SF180
Installation Instructions
RadonAway
3 Saber Way Ward Hill, MA 01835
www.radonaway.com
P/N IN065-REV C 2/12

IN065 Rev C Page 2 of 8
RadonAway Ward Hill, MA.
Series Fan Installation Instructions
Please Read and Save These Instructions.
DO NOT CONNECT POWER SUPPLY UNTIL FAN IS COMPLETELY INSTALLED.
MAKE SURE ELECTRICAL SERVICE TO FAN IS LOCKED IN "OFF" POSITION.
DISCONNECT POWER BEFORE SERVICING FAN.
1. WARNING! Do not use fan in hazardous environments where fan electrical system could provide ignition to
combustible or flammable materials.
2. WARNING! Do not use fan to pump explosive or corrosive gases.
3. WARNING! Check voltage at the fan to insure it corresponds with nameplate.
4. WARNING! Normal operation of this device may affect the combustion airflow needed for safe operation of fuel
burning equipment. Check for possible backdraft conditions on all combustion devices after installation.
5. NOTICE! There are no user serviceable parts located inside the fan unit.
Do NOT attempt to open any part of Fan other than Electrical Covers. Return unit to the factory for service.
Note: An Electrical Switch Box may be installed under the removeable bottom right corner cover.
6. All wiring must be performed in accordance with the National Fire Protection Association’s (NFPA)”National Electrical
Code, Standard #70”-current edition for all commercial and industrial work, and state and local building codes. All
wiring must be performed by a qualified and licensed electrician
7. WARNING! Do not leave fan unit installed on system piping without electrical power for more than 48 hours. Fan
failure could result from this non-operational storage.
8. WARNING! TO REDUCE THE RISK OF FIRE, ELECTRIC SHOCK, OR INJURY TO PERSONS, OBSERVE THE
FOLLOWING:
a) Use this unit only in the manner intended by the manufacturer. If you have questions, contact the manufacturer.
b) Before servicing or cleaning unit, switch power off at service panel and lock the service disconnecting means to
prevent power from being switched on accidentally. When the service disconnecting means cannot be locked, securely
fasten a prominent warning device, such as a tag, to the service panel."

IN065 Rev C Page 3 of 8
INSTALLATION INSTRUCTIONS IN065 Rev C
RadonAway - SF Series
SF180 p/n 28317
1.0 SYSTEM DESIGN CONSIDERATIONS
1.1 INTRODUCTION
The RadonAway SF Series Radon Fans are intended for use by trained, professional Radon mitigators.
The purpose of this instruction is to provide additional guidance for the most effective use of a
RadonAway Fan. This instruction should be considered as a supplement to EPA standard practices,
state and local building codes and state regulations. In the event of a conflict, those codes, practices and
regulations take precedence over this instruction.
1.2 ENVIRONMENTALS
The SF Series Fans are designed to perform year-round in all but the harshest climates without
additional concern for temperature or weather. For installations in an area of severe cold weather,
please contact RadonAway for assistance. When not in operation, the fan should be stored in an area
where the temperature is never less than 32 degrees F. or more than 100 degrees F.
1.3 ACOUSTICS
The SF Series Fan, when installed properly, operates with little or no noticeable noise to the building
occupants. The velocity of the outgoing air should be considered in the overall system design. In some
cases the "rushing" sound of the outlet air may be disturbing. In these instances, the use of a
RadonAway Exhaust Muffler is recommended.
1.4 GROUND WATER
In the event that a temporary high water table results in water at or above slab level, water may be
drawn into the riser pipes thus blocking air flow to the SF Series Fan. The lack of cooling air may result
in the fan cycling on and off as the internal temperature rises above the thermal cutoff and falls upon
shutoff. Should this condition arise, it is recommended that the fan be turned off until the water recedes
allowing for return to normal operation.
1.5 SLAB COVERAGE
The SF Series Fan can provide coverage up to 2000+ sq. ft. per slab penetration. This will primarily
depend on the sub-slab material in any particular installation. In general, the tighter the material, the
smaller the area covered per penetration. Appropriate selection of the a Fan best suited for the sub-slab
material can improve the slab coverage. The SF180 is best suited for general purpose use. Additional
suction points can be added as required. It is recommended that a small pit (5 to 10 gallons in size) be
created below the slab at each suction hole.

IN065 Rev C Page 4 of 8
1.6 CONDENSATION & DRAINAGE
Condensation is formed in the piping of a mitigation system when the air in the piping is chilled below
its dew point. This can occur at points where the system piping goes through unheated space such as an
attic, garage or outside. The SF Fan has an integral means for water to drain back to the slab hole to
remove the condensation. The SF Series Fan MUST be mounted vertically plumb and level, with the
outlet pointing up for proper drainage through the fan. Avoid mounting the fan in any orientation that
will allow water to accumulate inside the fan housing. The SF Series Fans are NOT suitable for
underground burial.
For SF Series Fan piping, the following table provides the minimum recommended pipe diameter and
inlet pitch under several system conditions.
Pipe
Dia. Minimum Rise per Ft of Run*
@25 CFM @50 CFM @100 CFM
4" 1/8 1/4 3/8
3" 1/4 3/8 1 1/2
*Typical SF160 Series Fan operational flow rate is 30 - 90 CFM 0n 3” and 4” pipe.
(For more precision, determine flow rate by measuring Static Pressure, in WC, and
correlate pressure to flow in the performance chart in the addendum.)
On an outdoor installation a condensate bypass is not required. The SF Fan contains an
integral internal bypass suitable for use in cold climate installations which require long lengths
of outlet ducting or where the outlet ducting is likely to produce large amounts of
condensation because of high soil moisture or outlet duct material. Schedule 20 piping and
other thin-walled plastic ducting and Aluminum downspout will normally produce much
more condensation than Schedule 40 piping which is prefered.
1.7 "SYSTEM ON" INDICATOR
A properly designed system should incorporate a "System On" Indicator for affirmation of
system operation. A manometer, such as a U-Tube, or a vacuum alarm is recommended for
this purpose.
1.8 ELECTRICAL WIRING
The SF Series Fans operate on standard 120V 60 Hz. AC. All wiring must be performed in
accordance with the National Fire Protection Association’s (NFPA)”National Electrical Code,
Standard #70”-current edition for all commercial and industrial work, and state and local
building codes. All wiring must be performed by a qualified and licensed electrician. Ensure that
all exterior electrical boxes and other components are outdoor rated and properly sealed to
prevent water penetration into the box. A means, such as a weep hole, is recommended to drain
the box. Note that the exterior electrical box may be mounted under the removeable bottom right
corner cover. If located under the corner cover the electrical box should be positioned relative to
the inlet pipe using the template provided.
1.9 SPEED CONTROLS
The SF Series Fans are rated for use with electronic speed controls. The recommended speed
control if used is Pass & Seymour Solid State Speed Control Cat. No. 94601-I.
RUN
RISE

IN065 Rev C Page 5 of 8
2.0 INSTALLATION
The SF Series Fan can be mounted indoors or outdoors. (It is suggested that EPA
recommendations be followed in choosing the fan location.) The SF Series Fan is intended be
mounted directly on the system piping. There is no mounting bracket available for this unit. In
addition to the inlet and outlet pipe mounts a single vibration mount is provided at the bottom
right hand corner of the inner housing, underneath the removeable corner cover, the vibration
mount may be screwed directly to the house siding.

IN065 Rev C Page 6 of 8
2.1 MOUNTING
Mount the SF Series Fan vertically with outlet up. Insure the unit is plumb and level. When
mounting directly on the system piping assure that the fan body does not contact any building
surface to avoid vibration noise.
2.2 SYSTEM PIPING
Complete piping run, using flexible couplings as means of disconnect for servicing the unit and
vibration isolation. If 3” inlet piping is used mount the eccentric adapter supplied inside the 4”
flexible coupling, connected to the inlet, with the “TOP” arrow at the high point pointing
towards outlet.
2.3 ELECTRICAL CONNECTION
Connect wiring with wire nuts provided, observing proper connections (See Section 1.8):
Fan Wire Connection
Green Ground
Black AC Hot
White AC Common
2.4 VENT MUFFLER (optional)
Install the muffler assembly in the selected location in the outlet ducting. Solvent weld all
connections. The muffler is normally installed at the end of the vent pipe.
2.5 OPERATION CHECKS
_____ Verify all connections are tight and leak-free.
_____ Insure the SF Series Fan and all ducting is secure and vibration-free.
_____ Verify system vacuum pressure with manometer. Insure vacuum pressure is less than
maximum recommended operating pressure
(Based on sea-level operation, at higher altitudes reduce by about 4% per 1000 Feet.)
(Further reduce Maximum Operating Pressure by 10% for High Temperature environments)
See Product Specifications. If this is exceeded, increase the number of suction points.
_____ Verify Radon levels by testing to EPA protocol.

IN065 Rev C Page 7 of 8
SF SERIES PRODUCT SPECIFICATIONS
The following chart shows fan performance for the SF Series Fan:
Typical CFM Vs Static Pressure "WC
0" .25" .5" .75" 1.0" 1.25" 1.5" 1.75" 2.0"
SF180 149 137 127 117 96 80 61 40 -
Power Consumption
120 VAC, 60Hz 1.0 Amp Maximum
Maximum Recommended
Operating Pressure* (Sea Level Operation)**
SF180 53 - 71 watts SF180 1.7" W.C.
*Reduce by 10% for High Temperature Operation
**Reduce by 4% per 1000 feet of altitude
Size Weight Inlet/Outlet
SF180 17.5H”x16W”x6.5D” 13.1 lbs. 4.5" OD (4.0" PVC Sched 40 size compatible)
Recommended ducting: 3" or 4" SF180, , Schedule 20/40 PVC Pipe (Sch.40 prefered)
Mounting: Mount on the duct pipe.
Storage temperature range: 32 - 100 degrees F.
Normal operating temperature range: -20 - 120 degrees F.
Maximum inlet air temperature: 80 degrees F.
Continuous Duty
Class F Insulation
Thermally protected
3000 RPM
Rated for Indoor or Outdoor Use

IN065 Rev C Page 8 of 8
IMPORTANT INSTRUCTIONS TO INSTALLER
Inspect the GP/XP/XR/SF Series Fan for shipping damage within 15 days of receipt. Notify
RadonAway of any damages immediately. Radonaway is not responsible for damages incurred
during shipping. However, for your benefit, Radonaway does insure shipments.
There are no user serviceable parts inside the fan. Do not attempt to open. Return unit to factory
for service.
Install the GP/XP/XR/SF Series Fan in accordance with all EPA standard practices, and state
and local building codes and state regulations.
WARRANTY
Subject to any applicable consumer protection legislation, RadonAway warrants that the GPX01/XP/XR/RP/SF SeriesFan (the “Fan”) willbe free
from defectsin materials and workmanship for a period of 90 days fromthe date of purchase (the “Warranty Term”).
RadonAway willreplace any Fan which fails due to defects in materials or workmanship. The Fan must be returned (at Owner’s cost)tothe
RadonAway factory.Any Fan returned to the factorywill be discarded unless the Owner provides specific instructionsalong with the Fan when itis
returned regardless of whether ornotthe Fan is actually replaced under this warranty. Proof of purchase must be supplied upon request for
service under this Warranty.
ThisWarranty iscontingent on installation of the Fan in accordance with the instructions provided. This Warranty does not applywhere any
repairsor alterations have been made orattempted by others, or if the unit has been abused or misused. Warrantydoesnot coverdamage in
shipment unlessthe damage isdue to the negligence of RadonAway.
5 YEAR EXTENDEDWARRANTYWITHPROFESSIONAL INSTALLATION.
RadonAway willextend the Warranty Term of the fan to 5 years from date of manufacture if the Fan is installed in a professionally designed and
professionally installed radon system or installed asa replacement fan in a professionally designed and professionally installed radon system.
Proof of purchase and/or proof ofprofessional installation may be required for service under this warranty. Outside the Continental United States
and Canada the extended WarrantyTerm is limited to one (1) year from the date of manufacture.
RadonAway is not responsible for installation, removal or delivery costs associated with this Warranty.
EXCEPT AS STATED ABOVE, THE GPx01/XP/XR/RP/SF SERIES FANS ARE PROVIDED WITHOUT
WARRANTY OF ANY KIND, EITHER EXPRESS OR IMPLIED, INCLUDING, WITHOUT LIMITATION,
IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE.
IN NO EVENT SHALL RADONAWAY BE LIABLE FOR ANY DIRECT, INDIRECT, SPECIAL, INCIDENTAL,
OR CONSEQUENTIAL DAMAGES ARISING OUTOF, OR RELATING TO, THE FAN OR THE
PERFORMANCE THEREOF. RADONAWAY’S AGGREGATE LIABILITY HEREUNDER SHALL NOT IN
ANY EVENTEXCEED THE AMOUNT OF THE PURCHASE PRICE OF SAID PRODUCT. THE SOLE AND
EXCLUSIVE REMEDY UNDER THIS WARRANTY SHALL BE THE REPAIR OR REPLACEMENT OF THE
PRODUCT, TO THE EXTENT THE SAME DOES NOT MEET WITH RADONAWAY’S WARRANTY AS
PROVIDED ABOVE.
For service under this Warranty, contact RadonAway for a Return Material Authorization (RMA) number and shipping
information. No returns can be accepted without an RMA. If factory return is required, the customer assumes all shipping
cost to and from fact ory.
RadonAway
3 Saber Way
Ward Hill, MA 01835
TEL. [phone]
FAX [phone]
Record the following information for your records:
Serial No.
Purchase Date
