Raychart Raychart 425 User manual

Distributed by
Any reference to Raytheon or
RTN in this manual should be
interpreted as Raymarine.
The names Raytheon and RTN
are owned by the
Raytheon Company.

TOPSHAM
EXETER
TEIGNMOUTH
EXMOUTH
TORQUAY
DARTMOUTH
PLYMOUTH
ENPORT
SALCOMBE
PORTLAND
HARBOUR
ISLE O
CAP DE
LA HAGUE
ALDERNEY
GUERNSEY
JERSEY PORTB
CSR 48°30.367'N
POS °35.636'W
128 nm
FIND SHIP ROUTES WAYPOINTS
BRG 23 °T
RNG 40.9 nm
GO TO
MOB
CLEAR
ENTER
PAGE
RANGE
POWER
D5964-1
Bridge Card - RayChart 425 Chartplotter
PAGE - Selects Setup options and display mode.
Press to display Setup Function Bar and use horizontal trackpad
movements to highlight required option. Press ENTER to select
Press PAGE again repeatedly to cycle through display modes
POWER
Press and hold until unit beeps to turn on display
Press once to adjust lighting & contrast.
Press and hold for 3 seconds to turn off display
Function Bar
Press ENTER to display primary Function Bar (as shown here)
Use trackpad to highlight function then ENTER to select
Elipses (...) after the text indicate further options available
by highlighting then pressing ENTER
ENTER
Confirms selection and (if appropriate) clears current
functions. It either performs the selected task and
accepts changes, or confirms selection of more options
GOTO WAYPOINT
Press GOTO to display Function Bar
Select GOTO WAYPOINT function to display Waypoint List
Trackpad
Controls cursor position on screen and highlights functions
RANGE
Adjusts chart scale
Displayed vertical distances shown in Status Bar (top of screen)
- Press top of key to increase the chart range
- Press bottom of key to decrease the chart range
- Press and hold to change the scale rapidly
CLEAR
Cancels operation in progress and returns to previous display
Deletes a highlighted item
WAYPOINT LIST
SYMBOL NAME
WAYPOINT 00
WAYPOINT 002
WAYPOINT 003
WAYPOINT 004
WAYPOINT 005
50°2 ,966'N
00 °20,368'W
POSITION
BRG _186°T RNG _21.0NM
DATE ---- TIME --:--
GOTO
WAYPOINT
TRACKPAD SELECTS WPT, "ENTER"
STARTS GOTO, "CLEAR" TO QUIT
Press ENTER to implement GOTO WAYPOINT function
MOVE CURSOR, "ENTER" TO START
GOTO CURSOR, "CLEAR" TO QUIT
GOTO
CURSOR
Use trackpad to highlight required waypoint
GOTO CURSOR
Press GOTO to display Function Bar
Select GOTO CURSOR function
Press ENTER to place a temporary waypoint and start the GOTO
TRACKPAD SELECTS PORT, "ENTER"
STARTS GOTO, "CLEAR" TO QUIT
GOTO
PORT
GOTO PORT
Press GOTO to display Function Bar
Select GOTO PORT function
- The Port List is displayed
Use trackpad to highlight required port
Press ENTER to start the GOTO
STOP
GOTO
To stop a GOTO
Press GOTO to display Function Bar (or move cursor over any
waypoint in the current route)
Select STOP GOTO or STOP FOLLOW (as appropriate)
Press ENTER to stop the GOTO
- The dotted line from your vessel to the target disappears
STOP
FOLLOW
SYSTEM SET UP
Use horizontal trackpad movements to highlight SYSTEM SET UP
Press ENTER to select
or
Use vertical trackpad movements to select parameter
Use horizontal trackpad movements to change setting
Press ENTER to implement change
SYSTEM
SET UP
CHART
SET UP
TRACK
SET UP SET UP
GPS
CHART SET UP
Use horizontal trackpad movements to highlight CHART SET UP
Press ENTER to select
Use vertical trackpad movements to select parameter
Use horizontal trackpad movements to change setting
Press ENTER to implement change
SYSTEM
SET UP
CHART
SET UP
TRACK
SET UP SET UP
GPS
TRACK SET UP
Use horizontal trackpad movements to highlight TRACK SET UP
Press ENTER to select
Use horizontal trackpad movements to select INTERVAL
Use vertical trackpad movements to change setting
Press ENTER to save value
Use horizontal trackpad movements to highlight TRACK OFF
Press ENTER to start track - text indicates TRACK ON
SYSTEM
SET UP
CHART
SET UP
TRACK
SET UP SET UP
GPS
GPS SET UP and Status
Use horizontal trackpad movements to highlight GPS SET UP
Press ENTER to display the GPS Status page
Press ENTER to display the Differential GPS Set Up page (RC420D)
Use vertical trackpad movements to select parameter
Use horizontal trackpad movements to change setting
Press ENTER to implement change
SYSTEM
SET UP
CHART
SET UP
TRACK
SET UP SET UP
GPS
SMARTROUTE
To convert a track to a route, select MAKE INTO ROUTE
Press ENTER to convert to a (reversed) route
Man OverBoard (MOB)
Press and hold GOTO for at least two seconds
- Waypoint 0999 is created and marked with MOB symbol
- Status Bar shows bearing and range to the MOB position,
elapsed time since initiated and Course Over Ground data

D5965_1
Press ENTER to display Primary Function Bar
Select WAYPOINTS
Select WAYPOINT LIST
Press ENTER to display Primary Function Bar
Select ROUTES, then select MORE and press ENTER
Select ROUTE LIST and press ENTER
50°45.000'N
01°06.000'W
COG 230° T
SOG 6.8 Kts
WAYPOINT 00
POSITION
STEER STARBOARD
BRG 234° T GPS FIX
RNG 2.4 nm TIME 4:32 2/ 2/99
TIME 12 34
DATE 26/01/99
ETA (WAYPOINT) 3:37 26/0 /99
TTG (WAYPOINT) 0 :03
ETA (ROUTE) 4:32 27/0 /99
TTG (ROUTE) 34:03
STEER STARBOARD
SUNRISE 06.23
SUNSET 21.34 TODAY
AT POSITION (USER SELECTED)
50°45 .000 N
001°06 .000 W (c)
COG 230° T TIME 3:29 2/ 2/99
SOG 6.8 Kts TTG 0 :03
XTE 0.5 nm ETA 4:32 2/ 2/99
BRG 234° T
RNG 12.4 nm
ROUTE
ROUTE 01
WPT 001 TO WPT 002
WAYPOINT
STEER STARBOARD
PAG E PAG E
PAG E
PAG E
PAG E
PAG EPAG E
From Chart Display
Press PAGE to display Set Up functions
Press
to display CDI
Press
to display
Waypoint Data
Press
to display
Navigation Data
Press
to return to
Set Up functions
Press to display
Time/Date
information
Press to display
BDI
TOPSHAM
EXETER
TEIGNMOUTH
EXMOUTH
TORQUAY
DARTMOUTH
PLYMOUTH
ENPORT
SALCOMBE
PORTLAND
HARBOUR
ISLE O
CAP DE
LA HAGUE
ALDERNEY
GUERNSEY
JERSEY PORTB
CSR 48°30.367'N
POS °35.636'W
128 nm BRG 23 °T
RNG 40.9 nm
SYSTEM
SETUP
CHART
SETUP
TRACK
SETUP
GPS
SETUP
Chart Boundary -
Indicates further detail is
available inside. Shown when using
Navionics®Nav-chart card.
Primary Function Bar
Press ENTER to display
Press CLEAR to remove
Chart Range
Chart Display Display Modes
Waypoint List Route List
Status Bar
Vessel's Position
Waypoint
TOPSHAM
EXETER
TEIGNMOUTH
EXMOUTH
TORQUAY
DARTMOUTH
PLYMOUTH
ENPORT
SALCOMBE
PORTLAND
HARBOUR
ISLE O
CAP DE
LA HAGUE
ALDERNEY
GUERNSEY
JERSEY PORTB
CSR 48°30.367'N
POS °35.636'W
128 nm
BRG 23 °T
RNG 40.9 nm
SHOW
ROUTE
ERASE
ROUTE
NAME
ROUTE
ROUTE LIST
ROUTE 0
2 -
3 -
4 -
5 -
TOPSHAM
EXETER
TEIGNMOUTH
EXMOUTH
TORQUAY
DARTMOUTH
PLYMOUTH
ENPORT
SALCOMBE
PORTLAND
HARBOUR
ISLE O
CAP DE
LA HAGUE
ALDERNEY
GUERNSEY
JERSEY PORTB
CSR 48°30.367'N
POS °35.636'W
128 nm
BRG 23 °T
RNG 40.9 nm
GOTO
WAYPOINT
EDIT
WAYPOINT
MAKE NEW
WAYPOINT
WPT/ROUTE
TRANSFER
SYMBOL NAME
POSITION 50°2 .966'N
00 °20.368'W
BRG 86° T RNG 2 .0 nm
DATE 3/ 0/99 TIME 5:30
WAYPOINT LIST
WPT 00
WPT 002
WPT 003
WPT 004
WPT 005
Note: In any display mode,
press GOTO to return
to chart display
SIM OV NU
SIM OV NU SIM OV NU
WESTHARBOR
CSR 48°30.367'N
POS °35.636'W
1 nm
BRG 23 °T
RNG 40.9 nm
FIND SHIP ROUTES WAYPOINTS
SIM OV NU
C
T
T
T
Port Services
Buoy
Cursor
Tide Height
Tide Current
