PumpWorks Industrial PWA User manual

Rev. 3
4/17/2018

TABLE OF CONTENTS
Introduction
Introduction INTRO-2
Safety INTRO-3
Warranty INTRO-4
Product Description
General Description DESIGN-2
Part Description DESIGN-2,3
Nameplates DESIGN-4,5,6
Figures
Figure 1: PWA Pump DESIGN-2
Figure 2: PWA Power End Cross Sectional DESIGN-3
Figure 3: Pump Casing Nameplate –English DESIGN-4
Figure 4: Pump Casing ID Tag DESIGN-4
Figure 5: Pump Casing Nameplate –Metric DESIGN-5
Figure 6: Bearing Frame Nameplate DESIGN-6
Tables
Table 1: Hydraulic Sizes by Group DESIGN-2
Table 2: Pump Casing Parts DESIGN-2
Table 3: Power End Main Parts DESIGN-3
Table 4: Nameplate Description DESIGN-4
Table 5: Casing Nameplate Definitions - English DESIGN-4
Table 6: Casing Nameplate Definitions - Metric DESIGN-5
Table 7: Power End Nameplate Definitions DESIGN-6
Handling
Delivery Inspection HANDLE-1
Transportation HANDLE-2
Pump Handling HANDLE-2
Lifting Methods HANDLE-3,4,5
Storage HANDLE-5
Pump Storage Requirements HANDLE-5
Frost Proofing HANDLE-6
Figures
Figure 1: Bare Pump Lifting HANDLE-3
Figure 2: Base Mounted Pump Lifting HANDLE-3
Figure 3: Base Mounted Pump with Motor HANDLE-4
Figure 4: Fab Base Mounted Pump with Motor HANDLE-4
Figure 5: Bare Pump with Adapter Lifting HANDLE-5
Tables
Table 1: Lifting Methods HANDLE-2
Table 2: Storage Requirements HANDLE-5
Table 3: Frostproofing HANDLE-6
Installation
Pre-installation INSTALL-2
Pump Location Guidelines INSTALL-2
Foundation Requirements INSTALL-3
Baseplate Mounting Procedures INSTALL-3
Install the Baseplate INSTALL-3,4,5,6
Grout the baseplate INSTALL-6,7
Install the pump, driver, and coupling INSTALL-8
Pump-to-driver alignment INSTALL-8
Alignment checks INSTALL-8
Permitted indicator values for alignment checks INSTALL-9
Alignment measurement guidelines INSTALL-9
Attach the dial indicators for alignment INSTALL-10
Pump-to-driver alignment instructions INSTALL-10,11,12,13
Piping checklists INSTALL-13
General piping checklist INSTALL-14
Suction-piping checklist INSTALL-15,16,17
Discharge piping checklist INSTALL-18,19
Figures
Figure 1: Sleeve Type Bolts INSTALL-2
Figure 2: J Type Bolts INSTALL-3
Figure 3: Baseplate Top View INSTALL-3
Figure 4: Baseplate Side View INSTALL-4
Figure 5: Jackscrew Bolts INSTALL-5
Figure 6: Leveling Baseplate –Motor Pads INSTALL-5
Figure 7: Leveling Baseplate –Pump Pads INSTALL-6
Figure 8: Initial Grout INSTALL-6
Figure 9: Final Grout INSTALL-7
Figure 10: Dial Indicator Alignment INSTALL-9
Figure 11: Incorrect Vertical Alignment INSTALL-10
Figure 12: Incorrect Horizontal Alignment INSTALL-11
Figure 13: Correct Vertical Alignment INSTALL-12
Figure 14: Correct Horizontal Alignment INSTALL-12
Tables
Table 1: Guidelines for Locations INSTALL-2
Table 2: Alignment Checks INSTALL-8
Table 3: Cold Alignment INSTALL-8
Table 4: Hot Alignment INSTALL-8
Table 5: Alignment Measurement Guidelines INSTALL-9
Table 6: Angular Alignment for Vertical Corr. INSTALL-10
Table 7: Angular Alignment for Horizontal Corr. INSTALL-11
Table 8: Parallel Alignment for Vertical Corr. INSTALL-11
Table 9: Parallel Alignment for Horizontal Corr. INSTALL-12
Table 10: Piping Guidelines INSTALL-14
Table 11: Suction Piping Guidelines INSTALL-15,16
Table 12: Suction Piping Guidelines –Liq. Below INSTALL-16
Table 13: Suction Piping Guidelines –Liq. Above INSTALL-16
Table 14: Discharge Piping Guidelines INSTALL-18
Commissioning, Startup, Operation and Shutdown
Preparation for Startup STARTUP-2
Coupling Guard STARTUP-2,3,4
Pump Rotation STARTUP-4
Setting Impeller Clearance STARTUP-5
PWA Standard Impeller Clearances STARTUP-6
Dial Indicator Method STARTUP-6
Feeler Gauge Method STARTUP-7
Install Coupling STARTUP-7
Install Coupling Guard STARTUP-7-11
Bearing Lubrication STARTUP-11
Pump Priming STARTUP-12,13,14
Start Up Precautions STARTUP-15,16
Shut Down STARTUP-16
Figures
Figure 1: Guard Removal, Slide Driver Half STARTUP-2
Figure 2: Guard Removal, Driver Side End Plate STARTUP-3
Figure 3: Guard Removal, Driver Half STARTUP-3
Figure 4: Guard Removal, Pump Half STARTUP-4
Figure 5: Mounting Indicator STARTUP-6
Figure 6: Setting Impeller Clearance STARTUP-7
Figure 7: Required Guard Parts STARTUP-8
Rev. 3
4/17/2018

TABLE OF CONTENTS
Figure 8: Guard Install, Slide Pump Half STARTUP-9
Figure 9: Guard Install, Slide Motor Half STARTUP-10
Figure 10: Guard Install, Slide End Plate STARTUP-10
Figure 11: Guard Install, Slide Motor Half to Fit STARTUP-11
Figure 12: Power End –Lube Fill STARTUP-12
Figure 13: Pump Priming –Supply Above Pump STARTUP-13
Figure 14: Pump Priming –Foot Valve STARTUP-14
Figure 15: Pump Priming –Foot Valve and Bypass STARTUP-14
Tables
Table 1: Impeller Clearances STARTUP-5
Table 2: Guard Installation Guidelines STARTUP-8
Table 3: Lubrication Capacities STARTUP-11
Table 4: Oil Requirements Based on Temperature STARTUP-12
Table 5: Recommended Lubricants STARTUP-12
Maintenance
Schedule MAINT-2
Bearings MAINT-2
Lubrication Requirements MAINT-3
Mechanical Seal Maintenance MAINT-3
Disassembly MAINT-4
Precautions MAINT-4
Required Tools MAINT-4
Drain Pump MAINT-5
Coupling Removal MAINT-5
Back Pull-Out Removal MAINT-5
Impeller Removal MAINT-7
Casing Cover Removal MAINT-9,10
Bearing Frame Disassembly MAINT-11-21
Pre-Assembly Checks MAINT-21
Part Replacement Guidelines MAINT-22
Bearing Frame Inspection MAINT-26
Seal Chamber Inspection MAINT-27,28
Bearing Housing Inspection MAINT-28
Bearing Fits and Tolerances MAINT-30
Reassembly MAINT-31
Group 1,2 MAINT-31-36
Group 3 MAINT-36-39
Group 4 MAINT-40-43
Power Frame Assembly MAINT-43-47
ISOMAG Labyrinth Seal Information MAINT-47
Final Assembly Checks MAINT-48-55
Figures
Figure 1: Guard Removal MAINT-5
Figure 2: Back Pullout Removal MAINT-6
Figure 3: Coupling Hub Removal MAINT-7
Figure 4: Impeller Removal MAINT-7
Figure 5: Impeller O-Ring MAINT-8
Figure 6: Impeller Plug Removal (Group 4) MAINT-8
Figure 7: Impeller O-Ring (Group 4) MAINT-9
Figure 8: Seal Chamber Removal MAINT-10
Figure 9: Mechanical Seal Removal MAINT-10
Figure 10: Adapter Removal MAINT-11
Figure 11: Labyrinth Seal Removal MAINT-11
Figure 12: Shaft Assembly Removal MAINT-12
Figure 13: Hardware Removal MAINT-12
Figure 14: Bearing Housing Removal MAINT-13
Figure 15: Bearing Removal MAINT-13
Figure 16: Hardware Removal Grp 1/2 Duplex Brg MAINT-14
Figure 17: Bearing Removal Grp 1/2 Duplex Brg MAINT-14
Figure 18: Labyrinth Seal Removal –Brg Hsg MAINT-15
Figure 19: Shaft Assembly Removal MAINT-15
Figure 20: Hardware Removal Grp 3 MAINT-16
Figure 21: Bearing Removal Grp 3 MAINT-16
Figure 22: Labyrinth Seal Removal Grp 3 MAINT-17
Figure 23: Shaft Assembly Removal Grp 4 MAINT-17
Figure 24: Flinger and Bearing Removal Grp 4 MAINT-18
Figure 25: Bearing Housing Removal Grp 4 MAINT-18
Figure 26: Bearing Housing Disassembly Grp 4 MAINT-19
Figure 27: Shaft Assbly Removal Grp 4 Duplex Brg MAINT-19
Figure 28: Flinger and Brg Removal Grp 4 Duplex Brg MAINT-20
Figure 29: Brg Housing Removal Grp 4 Duplex Brg MAINT-20
Figure 30: Brg Hsg Disassembly Grp 4 Duplex Brg MAINT-21
Figure 31: Bearing Frame Disassembly Grp 4 MAINT-22
Figure 32: Casing Inspection MAINT-23
Figure 33: Impeller Wear Inspection MAINT-24
Figure 34: Shaft TIR Inspection MAINT-25
Figure 35: Bearing Frame Surface Inspection MAINT-26
Figure 36: Casing Cover Inspection –Std. Bore MAINT-27
Figure 37: Casing Cover Inspection –Big Bore MAINT-27
Figure 38: Casing Cover Inspection –Taper Bore MAINT-28
Figure 39: Bearing Housing Inspection Grp 1/2 MAINT-29
Figure 40: Bearing Housing Inspection Grp 3 MAINT-29
Figure 41: Bearing Housing Inspection Grp 4 MAINT-30
Figure 42: Bearing Frame Assembly MAINT-31
Figure 43: Shaft Assembly MAINT-32
Figure 44: Shaft Assembly Installation MAINT-33
Figure 45: Bearing Frame Assembly –Duplex Brg MAINT-34
Figure 46: Duplex Bearing Installation on Shaft MAINT-34
Figure 47: Shaft Assembly –Duplex Brg MAINT-35
Figure 48: Housing Assembly –Duplex Brg MAINT-35
Figure 49: Shaft Assembly Installation –Duplex Brg MAINT-36
Figure 50: Bearing Frame Assembly –Grp 3 MAINT-37
Figure 51: Duplex Bearing Installation on Shaft Grp 3 MAINT-37
Figure 52: Shaft Assembly Duplex Brg –Grr 3 MAINT-38
Figure 53: Housing Assembly –Grp 3 MAINT-38
Figure 54: Shaft Assembly Installation –Grp 3 MAINT-39
Figure 55: Bearing Frame Assembly –Grp 4 MAINT-40
Figure 56: Bearing Housing Assembly –Grp 4 MAINT-41
Figure 57: Flinger and Bearing Installation –Grp 4 MAINT-41
Figure 58: Final Assembly - Grp 4 MAINT-42
Figure 59: Shaft Assembly Installation - Grp 4 MAINT-42
Figure 60: Shaft End Play Inspection MAINT-43
Figure 61: Shaft Sleeve TIR Inspection MAINT-44
Figure 62: Frame Face TIR Inspection MAINT-44
Figure 63: Frame Adapter Installation MAINT-45
Figure 64: Frame Adapter TIR Inspection MAINT-45
Figure 65: Bearing Isolator Installation MAINT-46
Figure 66: ISOMAG Oil Seal Assembly MAINT-47
Figure 67: INPRO Labyrinth Oil Seal Assembly MAINT-48
Figure 68: Mechanical Seal Installation MAINT-50
Figure 69: Seal Chamber TIR Inspection MAINT-51
Figure 70: Shaft Sleeve Installation MAINT-51
Figure 71: Impeller Installation MAINT-52
Figure 72: Setting Impeller Clearance MAINT-53
Tables
Table 1: Oil Change Schedule MAINT-2
Table 2: Oil Fill Capacity MAINT-3
Table 3: Oil Requirements Based on Temp MAINT-3
Table 4: Recommended Oils MAINT-3
Table 5: Labyrinth Oil Seal Fit MAINT-11
Table 6: When to Replace Impeller MAINT-24
Table 7: Shaft TIR Tolerances MAINT-25
Rev. 3
4/17/2018

TABLE OF CONTENTS
Table 8: Bearing Housing Checks MAINT-28
Table 9: Bearing Fits and Tolerances MAINT-30
Table 10: Shaft End Play MAINT-43
Table 11: ISOMAG Oil Seal Detail MAINT-47
Table 12: ISOMAG Oil Seal Installation MAINT-47
Table 13: INPRO Labyrinth Oil Seal Installation MAINT-48
Table 14: INPRO Labyrinth Oil Seal Installation MAINT-49
Table 15: Impeller Installation MAINT-52
Table 16: Bolt Torque Values MAINT-54
Table 17: Casing Bolt Torque Values MAINT-55
Table 18: Bearing Designations MAINT-55
Parts List
Figures
Figure 1: Group 1 Pump Exploded View PARTS-4
Figure 2: Group 2 Pump Exploded View PARTS-4
Figure 3: Group 3 Pump Exploded View PARTS-5
Figure 4: Group 4 Pump Exploded View PARTS-5
Tables
Table 1: Parts Lists PARTS-2,3
Table 2: Key PARTS-3
Rev. 3
4/17/2018

INTRO-1
Introduction and Safety
Rev. 3
4/17/2018

INTRO-2
Introduction
The purpose of this manual is to provide necessary information for installation, operation
and maintenance of the PumpWorks Industrial Model PWA
CAUTION:
Read this manual carefully before installing and using the product. Improper use of the product can
cause personal injury and damage to property, and may void the warranty.
Safety terminology and symbols
About safety messages
It is extremely important that you read, understand, and follow the safety messages in this
manual before handling the product. They are published to help prevent these specific
hazards:
Personal accidents and health
Product damage
Product malfunction
Hazard criteria
DANGER:
A situation where a hazard, if not avoided, will result in serious bodily injury and/or death.
WARNING:
A situation where a hazard, if not avoided, could result in serious bodily injury and/or
death.
CAUTION:
A situation where a hazard, if not avoided, could result in less severe bodily injury.
NOTICE:
A potential situation, which if not avoided, could lead to product malfunctions.
Safety
WARNING:
The operator must be aware of safety precautions to prevent physical injury.
Any pressure-containing device can explode, rupture, or discharge its contents if it is over
pressurized. Take all necessary measures to avoid over-pressurization.
Operating, installing, or maintaining the unit in any way that is not intended could cause
death, serious personal injury, or damage to the equipment. This includes any
modification to the equipment or use of parts not provided by PW-IND. If there is a question
regarding the intended use of the equipment, please contact a PW-IND representative
before proceeding.
This manual clearly identifies accepted methods for disassembling units. These methods
must be followed. Trapped liquid can rapidly expand and result in a violent explosion and
injury. Never apply heat to impellers or their retaining devices to aid in their removal unless
explicitly stated in this manual.
If the pump/motor is damaged or leaking, do not operate as it may cause an electric shock,
fire, explosion, release of toxic fumes, physical harm, or environmental damage.
Correct/repair the problem prior to putting the pump back in service.
Do not change the service application without the approval of an authorized PW-IND
representative.
Rev. 3
4/17/2018

INTRO-3
User safety
General safety rules
These safety rules apply:
Always keep the work area clean.
Pay attention to the risks presented by gas and vapors in the work area.
Avoid all electrical dangers. Pay attention to the risks of electric shock or arc flash
hazards.
Safety equipment
Use safety equipment according to local regulations. Use this safety equipment
within the work area:
Helmet
Safety glasses
Protective shoes
Protective gloves
Gas mask
Hearing protection
Safety devices
NOTICE:
Never operate a unit unless safety devices are installed. Also see specific information about safety
devices in other chapters of this manual.
Electrical connections
Electrical connections must be made by certified electricians in compliance with all
international, national, state, and local codes.
Precautions before work
Provide a suitable barrier around the work area, for example, a guard rail.
Make sure that all safety guards are in place and secure.
Make sure that you have a clear path of retreat.
Make sure that the product cannot roll or fall over and injure people or damage
property.
Make sure that the lifting equipment is in good condition.
Use a lifting harness, a safety line, and a breathing device as required.
Allow all system and pump components to cool before you handle them.
Make sure that the product has been thoroughly cleaned.
Disconnect and lock out power before you service the pump.
Check the explosion risk before you weld or use electric hand tools.
Precautions during work
CAUTION:
Read this manual carefully before installing and using the product. Improper use of the product can
cause personal injury and damage to property, and may void the warranty.
Always wear Personal Protective Equipment (PPE).
Always lift the product as illustrated in the Transportation and Storage Section.
Beware of the risk of a sudden start if the product is used with an automatic control.
Clean all components thoroughly after pump disassembly.
Do not exceed the maximum working pressure of the pump.
Do not open any vent or drain valve or remove any plugs while the system is
pressurized.
Rev. 3
4/17/2018

INTRO-4
Make sure that the pump is isolated from the system and that pressure is relieved
before you disassemble the pump, remove plugs, or disconnect piping.
Never operate a pump without a properly installed coupling guard.
Product Warranty
Basic Coverage
PW-IND will remedy faults in products under these conditions:
The faults are due to defects in design, materials, or workmanship.
The faults are reported to a PW-IND representative within the warranty period.
The product is used only under the conditions described in this manual.
All service and repair work is done by PW-IND authorized personnel.
Genuine PW-IND parts are used.
PW-IND will replace the Power End for 5 years after shipment,
regardless of cause of failure. Contact your PW-IND representative
for more information on the Power End warranty program.
Limitations to Warranty:
Except where noted above, the warranty does not cover faults caused by these situations:
Deficient maintenance
Improper installation
Modifications or changes to the product and installation made without consulting
PW-IND
Incorrectly executed repair work
Normal wear and tear
PW-IND assumes no liability for these situations:
Bodily injuries
Material damages
Economic losses
Environmental damage
Rev. 3
4/17/2018

DESIGN-1
Product Description
Rev. 3
4/17/2018

DESIGN-2
General description PWA
The PWA is a horizontal overhung, open impeller, centrifugal pump. This pump is ANSI
B73.1 compliant.
Figure 1: PWA pump
Table1: Hydraulicsizesperdrive unitsize
Drive-unit size group
Number of hydraulic sizes
Group 1
5
Group 2
15
Group 3
11
Group 4
9
Part description PWA
Table 2: Pump casing parts
Part
Description
Discharge
Top-centerline
Casing ventilation
Self venting
Gasket
Fully confined
Mounting method
Integral foot
Standard flange
ANSI class150#flat-face serrated flange
Optional flanges
• ANSI class 150# raised-face serrated flange
• ANSI class 300# flat-face serrated flange
• ANSI class 300# raised-face serrated flange
Impeller
The impeller is
Fully open
Threaded to the shaft
The threads are sealed from the pumped liquid by an o-ring.
Rev. 3
4/17/2018

DESIGN-3
Cover
Standard seal
The PWA is available with three stuffing-box / seal chamber designs
Standard Bore
Big Bore
Taper Bore
Table 3: Power end main parts
Part
Description
Frame adapter
The carbon steel frame adapter has
• A machined rabbet fitted to the seal chamber/ stuffing box cover
• a precision dowel pin fitted to the bearing frame.
Power end
• Flinger oil lubrication is standard.
• No machining is required to convert from oil to grease or oil-mist lubrication.
Regreaseable bearings and oil-mist lubrication are optional.
• The oil level is checked through a sight glass located on both sides of the
power end.
• The power end is sealed with labyrinth seals.
• The power end is made in the following sizes:
• Group 1
• Group 2
• Group 3
• Group 4
• Group 4-17
Shaft
The shaft is available with or without a sleeve.
Bearings
The Non-Drive End (INBOARD) bearing
• Carries only radial loads.
• Is free to float axially in the frame.
• Is a single-row deep-groove ball bearing
The Drive End (OUTBOARD) bearing
• Is shouldered and locked to the shaft and housing to enable it to carry radial
and thrust loads.
• Is a double-row angular-contact bearing, except for the Group 3 which uses a
pair of single-row angular-contact ball bearings mounted back-to-back.
Figure 2: PWA Power End Cross Sectional
Rev. 3
4/17/2018

DESIGN-4
Important information for ordering
Every pump has nameplates that provide information about the pump. The nameplates are
located on the casing and the bearing frame.
When you order spare parts, identify this pump information:
Model
Size
Serial number
Item numbers of the required parts
Refer to the nameplate on the pump casing for most of the information. See Parts List for item
numbers.
Nameplate types
Table 4: Nameplate Description
Nameplate
Description
Pump casing
Provides information about the hydraulic characteristics of the pump.
Discharge x Suction x Nominal Maximum Impeller diameter (in inches).
(Example: 2x3x8)
Bearing frame
Provides information about the bearings, lubrication and power end specific serial
number.
ATEX
If applicable, your pump unit might have an ATEX nameplate affixed to the pump, the
baseplate, or the discharge head. The nameplate provides information about the ATEX
specifications of this pump.
Figure 3: Nameplate on the pump casing using English units
Table 5: Definition of nameplate on the pump casing english units
Nameplate field
Definition
IMPLR. DIA.
Trimmed Impeller diameter, in inches
MAX. DIA.
Maximum impeller diameter, in inches
GPM
Rated pump flow, in gallons per minute
FT HD
Rated pump head, in feet
RPM
Rated pump speed, revolutions per minute
MOD.
Pump model
SIZE
Size of the pump
STD. NO.
ANSI standard designation
Rev. 3
4/17/2018

DESIGN-5
MAT L. CONST.
Material of which the pump is constructed
SER. NO.
Serial number of the pump
MAX DSGN PSI
@ 100ºF
Maximum pressure at 100ºF according to the pump design
Figure 4: Nameplate on the pump casing using metric units
Table 6: Definition of nameplate on the pump casing in metric units
Nameplate field
Definition
IMPLR. DIA.
Impeller diameter, in mm
MAX. DIA.
Maximum impeller diameter, in mm
M3/HR
Rated pump flow, in cubic meters per hour
M HD
Rated pump head, in meters
RPM
Rated pump speed, in revolutions per minute
MOD.
Pump model
SIZE
Size of the pump
STD. NO.
ANSI standard designation
MAT L. CONST
Material of which the pump is constructed
SER. NO.
Serial number of the pump
MAX. DSGN Pressure kPag
30°C
Maximum Design Working Pressure @ 30°C
Figure 5: Nameplate on the bearing frame
Rev. 3
4/17/2018

DESIGN-6
Table 7: Explanation of the nameplate on the Bearing Frame Assembly
Nameplate field
Definition
BRG. O. B.
Outboard bearing designation (Drive End)
BRG. I. B.
Inboard bearing designation (Non-Drive End)
S/N
Serial number of the Bearing Frame Assembly
LUBE
Oil or Grease Type
Rev. 3
4/17/2018

HANDLE-1
Transportation and Storage
Rev. 3
4/17/2018

HANDLE-2
Inspect the delivery
Inspect the package
1. Inspect the package for damaged or missing items upon delivery.
2. Note any damaged or missing items on the receipt and freight bill.
3. File a claim with the shipping company immediately if anything is out of order.
NOTE: Contact your local PW-IND sales office if any items are missing or for
replacement components.
Inspect the pump unit
1. Inspect the product to determine if any parts have been damaged or are missing.
2. Note and report any evidence of damaged paint to your PW-IND representative.
This might be evidence of impact damage during shipment that could result in reduced
product performance.
Transportation guidelines
Pump handling
WARNING:
Make sure that the unit cannot roll or fall over and injure people or damage
property.
PW-IND pumps contain sensitive parts that can be damaged if dropped or
subjected to impact. Handle the equipment with care and do not attempt to
install or operate a pump unit that is damaged.
Lifting methods
WARNING:
All lifting must be done in compliance with all applicable regulations/standards.
Assembled units and their components are heavy. Failure to properly lift and
support this equipment can result in serious physical injury and/or equipment
damage. Lift equipment only at the specifically identified lifting points.
Crush hazard. The unit and the components can be heavy. Use proper lifting
methods and wear steel-toed shoes at all times.
Do not lift any pump or motor by attaching lifting equipment to shaft ends.
Table 1: Lifting Methods
Pump type
Lifting method
A bare pump without lifting
handles
Use a suitable sling attached properly to solid points like the
casing, the flanges, or the frames.
A base-mounted pump
Use slings under the pump casing and the drive unit, or under the
base rails.
Mounted on a Polymer
Composite Baseplate
See separate information regarding the Polymer Composite
Baseplate.
Rev. 3
4/17/2018

HANDLE-3
Examples
Figure 1: Example of Proper Lifting –Bare Pump
NOTICE:
Do not use this lifting method to lift a Polymer Composite Baseplate with the pump and
motor mounted. Doing so may result in equipment damage.
Figure 2: Example of Proper Lifting –Base Mounted Pump
Rev. 3
4/17/2018

HANDLE-4
NOTICE:
Ensure that lifting strap is located at motor feet-frame, and clear of motor fan shroud
prior to lifting.
NOTICE:
Do not use this lifting method to lift a Polymer Composite Baseplate with the pump and
motor mounted. Doing so may result in equipment damage.
Figure 3: Example of Proper Lifting –Base Mounted Pump with Motor
Figure 4: Example of Proper Lifting –Fabricated Base Mounted Pump with Motor
Rev. 3
4/17/2018

HANDLE-5
Figure 5: Example of Proper Lifting –Pump with Frame Adapter
Storage guidelines
Pump storage requirements
Storage requirements depend on the amount of time the pump unit will be stored
prior to installation and start up. The normal packaging is designed only to protect the
unit during shipping.
Table 2: Storage
Length of time in storage
Storage requirements
Upon receipt/short-term (less than six months)
• Store in a covered and dry location.
• Store the unit free from dirt and vibration.
Long-term (more than six months)
• Store in a covered and dry location.
• Store the unit free from heat, dirt, and
vibration.
• Rotate the shaft by hand several times at
least every month ensuring that the shaft
is not in the same position each time.
NOTICE:
Risk of damage to the mechanical seal or shaft sleeve on units supplied with
cartridge mechanical seals. Follow seal manufacture’s recommendations for
long term storage.
Treat bearing and machined surfaces so that they are well preserved. Refer to
motor and coupling manufacturers for their long-term storage procedures.
Long term storage preparation is available as part of initial product purchase or after
your pump has been delivered. Contact your local PW-IND sales representative.
Rev. 3
4/17/2018

HANDLE-6
Frostproofing
Table 3: Situations when the pump is or is not frostproof
Situation
Condition
Operating
The pump is frostproof.
Not Operating
The pump internals might be subject to frost damage.
Protect non-operational units with climate control or
an anti-freeze solution in the casing. NEVER USE AN
ANTI-FREEZE AGENT IN THE PUMP BEARING
HOUSING.
Rev. 3
4/17/2018
