Rasha Arete PROFESSIONAL A Owner's manual

RASHA PROFESSIONAL A/S
Rasha Professional A/S 1800 Rustin Ave. Riverside CA, 92507 || 951-654-3585
rashaprofessional.com || [email protected]
1
QUICK USER MANUAL
Arete

Rasha Professional A/S 1800 Rustin Ave., Riverside CA, 92507 || 951-654-3585
rashaprofessional .com || [email protected]
2
Edition Notes
The Arete , User Manual Rev. 1 covers the description,
safety precautions, installation, programming, operation,
and maintenance of the Arete. Rasha released this edition
of the Arete User Manual in May 2023.
Trademarks
Rasha®Is a registered trademark of RASHA
PROFESSIONAL A/S. (D/b/a RASHA®or Rasha). The
RASHA® logo in its entirety including the RASHA®name
and the Globe with Rings, and all other trademarks in this
manual pertaining to services, products, or marketing
statements are owned or licensed by RASHA®. Any other
product names, logos, brands, company names, and other
trademarks featured or referred to within this document
are the property of their respective trademark holders.
Copyright
Notice
RASHA owns the content of this User Manual
in its entirety, including but not limited to
pictures, logos, trademarks, and resources.
© Copyright 2015 RASHA. All rights reserved.
Electronically published by Rasha in the United States of
America.
Manual Use
Rasha authorizes its customers to download and print this
manual for professional information purposes only. Rasha
expressly prohibits the usage, copy, storage, distribution,
modication, or printing of this manual or its content for
any other purpose without written consent from Rasha.
Document
Printing
For better results, print this document in color, on letter
size paper (8.5 x 11 in), double-sided. If using A4 paper
(210 x 297 mm), congure your printer to scale the content
accordingly.
Intended
Audience
Any person in charge of installing, operating, and/or
maintaining this product should completely read through
the guide that shipped with the product, as well as this
manual, before installing, operating, or maintaining this
product.
Document
Revision
The Arete User Manual Rev. 1 supersedes all previous
versions of this manual. Discard any older versions of
this manual and replace with this version. Go to www.
rashaprofessional.com for the latest version.
Author Date Editor Date
. 27/05/2023

Rasha Professional A/S 1800 Rustin Ave., Riverside CA, 92507 || 951-654-3585
rashaprofessional.com || [email protected]
3
1. Before You Begin................................. 4
What Is Included .................................. 4
Claims .................................................. 4
Manual Conventions ............................ 4
Symbols ............................................... 4
Safety Notes......................................... 5
Personal Safety.................................... 5
Mounting And Rigging .......................... 5
Power And Wiring................................. 5
Operation ............................................. 5
2. Introduction.......................................... 6
Description ........................................... 6
Features ............................................... 6
Overview .............................................. 6
Dimensions .......................................... 7
3. Setup..................................................... 8
Power Supply ....................................... 7
AC Plug ................................................ 8
Fuse Replacement ............................... 8
Power Linking....................................... 8
DMX Linking......................................... 8
DMX Personalities................................ 8
Mounting .............................................. 9
Orientation............................................ 9
Rigging ................................................. 9
Procedure............................................ 9
4. Menu Map........................................... 10
Menu Map ..................................... 10-11
Control Panel Description .................. 12
DMX Channels ..............................13-22
Returns.............................................. 23
Contact Us ........................................ 24
Table of Contents

Rasha Professional A/S 1800 Rustin Ave., Riverside CA, 92507 || 951-654-3585
rashaprofessional.com || [email protected]
4
What Is
Included
• Rasha Arete
• Edition to Trueone®
• DMX Cable
• Quick reference guide
Claims
Carefully unpack the product immediately
and check the box to make sure all the parts
are in the package are in good condition.
If the box or the contents (the product and included
accessories) appear damaged from shipping or show signs
of mishandling, notify the carrier immediately, not Rasha.
Failure to report damage to the carrier immediately may
Void your claim. In addition, keep the box and contents
for inspection.
For other issues, such as missing components or parts,
damage not related to shipping, or concealed damage, le
a claim with Rasha within 7 days of delivery.
Manual
Conventions
Convention Meaning
1–512 DMX value range in number
Symbols
Symbols Meaning
Display
Flashing
DMX Single lost or disconnected
The term “DMX” used throughout this manual refers to the DMX512 digital
data transmission protocol

Rasha Professional A/S 1800 Rustin Ave., Riverside CA, 92507 || 951-654-3585
rashaprofessional.com || [email protected]
5
Safety Notes
Read all the following Safety Notes before working with this product. These
notes include important information about the installation, usage, and
maintenance of this product. This product contains no user-serviceable
parts. Any reference to servicing in this User Manual will only apply to
properly trained Rasha certied technicians. Do not open the housing or
attempt any repairs. All applicable local codes and regulations apply to
proper installation of this product.
Personal
Safety
Avoid direct eye exposure to the light source while the product is on. Always
disconnect this product from its power source before servicing. Always
connect this product to a grounded circuit to avoid the risk of electrocution.
Do not touch this product’s housing during operation because it may be
very hot.
Rigging
This product is for indoor use only! To prevent risk of re or shock, do
not expose this product to rain or moisture. (IP20) CAUTION: When
transferring product from extreme temperature environments, (e.g. Cold
truck to warm humid ballroom) condensation may form on the internal
electronics of the product. To avoid causing a failure, allow product
to fully acclimate to the surrounding environment before connecting it
to power. Mount this product in a location with adequate ventilation,
at least 20 in (50 cm) from adjacent surfaces. Make sure there are
no ammable materials close to this product while it is operating.
Always carry
this product by the handles. Do not carry from the head. When hanging this
product, always secure to a fastening device using a safety cable.
Power And
Wiring
Always make sure you are connecting this product to the proper voltage
in accordance with the specications in this manual or on the product’s
specication label. Never connect this product to a dimmer pack or rheostat.
Never disconnect this product by pulling or tugging on the power cable.
Operation
Do not operate this product if you see damage to the housing, lenses,
or cables. Have the damaged parts replaced by an authorized
technician at once. To eliminate unnecessary wear and improve
its lifespan, during periods of non-use completely disconnect the
product from power via breaker or by unplugging it. Do not cover the
ventilation slots when operating to avoid internal overheating. Do not
aim this product toward the Sun. The lenses could concentrate the
solar energy and cause internal overheating. The maximum ambient
temperature is 113 °F (45 °C). Do not operate this product at a
higher temperature. In case of a serious operating problem, stop using this
product immediately!
The term “DMX” used throughout this manual refers to the DMX512 digital data
transmission protocol

Rasha Professional A/S 1800 Rustin Ave., Riverside CA, 92507 || 951-654-3585
rashaprofessional.com || [email protected]
6
Features • Highest e󰀩ciency & way to power ratio.
• Light weight, compact size.
• Shoots CO2 up to 30 feet or 10 Meter
•
• Electronic valve maximum pressure 1600 Psi.
• Ultra fast and smooth electronic moments.
• Produce high denseco2 smoke
Description
Arete is a newly deigned compact Arete special e󰀨ect xture, Designed
with industry’s best available component to ensure safety and best
output. Arete features audience safety(Absolutely no ice cubes/chips on
Co2) and Thick Co2 FX that reaches up to 39 feet /12 meter with Co2
e󰀩ciency of 1 lb: 1.5-2sec max output
INTRODUCTION
Product Overview
Hose in /out
Nozzle shooting angle Adjustment
Power In and out
DMX signal in and out
Power on/o󰀨/ DMX mode selector switch

Rasha Professional A/S 1800 Rustin Ave., Riverside CA, 92507 || 951-654-3585
rashaprofessional.com || [email protected]
7
SETUP
Power Supply
Each Arete has an auto-ranging power supply that works with an
input voltage range of 100VAC, 60 Hz. To determine the power
requirements for each Arete refer to the label a󰀩xed to the product.
Y o u c a n a l s o r e f e r t o t h e T e c h n i c a l S p e c i  c a t i o n s c h a r t i n t h i s m a n u a l
The listed current rating indicates the maximum current draw during
normal operation. For more information, you may download Sizing Circuit
Breakers from the Rasha website: www.rashaprofessional.com
Always connect this product to a protected circuit with an appropriate
electrical ground to avoid the risk of electrocution or re. To eliminate
unnecessary wear and improve its lifespan, during periods of non-use
completely disconnect the product from power via breaker or by unplugging it.
Never connect this product to a rheostat (variable resistor) or dimmer circuit,
even if the rheostat or dimmer channel serves only as a 0 to 100% switch.
AC Plug
The Arete comes with a power input cord terminated with a Trueone type®
connector on one end and an Edison plug on the other end (U.S. Market).
If the power input cord that came with your product has no plug, or if you
need to change the Edison plug, use the table below to wire the new plug.
Fuse
Replacement
1. Disconnect this product from the power outlet.
2. Using a at-head screwdriver, unscrew the fuse holder cap from the
housing.
3. Remove the blown fuse and replace with a another fuse of the same
type and rating (F 10 A, 250 V).
4. Screw the fuse holder cap back in place and reconnect power.
Make sure to disconnect the product’s power cord before replacing a
blown fuse. Always replace the blown fuse with another of the same type
and rating
Power Linking
0.25Amp @ 120V, On 20 AMP circuit, you can link up-to 580 Fixtures @
120V
DMX
Personalities
• The Arete uses a 3 pin DMX data connection for the 2 channel DMX
personalities.
• Refer to the Introduction chapter for a brief description of each DMX
personality.
• Refer to the Operation chapter to learn how to congure the Arete to
work in these personalities.
• The DMX Values section provides you with detailed information regarding
the DMX personalities
Connection Wire (U.S.) Wire (Europe) Screw Color
AC Live Black Brown Yellow or Brass
AC Neutral White Blue Silver
AC Ground Green/Yellow Green/Yellow Green

Rasha Professional A/S 1800 Rustin Ave., Riverside CA, 92507 || 951-654-3585
rashaprofessional.com || [email protected]
8
Before mounting this product, read and follow the Safety Notes. For our
Rasha®Professional line of mounting clamps, go to
https://www.rashaprofessional.com/clamps
Orientation Always mount this product in a safe position and make sure there is
adequate room for ventilation, conguration, and maintenance.
Rigging
Rasha recommends using the following general guidelines when
mounting this product.
• When selecting an installation location, consider easy access to
this product for operation, programming adjustments, and routine
maintenance.
• Make sure to mount this product away from any ammable material as
indicated in the Safety Notes.
• Never mount in places where rain, high humidity, extreme temperature
changes, or restricted ventilation may a󰀨ect the product.
• If hanging this product, make sure that the mounting location can
support the product’s weight. See the Technical Specications for the
weight-bearing requirements of this product.
• When hanging this product, always secure to a fastening device using
a safety cable.
Procedures
The Arete comes with a pre-installed mounting clamp. Make sure
the clamps are bolted proprely and capable of supporting the
weight of this product. Use at least 1 mounting point per product.
In addition, use a safety cable to link the product to the structure.
MOUNTING
Display:
Button:
To show Menu options and the selected functions
DOWN
UP To go forward in the selected functions
To go backward in the selected functions

Rasha Professional A/S 1800 Rustin Ave., Riverside CA, 92507 || 951-654-3585
rashaprofessional.com || [email protected]
9
MENU MAP
Menu Programming Level Description
UP / Down buttons 001-510
Selects and Sets DMX
address (select address as
required DMX address.

Rasha Professional A/S 1800 Rustin Ave., Riverside CA, 92507 || 951-654-3585
rashaprofessional.com || [email protected]
10
The Arete has been designed and constructed in such a manner that it can be used safely.
This applies to the use, the circumstances and the regulations as described in this documen-
tation. Reading this documentation and following the instructions are therefore necessary
for everyone who is authorised to Operate Arete. The Arete must be placed and used in sur-
roundings that preferably:
• Have a relative humidity degree of no more than 75%.
• Are reasonably free of dust, corrosive gases and high concentrations of organic va-
pours.
• Are not situated in the vicinity of a source of vibration.
GENERAL SAFETY RULES
1. DO NOT AIM OR POINT NOZZLE DIRECT CONTACT OF PEOPLE.
2. WEAR SOUND GUARD WHILE OPERATING
3. KEEP ARETE AWAY FROM CHILDREN
4. ALL SAFETY DECIVES MUST BE IN GOOD CONDITION
5. ENSURE SUFFICENT SURROUNDINGS
6. ONLY AUTHORIZED PERSON CAN OPERATE ARETE
HOW TO USE
1. Place the Arete on a solid and even surface,Always make sure that there are no people
within 10 feet of the Arete.
2. In order to test it, you rst need to check if the gas valve on the Co2 tank is still in a
closed position. Now you can check if the Arete has been installed properly by switch-
ing the electricity on and o󰀨. if the system has been connected properly you will hear a
clicking sound which is produced by the opening and closing of the magnetic valve in
the Arete.
3. Connect the high pressure CO2 hoses to the CO2 tank.Firmly secure the couplings by
hand and wrench. Place the CO2 tank (liquid CO2 with dip pipe) on an even and solid
surface.Place the bottles in such a position that the valve opening does not point in the
direction of persons or objects.
4. Connect the hose to the Arete and let it click into place so it is rmly secure.
5. When the system is properly connected you can open the valves of the CO2 bottles.
Check for leaks.
6. When the gas hoses are not properly connected gas can escape. If this is the case then
turn the couplings tighter until gas is no longer escaping. The Arete is now ready for use.
Note
CO2 Blasts duration should not exceed 10 seconds in length for each blast; two blasts can-
not occur within 5 seconds of each other, Power must be connected last as to ensure safety.
SAFETY

Rasha Professional A/S 1800 Rustin Ave., Riverside CA, 92507 || 951-654-3585
rashaprofessional.com || [email protected]
11
PRECAUTIONS
MAINTENANCE
To achieve the maximum service life of the Arete you must regularly clean the Arete and test if it is
working correctly. If Arete not work for some reason then please contact Rasha Professional/Autho-
rized reseller.
Do not replace parts yourself; always consult Rasha Professional/Authrorized reseller if necessary.
TROUBLESHOOTING
• The Arete is leaking
Check if the coupling of the gas hose is connected properly to the coupling of the Arete. If it
isn’t entirely secured then press it rmly. This’s only possible when there is no pressure on the hose.
If the problem persists, then consult customer service @ Rasha or Autorized reseller.
• Only a small smoke plume is visible when the CO2 gas exits the Arete.
Visibility can vary due to air humidity. The output will be more visible when there is high absolute air
humidity or Co2 tank(use Co2 tank with siphon- keep tank upside down)
• There is no white smoke plume visible when the CO2 gas exits the Arete.
You may not have the right carbon dioxide cylinders. Connect cylinders with liquid carbon dioxide
and a dip pipe to the Arete. In some cases the dip pipe may be broken. In that case replace the
carbon dioxide cylinder with another and inform your gas supplier about the cylinder with the
defective dip pipe.
• The Arete is still malfunctioning after troubleshooting
Always contact your Reseller or the technical service of our company rst in case of uncertainties,
questions about the Arete works or other issues with regard to the Arete

Rasha Professional A/S 1800 Rustin Ave., Riverside CA, 92507 || 951-654-3585
rashaprofessional.com || [email protected]
12
RETURNS
You must send the product prepaid, in the original
box, and with the original packing and accessories.
Rasha Professional will not issue call tags.
Call Rasha and request a Return Merchandise Authorization (RMA)
number before shipping the product. Be prepared to provide the
model number, serial number, and a brief description of the Claim(s)
for the return.
Clearly label the package with an RMA number. Rasha will refuse
any product returned without an RMA number.
DO NOT write the RMA number directly on the box. Instead, write it
on a properly a󰀩xed label.
Once you have received the RMA number, include the following
information on a piece of paper inside the box:
• Your Name
• Your Address
• Your Phone Number
• The RMA number
• A brief description of the problem(s).

Rasha Professional A/S 1800 Rustin Ave., Riverside CA, 92507 || 951-654-3585
rashaprofessional.com || [email protected]
13
www.rashaprofessional.com | www.rashalight.com
UNITED STATES – Rasha Professional A/S LLC.
General Information
Address: 1800 Rustin Ave Riverside, CA 92507
Technical Support
Email: [email protected]
Voice: [phone]
[phone]
Outside the U.S. Contact the dealer of record. Follow their instructions
to request support or to return a product. Visit our website for contact
details.
CONTACT US
