Dear Customer,
Greetings on purchasing the PURE eTryst 350, India’s premium electric Bike that is manufactured by PuR Energy Pvt Ltd.
Before you begin riding, please go through this manual to familiarize yourself with the mechanism and controls of the eTryst
350, and with its proper care and maintenance to ensure a long trouble-free ride.
Keeping the batteries in good health is vital for the economy and reliability of the eTryst 350.
Enjoy the PURE ride!
COPYRIGHTS
© Copyright PuREnergy Pvt Ltd. All rights reserved.
This material provided by PuREnergy Pvt Ltd is the property of PuREnergy Pvt Ltd and is protected by copyright, trademark and other intellectual
property laws. You may view this material and print this material only for personal use, provided that you maintain all copyright, trademark and other
proprietary rights or notices. You may not otherwise use, reproduce, store, post, broadcast, transmit, modify, sell or make available to others or the
public, content from this material without the prior written approval of PuREnergy Pvt Ltd. Version July 2021
Address:
H.No: 10-38/2, Survey No-424/AA3, Beside Arya College
of Pharmacy, Near IIT Hyderabad, Kandi Village,
Telangana.502285
Website: www.pureev.in
Follow Us at: @pureevindia

PURE EV
User Manual ii
DISCLAIMER
PuREnergy Pvt Ltd, here in after called as PURE EV TM. In this publication the specifications, information,
illustrations used, and performance of the eTryst 350 and other products manufactured by or sold under
the license granted by PURE EV is based on the latest information available at the time of printing. PURE
EV reserves the right to make changes at any time without prior notice. The use of this information or
products and the conditions under which the products are used are the sole responsibility of the buyer
and/or the rider. It is the buyer’s and/or rider’s responsibility to determine the correct and safe selection
of settings and conditions of use of the products and to periodically check the products for secure and
proper operation. To the extent that the law permits, any liability which may be incurred as a result of the
use of a product manufactured by or sold under license granted by PURE EV is limited to the cost of
repairing or replacing the failed product or component at the discretion of PURE EV either within or outside
of warranty periods, and does not extend to any loss or damage which may be caused as a consequence
of misuse or failure of the products. Damages to the product, other property or any persons are the
responsibility of the buyer and/or rider. By using this product manufactured by or sold under license
granted by PURE EV , you are stating that you have read this disclaimer and agree to hold PURE EV , its
owner(s) and any of its employees or Directors free from all liabilities, that you agree you are using and
operating the product at your own risk, and that no warranties or guarantees are made by PURE EV ,
expressed or implied, on performance or operation.

PURE EV
User Manual iii
Content
1Abou t eTry s t 3 50 ................. 5
Specifications & Features ......................9
Driving your PURE eTryst 350........... 11
2CHAR G ING e Trys t 350 ........ 15
Guidelines for Charging Socket........ 15
Infrastructure Requirements.............. 16
Component Essentials......................... 17
Important Safety Information............ 21
3P UR E Li t h i um B a tt e r y ......... 23
Critical...................................................... 23
Important ................................................ 24
Battery Health Tips............................... 25
4Servi c e & Warra n ty Pol i c y ... 27
Service Policy......................................... 27
Warranty Policy ..................................... 29
5M a nd a to r y R oa d S ig n s ........ 33
6T r o ub l e S h o o t i n g ............... 34
ANNE X URE 1 ........................ 22

4
ABOUT

PURE EV
USER MANUAL 5
1A b o u t e T r y s t 3 5 0
SIDE VIEW
Saddle
Grab Rail
Motor
Side Stand
Centre
Stand
Battery
Box
Head
Light
Charging
Port
Under Seat
Storage
Key Slot
MCB

PURE EV
USER MANUAL 6
FRONT & REAR VIEW
Rear View
Mirror
LED
Display
Rear Brake
Lever
Front Brake
Lever
Front Side
Indicator
Rider
Footrest
Pillion
Footrest
Front
Shock
Absorber
Rear
Shock
Absorber
Rear
Side
Indicator
Accelerator

PURE EV
USER MANUAL 7
HANDLE OPERATIONS
High / Low
Beam Switch
Side
Indicator
Horn
Kill Switch
Parking
Switch
Speed Mode
Selection
Key Slot
Throttle
Charging Port

PURE EV
USER MANUAL 8
LED DASHBOARD
Battery Level
Indicator
Kill Mode
High Beam
Indicator
Speedo Meter &
Parking Mode
Speed Mode
Right Side
Indicator
Odometer
Left Side
Indicator
Regeneration
Acceleration

PURE EV
USER MANUAL 9
Specifications & Features
Alloy Rim
85 KMPH Top Speed
72V 4KW Vector Looped Controller
Motor: 3.0 KW nominal and 4.0 KW Peak
84V, 8A Charger
3.5 KWH Patented High Performance PURE Lithium
Battery
Comfortable Seat for 2 PAX
7-inch LED Display
Tyre - Front: 2.75-18, Rear: 3.00—17
Front and Rear Disc Brakes
Twist Throttle
Active Balance BMS 100A
150 Kgs Load Capacity
Overall Length 2040 mm
Regenerative Braking
6 Hrs. Charging Time
eTryst 350 Kit
•eTryst 350 Battery
•1 Owner’s Manual
•4 Keys
•1 First Aid Kit
•1 Tool Kit
•1 Charger
•Puncture Kit
•(Optional) Other accessories:
Side Guards, Helmet Lock, Seat Cover, Mud Guard Flap

PURE EV
USER MANUAL 10
Smart Lock
Smart locking system for the eTryst 350 allows you to ride your eTryst 350 without any key and is loaded
with anti-theft abilities. The transponder that is built into the ignition key carries a unique identification
code. The vehicle unlocks when the code on the key matches with the code of the receiver inside the
vehicle.
The Ignition Switch
This mode allows to turn your vehicle on/off overriding the
need for the key. Also, it triggers a sound with blink of
taillight helping you find your ride in the parking area.
The Lock Mode
This mode locks down the vehicle centrally. Any kind of
impact, activity or attempt to start/move the vehicle even
using its own mechanical key triggeres an alarm.
The Unloack Mode
This mode unlocks down the vehicle centrally and it can be
started or operated with the key in this mode
Panic Mode
Trigger and alarm with single press. Pressing any key will
deactivate this alarm.

PURE EV
USER MANUAL 11
Driving your PURE eTryst 350
•Take eTryst 350 off the side stand.
•Check for the recommended tyre pressure Front 34 psi and rear 33 psi for smooth running.
•Ensure the battery is fully charged as per the detailed guideline provided in this manual.
•Put on your helmet (It is mandatory to use a safety helmet to ensure a safe ride).
•Turn on the Ignition key (Clockwise).
•Switch on your kill switch and press the parking button on the right-hand side (with “P” symbol).
•Choose the speed mode as per your comfort**
•Slowly twist the throttle to get the eTryst 350 moving.
•The vehicle should not be overloaded by putting on more load than recommended (Approx. 150
Kg).
**Riders are advised to be cautioned while starting at the 3rd Speed Mode
Do’s and Don’ts while riding:
•The power to the motor cuts off when brakes are applied. Do not hold on to the brakes when you
in regular riding mode as the throttle will be dissociated.
•It is strongly advised not to apply sudden brakes on wet and sandy surfaces.
•Avoid sudden and short distance braking for the safety of the driver as well as the health of the
brake lines.

PURE EV
USER MANUAL 12
•It is advisable to use both the brakes for smooth braking and better balancing.
•It is advisable to avoid driving in waterlogged areas, especially in exposure to electricity and electric
components to avoid short-circuit.
oThe motor has IP67 rating (Protection against full immersion for up to 30 minutes at depths
between 15 cm and 1 meter (limited ingress permitted with no harmful effects).
oThe Battery and LED Display has IP65 rating (Protection against low-pressure jets (6.3 mm) of
directed water from any angle (limited ingress permitted with no harmful effects).
•Avoid driving of the vehicle at the last bar of battery indicator.
After Ride
•After ride, turn off the ignition and remove the keys. Ensure, switching off the vehicle using both
remote and key.
•It is advisable to use the center stand for vehicle to be kept stand still for longer duration.
•It is recommended to park the vehicle on flat surface.

PURE EV
USER MANUAL 13
Important Riding Safety Advice
•Always use a full-face helmet with ISI Mark preferable bright colored. Ensure the strap is tightened
on wearing.
•Avoid wearing loose fit clothes while driving
•It is advisable to wear eye protection gear
•Always carry your license, registration certificate and insurance copy.
•Keep safe distance between yourself and the vehicle ahead.
•Avoid riding in low visibility zones
•Avoid operating phones while driving
•It is strictly advised not to drive when under influence of Alcohol. (Avoid Drink and Driving)
** The vehicle is designed to carry 150 Kgs of load (Comfortable for 1 Rider and 1 Pillion Rider), avoid over
loading.
** The vehicle is designed to be used on the roads only.

14
CHARGING

PURE EV
USER MANUAL 15
2C H A R G I N G e T r y s t 3 5 0
The charger provided with the Li-Ion
battery is sophisticated and is a special
purpose electronic charger. This charger
has an additional safety feature which
provides protection from output
overvoltage, output overcurrent and short-
circuit. The charger is designed to charge
only eTryst 350.
Guidelines for Charging Socket
It is mandatory to meet the charging point
requirements as mentioned further in this
manual. This is to ensure optimum
performance, maintain the battery health
and safety. This installation should be
inspected and verified by authorized PURE
EV technician in the verification form
attached in this manual.

PURE EV
USER MANUAL 16
Infrastructure Requirements
Parking area:
•Vehicle must be parked away from water and fire sources. Vehicle parking should be easily
accessible and must be of minimum 7ft X 4ft.
•Exposure to direct sun-light & rain shall be avoided
Sanctioned Load
•Consumer must have spare 0.75kW load. This can be ensured by verifying electricity bill of the
previous month. (Recorded Maximum Demand < Sanctioned Load)
Healthy Earthing
•A proper earthing must be ensured by any of the following methods,
✓Pipe Earthing
✓Rod Earthing
✓Cu Plate Earthing
•AC Voltage between Neutral (N) & Earth (E) must be ≤ 2V
•The resistance between Neutral (N) & Earth (E) must be ≤ 5 Ω
Healthy Voltage Requirement:
AC Voltage between Phase (P) & Neutral (N) must be 230V±10%.

PURE EV
USER MANUAL 17
Component Essentials
Sr.
No.
Essential Requirements
Specifications
Remark
1
AC Input Cable
3-Core, 1.5sqmm, Copper
conductor, PVC insulated,
PVC sheathed as per
IS:9938/1981 with ISI mark
Length should not be more
than 5 meters from energy
Meter
2
Voltage Stabilizer
Current rating: 16 A
Voltage Rating: 180-270 V
Recommended
3
PVC Box Socket
Current rating: 6 - 16 A
4
Flexible Conduit and Clamp
Size: ≥16 mm
5
MCB
2 NOS
Specifications: 1P 240V, 16A
MCB or 1PN 16A MCB
Curve Characteristics: B or C
Breaking Capacity: ≥ 6kA
Recommendation: Anchor,
Havells, Legrand, HPL, ABB
** Brands are mentioned just for recommendation purpose only, it is advisable to follow the electrical
guidance for installation
