Quincy Compressor QCV 045 User manual

Quincy
Dry claw vacuum and overpressure pumps 
QCV 045, QCV 110, QCV 220
QCLP 110, QCLP 220
Original instructions
Instruction Book
• Copyright
Any unauthorized use or copying of the contents or any part thereof is prohibited.
This applies in particular to trademarks, model denominations, part numbers and
drawings.
• Use only authorized parts. Any damage or malfunction caused by the use of
unauthorized parts is not covered by Warranty or Product Liability.
2016-09
No. 6996 0224 14
www.quincycompressor.com

This page intentionally left blank

Table of Contents
3
Section 1 - Safety precautions
Safety icons ....................................................................................................................... 5
Safety precautions, general ............................................................................................... 5
Safety precautions during installation ............................................................................... 6
Safety precautions during operation .................................................................................. 7
Safety precautions during maintenance or repair ............................................................. 8
Section 2 - General description
What is vacuum and how is flow rate understood ........................................................... 10
Introduction ...................................................................................................................... 11
Flow diagram ................................................................................................................... 16
Condensate system ......................................................................................................... 19
Section 3 - Installation
Dimension drawings ........................................................................................................ 20
Installation proposal ......................................................................................................... 26
Electrical connections ...................................................................................................... 31
Pictographs ...................................................................................................................... 32
Section 4 - Operating instructions
Initial start-up ................................................................................................................... 33
Starting ............................................................................................................................ 34
During operation .............................................................................................................. 34
Stopping ........................................................................................................................... 35
Taking out of operation .................................................................................................... 35
Section 5 - Maintenance
Preventive maintenance schedule .................................................................................. 36
Oil specifications .............................................................................................................. 38
Storage ............................................................................................................................ 38
Disposal of used material ................................................................................................ 38
Section 6 - Adjustments and servicing procedures
Air filter ............................................................................................................................. 39
Oil top-up ......................................................................................................................... 40
Cleaning motor fan and vent holes .................................................................................. 40
Section 7 - Problem solving

Table of Contents
4
Section 8 - Technical data
Reference conditions and limitations .............................................................................. 43
Pump data ....................................................................................................................... 43
Motor data ....................................................................................................................... 45
Electric cable size and fuses ........................................................................................... 46
Section 9 - Instructions for use
Section 10 - Declaration of conformity

Section I - Safety precautions
5
 Safety icons
 Safety precautions, general
 Safety precautions during installation
 Safety precautions during operation
 Safety precautions during maintenance or repair
Safety icons
Explanation
Danger to life
Warning
Important note
Safety precautions, general
1. The operator must employ safe working practices and observe all related work safety
requirements and regulations.
2. If any of the following statements does not comply with the applicable legislation, the
stricter of the two shall apply.
3. Installation, operation, maintenance and repair work must only be performed by
authorized, trained, specialized personnel.
4. This claw pump is primarily designed for the handing of clean and dry air but inevitably
it may be subjected to dirty and wet applications. If operating in aggressive, toxic,
explosive and possibly dangerous conditions for the pump and operators, consult
Quincy.
5. Before any maintenance, repair work, adjustment or any other non-routine checks,
 Stop the pump.
 Press the emergency stop button .
 Switch off the voltage.
 Make sure that the pump system is at atmospheric pressure level.
 Lock Out - Tag Out (LOTO):
• Open the power isolating switch and lock it with a personal lock.
• Tag the power isolating switch with the name of the service technician.
 The units may be powered by a frequency converter. Wait 10 minutes after
power down before starting any electrical repair.
 Never rely on indicator lamps or electrical door locks before maintenance
work, always disconnect and check with measuring device .
In a domestic environment, this product may cause radio
interference in which case supplementary mitigation measures
are required.

Section I - Safety precautions
6
If the machine is equipped with an automatic restart after voltage
failure function and if this function is active, be aware that the
machine will restart automatically when the power is restored if it
was running when the power was interrupted!
6. Avoid contact with pump intake during operation.
7. The owner is responsible for maintaining the unit in safe operating condition. Parts
and accessories shall be replaced if unsuitable for safe operation.
8. It is not allowed to walk or stand on the unit or on its components.
9. Never block the outlet in case the pump is used as a vacuum pump
Safety precautions during installation
All responsibility for any damage or injury resulting from neglecting
these precautions, or non-observance of the normal caution and
care required for installation, operation, maintenance and repair,
even if not expressly stated, will be disclaimed by the manufacturer
1 The machine must only be lifted using suitable lifting equipment in accordance with
the applicable safety regulations. Loose or pivoting parts must be securely fastened
before lifting. It is strictly forbidden to dwell or stay in the risk zone under a lifted
load. Lifting acceleration and deceleration must be kept within safe limits. Wear a
safety helmet when working in the area of overhead or lifting equipment.
2. The unit is designed for indoor use. If the unit is installed outdoors, special
precautions must be taken; consult Quincy.
3. Place the machine where the ambient air is as cool and clean as possible. Never
obstruct the cooling air inlet. Water handling capacity is limited. For operating in
such applications, consult Quincy.
4. Any blanking flanges, plugs, caps and desiccant bags must be removed before
connecting the pipes.
5. All connections must be of correct size and suitable for working pressure and
temperature. Never use frayed, damaged or worn hoses. Distribution pipes and
connections must be of the correct size and suitable for the working pressure and
temperature.
6. The aspirated air must be free of flammable fumes, vapors and particles, for
example, paint solvents that can lead to internal fire or explosion. Follow the material
safety.
7. Arrange the air intake so that loose clothing worn by people cannot be sucked in.
8. Ensure no external force exerted on the inlet and outlet connection. The connection
pipes must be free of strain. No supports may be fixed to the canopy of the machine.
9. If remote control is installed, the machine must bear a clear sign stating:
DANGER: This machine is remotely controlled and may start without warning.
The operator has to make sure that the machine is stopped and that isolating switch
is open and locked before any maintenance or repair. As a further safeguard,
persons switching on remotely controlled machines shall take adequate precautions
to ensure that there is no one checking or working on the machine. To this end, a
suitable notice shall be affixed to the starting equipment
10 Air-cooled machines must be installed in such a way that an adequate flow of
cooling air is available and that the exhausted air does not recirculate to the
vacuum/overpressure pump air inlet of the vacuum relief valve or cooling air inlet.

Section I - Safety precautions
7
11. The electrical connections must correspond to the applicable codes. The machines
must be earthed and protected against short circuits by fuses in all phases. A
lockable power isolating switch must be installed near the vacuum/overpressure
pump.
12. On machines with automatic start/stop system or if the automatic restart function
after voltage failure is activated, a sign stating “ This machine may start without
warning ” must be affixed near the instrument panel.
13. In multiple vacuum/overpressure pump systems, manual valves must be installed to
isolate each pump. Non-return valves (check valves) must not be relied upon for
isolating multiple systems.
14. Never remove or tamper with the safety devices, guards or insulation fitted on the
machine.
15. Piping or other parts with a temperature that exceeds 70°C (158°F) and which may
be accidentally touched by personnel in normal operation must be guarded or
insulated. Other high temperature piping must be clearly marked.
16. If the ground is not leveled or can be subject to variable inclination, consult the
manufacturer.
17. Whenever air containing hazardous substances are sucked in (that is, biological or
microbiological agents), use abatement systems placed upstream of the
vacuum/overpressure pump.
18. Any pump placed in an application with inlet gas stream temperatures above the
published maximum temperature should be approved by Quincy prior to start-up.
Also consult following safety precautions: Safety precautions during
operation and Safety precautions during maintenance or repair.
These precautions apply to machinery processing or consuming air
or inert gas.
Processing of any other gas requires additional safety precautions
typical to the application which are not included herein.
Some precautions are general and cover several machine types
and equipment; hence some statements may not apply to your
machine.
Safety precautions during operation
All responsibility for any damage or injury resulting from neglecting
these precautions, or non-observance of the normal caution and
care required for installation, operation, maintenance and repair,
even if not expressly stated, will be disclaimed by the manufacturer.
1. Never touch any piping or components of the pump during operation.
2. Use only the correct type and size of hose end fittings and connections. Make sure
that a hose is fully depressurized before disconnecting it.
3. Persons switching on remotely controlled machines shall take adequate precautions
to ensure that there is no one checking or working on the machine. To this end, a
suitable notice shall be affixed to the remote start equipment.
4. Never operate the machine when there is a possibility of taking inflammable or toxic
fumes, vapors or particles.
5. Never operate the machine below or in excess of its limit ratings.
6. Keep all bodywork panels shut during operation. The panels may be opened for
short periods only, for example, to carry out routine checks. Wear ear protectors

Section I - Safety precautions
8
when opening a panel. On vacuum/overpressure pumps without bodywork, wear ear
protection in the vicinity of the machine.
7. People staying in environments or rooms where the sound pressure level reaches or
exceeds 80 dB(A) shall wear ear protectors.
8. Periodically check that:
 All guards are in place and securely fastened
 All hoses and/or pipes inside the machine are in good condition, secure and not
rubbing
 There are no leaks
 All fasteners are tight
 All electrical leads are secure and in good order
 Air inlet valve and air net, that is pipes, couplings, manifolds, valves, hoses, and
so on are in good repair, free of wear or abuse
9. If warm cooling air from vacuum pumps is used in air heating systems, e.g. to warm up a
workroom, take precautions against air pollution and possible contamination of the
breathing air.
10. Do not remove any of, or tamper with, the sound-damping material.
11. Never remove or tamper with the safety devices, guards or insulation fitted on the
machine.
12. Do not change the purpose of the pump. If the pump is configured to be used as a
vacuum pump, do not use the pump as an overpressure pump. If the pump has
been configured to be used as an overpressure pump, do not use the pump as a
vacuum pump.
13. Never run the overpressure pump without the air intake filter mounted. For the
vacuum pump, Quincy recommends to install an air intake filter to safeguard the
pump. Consult Quincy to check whether the application for the vacuum pump
requires and air intake filter. Never remove or tamper with the safety devices.
Also consult following safety precautions: Safety precautions during
installation and Safety precautions during maintenance.
These precautions apply to machinery processing or consuming air
or inert gas.
Processing of any other gas requires additional safety precautions
typical to the application which are not included herein.
Some precautions are general and cover several machine types
and equipment; hence some statements may not apply to your
machine.
Safety precautions during maintenance or repair
All responsibility for any damage or injury resulting from neglecting
these precautions, or non-observance of the normal caution and
care required for installation, operation, maintenance and repair,
even if not expressly stated, will be disclaimed by the manufacturer.
1. Always use the correct safety equipment (such as safety glasses, gloves, safety
shoes, and so on).
2. Use only the correct tools for maintenance and repair work.
3. Use only genuine spare parts.
4. All maintenance work shall only be undertaken when the machine has cooled down.
5. A warning sign bearing a legend such as “ Work in progress; do not start ” shall be

Section I - Safety precautions
9
attached to the starting equipment.
6. Persons switching on remotely controlled machines shall take adequate precautions
to ensure that there is no one checking or working on the machine. To this end, a
suitable notice shall be affixed to the remote start equipment.
7. Before removing any component, effectively isolate the machine from all sources of
under- and/or overpressure and make sure that the pump system is at atmospheric
pressure level.
8. Never use flammable solvents or carbon tetrachloride for cleaning parts. Take safety
precautions against toxic vapors of cleaning liquids.
9. Carefully observe cleanliness during maintenance and repair. Keep dirt away by
covering the parts and exposed openings with a clean cloth, paper or tape.
10. Never weld or perform any operation involving heat near the oil system.
11. Whenever there is an indication or any suspicion that an internal part of a machine is
overheated, the machine shall be stopped but no inspection covers shall be opened
before sufficient cooling time has elapsed; this to avoid the risk of spontaneous
ignition of the oil vapor when air is admitted.
12. Never use a light source with open flame for inspecting the interior of a machine,
pressure vessel, and so on.
13. Make sure that no tools, loose parts or rags are left in or on the machine.
14. All regulating and safety devices shall be maintained with due care to ensure that
they function properly. They may not be put out of action.
15. Before clearing the machine for use after maintenance or overhaul, check that
operating pressures, temperatures and time settings are correct. Check that all
control and shut-down devices are fitted and that they function correctly. If removed,
check that the coupling guard of the vacuum/overpressure pump drive shaft has
been reinstalled.
16. Protect the motor, air filter, electrical and regulating components, and so on to
prevent moisture from entering them, for example when steam cleaning.
17. Make sure that all sound-damping material and vibration dampers, for example,
damping material on the bodywork and in the air inlet and outlet systems of the
pump, is in good condition. If damaged, replace it by genuine material from the
manufacturer to prevent the sound pressure level from increasing.
18. Never use caustic solvents which can damage materials of the air net, e.g.
polycarbonate bowls.
19. Faults or wearing of seals may cause oil lubricant leaks. Avoid dispersion in soil and
pollution of other materials.
Also consult following safety precautions: Safety precautions
during operation and Safety precautions during installation.
These precautions apply to machinery processing or consuming air
or inert gas.
Processing of any other gas requires additional safety precautions
typical to the application which are not included herein.
Some precautions are general and cover several machine types
and equipment; hence some statements may not apply to your
machine.

Section II - General description
10
 What is vacuum and how is flow rate understood
 Introduction
 Flow diagram
 Condensate system
What is vacuum and how is flow rate understood
What is vacuum and how to denote
A vacuum is any pressure in a system that is below the ambient atmospheric pressure.
It can be denoted in absolute terms or in effective (gauge) terms:
• Mbar (a) - Absolute pressure - denotes how much the pressure is above absolute zero
vacuum.
• (minus) mbar(e) - The Effective or Gauge pressure - denotes how much the pressure
is below local atmospheric pressure
(1)
Pressure
(2)
Absolute vacuum
(3)
Typical QCV/QCLP claw pump working range 600 mbar(a) (450
Torr(a)) – 150 mbar(a) (112.5 Torr(a))
(4)
Atmospheric pressure
Atmospheric pressure at sea level is roughly 1 bar or 1000 mbar (750 Torr). A typical
working range for the QCV/QCLP claw pumps is 600 mbar(a) (450 Torr(a)) to 150
mbar(a) (112.5 Torr(a)). From the illustration it can be seen clearly that this range is
also equivalent to - 400 mbar(e) (-300 Torr(e)) to - 850 mbar(e) (-637.6 Torr(e)).
It is important to understand which type of reference is required before selecting a
pressure instrument for measuring the vacuum. It must be noted that the distinction doesn't
matter for a pressure difference (delta P; for example, pressure loss), since it is always the
result of subtracting 2 pressures (whether stated as absolute or effective pressures).

Section II - General description
11
Flow rate definitions
There are two common but different ways to denote flow rate in vacuum. The first one is
based on the displacement or volumetric flow rate and the second one is based on the
throughput or mass flow rate. Quincy’s vacuum pumps use volumetric flow rate to
denote performance, the unit being Am³/hr.
Displacement/volumetric flow rate
For the relevant pressure range, when a QCV/QCLP claw pump operates at quasi
constant motor speed (rotations per minute) and since the compression chambers have
fixed dimensions, the same volume of air is pumped from inlet to outlet with falling
pressure level. Over the relevant pressure range, this makes the volumetric flow rate
quasi-independent of the vacuum level. It is the expression of the flow rate inside the
piping at the governing vacuum level (Am³/hr), and always higher than the throughput in
mass flow rate.
Throughput in mass flow rate
Even if the volumetric flow rate is quasi unchanged with falling pressure level, the
number of molecules in that pumped volume is not. By definition: the deeper the
vacuum, the lower the amount of molecules in the same volume of air. This means that
the mass flow will decrease with decreasing (absolute) pressure. It is clear that a flow
rate must be stated at a certain vacuum level when using this denotation.
Introduction
The QCV/QCLP series claw pumps are single-stage, dry vacuum and overpressure
pumps driven by an electric motor. The vacuum and overpressure pumps are air-
cooled.
The pump is designed to be run as a vacuum pump or an overpressure pump
dependent upon its configuration.
The pump is specifically designed to work with clean air, inert gas or small amounts of
water vapor. The ambient temperature must be between 0 °C to 40 °C.
These pumps are enclosed in a sound-insulated bodywork to aid noise reduction,
cleanliness and heat transfer.
The QCV/QCLP claw pump robust design ensures complete flexibility and quick access
to all parts. The claw pump mainly includes dry claw element, gearbox, electric motor
and drive train all mounted on a common base frame.
Element
The pumping chamber consist of duplex set of rotating claws / rotors on cantilevered
shafts. The two claws and the cylinder are all non-touching but have accurate
clearances to allow a very efficient performance.
The main chamber is completely lubrication free and designed with corrosion resistant
materials. The whole assembly is referred to as an element.
Inlet non-return valve
Inlet non-return valve prevents reverse flow of inlet air and thus prevents reverse
rotation of the pump.
Gearbox
The element is driven through an oil lubricated gearbox housing synchro-meshing gears
which in-turn is coupled to a direct drive motor.
Electric motor
Electric motors are 3 phase ‘multi voltage/multi frequency’. For 60Hz supplies they are
cUL/UL approved. The main motor options are:
 200/230V 50/60Hz

Section II - General description
12
 400V 50Hz
 380V 60Hz
 500V 50Hz and 575 60Hz
 460V 60Hz
 230/460V 60Hz (Optional)
The motors are suited to operate with Variable Speed Drive to have complete
controllability and to reduce power consumption. This efficiency improvement leads to
power reduction and consequently a lower carbon footprint. Following standard features
provided with the pump:
 Vacuum relief valve (In case of vacuum pump)
The relief valve is designed to open at a predetermined set pressure to protect the
pump from damage.
When the vacuum level is exceeded, the relief valve opens and allows air to enter
the pumping chamber. This has the effect of internal cooling.
 Intake filter (In case of overpressure pump)
Intake filter prevents foreign material from entering the pump. Abrasive, bulky
material will damage the pump’s internal parts and could cause catastrophic failure.
 Silencer (Extra inlet silencer in case of overpressure pump)
The pump inlet and discharge can be noisy. The pump is equipped with an outlet
silencer.
For the overpressure pump an extra inlet silencer is installed.
 Pressure Safety valve (In case of overpressure pump)
A pressure safety valve automatically releases air from a pump, when the pressure
exceeds preset limits.
The following features are available as an option:
 Humid Option (In case of vacuum pump)
‘Standard’ and ‘Humid’ versions are available dependent upon the harshness of the
application.
The harsh applications, generally wet application need more protection for the pump.
‘Humid’ version contains advanced corrosion resistant wetted parts.
In addition to this, pump is provided with inlet liquid separator, condensate drain
facility and corrosion resistive coating to the exhaust to withstand the harsh
applications.

Section II - General description
13
General views of Dry claw vacuum and overpressure pumps
QCV 045, QCV 110, QCV 220 Dry claw vacuum pumps back view
QCV 045, QCV 110, QCV 220 Dry claw vacuum pumps front view

Section II - General description
14
Reference
Name
1
Drive motor (Fixed speed or inverter driven)
2
Gearbox
3
Inlet Non Return valve
4
Element
5
Exhaust silencer
6
Air outlet
7
Base frame
8
Oil drain plug
9
Oil sight glass
10
Vacuum relief valve
11
Noise reducing canopy
QCLP 110, QCLP 220 Dry claw overpressure pumps back view

Section II - General description
15
QCLP 110, QCLP 220 Dry claw overpressure pumps front view
Reference
Name
1
Air inlet
2
Air intake filter
3
Inlet silencer
4
Inlet Non Return valve
5
Element
6
Exhaust silencer
7
Pressure Safety valve
8
Air outlet
9
Gearbox
10
Drive motor (Fixed speed or inverter driven)
11
Base frame
12
Oil drain plug
13
Oil sight glass
14
Noise reducing canopy

Section II - General description
16
Flow diagram
Flow diagram - QCV 045, QCV 110, QCV 220 Dry claw vacuum pumps
Vacuum Pump
Air comes in through air intake and non-return valve arrangement and displaced by the
vacuum pump element.
After passing the element, the air enters the discharge silencer before exiting to the
atmosphere.

Section II - General description
17
Flow diagram - QCLP 110, QCLP 220 Dry claw overpressure pumps
Over pressure Pump
Air comes in through air inlet filter and silencer. The air flows through the non-return
valve which prevents reverse flow of air to the inlet. The air is compressed in the
element and exhausted at pressure through the pressure port.
Ensure that the safety valve at the outlet is correctly installed and adjusted.

Section II - General description
18
Cooling
Pump cooling
The pump is cooled by forward curved fan located within the coupling housing. This
provides air flow around the pump to aid cooling. The cooling fins also radiate the heat
away and the motor fan cools the drive motor.
The gearbox oil is cooled down by recirculation and convection from the fan.
In many cases the process gas can also cool the element.

Section II - General description
19
Condensate system
Position of Drain port
Reference
Name
1
Drain port
A port (1) at the base of the exhaust silencing chamber allows draining of the
condensate.
Humid versions of this vacuum pump may have a manual drain valve / tap installed to
facilitate easy draining.
From factory this drain point is sealed with a threaded plug, but can be exchanged by a
connector with tube to drain the condensate.
Consult local regulations which are applicable for water drainage.

Section III - Installation
20
 Dimension drawings
 Installation proposal
 Electrical connections
 Pictographs
Dimension drawings
See the next page.
