Rampage ACC-30 User manual

OWNER'SOWNER'S
OWNER'SOWNER'S
OWNER'S
MANUALMANUAL
MANUALMANUAL
MANUAL
ACC-30
6-DISC CD CHANGER
ÿ
ÿþýüûÿú
ACC-30
DIGITAL AUDIO 6 DISC
COMPACT DISC CHANGER

1
HINTS FOR CORRECT AND SAFE OPERATION
This CD Changer is designed to be operated only on 12 volt DC
negative ground systems. The unit can not be used on 24 volt or
positive ground systems.
TEMPERATURE
The unit may not operate correctly in extremely hot or cold
temperatures. It is equipped with a built-in thermal protection
circuit which will stop operation of the unit when the temperature
reachesthepre-setlevel. Ifthisshouldhappen,theunitwillresume
operationwhenthevehicle returns to anormaltemperaturerange.
Removethemagazinefromtheunitwhenitisnotbeingusedduring
hot weather. If the discs are left in an extremely hot car they may
warp. IftheCDchangerisnotusedforlongperiodsof time, remove
the compact discs from the magazine, and store them in their
cases.
CONDENSATION
Moisturecan condenseon the laser lens of the CD changer during
rainyandhumiddays,or right after theheateristurnedon in the car
(if the changer is mounted in the passenger compartment). If this
should happen the unit will not operate correctly. To remedy the
situation, remove the discs from the unit and wait approximately
one hour. During this time the moisture will evaporate and the unit
will operate normally.
INTERRUPTIONS IN SOUND (Skipping)
The sound from the unit may "skip" and be interrupted if the anti-
vibration springs are not set correctly, if the changer is mounted in
excess of a 15° angle, or when travelling on very rough road
surfaces. If this should occur, check for errors made during
installation or wait for the road surface to improve.
3" (8cm) CD-SINGLES
This unit is not designed to play 3" (8cm) CD-Single discs.
Insertinga3"discintothe magazine, either with orwithouta3"disc
adaptor,can damage thechanger and thedisc. Such damage will
not be covered by the Warranty on this product.

2
HANDLING THE DISCS
Dirt, dust, scratches and warpage cause sound skips during playback and a deterioration of sound quality. To take proper care
of your discs:
1. Use compact discs that have the mark
2. Fingerprints and dust should be carefully wiped off the disc's signal surface (glossy side) with a soft cloth. Unlike conventional
records,the compact disc has no grooves tocollect dustand microscopic debris, so gently wiping witha softcloth should remove
most particles. Wipe in a straight motion from the inside to the outside of the disc. Small dust particles or light stains will have
absolutely no effect on reproduction quality.
3. Never use such chemicals as record sprays, antistatic sprays or fluids, benzine or thinner to clean compact discs. Such
chemicals could irreparably damage the disc's plastic surface.
4. Discs should be put back in their cases after use to avoid serious scratches that could cause the sound to skip.
5. Do not expose discs to direct sunlight, high humidity, or high temperatures for extended periods of time. Long exposure to high
temperatures can warp the disc.
6. Do not stick paper, labels, or tape on the disc surface.
7. Do not write with any type of pen, pencil, or marker on the disc surface.
8. To minimize fingerprints and smudges on the signal surface, always try to hold the discs by their outer edge and center hole.

3
USE OF THE CD MAGAZINE
LOADING DISCS INTO THE MAGAZINE
ThisCDChangerusesaspecially-designedmagazine to hold up
to 6 compact discs. Insert discs into the magazine with the label
side up as shown in Figure 1. As each disc is inserted into the
magazine, the release key for that slot will be raised.
The discs are numbered from 1 (bottom slot) to 6 (top slot).
REMOVING DISCS FROM THE MAGAZINE
To remove a disc from the magazine, press the release key for
the desired disc and carefully remove the disc by holding the
edge.
Fig. 1
Avoid touching the playing side of the disc.
Only one disc can be inserted into each slot of the magazine.
Do not try to insert more than one disc into each slot as
damage to the discs and magazine may occur.
This changer is not designed to play 3" CD-Single discs
(8cm). Inserting a 3" disc into the magazine, either with or
without a 3" disc adaptor, can damage the changer and the
disc. Such damage will not be covered by the Warranty on
this product.
Additional CD magazines are available as accessory item
P-16C from your Rampage/Audiovox dealer, or you may
contact us directly at:



Attention: Parts Division
AudiovoxCorporation
150 Marcus Blvd.
Hauppauge,NY 11788
NOTES:
Fig. 2
Release Keys

CD magazine
One disc in each slot
(maximum 6 discs)
Label side up
(playing side down)

4
LOADING THE MAGAZINE INTO THE CHANGER
Completely slide the door on the changer to the right as shown
in Figure 3. Making sure the top of the magazine is facing
upward, gently insert it into the unit until it clicks into place, as
shown in Figure 4. Slide the door of the changer fully closed and
the unit is ready for operation.
REMOVING THE MAGAZINE FROM THE CHANGER
To remove the magazine, slide open the door on the changer
and press the eject button as shown in Figure 5.
NOTE:
Be sure to keep the door on the changer closed at all times
when not loading or removing the magazine. Leaving the
door open could allow dust, dirt and moisture to enter the
changer which could cause the unit to malfunction.
To assure proper playback, it is recommended that the CD
magazine be loaded with more than one disc.
Fig. 3
Door
Fig. 4
Fig. 5
Eject Button


ÿ
ÿþýüûÿú
ÿ
ÿþýüûÿ ú
ÿ
ÿþýüûÿú

5
* Due to continuing improvement, Audiovox reserves the right to change features and design without notice.
CD CHANGER OPERATING INSTRUCTIONS
ThisCDChangerisdesignedtooperatethrough a compatible Rampage/Audiovoxcar
stereowhichincorporatesthecontrols and display functions. Pleasecheckwithyour
Rampage/Audiovox stereo specialist for recommendations of the models that will
work with this changer or contact us directly at 1-800-645-4994. The specific
operatinginstructions for the changer will be contained within the Owner's Manual of
the compatible unit.
NOTE: When using this changer with Rampage AV-427 radio/cassette player,
make certain the Changer Selector switch on the bottom of the radio is
set to position "B".
FrequencyResponse: 20 - 20,000 Hz. ±1 dB
Distortion: 0.03% @ 1 kHz.
DynamicRange: 87 dB
Signal-to-NoiseRatio: 85 dB
ChannelSeparation: 70 dB @ 1 kHz.
Wow & Flutter: below measurable limits
Dimensions: 11-3/8"W x 2-7/8"H x 7-5/8"D
288 mm x 76 mm x 192 mm
OperatingVoltage: 12 volts DC, negative ground
SPECIFICATIONS:

TROUBLESHOOTING
An error made in operation or during installation of this product may be mistaken for a system malfunction. Please perform
the checks described below before contacting your dealer or service facility.
No power
Magazine cannot be
installed
CD is not played
Noise, skipping, or
intermittent sound
during playback.
Blown fuse
Incorrect connection
Magazine is inserted in wrong
direction
Disc is loaded incorrectly in magazine
Scratches on disc or warped disc
Extremely dirty disc
Transit screws still in place
Mounting angle adjustment is not
correct
Possible Cause Remedy
Symptom
Check fuses in vehicle fuse box and changer system.
Replace as necessary with fuse of same type and rating as
original. If fuse blows again, consult with service facility.
Check all wiring and correct as necessary.
Insert magazine in proper direction.
Load disc correctly in the magazine.
Check sound on another disc. If sound from second disc is
OK, first disc is defective.
Clean disc
Remove the transit screws from bottom of the unit.
Set the mounting angle adjustment to the correct position as
per the installation instructions.
6

© 1999 AUDIOVOX CORP., HAUPPAUGE, N.Y. PRINTED IN KOREA
128-5569
AUDIOVOX CORPORATION (the Company) warrants to the original retail purchaser of this product that should this product or
any part thereof, under normal use and conditions, be proven defective in material or workmanship within 12 months from the date
of original purchase, such defect(s) will be repaired or replaced with new or reconditioned product (at the Company's option) without
charge for parts and repair labor.
To obtain repair or replacement within the terms of this Warranty, the product is to be delivered with proof of warranty coverage
(e.g. dated bill of sale), specification of defect(s), transportation prepaid, to the warranty center at the address shown below.
This Warranty does not extend to the elimination of car static or motor noise, to correction of antenna problems, to costs incurred
for installation, removal, or reinstallation of the product, or damage to tapes, compact discs, speakers, accessories, or vehicle
electrical systems.
This Warranty does not apply to any product or part thereof which, in the opinion of the Company, has suffered or been damaged
through alteration, improper installation, mishandling, misuse, neglect, accident, or by removal or defacement of the factory serial
number/bar code label(s). THE EXTENT OF THE COMPANY'S LIABILITY UNDER THIS WARRANTY IS LIMITED TO THE
REPAIR OR REPLACEMENT PROVIDED ABOVE AND, IN NO EVENT, SHALL THE COMPANY'S LIABILITY EXCEED THE
PURCHASE PRICE PAID BY PURCHASER FOR THE PRODUCT.
This Warranty is in lieu of all other express warranties or liabilities. ANY IMPLIED WARRANTIES, INCLUDING ANY IMPLIED
WARRANTYOFMERCHANTABILITY, SHALL BELIMITED TO THEDURATIONOF THIS WRITTENWARRANTY. ANY ACTION
FOR BREACH OF ANY WARRANTY HEREUNDER INCLUDING ANY IMPLIED WARRANTY OF MERCHANTABILITY MUST
BE BROUGHT WITHIN A PERIOD OF 30 MONTHS FROM DATE OF ORIGINAL PURCHASE. IN NO CASE SHALL THE
COMPANY BE LIABLE FOR ANY CONSEQUENTIAL OR INCIDENTAL DAMAGES FOR BREACH OF THIS OR ANY OTHER
WARRANTY, EXPRESS OR IMPLIED, WHATSOEVER. No person or representative is authorized to assume for the Company
any liability other than expressed herein in connection with the sale of this product.
Some states do not allow limitations on how long an implied warranty lasts or the exclusion or limitation of incidental or
consequential damage so the above limitations or exclusions may not apply to you. This Warranty gives you specific legal rights
and you may also have other rights which vary from state to state.
12 MONTH LIMITED WARRANTY
U.S.A. : AUDIOVOX CORPORATION, 150 MARCUS BLVD., HAUPPAUGE, NEW YORK 11788 1-800-645-4994
CANADA: CALL 1-800-645-4994 FOR LOCATION OF WARRANTY STATION SERVING YOUR AREA 128-4270E
