Quest Leisure Products Falcon AirShield 500 User manual

Falcon AShield
Instructions
Falcon AirShield 500 shown zipped together with a Falcon AirShield 160

Page: 2
Falcon AirShield instructions
These instructions are for your Falcon AirShield. You should read these thoroughly before you use the
product. Always keep these instructions as you may need to refer to them at a later date.
!
Parts List AirShield 500 (3 panels)
Description Quantity
Airshield panel 3
Steel Pegs 18
Guy Lines 12
Quest Falcon Air Technology hand pump 1
Kador Connection Strip 1
Before rst use: Check your AirShield before its rst use.
• Thank you for the purchase of this Quest Falcon AirShield.
• This AirSheild has been tested for defects and aws at the production facility, but we recommend checking your AirShield by erecting it before you go away in
case there is an issue with it.
Parts List AirShield 160 (1 panel)
Description Quantity
Airshield panel(s) 1
Steel Pegs 6
Guy Lines 4

Page: 2
Falcon AirShield instructions
Page: 3
Falcon AirShield instructions
1
No Description
1Viewing panel
2Guy line
3Air beam
4Air beam ination points (in the rear of the panel)
5Main panel
3
Details
Details about your falcon AirShield
5
No Description
6Pegging points
7Connection zips
2
4
6
7

Page: 4
Falcon AirShield instructions
Page: 5
Falcon AirShield instructions
Pitching: How to erect your AirShield.
• Guideline : This instruction is a guideline on how to erect your AirShield. With time and experience you may nd your own way to erect your AirShield, but
whatever way you erect your AirShield, you should always ensure that the fabric is tight, plus use all pegging points and guy lines to ensure no issues occur
during use.
• First remove the AirShield panel(s) from the bag and separate the panel(s) from the pump and peg(s).
• Zip together the panel(s) you wish to use.
• Screw both valves into place and screw the valve cap onto one of the valves.
• Insert the pump into the valve you haven’t put the top onto and inate the air beam using the pump provided. The pump has a dump valve on it to ensure you
do not over inate the AirShield. Simply inate the main beam until the air comes out of the dump valve rather than into the AirShield, at which point you will
hear a dierence as the air will come out of the dump valve when you depress the pump.
• Once the beam is inated, scew the valve cap on and repeat the process on each of the panels that you are using.
• Once all your panels are inated you simply position the AirShield where you want it and peg it using the pegging points and the guy lines. Or if you are going
to use the Kador connector, use this next before pegging.
• Optional : Kador Strip connector
• The Falcon 500 AirShield comes with a kador strip connector which allows you to connect your Falcon AirShield directly to your caravan.
• To use this strip you have to connect to the caravan before pegging the AirShield.
• To do this you simply zip the Kador strip connector onto either end of your AirShield and then slide the Kador strip into your caravan.
• You may nd that it is easier to slide the Kador connector into your caravan and then zip the AirShield onto the Kador strip, ether way is ne.
Pitching
How to pitch your falcon AirShield

Page: 4
Falcon AirShield instructions
Page: 5
Falcon AirShield instructions
Maintenance
How to maintain your falcon AirShield.
Maintenance: How to keep your AirShield in tip top condition.
• Ongoing maintenance - tube twist : When you get your AirShield all the tubes should be correct positioned without any twisted tubes or bladders. There is
very little movement inside the beams, so they should not twist, but due to the nature of air tubes they do move. They can move when in use, when being
inated or deated, when they are being dragged though the awning channel during pitching, or even more during transit. This is unavaoidable and can
happen at any time. When this happens it can aect the performance of the AirShield, or could stop it inating correctly. You should always be aware of the
tubes especially if they are twisted. Tubes can be untwisted by yourself at any time and should be done whenever you notice that they are twisted.
• Ongoing maintenance - valve movement : Due to the nature of valves and air pressure any of the valves can become loose over time and should be checked
each time you use your AirShield. If this is not done and a valve has worked loose your AirShield may deate over time.
• Fading : Your AirShield is coated against the suns harmful rays, but this will degrade over time and only delays the eect. Fading will aect the colour of your
AirShield, but not its performance and is not covered under your warranty as it is a natural process with any synthetic material used outdoors.
• U.V. Coating : Your Falcon AirShield has a U.V. coating on it which helps protect it against the harmful suns rays, but this coating will degrade over time. This
time will dier depending upon the weather and how often you use the AirShield. We always recommend re-coating your AirShield each year as this can add
years of extra life to your AirShield. If you do re-coat your AirShield we recommend cleaning it rst with a dedicated awning cleaner (the AirShield is made
from the same materials as the Falcon air awnings) and then re-coating it immediately after it has dried, again with a dedicated re-proong solution.
• Drying : You should never pack away a wet AirShield. If you pack away your AirShield wet it can lead to mould growth and this can damage your AirShield. If
you do have to pack away the AirShield wet, once back home you should immediately remove the AirShield from its bag and dry both the AirShield and the
bag before re-packing it away.
• Cleaning : You should aways keep your AirShield clean as dirt, water and mud can lean to mould growth and damage the AirShield, the coating, or both. We
recommend rstly brush o any lose dirt with a soft brush and then clean your AirShield with warm soapy water, without using any chemicals or solutions. If
you have more stubborn stains or dirt then use a dedicated awning cleaner, but remember if you use a dedicated awning cleaner you should also re-proof it
afterwards as the act of cleaning can damage the coating that has been applied to your AirShield.

Page: 6
Falcon AirShield instructions
Page: 7
Falcon AirShield instructions
Warranty Claim
• In the unlikely event of a warranty claim, you must contact your retailer.
• Take the product to your retailer that you purchased it from along with your proof of purchase and explain the issue with the retailer.
• You will be required to ll out a warranty form at the retailers once you have been though the issue with the retailer.
• The retailer will then check the product and get in touch with the wholesaler or manufacturer.
• The retailer will keep you informed of the progress of the claim.
The wholesaler or manufacturer will not (unless under special circumstances) get in touch with you as all information will be passed back directly to the retailer.
Warranty Information
• This product comes with a full 12 month manufacturers defect warranty and covers any manufacturers defects for one (1) year from the date of the original
purchase. It does not cover any damage occurred though:
• The product falling or being dropped.
• The product has been technically changed by the owner or another third party
• Improper use of the product and normal wear and tear, which includes fading and degradation of seams.
• The aected part will be replaced or repaired (manufacturers option) if they are found to be defective within the one (1) year time frame.
• The warranty will be void if the product has been subject to neglect, misuse, improper installation, misapplication, alteration or accident including, but not
limited to, improper installation, maintenance or use of unauthorised parts or attachments.
• Damage caused by not following the instruction manual in full will invalidate the warranty, if this results in consequential damages, Quest will not be liable
for these damages or any costs incurred due to these damages.
• Quest will not be liable for material damage or personal injury caused by improper use or if the safety instructions are not properly executed in full.
• All claims must be made though the retailer you purchased the product from and not direct with the wholesaler or manufacturer.
• Warranty claims cannot be honoured without an original dated receipt and or proof of purchase.
• By executing repairs the original warranty period of (1) one year will not be extended, nor the right to a complied new warranty. This warranty is only legal
on European soil. This warranty does not overrule the European directive 2011/83/EU.
• This product may not be amended or changed.
Warranty
Your falcon AirShield warranty details.

Page: 6
Falcon AirShield instructions
Page: 7
Falcon AirShield instructions
Your Name Your Email
Address
Model • Falcon 500 AirShield • Falcon 160 AirShield • (Delete as appropriate)
Frame Minimal quick t Batch Number (found on sewn in label inside the awning)
Purchase Date
Retailer Name
and address
Additional info

twitter.com/questleisure facebook.com/questleisure youtube.com/questleisure
www.questleisure.com
Template Version : 2 • Instruction Version : 1
