Proscenic 807C User manual

Ultrasonic Mist Humidifier
User Manual
807C

Operation steps 2-4
Connect To Mobile Client 4-6
Maintenance Instruction 7
Trouble Shooting Guide 8
Attentions 1-2
Catalog

Attentions
1
Thank you for purchasing your new Ultrasonic Humidifier.
The humidifier helps you to restore an appropriate level of humidity and eliminate
the discomfort associated with dry air. We wish you many years of healthy indoor
air with this efficient and effective product.
We recommend you spend some time reading this instruction manual in order to
fully understand all the operational features it offers.
* Read all the safety instructions carefully before use and keep this instruction
manual for future reference.
Warning: Please be aware of the following points or you might be in danger of
high voltage charges or burn your body.
1. Never disassemble the base unit without consulting qualified personnel.
2. If the supply cord is damaged, it must be replaced by the manufacturer, its
service agent or similarly qualified persons in order to avoid a hazard.
3. Unplug appliance during filling, cleaning and maintenance.
4. Keep detergents and chemical solutions away from children.
5. Do not change attachment without definitive permission from our company
otherwise you might cause a hazard.
6. If any abnormal smell during normal operation, please switch off and
disconnect power supply and have qualified personnel amend.
7. If when cleaning with water, detergents & chemical solutions splash into
mouth & eyes, consult a doctor to refrain from serious hazard.
8. Never touch water in the water basin & components in the water when the
unit is in function.
9. Never switch on when there is no water in the water basin.
10. Never scrape transducer on your own.
11. Never let water splash into inner base unit to avoid components damage.

Attentions & Operation steps
2
12. Care should be taken when using the appliance due to emission of hot
water vapor.
13. Before cleaning and maintenance, the appliance must be disconnected
from the power supply.
14. Prior to cleaning or other maintenance, the appliance must be disconnect-
ed from the supply mains.
15. This appliance can be used by children aged from 8 years and above if
they have been given supervision or instruction concerning use of the appli-
ance in a safe way and if they understand the hazards involved. Cleaning and
user maintenance shall not be made by children unless they are older than 8
and supervised. Keep the appliance and its cord out of reach of children aged
less than 8 years. Cleaning and user maintenance shall not be made by
children without supervision.
16. Children should be supervised to ensure that they do not play with the
appliance.
17. Indoor use only.
Instructions For Usage
1. Put the machine on a flat
surface. 2. Fill the water into the water tank, and then tighten the tank cover.

Operation steps
3
7. Touch the symbol HEATING “ ” the warm mist will come out after 10~15 minutes. On the LED
display, it shows the same symbol “ ” . Touch again to stop the function. Mist will become cool.
10. Timer setting: There are 12 timer setting: 1,2,3,4,5,6,7,8,9,10,11,12 hours. Touch the symbol
TIMER “ ” , the LED display will show the desired setting timer. The timer shows the rest
operation time and decreases by 1 hours.
8. Constant humidity: Before you touch the symbol HUMIDITY “ ” , LED display shows the
current humidity. You may set the humidity arranged from 30%RH to 75%RH. It will increase by
5%RH.
9. Touch the symbol MODE “ ” , baby mode will be turn on (keep constant humidity at 55% with
warm mist and anion turn on). In baby mode,mist output speed cannot be set. Press symbol MODE
“ ” again to enter auto mode. Press MODE “ ” for two seconds to enter sleep mode. In sleep
mode, display and water tank indication light will turn off and “ ” will be turn on. Humidifier will
keep running. Touch any button to cancel sleep mode and display will turn on.
Temperature of the
air, degrees Celsius ≤66
65
68
60
70
58
72
57
76
53
78
50
80
48
90
36
84
43
92
35
94
34
88
38
86
40
82
45
98
31
96
32
100
30
≥102
25
74
55Humidity(%)
11. Auto Shut-Off: Once the water in the basin is too little to keep the machine working, the
machine will automatically stop working. LED shows the shape of lack of water “ ” . Refill the
water, and the machine will restart. If don’t refill water within 15 minutes, the machine will
automatically power off.
12. Slide the symbol MAX-MIN “ ” , AUTO mode is cancelled and the mist
output is in the first speed. You may select 7 desired levels of mist volume. The corresponding
strip symbol will appear on the display.
3. Put the water tank on the main
base.
5. Touch the symbol POWER “ ” on the machine. The machine will begin to work in AUTO mode.
Display shows AUTO symbol.
4. Check if the rated voltage meets the input voltage, and
plug into the socket. Then display shows the current
temperature and humidity.
Temperature Humidity
6. Touch the symbol ANION “ ” the anion generator works. On the LED display, it shows the
shape of anion “ ” . Touch again to stop the function.

Operation steps & Connect To Mobile Client
4
13. On the remote controller, the related symbol controls the corresponding function.
14. No matter in any working mode, if no any operation in about 15 seconds, the display will turn dim.
press any key to wake up the display.
Instructions For Usage
Connect To The Mobile Client —— Quick Connect mode
1. Configure the network. 2. Scan the QR code above to download the
APP, or search for “ProscenicHome" in the
APP store to download the APP.
3. In the power-on state, long press the key
“ ” 3 seconds until the WiFi indicator “ ”
flashes quickly.
• Take the water tank out of the unit, open the water tank cover and fill the tank
with clear water. Close the cover and put the tank onto the base unit carefully.
• Put the nozzle into the socket on top of the water tank.
• Connect the power supply, switch on the unit (NEVER RUN THE UNIT WHEN
THERE IS NO WATER IN WATER BASIN), the main connection lamp will on. The
unit will begin working.

Connect To Mobile Client
5
Connect To The Mobile Client —— Hotspot mode
1. Connect your phone to WiFi, scan the QR
code above, or search for “ProscenicHome” in
the app store to download the app.
2. In the power-on state, long press the key “ ”
for 6 seconds until the WiFi indicator “ ” Slow
flash.
4. APP add device: turn on the APP, select
add humidifier device and confirm WiFi
indicator “ ” flash.
5. Perform network configuration.
According to the APP page prompt, select
and enter the WiFi password to make the
device enter the connection state and wait
for the distribution network to complete.
Add device
Add device
Add device
Confirmation indicator
confirm
Change network
* Note: the host does not support 5.8g band WiFi network.

Connect To Mobile Client
6
3. Add a humidifier device to the app, switch to the hotspot mode, and confirm that the WiFi
indicator is in a slow flashing state.
4. According to the prompt of the APP interface, select WiFi and enter the password.
5. According to the APP interface prompt, turn on“Phone Settings - Wireless LAN(WiFi)”, select
“Proscenic-xxxx”network connection and return to APP. Perform network configuration and wait
for the distribution network to complete.
* Note: the host does not support 5.8g band WiFi network.
807C
LDS-xxxx
M7
H500
H600
Please select the purchased device
Click or pull up to load more
Please select the purchas
807C
......
......
indicator flashes slowly
Add a Device AP mode
make sure the WiFi indicator flashes slowly
Add a Device AP mode
make sure the WiFi indicator flashes slowly
Setting
Available networks...
WLAN
WLAN
807C
XXXXXXXX
XXXXXXXX
Setting
Available networks...
WLAN
WLAN
807C
XXXXXXXX
XXXXXXXX
Network Configuration
SmartLife-XXXX
807C
Device Choice
Cancel Refresh
SmartLife-XXXX
807C
Device Choice
Cancel Refresh
The humidifier supports intelligent speaker voice control.

Maintenance Instruction
7
Maintenance
In a case when the water is hard which means water contains too much calcium and
magnesium, it can cause a “white powder” problem and leave heavy scales on the
surface of water basin, transducer and inner surface of the water tank. Scales on
the surface of transducer will let the unit work improperly.
TECHNICAL DATA
• Model: 807C
• Heating power: 80W
• Humidify power: 30W
• Noise level: ≤38dB(A)
• Total power: 110W
• Water tank capacity: 5.3L(1.4gal)
• Evaporation Rate: ≥350mL/h
• Power supply: (JP: 110V-120V 60Hz)
(US: 120V 60Hz) (EU: 230V 50Hz)
We recommend
1. Use cold boiled water or distilled water.
2. Clean the transducer, water tank and basin unit every week.
3. Change the water in water tank more often to keep it fresh.
4. Make sure to pull out the water from the water tank and dry the water basin
before you store the unit unused for a long period of time.
5. Clean the whole unit and make sure that all parts of the unit are dried completely
before unused for longer period of time.
How to clean the transducer
1. Put 5-10 drops of cleaning abluent on the surface of the transducer, wait for
2-5 minutes.
2. Brush off the scale from the surface.
3. Rinse the transducer with clean water.
How to clean the basin unit
1. Clean the water basin with soft cloth and the cleaning abluent if there is scale in it.
2. If the scale is covered on the security switch, drop the cleaning abluent on the
scale and clean it out with the brush.
3. Rinse the water basin with clean water.

Trouble Shooting Guide
8
Trouble Shooting Guide
If any trouble is found in normal operation, please kindly refer to the following points:
Trouble Possible reasons Solution
Power lamp off, does not work No power supply Connect power supply, switch on
Power lamp on, no mist outlet
with wind
Abnormal smell mist 1. New unit
2. Dirty water or water sitting too long
1. Take out water tank, open cover,
let it stay 12 hours in cool position
2. Clean water tank, fill with clear water
1. No water in water tank
2. Security switch is too loose
1. Fill water into water tank
2. Tighten the switch
Power lamp on, unit doesn’t work Too much water in the water basin
Pull out same water from the water
basin, close the cover of water tank
tightly
Mist fog is too low
1. Too much scale in the water basin
2. Water is too dirty or water kept too
long in the tank
1. Clean transducer
2. Clean water tank, change to fresh
clear water
Abnormal noise
1. Resonant in water tank when
water is too low
2. Unit is on a unstable surface
1. Fill water into water tank
2. Move the unit to a stable flat surface
Mist fog coming out from around
nozzle
There are apertures between the
nozzle and water tank
Dip the nozzle in water for a while and
then fix it to the socket on water tank
Do not dispose this product as unsorted municipal waste, collection of such
waste separately for special treatment is necessary.
DISPOSAL

Proscenic Technology Co., Ltd. (Authorized)
Shenzhen Proscenic Technology Co., Ltd. (Manufacturer)
Address: 10F No. 112, Wende Rd., Zhongli Dist.,
Taoyuan City 320, Taiwan
E-mail: [email protected]
Web: www.proscenic.com
