Pyle PLCD38 User manual

P / N : 570-981812-05
Page. 1
OWNER'S MANUAL
MODEL : PLCD38
ANTI-SHOCK COMPACT DISC PLAYER
AUXILIARY INPUT AND
SUPER POWER OUTPUT
FOLD-DOWN FACE DETACHABLE PANEL
FM-AM FM-MPX RADIO RECEIVER
WITH REMOTE CONTROL
All manuals and user guides at all-guides.com
all-guides.com

Page. 2
P / N : 570-981812-05
LOCATION OF CONTROLS FIGURE A
7. CLOCK CONTROL
During radio and CD operation, press this button to call the time display on the incorporated quartz clock.
SETTING CLOCK TIME
1. Press CLOCK button and hold it until the display lash and release.
2. Press “+” button to set HOUR and press “-” to set MINUTE.
8. STEREO/MONO CONTROL
Press this button to select “FM STEREO” or “MONO” reception.
OPERATING INSTRUCTIONS
1. POWER ON/OFF CONTROL
Press the button to turn the power “ON” or “OFF”.
Note : The unit can be turn on by pressing any keys on the panel (except panel release button & disc eject
button). It will help the user who cannot ind the power button in dark.
2. BAND SELECTOR
Each time this button is pressed, the radio band is changed. The indication “FM1”, “FM2”, “FM3”, “MW1” or
“MW2” will appear on the display according to your selection.
. SCAN CONTROL
Press this button to scan the receivable FM / MW stations. When receivable stations are tuned in, they are
monitored or approximately 5 seconds be ore advancing to the next receivable station. Press SCAN button
once again to stop scanning as desired.
4. PRE-SCAN/AUTO-STORE BUTTON
This button allows you to enjoy “Preset Memory Scan” unction by pushing it shortly, and “Auto-Store Memory”
unction by pushing it more than 2 seconds.
* PS (PRESET MEMORY SCAN ) - It calls the memorized station requencies ( rom 1-6 ) automatically every
5 seconds.
* AS (AUTO-STORE MEMORY ) - It searches all station requencies upward and memorize automatically 6
stations by catching the requency which has scan-stop level, the memorized station is shown on LCD as
“CH1...6”. A ter memorizing, auto-store memory unction will be changed to “Preset Memory Scan”
unction automatically.
5. DISC SLOT
Holding the disc and insert into the disc slot. The CD mechanism will automatically engage into CD play
mode.
6. LCD DIGITAL DISPLAY
The unit utilizes a digital type display which shows numerical indication o station FREQUENCY and other
FUNCTIONS.
All manuals and user guides at all-guides.com

P / N : 570-981812-05
Page. 3
1 . LOUD CONTROL
Press this button to activate the loudness circuitry which compensates or loss o high and low requencies
during low volume levels.
14. MUTE CONTROL
Press this button to mute the volume control and “MUT” will appear on LCD display.
15. AUDIO / SETTING SELECT
Brie ly press the button to select volume, bass, treble, balance or ader adjustment in cyclical mode.
When pressing the button or more than 2 seconds, it activates as unit setting selection in cyclical mode as
ollowing. The unit setting can be changed by using either “VOL +” or “VOL –” button.
· DSP OFF/ POP M/ ROCK M/ CLASS M/ FLAT M
· BEEP OFF/ BEEP ON (not available or this model)
· SEEK 1 (tune up/down button per orms ast tune unction) / SEEK 2 (per orms auto tuning unction when tune up/
down button pressed more than 1 second)
· COLOR 1 / COLOR 2 (not available or this model)
· VOL LAST / VOL ADJ (preset volume level when unit turn on)
16/17. AUDIO LEVEL DOWN/UP CONTROL ( - Button ) / ( + Button )
Press “SEL” button shortly and then pressing “+” or “-” button to adjust level o volume, bass, treble, balance or ader.
• VOLUME - Press the (+) button to increase, or (-) button to decrease volume level.
• BASS - While “BASS” is being displayed, press (+) button to increase or (-) button to decrease the bass level.
• TREBLE - While “TREB” is being displayed, press (+) button to increase or (-) button to decrease the treble level.
• BALANCE - While “BAL” is being displayed, press (+) or (-) button to level balance o speaker right and le t.
• FADER - While “FAD” is being displayed, press (+) or (-) button to level ader o speaker ront and rear.
18/19. MANUAL UP/DOWN TUNING / TRACK SEEK UP/DOWN CONTROL
On radio mode, press the button will tune one requency step higher or lower. Pressing the button more than 1
second can per orms ast tuning unction or auto tuning unction.
On CD mode, press this button will locate the beginning o the track being played or will locate the beginning
o the next track. When pressing more than 2 seconds, it will move ast orward or ast backward to a speci ic
position o a CD track.
20. STATION PRESET BUTTON (1-6)
The PRESET BUTTONS on the unit are used to store station requencies which you may wish to recall. Each
preset button can store FM1, FM2, FM3, MW1, MW2 station requency. Pressing the button momentarily recalls
the station requency which was memorized. There are 6 preset buttons, giving you capability o storing
18FM / 12MW.
NOTE: When the preset button to be memorized is kept pressed or more than 2 seconds, the receiving station
requency will be stored in the button pressed. A ter this, the memorized station can be recalled by pressing the
button once.
On CD Mode
• Preset 1 - press this button to pause the disc played.
• Preset 2 - press this button to scan the irst 10 seconds o all the tracks on the currently selected disc.
• Preset - press this button to repeat the current track o the disc.
• Preset 4 - press this button to play disc at random order - Disc shu le play.
9. EJECT BUTTON
Press the button to eject the disc inside disc slot.
10. PANEL RELEASE BUTTON (FIGURE A)
To detach the ront panel, press the release button so that the panel old down rom vertical position to
horizontal position and then pull it o o the chassis at horizontal position.
To re-attach the panel, push the old-down metal rame orward until it locks to the original postion. Then, put the
panel at the right side o the position irst and then press the le t side o the panel until the mechanism lock it
into place.
11. MODE SELECTION
Press this button to select Radio (TUNER), CD (S-CDP), or Auxiliary input (AUX) mode.
12. LOCAL/DISTANT SELECTOR
Press this button to prevent strong local stations rom overlapping weaker stations. For normal operation, press
this button again or distance.
All manuals and user guides at all-guides.com

Page. 4
P / N : 570-981812-05
P / N : 570-981812-05
WIRE CONNECTION RESET FUNCTION
UNIT REMOVAL
1. Remove Front Control Panel.
2. Slightly insert the key into the slot and
gently to release.
3. Separate the sleeve from the unit. Keep
release key in a safe place as you may
need for future removal of unit.
INSTALLATION
REMOTE CONTROL
The RESET button is located at the back o the
panel. It is recessed in order to prevent accidental
engagement, and can be activated with the tip o a
ball-point pen or any similar pointed object. This
reset circuitry is provided in order to protect the
unit's microprocessor, and should only be activated
under the ollowing conditions :
a) Initial installation a ter all wiring is completed.
b) Abnormal operation is encountered such as
numerical indication on display is erratic.
c) Whenever the reset button is activated, all preset
memory content will be erased and must be
reprogrammed.
CAUTION : Do not connect the speaker wires to chassis
or car body. Each speaker wire cannot be soldered
together with other wires. Otherwise, the unit will be
damaged and no sound will come out anymore.
CAUTION : DO NOT PLACE THE UNIT OVER THE
MAXIMUM INSTALLATION ANGLE OF 0°.
OTHERWISE, THE UNIT MAY NOT WORK
PROPERLY.
WARNING!!
Due to protection of CD Mechanism, two small screws on the top
of the unit must be released before operate the unit. Otherwise, the
CD Mechanism can not be working properly.
