Quintet C35 User manual

C35 User’s Manual
Quintet Digital Corporation
1
Quintet C35TM Handheld Device
User’s Manual

C35 User’s Manual
Quintet Digital Corporation
2
Quintet Digital Corporation
9F-A, 728, Yan’An West Rd., Changning District,
Shanghai, 200050, China
Quintet C35 - User's Manual
Edition: 11/2010
ALL RIGHTS RESERVED
Quintet reserves the right to make modifications and improvements without prior
notification.
Quintet shall not be liable for technical or editorial errors or omissions contained herein,
nor for incidental or consequential damages resulting from the use of this material.
QuintetTM is a registered trademark of Quintet Digital Corporation in many countries and
the
QuintetTM logo is a trademark of Quintet Digital Corporation. All other brand and
product names mentioned herein are for identification purposes only and may be
trademarks or registered trademarks of their respective owners.
© Quintet Digital Corporation 2007-2010

C35 User’s Manual
Quintet Digital Corporation
3
CONTENTS
Reference.......................................................................................................................................................... 5
Reference Documentation...................................................................................................................... 5
Services and Support................................................................................................................................ 5
Safety Regulation......................................................................................................................................... 5
General Safety Rules...................................................................................................................................5
Radio Compliance.........................................................................................................................................6
FCC Compliance.............................................................................................................................................6
Quick Start…………………………………………………………………………………………………………..7
Chapter 1 Introduction ...........................................................................................................................8
1.1 Introduction……………………………………………………………………….........................................8
1.2 Quintet C35TM Handheld Device Description....................................................................11
1.3 Package Contents...............................................................................................................................11
1.4 Accessories..............................................................................................................................................11
1.5 Operating System ..............................................................................................................................12
Chapter 2 Connections............................................................................................................................13
2.1 Inserting Micro SD Card ...............................................................................................................13
2.2 Installing Battery packs .................................................................................................................15
2.3 USB Direct Connections ...............................................................................................................16
2.4 Cradle Connections .........................................................................................................................16
2.5 AC Adaptor Connections .............................................................................................................17
Chapter 3 Use and Functioning...................................................................................................... 16
3.1 PDA Startup.............................................................................................................................................16
3.2 Using the Stylus...................................................................................................................................16
3.3 Description of the Keys .................................................................................................................17
3.4 Status Indicators.................................................................................................................................. 18
3.5 Control Panel ....................................................................................................................................... 18
3.5.1 Stylus Calibration............................................................................................................................. 19
3.5.2 Volume Settings ............................................................................................................................ 20
3.5.3 Backlight Settings …....................................................................................................................... 22
3.6 Windows Connections ........................................................................................................................22
Chapter 4 Maintenance
.............................................................................................................................. 24
4.1 Charging the Battery Pack.............................................................................................................. 24
4.2 Replacing the Battery Pack ............................................................................................................24
4.3 Cleaning the PDA ................................................................................................................................. 26
Chapter 5 Technical Features
................................................................................................................. 27
5.1 Technical Data .......................................................................................................................................27

C35 User’s Manual
Quintet Digital Corporation
4
5.1.1 Electrical Features........................................................................................................................ 27
5.1.2 Environmental Features .......................................................................................................... 27
5.1.3 Mechanical Features ................................................................................................................. 27
5.1.4 Programming Features............................................................................................................... 27
Glossary
............................................................................................................................................................ 28

C35 User’s Manual
Quintet Digital Corporation
5
Reference
Reference Documents
For further information regarding Quintet C35TM handheld device refer to the SDK Help
on-Line.
Service and Support
Quintet provides several services as well as technical support through its website.
Log on to
www.rfid-provider.com
and click on the links indicated for further information
including:
-- Products
Search through the links to arrive at your product page where you can download specific
Manuals
and
Software & Utilities
-- Service and support
-- Quintet Services Warranty Extensions and Maintenance Agreements
--Authorized Repair Center
-- Contact us
E-mail form and listing of Quintet Subsidiaries
Safety Regulations
General Safety Rules
−Use only the components supplied by the manufacturer for the specific Quintet C35TM
handheld device being used.
−Do not attempt to disassemble the Qunitet C35TM handheld device, as it does not contain
parts that can be repaired by the user. Any tampering will invalidate the warranty.
−When replacing the battery pack or at the end of the operative life of the Quintet C35TM
handheld device, disposal must be performed in compliance with the laws in force..
Note
Read this manual carefully before performing any type of connection to the
Quintet
C35TM handheld device.
The user is responsible for any damages caused by incorrect use of
the equipment or
by inobservance of the indication supplied in this manual.

C35 User’s Manual
Quintet Digital Corporation
6
Radio Compliance
In radio systems configured with handheld device, the frequencies to be used must be
allowed by the spectrum authorities of the specific country in which the installation takes
place. Be absolutely sure that the system frequencies are correctly set to be compliant
with the spectrum requirements of the country.
The radio modules used in this product automatically adapt to the frequencies set by
the system and do not require any parameter settings.
FCC Compliance
Modifications or changes to this equipment without the expressed written approval of
Quintet could void the authority to use the equipment.
This device has been tested and found to comply with the limits for a CLASS B digital
device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference when the equipment is operated in a
commercial environment. This equipment generates, uses, and can radiate radio frequency
energy and, if not installed and used in accordance with the instruction manual, may cause
harmful interference to radio communications. Operation of this equipment in a residential
area is likely to cause harmful interference in which case the user will be required to correct
the interference at his/her own expense.
FCC ID: YAAC35010

C35 User’s Manual
Quintet Digital Corporation
7
Quick Start:
1.
Control Panel:
Click”Start” on the top left corner of the home
screen, select “Setting” to launch control panel.
2.
Stylus calibration:
Launch “Control Panel”, then select
“System” tab; Click “Screen”, choose “General” tab. Click
“adjust” to perform stylus calibration.
3.
Volume:
Launch “Control penal”, select “Sound” to adjust the
system volume..
4.
Backlight:
Launch “Control Panel”, select “Backlight” to
adjust the brightness of backlight.
5.
RFID:
Click “Start”, selects “Explorer”; click “Up” on the bottom
left corner, open “OEM_APP”, then run “RFID_Reader”.
6.
GPS:
Click “Start”, selects “Explorer”; click “Up” on the bottom
left corner, open “OEM_APP”, then run “GISMapping”
7.
Wi-Fi:
“Start”->”Setting”->”Connection”->”Wi-Fi”
8.
Bluetooth:
“Start”->”Setting”->”Connection”->”Bluetooth”
9.
Camera:
“Start”->”Photo&Video”->”Camera”

C35 User’s Manual
Quintet Digital Corporation
8
Chapter 1 Introduction
1.1 General View
Figure 1 – Top View
A) Data capture output window
B) Scan key(s)
C) Standby & power/charger status LED
D) Power on/off switch
E) Microphone input
F) Keypad input functions rotation key
G) Alphabetic/Numerical indicator LED
A
B
C
D
F
G
B
E

C35 User’s Manual
Quintet Digital Corporation
9
Figure 2 – Side View
H) USB client connector
I ) DC in jack
J) Dock connector
H
I
J

C35 User’s Manual
Quintet Digital Corporation
10
Figure 3 – Bottom View
K) Camera (reserved)
L) UHF RFID antenna
M) Speaker
N) SIM socket (reserved)
O) Micro SD socket
K
L
M
N
O

C35 User’s Manual
Quintet Digital Corporation
11
1.2 Quintet C35TM Handheld Device Description
Thanks for purchasing Quintet C35TM handheld device.
Thanks to the state-of the-art architecture and the most advanced technologies, it can
provide the most suitable levels for capturing, computing and communicating data faster
and easier.
The Quintet C35TM is equipped with a function-based interface for direct ERP transactions
and with a web-based layout for HTML needs as well. These key requirements make the
Qunitet C35TM perfect for use in field force automation, in store and logistics applications.
The Quintet C35TM enables companies and organizations worldwide to make more effective
use of people and tools for receiving, storage, and shipping activities. For example,
extended mobility allows simultaneous real-time inventory management and control of all
stock movements to increase precision while minimizing operating costs. Data on store
shelves, inventory levels and storage bins are immediately available to permit greater
coordination and cut flow times.
The Quintet C35TM provides mobile professionals with the most relevant features needed
to operate in demanding environments: reliability, ruggedness, drop resistance, long lasting
batteries, flexible communication and efficient data capture.
To optimize mobile applications, a user-accessible memory slot is also present to backup
data, extend databases, etc.
Thanks to a set of accessories, such as a vehicle cradle, cigarette lighter power adapter,
dashboard mounting kit, with state-of-the art technology inside the PDA, the Quintet C35TM
is the right answer for all data management needs on the move.
1.3 Package Contents
The Quintet C35TM handheld device package contains:
−1 Quintet C35TM PDA
−1 CD-ROM Quintet C35TM Software Development Kit
−2 Styluses
−1 User’s manual
−1 Rechargeable battery pack
−1 Hand grip belt (length adjustable)
−1 USB data communication cable
−1 Warranty card
Caution
Keep the original packaging for use when sending products to the
technical assistance
center. Damage caused by improper packaging is not covered under the warranty.

C35 User’s Manual
Quintet Digital Corporation
12
1.4 Accessories
Cradles
91-C1 Quintet C35TM Single Cradle Desk (includes slot for spare battery pack recharge;
RS232 and USB communications)
91-C2 Quintet C35TM Vehicle Cradle Standard
Charger
91-C3 Quintet C35TM Multi-Battery pack Charger (2 slots)
Batteries
46-11 Quintet C35TM Standard Battery pack (Li-Ion battery pack 1800 mAh@7.4 V)
46-21 Quintet C35TM Large Capacity Battery pack (Li-Ion battery pack 2800 mAh@7.4 V)
Power Supply
34-11 Universal 90~265V 47~63Hz 12V/2A adaptor
45-11 Power cord CCC 3-pin
45-21 Power cord UL 3-pin
45-31 Power cord EU 3-pin
Cables
45-41 USB Cable; cable for USB direct connection between the PDA and the PC
45-51 Vehicle Power Cable; cable for powering Quintet C35TM from the car cigarette lighter
Various
64-11 Hand Grip Belt
64-21 Stylus Pen
1.5 Operating System
Quintet C35TM comes in two different models, respectively supporting Windows CE and
Windows Mobile.
For further information regarding Windows Mobile refer to the website:
http://www.microsoft.com/windowsmobile.
Note
Use only a Quintet approved power supply and cables. Use of an alternative power supply
will invalidate any approval given to this device and may be dangerous.

C35 User’s Manual
Quintet Digital Corporation
13
Chapter 2 Connections
2.1 Inserting Micro SD Card
With Quintet C35TM, it is possible to add a Micro SD Card for additional storage capacity.
To access the Micro SD card slot, unlock the battery cover at the bottom of Quintet
C35TM (see Figure 4, 5) and then proceed as follows:
1. Remove the battery cover
2. Pull out the metal sheet top on the Micro SD card slot to unlock the slot.
3. Open the Micro SD card slot. (see Figure 6)
4. Insert the card and then close the Micro SD card slot.
5. Push in the metal sheet to lock the slot.
6. Install the battery cover
To remove the Micro SD card, repeat the procedure 1 to 6.
Figure 4

C35 User’s Manual
Quintet Digital Corporation
14
Figure 5
Figure 6

C35 User’s Manual
Quintet Digital Corporation
15
2.2 Installing battery pack
To access the battery install, unlock the battery cover at the bottom of Quintet C35TM (see
Figure 7) and then proceed as follows:
1. Remove the battery cover
2. Insert the battery pack with metal contact pin down.
3. Install the battery cover and lock it.
Figure 7
Caution
Follow proper ESD precautions to avoid damaging the SD. Proper ESD precautions
include, but are not limited to, working on an ESD mat and ensuring that the operator
is properly grounded.
Do not force the card. If you feel resistance, remove the card, check
the orientation,
and reinsert it.
Do not use the SD card slot for any other accessories.
Note
Rechargeable battery packs are not initially charged. Therefore the
first operation to
perform is to charge them.

C35 User’s Manual
Quintet Digital Corporation
16
2.3 USB Direct Connections
You can use a cable to connect the Quintet C35TM handheld device to a host computer
to transfer data.
2.4 Cradle Connections
The Quintet C35TM can also communicate via RS232 and USB, using various cradle models.
For further details, refer to the specific cradle model User’s Manual.
2
2.5 AC Adaptor Connections
The Quintet C35TM may power from AC adaptor, see the Figure 8 for connection instruction.
Figure 8
Caution
• USB communication may not be completely guaranteed while batteries are simultaneously in charge.
Avoid the power supply connection when the USB link is active.
• Windows7/ Vista user need to use Windows Mobile Device Center6.1 on the PC end，
XP or earlier version of Windows, please use ActiveSync to synchronize the information with C35TM
for detail information please follow the link：
http://www.microsoft.com/windowsphone/en-us/howto/wp6/sync/installing-wmdc.aspx

C35 User’s Manual
Quintet Digital Corporation
17
Chapter 3 Uses and Functioning
The use of the Quintet C35TM handheld device depends on the application software loaded.
However there are several parameters that can be set and utilities that can be used to
perform some basic functions such as data capture, communications, file management,
etc.
3.1 PDA Startup
The Quintet C35TM handheld device turns on when the battery pack or the external supply
is inserted.
After the battery pack is installed, use the [ON/OFF] key to turn the PDA on and off.
As soon as the PDA is on, the Windows CE/ Windows Mobile desktop screen will appear.
Wait a few seconds before starting any activity so that the PDA completes its startup
procedure.
When it is no longer used for more than a programmable timeout, which is defined in
the Power applet of the Control Panel, the PDA goes into power-off (low power with display
and keyboard backlight off). In this mode it can be awakened (resuming operation) by
the [Standby] key.
3.2 Using the Stylus
The stylus selects items and enters information. The stylus functions like a mouse.
Tap
: Touch the screen once with the stylus to open items and select options (Windows
Mobile only).
Double Tap
: Touch the screen twice with the stylus to open items and select options
(Windows CE only).
Drag
: Hold the stylus on the screen and drag across the screen to select text and images.
Drag in a list to select multiple items.
Tap-and-hold
:
Tap and hold the stylus on an item to see a list of actions available for that item. On
the pop-up menu that appears, tap the action you want to perform.
NOTE
The PDA can also be awakened or turned off by the application program.

C35 User’s Manual
Quintet Digital Corporation
18
Figure 9
3.3 Description of the Keys
The Quintet C35TM provides a function-oriented keyboard having a total of 19 keys.
The keyboard can be divided as follows:
Power ON/OFF key
Power ON/OFF the Quintet C35TM handheld device while press the key.
Standby key
Switch off the backlight for saving power while press.
Fn key
Rotate with Navigation, Alphabetic and Numerical while press the key.
Caution
Use only original Quintet styluses supplied with the product itself.
In harsh applications, use of screen protectors should be taken into consideration, in
order to extend the touch screen operating life.
To prevent damage to the screen, do not use sharp devices or any
device other than
the Quintet-provided stylus.
Do not apply not necessary high pressures on the screen.
For applications where an intensive use of the touch screen is foreseen, please consider
that touch screen components are subject to progressive wear.

C35 User’s Manual
Quintet Digital Corporation
19
System Control and Navigation Keys
They let you move forwards or backwards within the Internet Explorer browser pages.
They let you move forwards, backwards, upwards or downwards within Text fields, scroll
through a Menu list or browse among folder files.
3.4 Status Indicators
The Quintet C35TM provides two different LEDs signaling the PDA status.
Power on/Charging status LED
: Green/Amber (left side)
Green constant: It is constant once the charging process has been completed.
Amber blinking: It blinks when the battery pack is running down.
Amber constant: It is constant while charging.
Green/Amber blinking: It blinks while battery pack has errors occurred while in charging
process.
Alphabetic/Numerical LED:
Green/Red (right side)
Green: It is constant green in alphabetic mode.
Red: It is constant red in numerical mode.
3.5 Control Panel
From the Windows CE Desktop, double tap on the "Control Panel" icon to open the
Windows CE control panel main window. The Control Panel can also be launched from
Start ->Settings ->Control Panel.
Figure 10 Figure 11

C35 User’s Manual
Quintet Digital Corporation
20
3.5.1 Stylus Calibration
You might need to recalibrate the touch screen (i.e. when you attempt to select one item
with the stylus, another item is erroneously selected).
To recalibrate the touch screen on Windows CE, complete the following steps:
1. Select
Start > Settings > Control Panel > Stylus
to open the
Stylus Properties
dialog
as shown in Figure 12.
2. Adjust
Double-Tap
sensitivity if needed or desired.
3. Select the
Calibration
tab to open the
Calibration
application.
4. Tap
Recalibrate
to open the
Calibration
screen shown in Figure 13.
5. Carefully press and briefly hold stylus on the center of the target. Repeat as the target
moves around the screen. Press the
<ESC>
key to cancel the stylus calibration.
6. Press the
<ENTER>
key or tap the screen to accept the new calibration settings.
7. Press the
<ESC>
key to keep the old settings.
8. New calibration settings are persistently saved in registry.
Figure 12 Figure 13
Startup stylus calibration on Windows CE
When starting the terminal, a stylus calibration screen comes up if valid calibration settings
are not available. This happens in the following circumstances:
1. At the first startup of the terminal.
2. After restoring registry default settings using the applet
Registry Admin
and performing
a warm boot.
