QUALISYS MARKER 1 User manual

CONTENTS:
• Driver for 4 markers
• 4 piece set of 50mm markers with 5
meter cable
• Battery pack 14.8V 2200 mAh, Li-lon
charger and battery cable
• 2 meter sync cable
• IR Receiver with 5 meter cable
Long Range Active Marker
POWER
The Long Range Active Marker is delivered with a battery pack, which
contains a rechargeable LI-ION battery. When the POWER/BATT LOW
LED flashes red, it is time to charge the battery. The charging time for an
empty battery is about 3 hours and 30 minutes. The control box can also
be powered by any 12VDC power supply.
PERFORMANCE
• The Long Range Active Marker can be used with frequencies from 1 to
200Hz. The marker will not work correctly above 200 Hz.
• The maximum triggering distance for the IR eye is at least 100 m.
• When the control box is operated on battery power, it will enter standby
mode after 30 seconds (power LED flashes green) and shut itself down
automatically after 6 hours to save battery.
• The continuous operation with 4 markers at 100 Hz is 9 hours with the
supplied battery pack. Other operation times can be calculated from
frequency and the number of markers connected to the control box.
2018-05-07
qualisys.com [e-mail]
LONG RANGE ACTIVE MARKER

Qualisys reserves the right to change specifications without notice. For a complete description of
the Long Range Active Marker, please refer to the technical reference.
Control box  x  x  mm,  g
Battery pack  x  x  mm,  m cable,  g
Spherical marker  mm in diameter,  m cable,  g
IR eye  x  x  mm,  m cable,  g
Total weight of a long range marker calibration kit  kg
Frequency range – fps
Flash time  m
Maximum trigger distance At least  m
Battery time, 50 fps, 4 markers  hours
Battery time, 100 fps, 4 markers  hours
Time to charge battery  hours  min
Nominal battery capacity  mAh,  V
Input power range - VDC
SPECIFICATIONS
HOW TO CONNECT:
1. Connect the spherical markers to the connections MARKER 1 –
MARKER 4 on the control box. Part of the thread is still visible when it
is connected correctly.
IMPORTANT: The markers must be connected before the control box is
turned on to operate with full intensity. The spherical markers are delivered
with the cable attached. Do not remove - it is diicult to reconnect.
2. Connect the battery pack or power supply to the BATTERY/12 VDC
connection. Make sure to fully charge the battery before first time use.
3. Connect the IR eye to the IR IN/SYNC IN connection.
4. Attach a protective cover to any unused connection to keep the box splash-proof.
5. Start the control box with the ON/OFF button.
IMPORTANT: The button must be pressed and held until the POWER/BATT LOW LED is lit green. When switching o the
control box press and hold the button until the POWER/BATT LOW LED is turned o.
6. The Long range active marker is now ready for use.
7. Activate it in QTM by selecting “Long Range Active Marker” as “Marker type” on Camera system/Camera settings/
Advanced in the Project Options.
