Pyramid PB1036GX User manual

USER'S MANUAL www.pyramidcaraudio.com
PB-136GX PB-336GX
PB-536GX PB-736GX
PB-936GX PB-1236GX
PB-1836GX
PB-236GX PB-636GX
PB-836GX PB-1036GX

congratulations...
on your purchase of a Pyramid Royal Blue Series
amplifier. This amplifier extends the Pyramid
tradition into a totally new series of amps, designed
from the ground up to deliver the power,
performance and flexibility the modern car audio
enthusiast demands.
When you check the list of features offered by the
PB-136GX, PB-236GX, PB-336GX, PB-536GX, PB-
636GX, PB-736GX, PB-836GX, PB-936GX, PB-1036GX,
PB-1236GX, PB-1836GX, you’ll know you made the
right choice with a Pyramid Power amplifier.

1
mono input connections
PB-336GX/PB-536GX
PB-736GX/PB-936GX
PB-1236GX/PB-1836GX
24
stereo input connections
PB-136GX/PB-336GX/PB-536GX
PB-736GX/PB-936GX/PB-1236GX
PB-1836GX
22-23
speaker connections
PB-236GX/PB-636GX
PB-836GX/PB-1036GX
table of contents
mounting and installation 34
protection circuitry and troubleshooting 35
27-28
29
31
32-33
30
speaker connections
PB-136GX/PB-336GX
PB-536GX/PB-736GX
PB-936GX/PB-1236GX/PB-1836GX
high level mono input connections
PB-636GX/PB-836GX/PB-1036GX
mono input connections
PB-636GX/PB-836GX/PB-1036GX
high level input connections
PB-636GX/PB-836GX/PB-1036GX
electrical connections
PB-136GX/PB-236GX/PB-336GX
PB-536GX/PB-636GX/PB-736GX
PB-836GX/PB-936GX/PB-1036GX
PB-1236GX/PB-1836GX
20-21
2/4 channel input connections PB-236GX 25-26
features and specifications PB-136GX 6-7
PB-236GX 8-9
PB-336GX/PB-536GX/PB-736GX
PB-936GX/PB-1236GX/PB-1836GX
10-15
PB-636GX 16-17
general features 2-5
precautions 36
PB-836GX/PB-1036GX18-19

2
· 100 Watts x 4 Output
· Variable Input Level (Gain) Control
· Remote Turn On/Off
· Gold Plated RCA Inputs
· High Level MOLEX Input
· Power ON LED Indicator
· S/N Ratio: > 95 dB
· THD: <0.04%
· Thermal Protection
· Overload Protection
· Short Circuit Protection
· Anti-Thump Turn-On
PB -236G X
High Performance 4 00 Watt 4 Channel Amplifier
· 300 Watts x 2 Output
· 600 Watts x 1 Bridged Output
· Variable Hi/Lo Electronic Crossover Network
· Variable Bass Boost (0 - +18 dB @ 60Hz)
· Variable Input Level (Gain) Control
· Remote Turn On/Off
· Gold Plated RCA Inputs
· High Level MOLEX Input
· Power ON LED Indicator
· LED Protection Indicator
· S/N Ratio: > 95 dB
· THD: <0.04%
· Thermal Protection
· Overload Protection
· Short Circuit Protection
· Anti-Thump Turn-On
PB -336G X
High Performance 6 00 Watt 2 Channel
Bridgeable MOSFET Amplifier
· 120 Watts x 2 Output
· Variable Input Level (Gain) Control
· Remote Turn On/Off
· Gold Plated RCA Inputs
· High Level MOLEX Input
· Power ON LED Indicator
· S/N Ratio: > 95 dB
· THD: <0.04%
· Thermal Protection
· Overload Protection
· Short Circuit Protection
· Anti-Thump Turn-On
PB -136G X
High Performance 240 Watt 2 Channel Amplifier
general features

3
· 250 Watts x 4 Output
· 500W x 2 Bridged Output (250W x 2 + 500W x 1)
· Dual Variable Hi/Lo Electronic Crossover Network
· Dual Variable Bass Boost (0 - +18 dB @ 60Hz)
· Variable Input Level (Gain) Control
· Remote Turn On/Off
· Gold Plated RCA Inputs
· High Level MOLEX Inputs
· Power ON LED Indicator
· LED Protection Indicator
· S/N Ratio: > 95 dB
· THD: <0.04%
· Thermal Protection
· Overload Protection
· Short Circuit Protection
· Anti-Thump Turn-On
· Tri-Mode Configurable
PB -636G X
High Performance 1000 Watt 4 Channel
Bridgeable MOSFET Amplifier
· 500 Watts x 2 Output
· 1000W x 1 Bridged Output
· Variable Hi/Lo Electronic Crossover Network
· Variable Bass Boost (0 - +18 dB @ 60Hz)
· Variable Input Level (Gain) Control
· Remote Turn On/Off
· Gold Plated RCA Inputs
· High Level MOLEX Inputs
· Power ON LED Indicator
· LED Protection Indicator
· Remote Bass Boost
· S/N Ratio: > 95 dB
· THD: <0.04%
· Thermal Protection
· Overload Protection
· Short Circuit Protection
· Anti-Thump Turn-On
PB -736G X
· 400 Watts x 2 Output
· 800W x 1 Bridged Output
· Variable Hi/Lo Electronic Crossover Network
· Variable Bass Boost (0 - +18 dB @ 60Hz)
· Variable Input Level (Gain) Control
· Remote Turn On/Off
· Gold Plated RCA Inputs
· High Level MOLEX Inputs
· Power ON LED Indicator
· LED Protection Indicator
· Remote Bass Boost
· S/N Ratio: > 95 dB
· THD: <0.04%
· Thermal Protection
· Overload Protection
· Short Circuit Protection
· Anti-Thump Turn-On
PB -536G X
High Performance 800 Watt 2 Channel
Bridgeable MOSFET Amplifier High Performance 1000 Watt 2 Channel Bridgeable MOSFET Amplifier
general features

4
· 400 Watts x 4 Output
· 800 Watts x 2 Bridged Output(400Wx2+800Wx1)
· Dual Variable Hi/Lo Electronic Crossover Network
· Dual Variable Bass Boost (0 - +18 dB @ 60Hz)
· Variable Input Level (Gain) Control
· Remote Turn On/Off
· Gold Plated RCA Inputs
· High Level MOLEX Input
· Power ON LED Indicator
· LED Protection Indicator
· Remote Bass Boost
· S/N Ratio: > 95 dB
· THD: <0.04%
· Thermal Protection
· Overload Protection
· Short Circuit Protection
· Anti-Thump Turn-On
· Tri-Mode Configurable
PB -836G X
High Performance 1 600 Watt 4 Channel
Bridgeable MOSFET Amplifier
· 500 Watts x 4 Output
· 1000 Watts x 2 Bridged Output(500Wx2+1000Wx1)
· Dual Variable Hi/Lo Electronic Crossover Network
· Dual Variable Bass Boost (0 - +18 dB @ 60Hz)
· Variable Input Level (Gain) Control
· Remote Turn On/Off
· Gold Plated RCA Inputs
· High Level MOLEX Input
· Power ON LED Indicator
· LED Protection Indicator
· Remote Bass Boost
· S/N Ratio: > 95 dB
· THD: <0.04%
· Thermal Protection
· Overload Protection
· Short Circuit Protection
· Anti-Thump Turn-On
· Tri-Mode Configurable
PB - 1036G X
High Performance 20 00 Watt 4 Channel
Bridgeable MOSFET Amplifier
· 600 Watts x 2 Output
· 1200 Watts x 1 Bridged Output
· Variable Hi/Lo Electronic Crossover Network
· Variable Bass Boost (0 - +18 dB @ 60Hz)
· Variable Input Level (Gain) Control
· Remote Turn On/Off
· Gold Plated RCA Inputs
· High Level MOLEX Input
· Power ON LED Indicator
· LED Protection Indicator
· Remote Bass Boost
· S/N Ratio: > 95 dB
· THD: <0.04%
· Thermal Protection
· Overload Protection
· Short Circuit Protection
· Anti-Thump Turn-On
PB - 936G X
High Performance 12 00 Watt 2 Channel
Bridgeable MOSFET Amplifier
general features

· 1200 Watts x 2 Output
· 2400W x 1 Bridged Output
· Variable Hi/Lo Electronic Crossover Network
· Variable Bass Boost (0 - +18 dB @ 60Hz)
· Variable Input Level (Gain) Control
· Remote Turn On/Off
· Gold Plated RCA Inputs
· High Level MOLEX Inputs
· Power ON LED Indicator
· LED Protection Indicator
· Remote Bass Boost
· S/N Ratio: > 95 dB
· THD: <0.04%
· Thermal Protection
· Overload Protection
· Short Circuit Protection
· Anti-Thump Turn-On
PB-1836GX
High Performance 2400 Watt 2 Channel
Bridgeable MOSFET Amplifier
· 800 Watts x 2 Output
· 1600W x 1 Bridged Output
· Variable Hi/Lo Electronic Crossover Network
· Variable Bass Boost (0 - +18 dB @ 60Hz)
· Variable Input Level (Gain) Control
· Remote Turn On/Off
· Gold Plated RCA Inputs
· High Level MOLEX Inputs
· Power ON LED Indicator
· LED Protection Indicator
· Remote Bass Boost
· S/N Ratio: > 95 dB
· THD: <0.04%
· Thermal Protection
· Overload Protection
· Short Circuit Protection
· Anti-Thump Turn-On
PB-1236GX
High Performance 1600 Watt 2 Channel
Bridgeable MOSFET Amplifier
5
general features

pb-136GX
6
+ - - +
POWER
LOW IN
CH R CH L
MIN MAX
LEVEL
HI IN
CH R CH L
2 CHANNEL POWER AMPLIFIER
GROUND +12V BATT
REM
FUSE
-
+
-
+
LR
high level inputs
input level control
low level inputs power LED
speaker connections power terminals
power fuse
features and controls
2 ch amp PB-136GX

7
frequency response
power supply voltage
output power @ 14.4v DC, 1KHz
RMS Power @ 4 Ohms
Maximum Power Output
input sensitivity
low level inputs
high level inputs
30 Watts x 2
120 Watts x 2
15 Hz-30 KHz
250mV
2.5V
14.4V DC Neg. Ground (10.5-16V)
input level control
low level inputs
high level inputs
power LED
power fuse
power terminals
speaker connections
use this control to match the outputs of your head unit to the amplifier.
Starting with your head unit set at about the 2 o’clock position, increase
the amp level control until distortion begins to occur, and reduce slightly
from this point.
this amp features gold-plated RCA input jacks for high impedance input.
Use these with car stereo output which uses RCA-type connector cables.
if your car stereo lacks RCA-type output jacks, you may connect speaker
output leads to these input connectors.
this indicator is illuminated when power is applied.
the fuse protects the amplifier and your car’s electrical system from short
circuit conditions.
use these connectors to deliver power, ground and remote turn-on control
to the amplifier.
these terminals are 14K gold plated to guarantee high conductivity and
minimum signal loss.
maximum current draw
dimensions (W x H x L)
mm
inches
2-4 Ohms
5A
input impedance
low level inputs
high level inputs 10K Ohms
100 Ohms
matching speaker impedance
stereo mode
bridged mode
278 x 81 x 209
10.9 x 3.2 x 8.25
features and specifications
2 ch amp PB-136GX

pb-236GX
8
+-- +
-
+
-
+
CH3 CH4
GROUND +12V BATT
REM
FUSE
CH1 CH2
POWER
LOW IN
HI IN
CH2 CH1
+ - - +
MIN MAX
LEVEL
CH 2 CH 1
LOW IN
CH 4 CH 3
MIN MAX
LEVEL
HI IN
CH4 CH3
+ - - +
4 CHANNEL POWER AMPLIFIER
features and controls
speaker connections power terminals
power fuse
high level inputs
input level control
low level inputs high level inputs
input level control
low level inputs
power LED
4 ch amp PB-236GX

9
input level control
low level inputs
high level inputs
power LED
power fuse
power terminals
speaker connections
use this control to match the outputs of your head unit to the amplifier.
Starting with your head unit set at about the 2 o’clock position, increase
the amp level control until distortion begins to occur, and reduce slightly
from this point.
this amp features gold-plated RCA input jacks for high impedance input.
Use these with car stereo output which uses RCA-type connector cables.
if your car stereo lacks RCA-type output jacks, you may connect speaker
output leads to these input connectors.
this indicator is illuminated when power is applied.
the fuse protects the amplifier and your car’s electrical system from short
circuit conditions.
use these connectors to deliver power, ground and remote turn-on control
to the amplifier.
these terminals are 14K gold plated to guarantee high conductivity and
minimum signal loss.
frequency response
power supply voltage
output power @ 14.4v DC, 1KHz
RMS Power @ 4 Ohms
Maximum Power Output
input sensitivity
low level inputs
high level inputs
30 Watts x 4
100 Watts x 4
15 Hz-30 KHz
250mV
2.5V
14.4V DC Neg. Ground (10.5-16V)
maximum current draw
dimensions (W x H x L)
mm
inches
2-4 Ohms
input impedance
low level inputs
high level inputs 10KOhms
100 Ohms
matching speaker impedance
stereo mode
bridged mode
10A
278x 81 x 235
10.9 x 3.2 x 9.25
features and specifications
4 ch amp PB-236GX

pb-336GX
pb-536GX
10
features and controls
2 ch amp PB-336GX • PB-536GX
Remote Bass Boost
(PB-336GX Without )
crossover mode selector
protection LED
low pass frequency control
bass boost level
power LED
high pass frequency control
GROUND
FUSE
BRIDGED
-
+
-
+
-
+
LR
+12V BATT
REM
high level inputs
input level control
low level inputs
LEVEL
REMOTE
BASS BOOST
POWERPROTECT
+18db
0
BASS
BOOST
35 400
Hz
LPF
HPF
80 2.5k
Hz
FREQ.
FULL
HPF
LPF
L
R
HI IN
R L
+ - - +
LOW IN
MIN MAX
2 CHANNEL MOSFET AMPLIFIER
speaker connections power terminals
power fuse

frequency response
power supply voltage
output power @ 14.4v DC, 1KHz
RMS Power @ 4 Ohms
RMS Power @ 2 Ohms
Maximum Power Output
input sensitivity
low level inputs
high level inputs
40 Watts x 2
60 Watts x 2
300 Watts x 2
15 Hz-30 KHz
250mV
2.5V
14.4V DC Neg. Ground (10.5-16V)
maximum current draw
dimensions (W x H x L)
mm
inches
2-4 Ohms
4-8 Ohms
input impedance
low level inputs
high level inputs 10KOhms
100 Ohms
matching speaker impedance
stereo mode
bridged mode
15A
278 x 81 x 209
10.9 x 3.2x 8.25
crossover mode selector
input level control
low pass frequency control
high pass frequency control
bass boost level control
low level inputs
high level inputs
power LED
protection LED
power fuse
power terminals
speaker connections
when used with normal, full range systems, set this switch to “FULL.” If
youwishto use theinternalcrossoverto power adriverofspecific frequency
range, use the “LOWPASS” or “HIGHPASS” settings.
use this control to match the outputs of your head unit to the amplifier.
Starting with your head unit set at about the 2 o’clock position, increase
the amp level control until distortion begins to occur, and reduce slightly
from this point.
when the crossover selector switch is in “low pass” mode, this control
sets the upper frequency limit for audio program sent to the speakers.
when the crossover selector switch is in “high pass” mode, this control
sets the lower frequency limit for audio program sent to the speakers.
this control permits adjustment of the bass level up to an increase of
approximately 18 dB.
this amp features gold-plated RCA input jacks for high impedance input.
Use these with car stereo output which uses RCA-type connector cables.
if your car stereo lacks RCA-type output jacks, you may connect speaker
output leads to these input connectors.
this indicator is illuminated when power is applied.
this indicator is illuminated when built-in protection circuitry is activated.
the fuse protects the amplifier and your car’s electrical system from short
circuit conditions.
use these connectors to deliver power, ground and remote turn-on control
to the amplifier.
these terminals are 14K gold plated to guarantee high conductivity and
minimum signal loss.
Remote Bass Boost Plug in the Remote Bass Boost Control wire in here. 11
50 Watts x 2
75 Watts x 2
400 Watts x 2
15A
278 x 81 x 235
10.9 x 3.2x 9.25
features and specifications
2 ch amp PB-336GX • PB-536GX

pb-736GX
pb-936GX
12
LEVEL
REMOTE
BASS BOOST
POWERPROTECT
+18db
0
BASS
BOOST
35 400
Hz
LPF
HPF
80 2.5k
Hz
FREQ.
FULL
HPF
LPF
L
R
HI IN
R L
+ - - +
LOW IN
MIN MAX
2 CHANNEL MOSFET AMPLIFIER
GROUND
FUSE
BRIDGED
-
+
-
+
-
+
LR
+12V BATT
REM
Remote Bass Boost
crossover mode selector
protection LED
low pass frequency control
bass boost level
power LED
high pass frequency control high level inputs
input level control
low level inputs
pb-1236GX
speaker connections power terminals
power fuse
features and controls
2 ch amp PB-736GX • PB-936GX • PB-1236GX

PB-736GX
frequency response
power supply voltage
output power @ 14.4v DC, 1KHz
RMS Power @ 4 Ohms
RMS Power @ 2 Ohms
Maximum Power Output
input sensitivity
low level inputs
high level inputs
75 Watts x 2
125 Watts x 2
500 Watts x 2
15 Hz-30 KHz
250mV
2.5V
14.4V DC Neg. Ground (10.5-16V)
90 Watts x 2
150 Watts x 2
600 Watts x 2
maximum current draw
dimensions (W x H x L)
mm
inches
2-4 Ohms
4-8 Ohms
matching speaker impedance
stereo mode
bridged mode
input impedance
low level inputs
high level inputs 10K Ohms
100 Ohms
20 A 30 A
278 x 81 x 305
10.9 x 3.2 x 12 278 x 81 x 343 10.9 x 3.2 x 13.5
whenusedwithnormal,full range systems, set these switches to “FULL.”
If you wish to use the internal crossovers to power a driver of specific
frequency range, use the “LOWPASS” or “HIGHPASS” settings.
usethese controls to match the outputs of your headunit to the amplifier.
Starting with your head unit set at about the 2 o’clock position, increase
theamplevelcontrolsuntildistortionbeginstooccur,andreduceslightly
from this point.
when one or both of the crossover selector switches is in “low pass”
mode, one can set the upper frequency limit for audio program sent to
the speakers.
whentheoneorbothofcrossoverselectorswitchisin“highpass”mode,
one can set the lower frequency limit for audio program sent to the
speakers.
this control permits adjustment of the bass level up to an increase of
approximately 18 dB in either or both pairs of channels.
this amp features gold-plated RCA input jacks for high impedance input.
Use these with car stereo output which uses RCA-type connector cables.
if your car stereo lacks RCA-type output jacks, you may connect speaker
output leads to these input connectors.
this indicator is illuminated when power is applied.
thisindicatorisilluminated when built-in protection circuitry is activated.
the fuse protects the amplifier and your car’s electrical system from short
circuit conditions.
usetheseconnectorstodeliverpower,groundandremoteturn-oncontrol
to the amplifier.
these terminals are 14K gold plated to guarantee high conductivity and
minimum signal loss.
13
PB-936GX
crossover mode selectors
input level controls
low pass frequency controls
high pass frequency controls
bass boost level controls
low level inputs
high level inputs
power LED
protection LED
power fuse
power terminals
speaker connections
Remote Bass Boost Plug in the Remote Bass Boost Control wire in here.
features and specifications
2 ch amp PB-736GX • PB-936GX

pb-1836GX
14
speakerconnections power terminals
power fuse
GROUND
BRIDGED
-
+
-
+
-
+
LR
FUSE +12V BATT
REM
LEVEL
REMOTE
BASS BOOST
POWERPROTECT
+18db
0
BASS
BOOST
35 400
Hz
LPF
HPF
80 2.5k
Hz
FREQ.
FULL
HPF
LPF
L
R
HI IN
R L
+ - - +
LOW IN
MIN MAX
2 CHANNEL MOSFET AMPLIFIER
Remote Bass Boost
crossover mode selector
protection LED
low pass frequency control
bass boost level
power LED
high pass frequency control high level inputs
input level control
low level inputs
features and controls
2 ch amp P B 1836G X

PB-1236GX
frequency response
power supply voltage
output power @ 14.4v DC, 1KHz
RMS Power @ 4 Ohms
RMS Power @ 2 Ohms
Maximum Power Output
input sensitivity
low level inputs
high level inputs
125 Watts x 2
200 Watts x 2
800 Watts x 2
15 Hz-30 KHz
250mV
2.5V
14.4V DC Neg. Ground (10.5-16V)
150 Watts x 2
225 Watts x 2
1200 Watts x 2
maximum current draw
dimensions (W x H x L)
mm
inches
2-4 Ohms
4-8 Ohms
matching speaker impedance
stereo mode
bridged mode
input impedance
low level inputs
high level inputs 10K Ohms
100 Ohms
30 A 40 A
278 x 81 x 381
10.9 x 3.2 x 15 278 x 81 x 432 10.9 x 3.2 x 17
whenusedwithnormal,full range systems, set these switches to “FULL.”
If you wish to use the internal crossovers to power a driver of specific
frequency range, use the “LOWPASS” or “HIGHPASS” settings.
usethese controls to match the outputs of your headunit to the amplifier.
Starting with your head unit set at about the 2 o’clock position, increase
theamplevelcontrolsuntildistortionbeginstooccur,andreduceslightly
from this point.
when one or both of the crossover selector switches is in “low pass”
mode, one can set the upper frequency limit for audio program sent to
the speakers.
whentheoneorbothofcrossoverselectorswitchisin“highpass”mode,
one can set the lower frequency limit for audio program sent to the
speakers.
this control permits adjustment of the bass level up to an increase of
approximately 18 dB in either or both pairs of channels.
this amp features gold-plated RCA input jacks for high impedance input.
Use these with car stereo output which uses RCA-type connector cables.
if your car stereo lacks RCA-type output jacks, you may connect speaker
output leads to these input connectors.
this indicator is illuminated when power is applied.
thisindicatorisilluminated when built-in protection circuitry is activated.
the fuse protects the amplifier and your car’s electrical system from short
circuit conditions.
usetheseconnectorstodeliverpower,groundandremoteturn-oncontrol
to the amplifier.
these terminals are 14K gold plated to guarantee high conductivity and
minimum signal loss.
15
PB-1836GX
crossover mode selectors
input level controls
low pass frequency controls
high pass frequency controls
bass boost level controls
low level inputs
high level inputs
power LED
protection LED
power fuse
power terminals
speaker connections
Remote Bass Boost Plug in the Remote Bass Boost Control wire in here.
features and specifications
2 ch amp PB-1236GX • PB-1836GX

4 CHANNEL MOSFET AMPLIFIER
FREQ.
CH 3
LOW IN
LEVEL
MIN MAX
CH 4
HPF
+18db
035 400
Hz
LPF HPF
2.5k
BASS
BOOST
MIN MAX
FREQ.
POWER
CH 1
CH 2
80 Hz
LPF
HI IN
CH4 CH3
+ - - +
LOW IN
BASS
BOOST LEVEL
FULL
HPF
LPF
FULL
HPF
LPF
CHANNEL 1/2CHANNEL 3/4
HI IN
CH2 CH1
+ - - +
+18db
0
2.5k
80 Hz 35 400
Hz
PROTECT
BRIDGED
+-- +
-
+
-
+
CH3 CH4
GROUND +12V BATT
REM
BRIDGED
FUSE
-
+
-
+
CH1 CH2
pb-636GX
16
speaker connections power terminals
power fuse
protection LED
power LED
ch 1/2 low level inputs
ch 1/2 high level inputs
ch 3/4 low level inputs
ch 3/4 high level inputs
ch 1/2 input level control
ch 1/2 bass boost level control
ch 1/2 low pass frequency control
ch 1/2 high pass frequency control
ch 1/2 crossover mode selector switch
ch 3/4 bass boost level control
ch 3/4 low pass frequency control
ch 3/4 high pass frequency control
ch 3/4 crossover mode selector switch
ch 3/4 input level control
features and controls
4 ch amp PB-636GX

17
frequency response
power supply voltage
output power @ 14.4v DC, 1KHz
RMS Power @ 4 Ohms
RMS Power @ 2 Ohms
Maximum Power Output
input sensitivity
low level inputs
high level inputs
35 Watts x 4
55 Watts x 4
250 Watts x 4
15 Hz-30 KHz
250mV
2.5V
14.4V DC Neg. Ground (10.5-16V)
maximum current draw
dimensions (W x H x L)
mm
inches
2-4 Ohms
4-8 Ohms
input impedance
low level inputs
high level inputs 10KOhms
100 Ohms
matching speaker impedance
stereo mode
bridged mode
20A
278x 81 x 305
10.9 x3.2 x 12
dual crossover mode selectors
dual input level controls
dual low pass frequency controls
dual high pass frequency controls
dual bass boost level controls
low level inputs
high level inputs
power LED
protection LED
power fuse
power terminals
speaker connections
whenusedwithnormal,full range systems, set these switches to “FULL.”
If you wish to use the internal crossovers to power a driver of specific
frequency range, use the “LOWPASS” or “HIGHPASS” settings.
usethese controls to match the outputs of your headunit to the amplifier.
Starting with your head unit set at about the 2 o’clock position, increase
theamplevelcontrolsuntildistortionbeginstooccur,andreduceslightly
from this point.
when one or both of the crossover selector switches is in “low pass”
mode, one can set the upper frequency limit for audio program sent to
the speakers.
whentheoneorbothofcrossoverselectorswitchisin“highpass”mode,
one can set the lower frequency limit for audio program sent to the
speakers.
this control permits adjustment of the bass level up to an increase of
approximately 18 dB in either or both pairs of channels.
this amp features gold-plated RCA input jacks for high impedance input.
Use these with car stereo output which uses RCA-type connector cables.
if your car stereo lacks RCA-type output jacks, you may connect speaker
output leads to these input connectors.
this indicator is illuminated when power is applied.
thisindicatorisilluminated when built-in protection circuitry is activated.
the fuse protects the amplifier and your car’s electrical system from short
circuit conditions.
usetheseconnectorstodeliverpower,groundandremoteturn-oncontrol
to the amplifier.
these terminals are 14K gold plated to guarantee high conductivity and
minimum signal loss.
features and specifications
4 ch amp PB-636GX

pb-836GX
pb-1036GX
18
4 CHANNEL MOSFET AMPLIFIER
FREQ.
CH 3
LOW IN
LEVEL
MIN MAX
CH 4
HPF
+18db
035 400
Hz
LPF HPF
2.5k
BASS
BOOST
MIN MAX
FREQ.
POWERPROTECT
CH 1
CH 2
80 Hz
LPF
HI IN
CH4 CH3
+ - - +
LOW IN
BASS
BOOST LEVEL
FULL
HPF
LPF
FULL
HPF
LPF
CHANNEL 1/2CHANNEL 3/4
HI IN
CH2 CH1
+ - - +
+18db
0
2.5k
80 Hz 35 400
Hz
REMOTE
BASS BOOST(CH3/4)
BRIDGED
+-- +
-
+
-
+
CH3 CH4
GROUND +12V BATT
REM
BRIDGED
FUSE
-
+
-
+
CH1 CH2
speaker connections power terminals
power fuse
protection LED
power LED
ch 3/4 low level inputs
ch 3/4 high level inputs
ch 1/2 low level inputs
ch 1/2 high level inputs
ch 3/4 bass boost level control
ch 3/4 low pass frequency control
ch 3/4 high pass frequency control
ch 3/4 crossover mode selector switch
ch 3/4 input level control ch 1/2 input level control
ch 1/2 bass boost level control
ch 1/2 low pass frequency control
ch 1/2 high pass frequency control
ch 1/2 crossover mode selector switch
features and controls
4 ch amp PB-836GX • PB-1036GX
