Quick Track OMNI User manual

1
User Guide

2
System Overview:
Tell me about the New Quick Track Omni.
The Quick Track OMNI system takes tracking to the next
generation with unlimited range capability and an interactive app
designed for your smartphone or tablet.
Key Features and capabilities include your hound’s satellite position
displayed on satellite terrain and street view maps, simple hunter
interface (easy to use), and dead reckoning.
How are you able to get unlimited range?
The Omni collar transmits the hound’s satellite position via two
ways. One is MURS (Multi-Use Radio Service)and the other is
through cell data. When the dog and hunter have cell service the
Omni system will have unlimited range. However if cell service is
unavailable the OMNI system uses MURS data transmissions which
will provide line of sight tracking range.
How can I have maps on my phone if I don’t have cell
service where I hunt?
The Quick Track app allows you to stream maps and also download
maps. Streaming is recommended for getting familiar with the
Omni system before you hunt. While you are at home on WI-FI you
should preload or download the map for the area you plan on
hunting. When you download a map it will download a 100 square
mile map with your specified hunt location being the center of the
map. This will store the map and not require cell service to load the
map while you are hunting. This map will be stored for future
hunts.

3
What is dead reckoning?
Dead reckoning determines your dog’s satellite position by
calculating the direction and distance your dog has traveled when
satellites are obstructed.
Do I have to have a smartphone or tablet?
Yes. A smartphone or tablet is required in order to use the quick
track app which is your interface for tracking your dogs. You must
have an Apple or Android smartphone or tablet which must have
Bluetooth smart or Bluetooth smart ready. If you plan on using a
tablet make sure the tablet has a data plan.
Do I have to have Bluetooth turned on?
Yes Bluetooth must be turned on in order for the system to work.
The receiver and the smartphone or tablet must stay within
Bluetooth range (approximately 15 feet).
Important Notes:
Prior to turning out your hounds make sure the receiver and collar
have acquired satellites. This is indicated by a blinking green light on
the receiver and collar.
Prior to turning out your hounds verify you are getting your hounds
position by viewing the dog’s icon on the map and seeing the icon
pulse and or move.
Prior to a hunt while you are on WI-FI pre-load (download) the map
area location in which you will be hunting in order to prevent map
streaming for best results.
If the receiver becomes disconnected power off the receiver and then
power on the receiver and go to settings or the devices tab and
reconnect.

4
Table of Contents
Important Notes:.......................................................................................3
Getting Started..........................................................................................6
Getting Started Continued........................................................................7
App Screen Overview................................................................................8
App Features .............................................................................................9
Locate....................................................................................................9
Dogs ......................................................................................................9
..................................................................................................9
Add dog .............................................................................................9
Edit Existing dogs: .............................................................................9
Delete Dog.......................................................................................10
Waypoints ...........................................................................................10
.................................................................................................10
New Waypoint: ...............................................................................10
Edit Waypoint..................................................................................10
Delete Waypoint .............................................................................10
Settings................................................................................................11
Information Bars .................................................................................11
Compass Page .....................................................................................11
Symbols ...............................................................................................12
Collar and Receiver Light Indications......................................................13
Receiver...................................................................................................14
Collar .......................................................................................................15

5
FCC ..........................................................................................................15
Troubleshooting......................................................................................18
Pairing receiver failed: ........................................................................18
Pairing collar failed:.............................................................................18
App closes unexpectedly:....................................................................18

6
Getting Started
Step 1
Download the Quick Track app from the app store for apple devices or
google play for android devices.
Step 2
Use the username and password supplied by Quick Track to login to the
Quick Track app. Username:____________ Password: Omni
Step 3
Once you login the “Hunt Locations screen will display.
Touch “Devices”
Step 4
Turn on Bluetooth on your smartphone or tablet.
Power on the receiver and place next to your smartphone or tablet.
On the devices page touch “Pair Receiver” below the X.
See troubleshooting page 18 if pairing fails.
Step 5
Power on a single collar and place next to your smartphone or tablet
and the receiver.
On the devices page touch “Pair Collar”.
Step 6
Select color for collar and name then press enter on key pad .
Step 7
Power off paired collar and repeat steps 5 through 7 to pair additional
collars. Recommend only powering one collar at a time during pairing.

7
Getting Started Continued
Step 8
After pairing all of your collars touch “Hunt Locations”
Step 9
Touch “Add Hunt Location”
Step 10
IMPORTANT NOTE:
Stream Map is used for getting familiar with OMNI system.
Preload Map should be used for an actual hunt and must be
downloaded while on WI-FI prior to the hunt. When selecting preload
map make sure hunt location address or GPS coordinates is near the
center of the hunt location. Downloading a map will take anywhere
from 15 minutes to 1 hour depending on the speed of your WI-FI.
The Pre-Hunt screen will appear. Name the location, enter address or
select use current location, select map style, and choose stream map or
preload map and touch “Start Hunt”
Step 11
While outdoors power on paired collars and wait for receiver and collars
to acquire a satellite signal.
Step 12
Verify both collars and receiver have acquired satellites by having a
blinking green light, and dog icon pulses approximately every 10
seconds on the map.
Step 13
You are now ready to hunt if you have completed steps 1 through 12
and have downloaded a hunt area map on WI-FI.

8
App Screen Overview
Selected Dog’s Info
bar with name and
collar color displayed
Rex’s
Collar
Battery Life
Distance to
Rex
Selected
Dog’s Icon
and name
are larger
Map Scale, Receiver Battery Life, Your Heading, Access compass page
You
Bearing to
Rex
You can touch
another dog’s icon
on map to select
Adjust Rex’s Settings

9
App Features
Locate
Centers waypoints, dogs, or you on the map and updates
information bar
Dogs
Add dog
1. Remove Magnet from collar and place next to device and
receiver
2. Touch Add Dog
3. When prompted name and select collar color.
4. Adjust collar settings then touch back.
5. Collar has now been added.
Edit Existing dogs:
1. Touch Dogs Icon or 3 dots
2. Select desired dog and edit the following:
Bread Crumbs ON/OFF
Display on Map ON/OFF
Display Dog Name ON/OFF
Name & Color

10
Delete Dog
1. Touch Dogs Icon
2. Select desired dog
3. Press X by dog name
4. Select Delete
Waypoints
New Waypoint:
1. Touch Waypoints Icon
2. Select Add Waypoint
3. Choose Color and Name waypoint
4. Adjust Waypoint settings
5. Touch “Back” and then “Done”
6. Touch “Locate” and select desired waypoint
7. Drag and drop added waypoint on map to desired location
Edit Waypoint
1. Touch Waypoints Icon on menu bar.
2. Select desired waypoint and edit the following:
Display on Map ON/OFF
Display Waypoint Name ON/OFF
Name & Color
Delete Waypoint
1. Touch Waypoints Icon on menu bar.
2. Select desired waypoint
3. Press X by waypoint name
4. Select Delete

11
Settings
Choose Day Mode/Night Mode
Close Map (allows you to change maps)
Reset Breadcrumbs
Reconnect Receiver
Information Bars
Top information bar displays map scale, receiver battery level, and
hunter’s heading.
Bottom information bar displays selected dog’s battery level,
distance, and bearing to dog.
Compass Page
Touch the blue compass symbol on top right of map page
Touch the blue compass symbol again to exit
Whichever dog is selected on the bottom information bar will be
the dog displayed on the compass page. Touch “Locate” and select
a different dog to change which dog is displayed on the compass
page.

12
Symbols
There are four visual states a dog can have on the map or in a list:
📡+name
⚠+name
❔+name
Name (only)
These symbols are a visual way to indicate the connectivity of that
dog's collar.
No symbol: The receiver is currently receiving data from the
collar.
❔: The receiver has not received any information from this
collar, but there hasn't been enough time to deem the collar
unavailable.
⚠: The receiver has not received any information from this collar
📡: The receiver is actively receiving data from the collar over
cell only.

13
Collar and Receiver Light Indications
Unit
Light
Meaning
Receiver
Blinking Blue
Bluetooth
Discoverable
Receiver
Blinking Red
No GPS fix
Receiver
Blinking
Green
Has GPS fix
Collar
Blinking Blue
Bluetooth
Discoverable
Collar
Blinking Red
No GPS fix
Collar
Blinking
Green
GPS fix

14
Receiver
Power Button
Change AA batteries by removing the two Philips head screws on
back of receiver

15
Collar
Remove magnet to power on. Insert magnet to power off.
FCC
This device complies with Part 15 of the FCC Rules. Operation is
subject to the following two conditions: (1) this device may not
cause harmful interference, and (2) this device must accept any
interference received, including interference that may cause
undesired operation.
FCC CAUTION: Changes or modifications not expressly approved
by the party responsible for compliance could void the user’s
authority to operate this equipment.

16
Collar
MURS Radio FCC ID: 2AERJ-OC-Ø1
Location of the collar FCC label
CE910-DUAL Module FCC ID: RI7CE910-DUAL

17
Receiver
FCC ID: 2AERJ-OR-Ø1
Location of the receiver FCC label

18
Troubleshooting
Pairing receiver failed:
If the receiver fails to pair turn off the receiver and then back on
and go to settings or the device page and try to reconnect the
receiver.
If the above procedure still results in the receiver failing to pair
force close the Quick Track app and power the receiver off. To
force close the app on an iphone double press circle home button
then find the Quick Track app and swipe up. To force close the
app on an android press the double squares on the screen and swipe
left. Then power on the receiver and re-open the Quick Track app
and try to pair again.
Pairing collar failed:
If the collar fails to pair put the magnet in the collar to power off.
Remove the magnet to power on the collar and try to pair again.
If the above procedure still results in the collar failing to pair force
close the Quick Track app and power the collar and receiver off.
To force close the app on an iphone double press circle home
button then find the Quick Track app and swipe up. To force close
the app on an android press the double squares on the screen and
swipe left. Then power on the receiver and collar and re-open the
Quick Track app pair the receiver then pair the collar.
App closes unexpectedly:
If the Quick Track app closes unexpectedly reopen the app and go
to either settings or devices page and re-pair the receiver to resume
the hunt.
