ProLights SIGMAPIX OUTDOORS SIGMAX39T1X2BF User manual

USER MANUAL
English version
SIGMAPIX OUTDOORS
Outdoor LED wall module, p.3,9mm, 3500nit,
Black or White Face
REV.01-07/23

Thank you for choosing PROLIGHTS
Please note that every PROLIGHTS product has been designed in Italy to meet quality and performance requirements
for professionals and designed and manufactured for the use and application as shown in this document.
Any other use, if not expressly indicated, could compromise the good condition/operation of the product and/or be
a source of danger.
This product is meant for professional use. Therefore, commercial use of this equipment is subject to the respectively
applicable national accident prevention rules and regulations.
Features, specications and appearance are subject to change without notice. Music & Lights S.r.l. and all afliated
companies disclaim liability for any injury, damage, direct or indirect loss, consequential or economic loss or any other
loss occasioned by the use of, inability to use or reliance on the information contained in this document.
Product user manual can be downloaded from the website www.prolights.it , or can be inquired to the ofcial
PROLIGHTS distributors of your territory (https://www.prolights.it/sales_network.html).
Scanning the below QR Code, you will access the download area of the product page, where you can nd a broad
set of always updated technical documentation: specications, user manual, technical drawings, photometrics,
personalities, xture rmware updates.
The PROLIGHTS Logo, PROLIGHTS names and all other trademark in this document pertaining to PROLIGHTS services
or PROLIGHTS product are trademarks OWNED or licensed by Music & Lights S.r.l., its afliates, and subsidiaries.
PROLIGHTS is a registered trademark by Music & Lights S.r.l. All right reserved. Music & Lights – Via A. Olivetti, snc -
04026 - Minturno (LT) ITALY.
Visit the download area
of the product page

PROLIGHTS - SIGMAPIX Outdoors 01
INDEX
SAFETY INFORMATION 02
1 - OPTIONAL ACCESSORIES 4
2 - TECHNICAL DRAWING 5
3 - PRODUCT OVERVIEW 6
4 - INSTALLATION 7
GROUND BAR STACKING SYSTEM................................................................................. 7
FLY BAR HANGING SYSTEM.......................................................................................... 11
5 - INSTALLATION OF SPECIAL CABINET ACCESSORIES 14
INDOOR LED 45° MODULE (OPTIONAL SIGMAX39TC1X1WF)................................... 14
6 - CONNECTION TO THE MAINS SUPPLY 19
7 - START UP 19
CONNECT AND DISCONNECT POWER FROM THE PRODUCT.................................. 19
8 - DATA CONNECTION 20
DATA CABLING .............................................................................................................. 20
MAIN AND BACKUP DATA LINE.................................................................................... 20
9 - LED DISPLAY CONTROL SETTING 22
SYSTEM CONFIGURATION............................................................................................ 22
RESOLUTION MANAGEMENT ...................................................................................... 23
LED SCREEN CONFIGURATION WITH NOVALCT ........................................................ 24
APPLICATION EXAMPLE................................................................................................ 26
10 - MAINTENANCE 29
MAINTENANCE AND CLEANING THE PRODUCT........................................................ 29
MAINTENANCE ON INDOOR PRODUCT ..................................................................... 29
MAINTENANCE ON OUTDOOR PRODUCT ................................................................. 30
CORRECT STARTUP/SHUTDOWN SEQUENCE............................................................. 30
TRANSPORTATION AND STORAGE.............................................................................. 30
GENERAL INDICATIONS FOR USE................................................................................ 31
TROUBLESHOOTING..................................................................................................... 32

PROLIGHTS - SIGMAPIX Outdoors02
SAFETY INFORMATION
WARNING!
• See https://www.prolights.it/product/SIGMAX39T1X1BF#download for installation
instructions.
• See https://www.prolights.it/product/SIGMAX39T1X1WF#download for installation
instructions.
• See https://www.prolights.it/product/SIGMAX39T1X2BF#download for installation
instructions.
• See https://www.prolights.it/product/SIGMAX39T1X2WF#download for installation
instructions.
• Please read carefully the instruction reported in this section before installing, powering,
operating or servicing the product and observe the indications also for its future handling.
This unit is not for household and residential use, only professional applications.
Connection to mains supply
• The Connection to the mains supply must be carried out by a qualied electrical
installer.
• Use only AC supplies 100-240V 50-60 Hz, the xture must be electrically connected
to ground (earth).
• Select the cable cross section in according with the maximum current draw of the
product and the possible number of products connected at the same power line.
• The AC mains power distribution circuit must be equipped with magnetic+residual
current circuit breaker protection.
• Do not connect it to a dimmer system; doing so may damage the product.
Protection and Warning against electrical shock
• Do not remove any cover from the product, always disconnect the product from AC
power before servicing.
• Ensure that the xture is electrically connected to ground (earth). And use only a
source of AC power that complies with local building and electrical codes and has
both overload and ground-fault (earth-fault) protection.
• Before using the xture, check that all power distribution equipment and cables are
in perfect condition and rated for the current requirements of all connected devices.
• Isolate the xture from power immediately if the power plug or any seal, cover, ca-
ble, or other components are damaged, defective, deformed or showing signs of
overheating.
• Do not reapply power until repairs have been completed.
• Refer any service operation not described in this manual to PROLIGHTS Service team
or an authorized PROLIGHTS service center.
Protection from burns and re
• The exterior of the xture becomes hot during use. Avoid contact by persons and
materials.
• Ensure that there is free and unobstructed airow around the xture.
• Keep ammable materials well away from the xture.
• Do not expose the front glass to sunlight or any other strong light source from any an-
gle. Lenses can focus the sun’s rays inside the xture, creating a potential re hazard.
• Do not attempt to bypass thermostatic switches or fuses.

PROLIGHTS - SIGMAPIX Outdoors 03
Installation
• Make sure that all visible parts of the product are in good visible condition before its
use or installation.
• Make sure the point of anchorage is stable before positioning the projector.
• When suspending the xture above ground level, secure it against failure of primary
attachments by attaching a safety cable that is approved as a safety attachment for
the weight of the xture to the attachment point on the main frame of the product. ln
case the safety cable, enter in action, it needs to be replaced with a new one.
• Install the product only in well ventilated places.
• For non temporary installations, ensure that the xture is securely fastened to a load-
bearing surface with suitable corrosionresistant hardware.
• For a temporary installation with clamps, ensure that the quarter-turn fastener and/or
screws are turned fully, and secured with a suitable safety cable.
IP65
Outdoor (temporary) use
• This product is rated with an IP (Ingress protection) for temporary outdoor use when
used and serviced according to the instruction contained in this document.
• Never use the xture in places subject to vibrations or bumps.
• Make certain that no inammable liquids, water or metal objects enter the xture.
• Excessive dust, smoke uid, and particle build up degrades performance, causes
overheating and will damage the xture.
• Damages caused by inadequate cleaning or maintenance are not covered by the
product warranty.
Maintenance
• Warning! Disconnect the xture from AC mains power and allow to cool for at least
10 minutes before handling.
• Only technicians who are authorized by PROLIGHTS or Authorised service partners
are permitted to open the xture.
• Users may carry out external cleaning, following the warnings and instructions pro-
vided, but any service operation not described in this manual must be referred to a
qualied service technician.
• Important! Excessive dust, smoke uid, and particle build up degrades performance,
causes overheating and will damage the xture. Damages caused by inadequate
cleaning or maintenance is not covered by the product warranty.
Disposal
• This product is supplied in compliance with European Directive 2012/19/EU – Waste
Electrical and Electronic Equipment (WEEE). To preserve the environment please dis-
pose/ recycle this product at the end of its life according to the local regulation.
The products to which this manual refers comply with:
• 2014/35/EU - Safety of electrical equipment supplied at low voltage (LVD).
• 2014/30/EU - Electromagnetic Compatibility (EMC).
• 2011/65/EU - Restriction of the use of certain hazardous substances (RoHS).
Other approvals

PROLIGHTS - SIGMAPIX Outdoors4
1 - OPTIONAL ACCESSORIES
• SXFCM80391X1 Flightcase 8 in1 per SIGMAX39T1X1
• SXFCM40391X2 Flightcase 4 in1 per SIGMAX39T1X2
• SIGMAX39TC1X1BF Modulo LED 45° outdoor, SMD1921 BF, p.3,9, 50x50cm, 128x128pix, 3500
nit, 8,6kg
• KSXHGB01 Fly bar / ground bar for SIGMAX and KAPPAX systems, 1 column
• KSXHGB02 Fly bar / ground bar for SIGMAX and KAPPAX systems, 2 columns
• KSXHGB01SLR Fly bar / ground bar for SIGMAX26BS1X1BF
• KSXHGB01C45LR Double side 45° cut y bar / ground bar for SIGMAX C cabinets
• KSXCJB Ground system back horizontal support for SIGMAX and KAPPAX series LED wall
• KSXBS21 2in1 back support for GAMMAX series LED wall for ground system xing
• KSXBS31 3in1 back support for GAMMAX series LED wall for ground system xing
• KSXBSC Back plate for GAMMAX series LED wall for ground system xing
• KSXGHR Ground system back horizontal reinforcement for SIGMAX & KAPPAX series LED wall
• SXXJ Metal joint used to connect 4 pcs SIGMAX series cabinets
• OXXJ Metal joint used to connect 4 pcs OMEGAX or SIGMAX cabinets, M10 hole
• OXFCIS100 Rigging/ground-stack structure ightcase OMEGAX-DELTAX LED-display, 100cm
• OXFCIS200 Rigging/ground-stack structure ightcase OMEGAX-DELTAX LED-display, 200cm
• OXFCSP Spare part ightcase for OMEGAX-DELTAX series LED-display
• OXACL01 Power cable for LED display series, L.140 cm
• OXACL10 Power cable for LED display series L.10 m
• SXDCL01 Data cable for SIGMAX LED display series assembled with RJ45, L 140 cm
• SXDCL10 Data cable for SIGMAX LED display series assembled with RJ45, L 10 m

PROLIGHTS - SIGMAPIX Outdoors 5
1000 mm
[39.4 in]
500 mm
[19.7 in]
82 mm
[3.2 in]
Fig. 01
Weight: 14,6 kg - 32,19 lbs
2 - TECHNICAL DRAWING
Fig. 02
Weight: 8,6 kg - 18,96 lbs
83 mm
[3,3 in]
500 mm
[19.7 in]
500 mm
[19.7 in]
SIGMAX39T1X2BF/ SIGMAX39T1X2WF
SIGMAX39T1X1BF/ SIGMAX39T1X1WF

PROLIGHTS - SIGMAPIX Outdoors6
3 - PRODUCT OVERVIEW
1. MODULE: single LED display module that makes up the cabinet with magnetic attachment
2. SIDE LOCK MECHANICS: Side Panel locking and unlocking mechanism.
3. UPPER LOCK MECHANICS: Upper Panel locking and unlocking mechanism.
4. SIGNAL CONNECTORS: Ethernet connectors for sending and receiving Data Information from the
controller.
5. POWER BOX LOCK: handle to release power box
6. POSITIONING PIN: allows to center and hook cabinet easier.
7. MOUNTING HOLE: to be used to x the cabinets together using a metal plate
8. CORNER PROTECTION: corner protection system with lock
9. CABINET HANDLE: handy handles for easy assembly.
10. LOCKING TAB: to hook cabinet to underside.
11. POWER IN CONNECTOR: for connection to the Mains 100-240V~/50-60Hz.
12. POWER OUT CONNECTOR: power output for connection of multiple units in series
13. MECHANICAL RELEASE OF LDM: mechanical release of single LED display module
14. ANGLE MECHANICS: allow both concave and convex precise installation of +10° / -10°
Fig 03
1
26
4
12
11
10 14
37
9
4
5
13
8

PROLIGHTS - SIGMAPIX Outdoors 7
Remove highlighted pins on the KSXHGB01 accessory for grounding applications.
If you use the KSXHGB02 accessory, remove highlighted pins for grounding applications.
Align the KSXHGB y/ground bar accessories, then adjust the height of the feet toward the ground
to keep the ground beam perfectly horizontal.
4 - INSTALLATION
GROUND BAR STACKING SYSTEM
Fig 04

PROLIGHTS - SIGMAPIX Outdoors8
Insert the KSXCJB accessory into the prepared slot in the KSXHGB, then lock it using the lever by
turning it following the closed padlock icon. after which align with respect to the horizontal plane
also the horizontal support if necessary by helping with a hexagonal wrench.
Hook the cabinet to the ground bar, taking care to align the holes in the screen with the pins in
the bar.
Hook the panels sideways and lock them by push and turning the locking lever.
Fig 05

PROLIGHTS - SIGMAPIX Outdoors 9
Pull the bracket knobs on the ground bar and slide it to the next ground bar to lock them to
each other.
NOTE: when connecting the bars, make sure there are no steps between one panel and
another horizontally and on the front of the panels.
Hook down the cabinet of the next row and lock them by push and turning the locking lever, and
continue horizontally forward.
Hook the panels sideways and lock them by turning the locking lever.
Fig 06

PROLIGHTS - SIGMAPIX Outdoors10
Install SIGMAX series LED wall back plates, KSXBSC accessory, for ground xing.
Finally, to stiffen the structure, install the KSXGHR accessory between the two rear supports,
and if the installation is complex help with the use of the SXXJ or OXXJ accessory.
Fig 07

PROLIGHTS - SIGMAPIX Outdoors 11
FLY BAR HANGING SYSTEM
Fig 08
Remove the noted feet and center pin on the KSXHGB01 accessory, then install the eye hook.
If you use the KSXHGB02 accessory, remove highlighted feet and center pins, then install the eye
hook.

PROLIGHTS - SIGMAPIX Outdoors12
Attach the flybar KSXHGB/KSXHGB02 to the truss with the help of fastening accessories such as
clamps and/or safety ropes.
Hook the cabinet to the KSXHGB01/KSXHGB02 y/ground bar accessories, taking care to align
the holes in the screen with the pins in the bar.
Hook down the panels of the next row and lock them by push and turning the locking lever, and
continue horizontally forward.
Fig 09

PROLIGHTS - SIGMAPIX Outdoors 13
Hook the panels sideways and lock them by push and turning the locking lever.
Pull the bracket knobs on the ground bar and slide it to the next ground bar to lock them to
each other.
NOTE: when connecting the bars, make sure there are no steps between one panel and
another horizontally and on the front of the panels.
Finally, when finished assembling the first row in the same way proceed with the others, and if
the installation is complex help with the use of the SXXJ or OXXJ accessory.
Fig 10

PROLIGHTS - SIGMAPIX Outdoors14
5 - INSTALLATION OF SPECIAL CABINET ACCESSORIES
INDOOR LED 45° MODULE (OPTIONAL SIGMAX39TC1X1WF)
Fig 11
The C Tile is a special 90° cutted edge panel on every side allowing to create 90° seamless
corner on every edge.
To arrange the cabinets at a 90° angle, proceed as described below:
Remove the side mechanical locking components highlighted in the image from the cabinet.
Assemble the SIGMAXCFM accessories as shown in the pictures.
On another cabinet remove the side mechanical locking components highlighted in the image
from the cabinet.

PROLIGHTS - SIGMAPIX Outdoors 15
Assemble the SIGMAXCMM accessories as shown in the pictures.
Hook the panels sideways and lock them by push and turning the locking lever.
Fig 12

PROLIGHTS - SIGMAPIX Outdoors16
To build a cube follow the following steps:
Remove from the cabinet the components highlighted in the image.
Remove the side mechanical locking components highlighted in the image from the cabinet.
Assemble the SIGMAXCFM and SIGMAXCMM accessories as shown in the pictures. Prepare
4 panels that will form the base of the cube with No.4 SIGMAXCMM and No.4 SIGMAXCFM.
Assemble No.8 SIGMAXCFM on cabinet that will close the cube.
Fig 13

PROLIGHTS - SIGMAPIX Outdoors 17
Hook the panels sideways and lock them by push and turning the locking lever.
Put the upper cabinet without tiles on the base, engage the locking levers
Fig 14

PROLIGHTS - SIGMAPIX Outdoors18
Finally reassemble the tiles on the cabinet.
Fig 15
This manual suits for next models
3
Table of contents
Other ProLights Monitor manuals
