Quartix TCSV12 User manual

www.quartix.com/ie [phone]
Getting started
Before installing the TCSV12 unit, make sure
you record the unit serial number (SN) from
the label. 1Many customers choose to take
a close-up photo of the unit. Please send this
information along with the vehicle’s registration,
brief description (ie: make/model, colour, etc),
and an email address where you wish to receive
weekly reports to [e-mail]
after installation.
• Park the vehicle in a safe area, outside, with a
clear view of the sky.
• Ensure the vehicle’s engine is switched off.
• Locate the position of the 16-pin diagnostic
port for the vehicle. 2The connector is
usually under the dash, on either side of the
foot-well or within the centre console. It may
be necessary to remove a small section of
trim or lift an access cover. If you’re not sure
where to nd the diagnostic port on your
vehicle, please check our plug and track wiki
page or contact our Support team.
• Ensure that your vehicle’s diagnostic port is
the 16-pin port type. 3
2
Plug and Track (TCSV12)
Quick Installation Guide
1
3
Round 9-pin Round 6-pin 16-pin

www.quartix.com/ie [phone]
5
Step 1: Installation
With the engine switched off, simply plug the
unit into the 16-pin diagnostic port connector.
4 It may require rm pressure to mate with
the connector. Leave the unit in position with
the vehicle’s doors open for approximately
ve minutes (to acquire GPS data) before
proceeding to Step 2. Replace any trim after
inserting the unit.
Step 2: Pairing the device
Switch the ignition on (with engine running) and
leave this on for approximately two minutes.
Then switch off the engine and remove the
ignition key. Log on to the Quartix tracking
app to ensure your vehicle appears on the live
tracking map.
4
Support and Questions
If you have any questions during
installation, please contact our Support
team through our online form, by emailing
suppor[email protected].
Compatibility and Safety
Summary
The TCSV12 is designed for 12v cars and light
commercial vehicles. The device cannot be
plugged into 24v vehicles tted with a Type B
diagnostic connector. After installation, you
should check that the device does not impede
or affect the driver’s operation or control of the
vehicle in any way. If it does, then remove the
product and contact Quartix in order for us to
make alternative arrangements.
The product must not be opened. It contains
a Lithium Polymer battery and there are no
user-serviceable items inside the product.
Any repair or disposal of the product must be
carried out by Quartix. If the unit experiences
any operational problems, contact our Support
team and they will arrange for the product to be
replaced. The TCSV12 includes an internal 2A
fuse. The vehicle diagnostic port also includes
a fused 12v power feed. The TCSV12 has been
independently tested and meets all relevant
CE (EMC) and VCA e-mark compliance. The
product is designed to operate from -30°C to
+80°C. The internal Lithium Polymer battery will
only charge between 0°C to +40°C.
