QOLSYS IQ WiFi User manual

The IQ WiFi is a mesh capable router that
covers every corner of every room with safe,
seamless WiFi.
Features:
•WiFi mesh prioritizes ethernet backhaul
(wired connection) then shared wireless
backhaul (if wired connection isn’t available)
•Stand alone or parallel configuration
supported
•Web interface or IQ Panel configurable
•WiFi version 5
•Supports Dual-band 2.4G/5G
•Supports 7 additional Agents (1 Controller)
IQ WIFI QUICK INSTALL GUIDE
SKU: QW8200-840
Dimensions: 150mm x 89 mm x 57.2 mm
Weight: 172g
Usage: For Indoor use only
Compliance: FCC
Process and Memory: SSoC: MT7621DA
(MIPS1004Kc dual-core 880MHz, SPI NOR Flash
64MB)!
Memory: 128MB DDR3 embedded
Operating Temperature: 0°C - 40°C (32°F - 104°F)
Relative Humidity: 10% - 90% RH (non-condensing)
Operating Distance: Up to 130ft
Frequency Type:
Wireless IEEE 802.11 b/g/n 2.4GHz
IEEE 802.11 a/n/ac 5GHz
Wired Type:
LAN and WAN Gigabit Ethernet Ports
LED Indicator: 2 color LED (Green and Red)
Power Supply:
Input: 100-240VAC, 50-60Hz, 0.3A Max
Output: 12 VDC, 1A
SPECIFICATIONS
FEATURES & OVERVIEW
This is a quick guide for experienced installers only. Refer to technical downloads at http://dealers.qolsys.com (login required)
CONNECT THE IQ WIFI
STEP
3
POWER UP THE IQ WIFI
STEP
1
This is a quick guide for experienced installers only. Refer to http://dealers.qolsys.com (login required)
STEP
2
CONNECT TO THE MODEM OR EXISTING NETWORK
1. Plug the barrel jack end of
the power supply into the
“DC-IN” port
2. Connect the provided
ethernet cable into the
“WAN” port
Connect the opposite end of the provided
ethernet cable into the “ETHERNET” port on
the modem*.
Plug in your power
supply to the wall
outlet.
* Note: IQWIFI may
take up to 5 minutes to
power up before
proceeding to the next
step.
*Note: for parallel installs plug the
ethernet cable into an available
port on the customer’s existing
router (see additional
considerations)
STEP
4
ADD ALL AGENTS
1. Power up an additional IQ WiFi (see step 3)
2. From the controller briefly touch the WPS button
to activate pairing mode.
3. From the agent briefly touch the WPS button to
pair
4. Allow 3-4 minutes for the agent to pair and auto
update.
Note: LED behavior; LED will slowly flash indicating
pairing WPS mode has been enabled. If followed by
a red flash, pairing was unsuccessful.
1
2
2
3
3
PAIR CONTROLLER TO IQ PANEL
STEP
6
RENAME YOUR NETWORK (SSID)
STEP
5
This is a quick guide for experienced installers only. Refer to http://dealers.qolsys.com (login required)
1. Open settings tray from IQ
Panel > Settings >
Advance Settings > type in
valid code > touch
Installation > Devices >
WiFi devices > IQ WiFi
icon
2. Touch the down arrows to
make edits to the Network
Name (SSID’s)
STEP
7
CREATE UNIQUE SSID AND PASSWORD
2
1. Enter a unique
network name
2. Enter a unique
security key
3. Touch Save
1
2
1. Open settings tray,
touch Settings >
Advanced settings >
type valid dealer or
install code > WiFi.
1
3
2
2. Look for the
broadcasting SSID
or network name
and touch it. SSID
will be IQ WiFi
(+Last 6 of MAC)
3
3. Enter password
printed on sticker
or bottom of router.
Password: (S/N)
4. Touch connect
Adding Additional Agents:
- Add up to 7 agents per Controller for a total of 8 IQ WiFi units.
- Ethernet backhaul is supported and will default to wired
connectivity so long as an ethernet cable has been connected
properly.
Document#: IQWIFI06152021
Revision#: 6/15/21
Issue Date: JUNE 2021
Qolsys Product #: QW8200-840
[email protected]
Johnson Controls proprietary.
Reproduction without permission is not permitted.
This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may
cause undesired operation. Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment.
This device complies with Industry Canada licence-exempt RSS standard(s). Operation is subject to the following two conditions: (1) this device may not cause interference, and (2) this device must accept any interference, including interference
that may cause undesired operation of the device.
Cet appareil est conforme avec Industrie Canada exempts de licence standard RSS (s). Son fonctionnement est soumis aux deux conditions suivantes: (1) cet appareil ne doit pas provoquer d'interférences et (2) cet appareil doit accepter toute
interférence, y compris celles pouvant causer un mauvais fonctionnement de l'appareil.
CONTACT TECH SUPPORT
QUESTIONS?
TROUBLESHOOTING
ADDITIONAL CONSIDERATIONS
Factory Default:
- Press and hold the physical
reset button for about 15-20
seconds or until the Power LED
begins to flash. During a reset
the power LED will flash quickly,
slow to a stop, reboot and then
slowly pulse until it remains solid
GREEN.
You can set up the IQ WiFi in either of these ways:
As the only wireless network on the premises:
In parallel with an existing wireless network:
Great for:
-Improving connectivity for ALL WiFi devices
on the network.
-Offering support for the entire network.
Great for:
-Keeping the security and smart-home devices
private/hidden from the rest of the WiFi connected
devices on the network.
-Making online/remote support easier as only
known/authorized devices should be connected.
-Ensuring better connectivity for dealer supported
devices.

This manual suits for next models

1

Popular Wireless Router manuals by other brands

D-Link GO-RT-N300 user manual

D-Link

D-Link GO-RT-N300 user manual

Asus WL-500W SuperSpeed N user manual

Asus

Asus WL-500W SuperSpeed N user manual

Technicolor TG587n Setup and user guide

Technicolor

Technicolor TG587n Setup and user guide

Draytek Vigor 2104 Declaration of conformity

Draytek

Draytek Vigor 2104 Declaration of conformity

MSI RG60G - Wireless Router Quick user guide

MSI

MSI RG60G - Wireless Router Quick user guide

Linksys EA6700 user guide

Linksys

Linksys EA6700 user guide

D-Link EAGLE PRO AI manual

D-Link

D-Link EAGLE PRO AI manual

Linksys FGMM1000 user guide

Linksys

Linksys FGMM1000 user guide

ConnectGear GR-104 user guide
