................16 ..........................
Turning Radius (uncut circle, in) .............................0 ...........................
Cutting Height (in) Minimum ...........................1/2..........................
Maximum .............................4 ...........................
Transport Features Max. Speed ........................20 mph......................
Safety .........SMV Sign & Safety Chain........
Mower Decks
Skin .....................Galvanized...................
Configuration 5 deck staggered independent
Suspension 4-way floatation
Construction Replaceable 3/16 in thick skin with reinforced welded tube frame
Spindles 35mm shaft, double ball bearing with integral blade stiffener
Blades 24”diameter, 5/16” thick. (high-lift solid std., see options below)
Blade Mounting Two bolts/nuts per blade (No internal threads)
Blade Speed 2914 rpm / 18300 sfpm
Rollers (10) 6” Dia. Heavy wall steel with replaceable shafts
Roller Bearings Hex bore (positive drive) with triple lip seals. Ductile Iron housing
Ground Pressure 6 psi
Power Transmission
Input Shaft Cat. 6 1 3/8 dia –6 Spline, with auto locking collar
Deck Drive Shafts Cat. 3 1 3/8 dia –6 spline with quick connect yokes
Gearboxes (4) Cast Iron Housing /w Bevel gears
Deck Drive Fiber reinforced V-Belts
Belt Tensioning Positive draw bolt tensioner (2 per deck)
Transport Tires (2) Heavy Duty 33x16LL-16.1 Floatation, 8 bolt.
Productivity (acres/hr*) 2 mph ...................7.4...................
4 mph ..................14.6..................
6 mph ....................22 ...................
7.5 mph ....................27 ...................
Transport Dimensions (in) Width ....................94 ...................
Height ...................156 ..................
Length .............204 (17 ft) .............
Weight (lb) Machine ..................7400 .................
Tongue (transport) ..................1850 .................
Tongue (mowing) ...................560 ..................
Optional *Low-Lift Solid Blades, Pro EZ-Change Blades (Std. & Low Lift)
*assumes no stopping or overlap

TDR-30 Operator’s Manual
7
COMPONENT IDENTIFICATION
NOTES
1) Throughout this manual, references are made to
right and left directions. These are determined
by standing at the rear of the equipment and
facing the direction of forward travel.
PARKING
JACK
INPUT PTO
SHAFT
DRAW
CLEVIS
PULL
ROPE
DECK LIFT
CYLINDERS
DECK SAFETY LOCKS
DECK ROLLER
(FRONT& REAR EACH DECK)
DECK GEAR
BOX
TRANSPORT
SAFETY CHAIN
4-WAY GEAR
BOX
HYDRAULIC
CONNECTION
DECK ADJUSTMENT
WRENCH
OPERATOR’S
MANUAL
HOSE
SUPPORT

TDR-30 Operator’s Manual
8
SAFETY RULES
All rotary mowers are potentially dangerous machines; this mower has
been designed to minimize the safety risks to the operator, bystanders
and property. This section of the Operator’s Manual details a number of
safety rules pertaining to the operation and maintenance of Progressive
Turf Equipment mowers. In order to minimize risks and promote safety
at all times, these rules must always be followed and obeyed.
Further safety rules and warning texts are given within the respective
sections of this manual.
IMPORTANT! - When it comes to safety, nothing will ever replace a
careful operator.
It is imperative that the operator and safety personnel read and
understand all of the safety information in this manual before proceeding.
Failure to follow the instructions or heed the warnings could result in
injury or death.
Proper care is your responsibility.
The manufacturer cannot anticipate every possible circumstance that
might involve a hazard. The hazard alerts in this publication and on the
product, are therefore not all inclusive. If a tool, procedure, work method,
or operating technique not specifically recommended by the
manufacturer is used, it is your responsibility to ensure that it is safe for
you and others. You should also ensure the machine will not be
damaged or made unsafe by the operation, maintenance, or repair
procedures you choose. Modifications or adaptations to the machine are
not allowed.
Various jurisdictions have specific requirements for work zone safety.
Know and adhere to your local requirements. Treat the instructions in
this manual as minimum requirements for safe operation.
SAFETY ALERT SYMBOL
This symbol appears at various points in the manual together with a
signal word and warning text. It means –Be alert! Your safety is
involved. This symbol is used throughout the manual to call attention to
areas in which carelessness or failure to follow specific procedures may
result in personal injury or component damage / malfunction or both.
HAZARD SERIOUSNESS LEVEL
The following signal words are found throughout the manual together
with the safety alert symbol to indicate the seriousness level of identified
hazards. Their selection is based on the consequence of human
interaction with a hazard.
DANGER! –Hazards or unsafe practices which WILL result in
severe personal injury or death.
WARNING!
–Hazards or unsafe practices that COULD result
in severe personal or death.
CAUTION!
–Hazards or unsafe practices that COULD result
in minor personal injury or product or property damage

TDR-30 Operator’s Manual
9
GENERAL SAFETY PRECAUTIONS
The operator of this machine must have sufficient knowledge and
instructions in the care and operation of this mower and the power
unit being used before he / she uses the machine. Do not allow
unauthorized persons or children to operate the machine. Do not
allow riders on the machine.
It is the obligation of the operator to make sure that all guards and
shields are in place on the machine. Safety decals must be in
place and be readable –accidents may otherwise occur. Contact
your dealer or the manufacturer for replacement manuals or
decals.
Never use a machine that does not have an operator’s manual
available. Learn and understand the safety signs and symbols on
the machine and the operator instructions before you begin to use
the machine.
Wear personal protective equipment. Know and use the protective
equipment that is to be worn when operating or servicing the
machine. Hard hats, protective glasses and face shields, protective
shoes, gloves, reflector type vests, and ear protection are types of
equipment that may be required. Prolonged exposure to loud noise
can cause hearing damage.
Never operate a mower while under the influence of drugs or
alcohol. These make reflexes slow and put you and others in grave
danger. Always make sure you have full concentration while
mowing.
Adhere strictly to all regulations at the worksite pertaining to the
operation of this equipment.
Always disengage power takeoff (PTO) when transporting or
traveling between work sites.
Be prepared for emergencies. Have a first aid kit, fire extinguisher
and emergency contact information available at the work site.
POWER UNIT SAFETY
The operator must have sufficient knowledge in the care and
operation of the power unit (tractor) before connecting power unit
to mower. Read and understand power unit operator’s manual
before connecting mower.
Power unit must be equipped with ROPS and seat belt. Foldable
ROPS must be secured in the upright position. Follow
recommendations of power unit manufacturer. Seat belt must be
worn at all times.
Power unit must be equipped with a 1-3/8” 6 spline 540 RPM PTO
connection. Never use PTO adapters to connect implements.
Never connect mower driveline to 1000 RPM PTO.
Hydraulic circuits to control mower functions must be set to 2500
psi maximum working pressure.

TDR-30 Operator’s Manual
10
OPERATING EQUIPMENT SAFELY
Never allow persons to stand between power unit and mower while
backing power unit up to hitch the mower.
Before hitching mower to power unit, place transmission in neutral,
set park brake, and turn engine off. Remove the ignition key.
Make sure locking collar on PTO shaft is properly locked. If the
PTO shaft comes off during operation, personal injury or
equipment damage could result.
Tall grass can hide obstacles. Carefully walk the entire area to be
mowed beforehand. Look for debris, rocks, tree limbs etc. that will
damage or be thrown by the mower blades. Identify objects that
cannot be removed. Set mower cutting height to avoid contact.
Disengage the PTO when crossing gravel areas or roadways.
Disengage the PTO and turn power unit off upon striking any
object. Inspect mower and repair any damage before continuing.
Mower blades can cause small objects and debris to be thrown
from under the mower deck at high speeds, up to 300 ft away.
Objects ejected by the mower blades can cause severe injury.
If the equipment should start to vibrate abnormally during
operation, stop the mower, shut down power unit, and immediately
check for the cause. Excess vibration is generally an indication of a
problem. Replace bent or damaged parts, do not attempt to
straighten a bent blade.
Ensure that no bystanders are within 10 ft of mower when wing
transport locks are released.
Keep all bystanders well away from the machine when it is
operating. Always maintain a safe operating distance from
personnel, other equipment, or vehicles.
Never operate the mower with shields or guards removed.
Never tamper with safety devices or operate the mower with them
removed. Check proper operation regularly.
Always disengage PTO, place all controls in neutral, turn power
unit off, set parking brake, and remove key before dismounting, for
any reason.
Never place hands or feet under mower deck when the mower is
operating or power unit engine is running.
Use extreme care when operating on uneven terrain.
Reduce speed when operating on slopes during wet conditions,
especially when making sharp turns.
Do not use the mower in limited visibility (e.g. at dusk, in fog,
heavy rain etc.). Mow only in daylight or good artificial light.
Disengage PTO and ensure blades are completely stopped before
raising wings.
Ensure deck safety locks are securely engaged before transporting
mower with wings in raised position.
Be aware of over-head obstacles such as trees, building
overhangs when transporting mower.

TDR-30 Operator’s Manual
11
Keep away from overhead electrical lines. Electrocution can occur
without direct contact
Clean reflectors, Slow Moving Vehicle sign and lights before
transporting. Use power unit hazard lights.
Before disconnecting from power unit, always place controls in
neutral, set park brake, turn engine off, and wait for all moving
parts to stop. Relieve hydraulic pressure per power unit
manufacturer’s instructions.
Ensure mower parking jack is securely fastened to mower frame
with supplied pin before removing hitch draw pin.
MAINTENANCE SAFETY PRECAUTIONS
Never make adjustments or repairs with the engine running. Always
disengage PTO, engage parking brake, turn engine off, lower wings to
cutting position and relieve hydraulic pressure before performing any
maintenance.
Observe and perform proper lock-out procedures for power unit if
attached to mower during service.
Keep nuts and bolts tight and properly torqued, especially blade
attachment bolts. Check that all cotter pins are properly installed.
Keep equipment in good condition.
Keep mower free of grass, leaves, or other debris build-up.
Never work on raised mower decks without safety locks in place.
Periodically check condition of safety devices, guards, and deflectors.
Replace only with manufacturer’s recommended parts.
Inspect and replace damaged blades. Use only original OEM parts.
Blades can fail from poor maintenance practices.
Handle mower blades carefully. They are sharp and can cut
unprotected skin. Use caution and wear gloves when handling them.
Check to make sure hydraulic hoses are not worn or damaged, and
are routed to avoid chafing.
Immediately replace any hydraulic hose that shows signs of swelling,
wear, leaks or damage so it does not burst.
Do not use your hand to check for hydraulic oil leaks. Use a piece of
cardboard instead.
Hydraulic fluid escaping under pressure can penetrate the skin
causing serious injury. If skin penetration occurs, seek medical
attention immediately. Relieve all pressure before disconnecting
hoses.
Do not bend or strike hydraulic lines, tubes or hoses, or reinstall them
in a bent or damaged condition.
Inspect tires daily for wear or damage. Check tire pressures weekly
with an accurate pressure gauge. Do not inflate tires beyond 35 psi.
Mounting and dismounting tires from rims can be dangerous and
should be performed by trained personnel using correct tools,
equipment and procedures.

TDR-30 Operator’s Manual
12
Never perform service on a machine that is supported solely by a
jack. Always ensure proper blocking is placed to support load
during service. Do not support the machine on cinder blocks,
hollow tiles or other members that may fail under continuous
load.
WELDING AND GRINDING WORK PRECAUTIONS
IMPORTANT! A fire extinguisher should be easily accessible during
all welding work.
Welding repairs are to be performed by a trained welder with proper
service instructions. Know the material to be welded and select the
correct welding procedure and materials (electrodes, rods, wire) that will
provide a weld metal strength equivalent to the parent material.
Move the machine to a clean, safe area before welding, grinding or using
a cutting torch on it. This type of work should only be done in a clean
area and not in places that contain combustible liquids, such as fuel
tanks, hydraulic pipes or similar.
Connect arc welder ground as close as possible to work area.
Work with extra care when welding, grinding or torch cutting near
flammable objects.
WORKING ON PAINTED SURFACES
Heated paint gives off poisonous gases. Therefore, paint must be
removed from an area with a radius of at least 4 in (10 cm) before
carrying out welding, grinding, or gas cutting. In addition to the health
hazard, the weld will be of inferior quality and strength if the paint is not
removed.
WORKING ON GALVANIZED / PLATED SURFACES
Only qualified welders should attempt a weld repair on galvanized or
plated components. Proper pre-welding surface preparation is required.
Always ensure proper ventilation, wear proper respiratory protective
equipment and avoid direct contact with smoke emitted from welding
process.

TDR-30 Operator’s Manual
13
HYDRAULIC SYSTEM SERVICE PRECAUTIONS
Risk of personal injury! Wear safety glasses
and use protective gloves.
Relieve all trapped pressure before performing any service to the
hydraulic system. Pressure can be maintained in the hydraulic circuits
long after the power source and pump have been shut down.
Relieve all pressure before disconnecting hoses or tubes.
Tighten all connections before applying pressure.
It is important that each person who comes in contact with the machine
be alert to any faults.
Follow these basic precautions:
Never adjust a pressure relief valve or other pressure-limiting
device to a higher pressure than specified.
Check to make sure hydraulic hoses are not worn or damaged,
and are routed to avoid chafing.
When connecting mower to tractor ensure hydraulic hoses have
sufficient slack for negotiating turns and uneven terrain.
Immediately replace any hydraulic hose that shows signs of
swelling, wear, leaks or damage so it does not burst.
Do not use your hand to check for hydraulic oil leaks. Use a
piece of cardboard instead. Hydraulic fluid escaping under
pressure can penetrate the skin causing serious injury. If skin
penetration occurs, seek medical attention immediately. Relieve
all pressure before disconnecting hoses.
Do not bend or strike high-pressure lines, tubes or hoses, or
reinstall them in a bent or damaged condition.
HYDRAULIC OIL HANDLING PRECAUTIONS
Oils can irritate and damage the eyes, throat, and sensitive skin. Avoid
contact.
Petroleum based oils are hazardous to the environment. Take special
care not to spill or discharge these fluids. Use approved containers and
methods to handle and dispose of them.
Use authorized disposal and recycling methods per jurisdictional
requirements.

TDR-30 Operator’s Manual
14
SAFETY DECALS
DECAL LOCATIONS
If decals become faded, damaged, or lost, replace immediately.
Order TDR-30 Decal Kit 607080
ITEM
DESCRIPTION
QTY
ITEM
DESCRIPTION
QTY
1
DANGER –READ MANUAL
1
11
PROGRESSIVE DECAL
2
2
CAUTION - TURNING
1
12
MODEL DECAL
2
3
CAUTION –REPLACE SHIELDS
8
13
CAUTION - PTO ALIGNMENT
1
4
COMPANY NAME
1
14
WING DECK BELT LAYOUT
2
5
DANGER - BLADE HAZARD
7
15
REAR DECK BELT LAYOUT
1
6
WARNING –OEM PARTS
1
16
CE –ROTATING DRIVELINE
5
7
CAUTION –DISENGAGE PTO
1
17
DANGER –ROTATING DRIVELINE
5
8
GREASING SCHEDULE
1
18
DANGER –GUARD MISSING
5
9
PTO GREASING
1
19
WARNING - BLADE HARDWARE
1
10
NOTICE –HITCH SETUP
2
20
GREASE POINT
14
5
(BOTH SIDES)
11
12
5
1
2
10
6
9
8
19
5
5
5
3(ALL SHIELDS)
5
5
3
7
16
(7 SHAFTS)
17
18
13
6
3
14
15
4
5
5
14

TDR-30 Operator’s Manual
15
DECAL LISTING
ITEM 1 ITEM 2
(209175) (209171)
ITEM 3 ITEM 4 ITEM 5
(209113) (521817) (209173)
ITEM 6 ITEM7 ITEM 8
(209115) (521820) (526003)
ITEM 11
209103
ITEM9 ITEM 10 ITEM 12
(526001) (521784) 209179
PROGRESSIVE
TDR-30
ROLLER MOWER

TDR-30 Operator’s Manual
16
ITEM 13 ITEM 14 ITEM 15
209189 527381 527383
ITEM 16 ITEM 17 ITEM 18
(210238) (210239) (210237)
ITEM 19 GREASE POINT DECAL
(209196) (521014)

TDR-30 Operator’s Manual
17
ASSEMBLY INSTRUCTIONS
SET-UP
The mower is shipped in a 90% assembled condition to facilitate
shipping of the mower in enclosed vans. Approximately 1 1/2
hours are required to complete the mower to field ready
condition. Assembly will be easier if components are aligned and
loosely assembled before tightening hardware. Recommended
torque values are found on page 44. Select a suitable working
area. A tractor or portable hydraulic supply is necessary to
complete assembly.
Assembly should be completed by a competent individual who
has an understanding of safe machinery operation practices and
tool operation. Always use personal protection devices such as
eye and ear protection during assembly. Ensure the area is free
of hazards and can accommodate the assembly of the mower
WING DECKS
1) With the mower parked in a level work area, place deck spreader fixture (PTE 526498) underneath the
mower frame, centered between the wing decks on the floor, see photos below. This spreader prevents
the decks from swinging beneath the mower frame when the wings are initially lowered, allowing for
proper deck swivel pin alignment in subsequent steps.
If the 526498 deck spreader is unavailable, an alternative is to place suitable wood blocking under the
frame with a width of 75.5 in. The blocking must be arranged so that the decks cannot swing under the
main frame when lowered from the transport position.

TDR-30 Operator’s Manual
18
2) With the TDR Spreader Fixture (526498) in place, attach a ratchet equipped strap between both wing
decks using the points shown.
3) Tighten the device until enough tension is relieved from the shipping brace bar. Remove the wire securing
the flat bar to the wing, and the flat bar itself.
Be sure to stay clear of the each wing deck as you loosen the ratchet strap.
The top of each deck will quickly swing outwards from the machine once
tension is released from the strap.
4) Connect the mower to a hydraulic supply. Retract the hydraulic cylinders and release the deck locks.
Ensuring the deck spreader prevents the decks from swinging under the main frame; lower all decks until
they are fully resting on the ground.
5) Remove each pin and shipping link on each side of the deck swivel. The unpainted shipping links & pin
may be suitably disposed of.
Never retract the wing cylinders into the lift and turn position when the decks
are not attached to the wings. You will damage the wing and lock
components; the force the cylinders supply is too great without the
counterweight of the decks.
6) Remove the wooden shipping blocks from the four stand-off arms.
Shipping Brace
Bar
