Pyle PPBCM8 User manual

PPBCM8
Compact & Portable HD Body Camera
Wireless Camera (Audio & Video Recording) Night Vision,
Waterproof, Built-in Rechargeable Battery,
Removable 16GB Memory

www.PyleUSA.com
2
IR LED’s
Lazer light
Torch Light
Video
Menu
USB port
Power/Lazer
PPBCM6 Body Camera Diagram
Video
Audio
OK/Playback
Up/IR LCD
Down/Torch
LED Status Indicator

www.PyleUSA.com
3
POWER ON/OFF
POWER ON
1. Press “Power” button, the LED Status Indicator will light up green with power
on sound and LCD screen will display the PYLE logo.
2. The camera system will enter into recording standby mode and the LED Status
Indicator will remain lit green.
3. The LCD will display the currently recording interface and your body camera is
ready to use.
Note: If you have set the screen saver setting to be 1min/3min/5min, if there is
no interaction with the camera, the camera LCD screen will turn o.
POWER OFF
1. Press and hold the “Power” button for at least two seconds.
2. The current le will be saved to the internal storage and the device will power
down.
VIDEO RECORDING
1. Press the “Video”button until the LED Status Indicator lights up red and ash.
The camera will beep audibly.
2. The camera will enter into Video Recording Mode and begin to record. It will
save a le every 3min/5min/10min/20min. The recording time can be set in
video setting menu list.
Note: If you have set the Auto night vision in the system setting list to be Manual.
When the lighting is insucient, press the Up/IR button can enable Night Mode
and the IR LEDs. If you have set the Auto night vision to be Auto. When the lighting
is insucient, the camera will automatically enable Night Mode and the IR LEDs.
It will automatically return to the normal recording mode when light conditions
improve.
Stop Video Recording
1. Press the “Video”button until the LED Status Indicator Lights up green.
2. The camera will enter Recording Standby Mode.
AUDIO RECORDING
1. Press the “Audio” button until the LED Status Indicator ashes green.
2. The camera will beep, the LCD screen will show the Audio Recording Mode
Screen to indicate it has begun recording audio only.
Stop Recording Audio
1. Press the “Audio” button until the LED Status Indicator shows solid green.
2. The camera will enter Recording Standby Mode.

www.PyleUSA.com
4
TAKING A PHOTO
1. When the camera is in Recording Standby Mode or during Video Recording
Mode, press the“Photo”button to take a photo.
2. The LED Status Indicator will ash green once if take a photo in Recording
Standby Mode. There is photo capturing sound when taking a photo.
FILES PLAYBACK
1. Press and hold the “Audio/Playback” button until the camera enters into
Playback Mode.
2. To play the currently recording le, press the “OK” button again.
3. To play another le, use the“UP” or “Down” button to cycle through the les.
Press the “OK” button when you have found the le to play it.
EXIT PLAYBACK MODE
1. To exit the Playback Mode, long press the “Audio/Playback” button.
2. The camera will return to the Recording Standby Mode.
CHARGING BATTERY WITH USB CABLE
1. Connect a USB cable with a compatible connector to a computer/wall charger.
2. Connect the USB cable to the USB port on the body camera.
BATTERY STATUS ICONS
Low Power Not Fully Charged Fully Charged
When charging battery while camera is power o, the LED Status Indicator will
light up red. When the battery is fully charged, the red LED Status Indicator will
turn o.
CONNECT TO PC
Connect to PC via mini USB cable, on camera LCD, it will display “Connected
Computer”. You will nd the camera disk on PC.
PARAMETER SETTING
1. Short press Menu button, rst menu is Video parameters setting list. Press and
hold Menu button to enter into second menu which is System parameters
setting list.
2. Video parameters setting list as below:
• Resolution: 2304*1296 20P, 1920x1080 30P, 1440x1080 30P, 1280x720 30P,
800x480 30P, 640x480 30P
• Video Quality: Fine, Normal, Economy. (Bitrate is dierent for dierent options)
• Loop Recording: O, On
• Recording Time: 3minutes, 5minutes, 10minutes, 20minutes

www.PyleUSA.com
5
• Video Delay: O, On
• Motion Detection: O, On
• Photo Size: 36M, 21M, 16M, 12M, 10M, 8M, 5M, 2M
• Continuous Shoot: O, 2 sheets, 3 sheets, 5 sheets, 10 sheets
3. System parameters setting list as below:
• Volume: O, Low, Medium, High
• Screen Saver: O, 1 Minute, 3 Minutes, 5 Minutes
• Auto Power O: O, 3 Minutes, 5 Minutes, 10 Minutes
• Auto night vision: Manual, Auto
• Frequency: 50Hz, 60Hz
• Date/Time: YYYY/MM/DD, HH/MM/SS. Press UP/Down button to select correct
date and time, press OK button to conrm each gure, after date and time
xed, press Menu button to get back to System parameters setting list.
• Language: English, Traditional Chinese, Simplify Chinese, Japanese, Korean,
Russian
• ID setting: 6 gures ID number. Press UP/Down button to select correct each
gure and conrm by pressing OK button, after ID number is xed, press
Menu button to get back to System parameters setting list.
• Format: Cancel, OK
• Default Setting: Cancel, OK
• Version: version number
Other features:
• Torch light: short press “Up/Torch” button to turn on/o torch light.
Torch light is for using in dark situation to add more light.
• Laser pointer: short press “Power” button to turn on/o laser pointer.
Laser pointer can show the direction where lens is recording.
TROUBLE SHOOTING AND HANDLING
1. Camera cannot boot.
• Please charge camera battery for more than 2hours rst then try to turn on
camera again.
2. Camera cannot respond.
• Please press reset button for 2seconds then restart camera.
3. Device failed to connect to computer.
• Please change to another USB port on computer to connect the camera or
change another USB cable.
Note: If above solutions cannot solve the problems, please contact customer
service sta to return for factory repair.

www.PyleUSA.com
6
PPBCM8
Compact & Portable HD Body Camera
Wireless Camera (Audio & Video Recording) Night Vision, Waterproof,
Built-in Rechargeable Battery, Built-in 16GB Memory
Features:
• Anti-fog, Waterproof and Shockproof
• Lightweight, Portable, Versatile & Wearable Body Camera
• Multi-Functional: Camera + Camcorder + Voice Recorder
• Record Full HD 1080p Video, Snap up to 36MP Hi-Res Images
• Button-Activated Night Vision Illumination
• Water-Resistant Design
• 2.0'' Digital LCD Display
• Displays Video Recording Time/Memory Remaining
• Built-in Microphone & Speaker for Audio Recording
• Ability to Instantly Playback Captured Media Files (Audio +Video)
• 16 GB Built-in Memory
• Built-in Rechargeable Battery
• Input Interface: USB Mini Connectors
• Simple Touch Button Control Operation
• Durable Engineered ABS Construction
• Date + Time Setting / Display
• Auto Exposure & Picture Adjustment
• Connect to Computer: Easy File Save, Share & Transfer
• Integrated Torch Light to Add More Light in Dark Situation
• Integrated Pointer to Show Direction where the Lens is Recording
Video Recording:
• Simple One-Button Video Record Ability
• Displays Video Recording Time Remaining
• Motion Detector Function
• Loop Recording Ability (2 Minutes, 5 Minutes)
• Selectable Recording Options: 1080p, 720p, 480p
(1920 x 1080, 1280 x 720, 640 x 480)
• Video File Format: MOV
• Captures Over 8+ Hours of Video

www.PyleUSA.com
7
Picture Snapping:
• Simple One-Button Image Snap Ability
• Photo Resolution: 2M/5M/8M/10M/12M/16M/21M/36M
• Image File Format: JPG
• Capture Over 10,000+ Images
Audio/Voice Recording:
• Simple One-Button Voice Record Ability
• Audio File Format: WAV
• Record Over 10+ Hours of Audio
What's in the Box:
• Body Camera
• USB Wall Adapter & Charging Cable
• (2) Mounting Clip
Technical Specs:
• Material: ABS and PC
• Night Vision: IR, 32.81 ft. can recognize the face
• Waterproof: IP56, Rainproof
• Shockproof: Up To 2 Meters Free-fall
• Motion Detection: On/O
• Display: 2.0 inch. 4:3 FHD Color Display
• Operating System: Windows XP/Windows 7/Windows 8/Windows 10
• Built-in Night Vision IR LED Lights
• Interface: USB 2.0
• LCD Display: 320 x 240 Output, 4:3
• Extra Wide 130°Degree Wide Angle Lens
• Imaging Sensor: 1/3'' Full-Color CMOS
• Electronic Shutter: 1/2 - 1/2000s
• Battery: 2650mAh, 3.7V (Up to 8 Hours Recording 720p)
• Dimensions: 3.07'' x 2.3'' x 1.02'' -inches
