RCA RPX4600 Series User manual

RPX4500 Series –
7 Function Keys w/ Display
RPX4500V- VHF (136-174 MHz)
RPX4500U - UHF (400-480 MHz)
RPX4500U2 - UHF (440-520 MHz)
Communications Systems
USER MANUAL
RPX4600 Series -
7 Function Keys, Full Keypad w/ Display
RPX4600V - VHF (136-174 MHz)
RPX4600U - UHF (400-480 MHz)
RPX4600U2 - UHF (440-520 MHz)
RCA P25 Portable Radios
5Watts,IP67Submersible

Copyright © 2015 RCA Communications Systems
RPX4500/RPX4600 P25 PORTABLE RADIO – USER MANUAL
2
PREFACE
This user manual covers the RPX4500/RPX4600 Series – RCA P25 Portable Radios.
Any performance figures quoted are subject to normal manufacturing and service tolerances.
The right is reserved to alter the equipment described in this manual in the light of future
technical development.
Changes or modifications not expressly approved by the party responsible for compliance could
void the user’s authority to operate the equipment.
NOTE.
The manufacturer is not responsible for any radio or television interference caused by
unauthorized modifications to this equipment. Such modifications could void the user’s authority
to operate the equipment.
COPYRIGHT
All information contained in this document is the property of RCA Communications Systems
(RCA). All rights are reserved. This document may not, in whole or in part, be copied,
photocopied, reproduced, translated, stored, or reduced to any electronic medium or machine-
readable form, without prior written permission from RCA.
DISCLAIMER
There are no warranties extended or granted by this document. RCA accepts no responsibility for
damage arising from use of the information contained in the document or of the equipment and
software it describes. It is the responsibility of the user to ensure that use of such information,
equipment and software complies with the laws, rules and regulations of the applicable
jurisdictions.
EQUIPMENT AND MANUAL UPDATES
In the interests of improving the performance, reliability or servicing of the equipment, RCA
reserves the right to update the equipment or this document or both without prior notice.
ERRORS AND OMISSIONS
Every effort has been made to ensure the accuracy and completeness of this manual; however,
some errors and/or omissions may still exist. It is requested that any errors or omissions should be
reported to RCA’s authorized North American dealer:
RCA Communications Systems
1421 Gould Blvd., Suite #A
La Vergne, TN 37086
Toll Free: [phone]/Fax [phone]
www.RCACommunicationsSystems.com/
Discount Two-Way Radio
555 W Victoria St.
Rancho Dominguez, CA 90220
Toll Free: [phone]/Fax [phone]
Email: [email protected]
www.DiscountTwo-WayRadio.com

Copyright © 2015 RCA Communications Systems
RPX4500/RPX4600 P25 PORTABLE RADIO – USER MANUAL 3
TABLE OF CONTENTS
1. INTRODUCTION..............................................................................10
1.1. OVERVIEW ....................................................................................................... 10
1.2. CONFIGURATION.............................................................................................. 10
1.3. MODES OF RPX4600 P25 OPERATION .............................................................. 11
2. CONTROLS.....................................................................................12
3. MAIN SCREEN................................................................................14
3.1. LAYOUT............................................................................................................ 14
4. MENU SYSTEM...............................................................................17
4.1. MENU NAVIGATION ......................................................................................... 18
5. MENU SCREENS .............................................................................20
5.1. CHANNEL SCREEN............................................................................................ 20
5.2. ZONE SCREEN .................................................................................................. 21
5.3. SQUELCH ......................................................................................................... 21
5.4. MUTE ADJUST/MONITOR (ANALOG CHANNELS) .............................................. 22
5.5. PHONEBOOK SCREEN....................................................................................... 23
5.6. PHONEBOOK EDIT SCREEN............................................................................... 24
5.7. SETUP............................................................................................................... 27
5.8. STORED CALLS ................................................................................................. 33
5.9. MESSAGES ....................................................................................................... 34
5.10. SCAN EDIT MENU............................................................................................. 39
5.11. NO MENU ........................................................................................................ 41
6. FEATURES AND FUNCTIONS ...........................................................41
6.1. BATTERY .......................................................................................................... 41
6.2. SWITCH ON/SWITCH OFF ................................................................................. 42
6.3. CHANNEL SELECTION....................................................................................... 43
6.4. ZONE SELECTION.............................................................................................. 43
6.5. THREE POSITION FUNCTION SWITCH................................................................ 43
6.6. RECEIVING (SINGLE CHANNEL SCREEN)............................................................ 43
6.7. TRANSMITTING ................................................................................................ 44
6.8. SCAN FUNCTIONS ............................................................................................ 44
6.9. KEYPAD LOCK.................................................................................................. 46
6.10. ENCRYPTION .................................................................................................... 46
6.11. EMERGENCY ALARM ....................................................................................... 46
6.12. CONNECTING AUDIO ACCESSORIES ................................................................ 47
7. SPECIAL FUNCTION KEYS...............................................................47
7.1. ALARM............................................................................................................. 47
7.2. ANNOUNCE ..................................................................................................... 47
7.3. CHANNEL UP AND DOWN................................................................................ 48

Copyright © 2015 RCA Communications Systems
RPX4500/RPX4600 P25 PORTABLE RADIO – USER MANUAL
4
7.4. CRYPTO ........................................................................................................... 48
7.5. DTMF SEND 1 AND 2 (ANALOG)....................................................................... 48
7.6. KEY LOCK ........................................................................................................ 48
7.7. LOW POWER .................................................................................................... 48
7.8. MENU .............................................................................................................. 48
7.9. MODE .............................................................................................................. 49
7.10. MUTE ............................................................................................................... 49
7.11. RESET ............................................................................................................... 49
7.12. SCAN ............................................................................................................... 49
7.13. SCAN EDIT ....................................................................................................... 49
7.14. SCRAMBLER (ANALOG) .................................................................................... 50
7.15. SKIP.................................................................................................................. 50
7.16. SQUELCH ......................................................................................................... 50
7.17. TALK AROUND ................................................................................................. 50
7.18. ZONE................................................................................................................ 50
8. ACCESSORIES ................................................................................51
8.1. LITHIUM ION BATTERY (B4522LI) ...................................................................... 51
8.2. LITHIUM ION BATTERY (B4530LI) ...................................................................... 51
8.3. SINGLE UNIT CHARGER (CH4501 PKG)............................................................. 51
8.4. DUAL UNIT CHARGER (CH4502 PKG) ............................................................... 51
8.5. SIX BANK CHARGER (CH4506 PKG) ................................................................. 51
8.6. SINGLE UNIT VEHICLE CHARGER (VCH4501) .................................................... 51
8.7. BATTERY BELT CLIP (BC4500)............................................................................ 51
8.8. VHF MOULDED ANTENNA 136-300 MHZ (ANH4500V 136-300)....................... 51
8.9. WIDEBAND UHF WHIP ANTENNA 440-500 MHZ (ANH4500U-6 440-500)......... 51
8.10. WIDEBAND UHF WHIP ANTENNA 400-480 MHZ (ANH4500U-6 400-480)......... 51
8.11. STUBBY UHF WHIP ANTENNA 400-480 MHZ (ANH4500U-3 400-480) .............. 52
8.12. HEAVY DUTY SPEAKER MICROPHONE – IP56 (SM310-X43) .............................. 52
8.13. HEAVY DUTY WATERPROOF SPEAKER MICROPHONE – IP68 (SM311WP-X43) .. 52
8.14. SPEAKER MICROPHONE W/4 FUNCTION KEYS (SM352-X43) ............................ 52
8.15. DELUXE SPEAKER MICROPHONE – IP67 (SM352WPG-X43)............................... 52
8.16. SURVEILLANCE KIT (SK22NE-X43)..................................................................... 52
8.17. NOISE REDUCTION HEADSETS – IP56 (HS61NR) ................................................ 52
8.18. NOISE REDUCTION HEADSETS – IP56 (HS71NR) ................................................ 52
8.19. HOLSTERS ........................................................................................................ 52
9. ALERT TONES AND MESSAGES.......................................................53
10. TROUBLESHOOTING.....................................................................53
11. SPECIFICATIONS ...........................................................................54
12. WARRANTY ..............................................................................55

Copyright © 2015 RCA Communications Systems
RPX4500/RPX4600 P25 PORTABLE RADIO – USER MANUAL 5
PERSONAL SAFETY
SAFETY PRECAUTIONS
These Safety Precautions, Warnings and Cautions advise personnel of specific hazards which
may be encountered when using this equipment and that control measures may be required to
prevent injury to personnel, and damage to equipment and/or the environment.
Before using this equipment, users are to acquaint themselves with all risk assessments relevant
to the equipment and area of use. Users must comply with the control measures detailed in the
risk assessments.
References covering safety regulations, health hazards and hazardous substances are detailed
under the WARNINGS section below. These are referred to in this user manual when they are
encountered.
GENERAL SAFETY PRECAUTIONS
Do NOT operate your portable radio without a hands-free kit while driving a vehicle (subject to
local law).
Do NOT operate your radio in areas that contain hazardous material – unless the radio’s level of
IECEx approval is approved for use in that area.
Obey the ‘Turn Off Two-way Radios’ signs where they are posted, e.g. in a fueling station.
Do NOT touch the antenna while the radio is transmitting.
Do NOT dispose of batteries in a fire.
Dispose of batteries according to local recycling regulations. Do not dispose as household waste.
Do NOT attempt to disassemble the battery.
When charging a battery, keep it at a temperature between 41°F ~ 104°F (5°C ~ 40°C) to ensure
a full charge. Temperatures outside this range significantly reduce battery life. The operating time
(talk-time and standby time) is noticeably shorter than normal, replace the battery.
Before charging a battery attached to a radio, turn the radio off to ensure a full charge. Never
leave a radio on while in the charger, as it can damage both the battery and the radio; the
charger is not a radio stand.
Do NOT cut off the power supply or remove battery while charging.
Do NOT charge a battery that is wet. Dry it with soft cloth prior charging.
The battery will eventually weaken. When the operating time (talk-time and standby time)
becomes noticeably shorter than normal, replace the battery.

Copyright © 2015 RCA Communications Systems
RPX4500/RPX4600 P25 PORTABLE RADIO – USER MANUAL
6
Battery performance greatly decreases at temperatures below -4°F (-20°C). Having a spare
battery is always necessary in extremely cold environments. A cold battery may work again when
it returns to room temperature, so keep it for later use.
Dust on the battery contact may cause the battery not to work or charge properly. Use a clean
dry cloth to wipe it before attaching the battery to the radio.
Batteries with damaged contacts can be extremely dangerous. Any battery with damage to one
or more contacts should be replaced immediately and not used under any circumstances.
Do NOT operate the radio if the antenna has become disconnected or damaged. Recharge
batteries only in an approved battery charger.
HAZARDOUS SUBSTANCES
Before using the radio around any hazardous substance or material, the user must become
acquainted with the safety precautions and first aid instructions:
• On the label of the container in which it was supplied.
• On the Material Safety Data Sheet.
• In any local Safety Orders and Regulations.
WARNINGS
Lithium Batteries
WARNING
LITHIUM BATTERIES - THIS EQUIPMENT USES LITHIUM ION BATTERIES.
REFER TO THE APPROPRIATE MATERIAL SAFETY DATA SHEET (MSDS)
FOR SAFETY INFORMATION.
Radio Frequency Radiation
WARNING
RADIO FREQUENCY RADIATION. A RADIO FREQUENCY (RF) RADIATION
HAZARD EXISTS WHEN USING THIS EQUIPMENT. TO AVOID RF INJURY,
DO NOT TOUCH THE ANTENNA WHEN THE TRANSMITTER IS IN USE AND
DO NOT OPERATE THE TRANSMITTER WITH ANTENNA DISCONNECTED.
Dangerous Voltages
Dangerous voltages exist in the radio equipment. For the appropriate safety precautions, refer to
the relevant Electrical Safety Regulations appropriate to the country of operation.
WARNING
DANGEROUS VOLTAGES. DANGEROUS VOLTAGES EXIST IN ALL THE
BATTERY CHARGERS USED WITH THIS RADIO. FOR THE APPROPRIATE
SAFETY PRECAUTIONS REFER TO THE RELEVANT ELECTRICAL SAFETY
REGULATIONS APPROPRIATE TO THE COUNTRY OF OPERATION.

Copyright © 2015 RCA Communications Systems
RPX4500/RPX4600 P25 PORTABLE RADIO – USER MANUAL 7
HINTS FOR USING THE RADIO
When transmitting, hold the radio a few inches from your mouth and speak across it, rather
than into it. The microphone is located near the bottom right hand corner of the portable radio’s
speaker grille.
Keep the length of your conversation to a minimum to conserve battery life.
When possible, avoid making calls from known poor signal-strength areas such as the radio
systems fringe areas (limit of range) or from screened or shadowed areas, e.g. an underground
parking garage or underpass.
GENERAL NOTES
PLEASE NOTE
Configuration is dependent upon the specification by the customer when the equipment was
ordered and installed.
CONVENTIONS
Where the word “generally” or “may” is used to describe a facility, this operation is an option
that may be enabled with your Programming Software (PS).
In some cases, key functions will be determined by the customer configuration. When a key
function is referred to in these instructions, it is possible the function may be assigned to another
location than designated in this manual.
PLEASE NOTE
When this manual refers to RPX4600, reference can also be applied to the RPX4500, except
when the keypad is used. The RPX4600 model has a keypad and seven function keys. The
RPX4500 model has seven function keys but no keypad.

Copyright © 2015 RCA Communications Systems
RPX4500/RPX4600 P25 PORTABLE RADIO – USER MANUAL
8
ABBREVIATIONS
The following abbreviations are used throughout this manual. When possible, whenever the
abbreviation is first used, the full term is given with the abbreviation in parenthesis. After that
only the abbreviation is used.
ABBREVIATION MEANING
ANSI American National Standards Institute
APCO Association of Public Safety Communications Ocials
BER Bit Error Rate
COSHH Control Of Substances Hazardous to Health
CTCSS Continuous Tone Coded Squelch System
DCS Digital Coded Squelch
DSP Digital Signals Processor
DTMF Dual Tone Multi Frequency
FCC Federal Communications Commission
FM Frequency Modulation
GPS Global Positioning System
ICNIRP International Commission on Non-Ionising Radiation Protection
ID Identication
IEC International Electrotechnical Commission
IEEE Institute of Electrical and Electronic Engineers
IP Internet Protocol
LED Light Emitting Diode
LMR Land Mobile Radio
NAC Network Access Code
PLA Programmable Logic Array
PMR Private Mobile Radio
PS Programming Software
PSTN Public Switched Telephone Network
PTT Press-To-Talk
RF Radio Frequency
RSSI Received Signal Strength Indicator
Rx Receive/Receiver
SMSG Short Message
SW Software
TGID Talk Group Identication
TMR Trunked Mobile Radio
Tx Transmit/Transmitter
TXTMSG Text Message
USB Universal Serial Bus
WACN Wide Area Coverage Network

Copyright © 2015 RCA Communications Systems
RPX4500/RPX4600 P25 PORTABLE RADIO – USER MANUAL 9
GLOSSARY OF TERMS
A summary of common radio terms and some other terms used in this document, and their
meanings, are given below.
BANK SEE ZONE.
Channel
A logical combination of: Network Access Code (NAC); Radio Frequency; De-
fault Talk Group Identity (TGID); Encryption Key Index (KID); and other channel
associated parameters (CTCSS, Scan etc).
PS Programming Software. Used to congure the radio options and parameters.
DTMF Dual Tone Multi-Frequency signaling. Used to dial into telephone networks
using tone dialing.
IECEx Scheme The International Electrotechnical Commission Scheme for Certication to
Standards Relating to Equipment for use in Explosive Atmospheres.
Monitor Mode of Radio Receive – Any P25 signal regardless of NAC or TGID will be
heard
MPT1327 A signaling standard for Trunked Private Land Mobile Radio Systems. Dened
for systems in the UK but also used outside the UK. Issued January 1988.
Muted Audio is prevented from being heard through the speaker.
NAC Network Access Code – Used as a lter where multiple networks may share a
common RF frequency.
Normal Mute Mode of Radio Receiver – Only signals with matching NAC will be heard.
P25 Channel Denition consisting of Tx and Rx RF frequencies, NAC and TGID.
P25 Conventional Non-trunked digital, like digital Private Mobile Radio (PMR).
PTT Press To Talk. This is the term given to the operator’s key normally used to
transmit a message.
Radio Unit ID Unique identier allocated to each radio (0-16,000,000).
Selective Mode of radio receiver – Only signals with matching NAC and TGID or Unit ID
will be heard.
Unmuted Audio can be heard from the loudspeaker.
Zone A collection of channels (usually organized by functional group of users).

Copyright © 2015 RCA Communications Systems
RPX4500/RPX4600 P25 PORTABLE RADIO – USER MANUAL
10
1. INTRODUCTION
1.1. OVERVIEW
RCA’s RPX4500 and RPX4600 Radios are a family of versatile Digital Signal Processor (DSP)
controlled, software defined two-way portable radios.
This User Manual describes the operation of the Association of Public Safety Communications
Officials (APCO) P25 Standard compliant Portable Radio.
RPX4600 P25 radios are software programmable and can be customized to the operational
requirements of your particular needs using the Programming Software (PS). Your RCA
representative can help program your radio to meet your present and future requirements.
A wide-range of accessories are available to complement the P25 radios including: chargers,
antennas, headsets, covert kits, holsters and speaker microphones. Refer to RCA for
comprehensive descriptions.
Please Note: The RPX4600 model has seven function keys, a keypad and a display. The
RPX4500 model has seven function keys, a display, but no keypad.
1.2. CONFIGURATION
Before you can use your P25 Radio, it must be configured using the P25 Programming Software.
The configuration process defines and loads the radio channels, signaling and user options/
settings so that the radio will operate within your system.
1.2.1. PRODUCT INSPECTION
Prior to unpacking your RPX4500 or RPX4600 portable radio, please inspect the packaging
for signs of damage and report any damage or missing components immediately to your RCA
Communications Systems Sales and Service Outlet. Every RPX4500 or RPX4600 portable radio
comes with the following items:
Item Qty.
RXP4500 or RPX4600 Handheld Radio 1
B2245LI – Li-Ion Battery (2200mAh/Approx. 13 hrs.) 1
BC4500 (Belt Clip) and 2 screws 1
ANH4500U-6-400-480 (Antenna for UHF models) OR -
ANH4500V-6-136-300 (Antenna for VHF models) 1
Instruction Manual 1
____________________________________________________
CH4501* (Single Pocket Charger) 1
PS4501* (Power Supply) 1
*=Items sent in separate box if ordered.

Copyright © 2015 RCA Communications Systems
RPX4500/RPX4600 P25 PORTABLE RADIO – USER MANUAL 11
1.2.2. ATTACHING/REMOVING THE BELT CLIP
Using a small screwdriver, align the belt clip’s screw holes to the back of the battery. Attach the
belt clip by turning the screws clockwise into the screw holes. Remove by doing the reverse.
1.3. MODES OF RPX4600 P25 OPERATION
Your RPX4600 P25 Radio operates in Analog Frequency Modulation (FM), P25 Conventional
Digital and P25 Trunked Digital modes.
Radio channels are organized in groups of up to 250 per zone. Up to 40 zones may be defined.
Generally, zones can be programmed with channels belonging to common function groups.
A radio channel can be defined as; Analog, a Conventional P25 channel or Trunked P25 Talk
Group. A Zone may contain a mix of Channel types.

Copyright © 2015 RCA Communications Systems
RPX4500/RPX4600 P25 PORTABLE RADIO – USER MANUAL
12
2. CONTROLS
The controls of the RPX4600 P25 Portable radio are shown below in Figure 1.
Selector Switch
ABC Switch
On/Off Volume
Indicator LED
Function #5
Function #6
PTT
Function #2
Function #1
Antenna
Function #7
Accessory
Connector
Function #3
Function #4
Keypad
Figure 1. RPX4600 Portable Layout.

Copyright © 2015 RCA Communications Systems
RPX4500/RPX4600 P25 PORTABLE RADIO – USER MANUAL 13
The functions of each of the controls are detailed below in Table 1.
Table 1. RPX4600 Control Functions.
KEY/CONTROL LABEL FUNCTION
On/O/Volume Rotate clockwise to turn the radio on. Rotate counter-clockwise to turn
the radio o. Rotate clockwise to increase volume to desired level.
Selector Switch Rotate the switch to select the desired channel.
ABC Switch Programmer congurable three position function switch.
PTT Push-to-Talk. Hold the radio 3 – 4 inches from your mouth. Press and
hold the PTT switch and speak. Release to listen.
Function Key F1 MProgrammer congurable function key. Programmed Default is Menu
Select key.
Function Key F2 Programmer congurable function key. Programmed Default is Chan-
nel Down key.
Function Key F3 Programmer congurable function key. Programmed Default is Chan-
nel Up key.
Function Key F4 OK Programmer congurable function key. Programmed Default is OK key.
Function Key F5 Programmer congurable function key.
Function Key F6 Programmer congurable function key. Programmed Default is Reset/
Cancel key.
Function Key F7 Programmer congurable function key. Programmed Default is
Alarm/Emergency key
Keypad 0 to 9
* & #
The Keypad can be used to select a Channel or Special Function.
E.g. 12# will select channel 12.
INDICATOR LED FUNCTION
A Green LED when receiving a signal.
A Red LED when the radio is transmitting.
PLEASE NOTE
When the manual refers to RPX4600, reference can also be applied to the RPX4500, except
when the keypad is used.

Copyright © 2015 RCA Communications Systems
RPX4500/RPX4600 P25 PORTABLE RADIO – USER MANUAL
14
3. MAIN SCREEN
3.1. LAYOUT
An example of the main or default screen that is displayed when the radio is switched on is
shown below in Figure 2.
MOK
Channel
Name
Zone
Name
RSSI Bars Battery
Bars
Figure 2. Main/Default screen.
The screen has three main areas: the Icon Area; the Text Panel; and the Soft Labels area.
3.1.1. SOFT LABELS
The bottom of the screen is used to display the Soft Labels associated with the function buttons.
The soft label text is defined in the PS and can be assigned to the F1 to F4 function buttons.
Each soft label can be up to five characters.
3.1.2. TEXT PANEL
The main area of the default screen is the Text Panel, which displays textual information. This
information contains both Persistent and Non-persistent text information as follows:
• Persistent Text, e.g. Channel Name, Zone Name.
* The Channel Name shows the text associated with the currently selected radio channel.
* The Zone Name shows the text associated with the currently selected radio zone.
• Non-persistent Text messages, e.g. keypad dial string entries, received status/data messages,
error messages, etc.

Copyright © 2015 RCA Communications Systems
RPX4500/RPX4600 P25 PORTABLE RADIO – USER MANUAL 15
3.1.3. ICONS
The lower part of the display is reserved for Standard and Special Icons.
There are only six positions for icons to be displayed (see Figure 3). However, the number of
icons that can be displayed exceed the six positions. Therefore, some icons will share the same
location.
RSSI (Received Signal Strength Indication) Bars is a special icon which is displayed at the left of
the default screen when a signal is received. The bars indicate the signal strength of the current
channel. The stronger the signal, the more bars will be displayed.
Battery Bars is a special icon, displayed on the right of the default screen. They indicate the
condition of the battery charge level.
Menu
MOK
Icon Area
Figure 3. Icon Locations.

Copyright © 2015 RCA Communications Systems
RPX4500/RPX4600 P25 PORTABLE RADIO – USER MANUAL
16
Details of the Icons that can be displayed in the Icon Area are contained below in Table 2.
Table 2. Icon Details.
ICON INDICATION
A lled speaker icon indicates that a signal is present and the audio can be heard
from the speaker (unmuted).
The outline speaker icon indicates that a signal is present and the radio is muted.
This could be another user group, for instance.
Scan/Search Indicator. When radio is on a scan channel and scanning, the arrow will
rotate.
ѬTransmit indicator.
Received Signal Strength Indication (RSSI). A stronger signal will display more bars
above the antenna icon.
%Encryption Indicator. This icon is shown when the selected channel is programmed
for encryption. If an unencrypted signal is received, the icon will not be displayed.
25 25 = Digital Mode Indicator.
SSelective Mute. Only radio signals specically directed to the user or the channel’s
dened talk group will be heard on the speaker.
NNormal Mute. Only radio signals from the users own network will be heard on the
speaker.
MMonitor. All P25 digital radio signals on the channel will be heard.
Key-lock indicator. All keys except PTT, or any function assigned as Alarm, will be
disabled. Press the OK key for 2 seconds to unlock all keys.
TA Talk Around enabled indicator. When shown, Talk Around is active.
SC Scrambler indicator (analog only).
E
Emergency mode. Blinking icon indicates that the emergency key has been
pressed.
Individual Addressing Mode. When shown, the radio will transmit to an individual
address instead of a talk group.
ჸThe Envelope icon. A steady icon indicates there is one or more stored messages. A
ashing icon indicates an unread message(s) is stored.
Battery charge indicator. Six vertical bars above the icon show the charge state of
the battery.
TTrunking mode. Icon is displayed when a trunking system has been selected.
C
Connecting icon. Displayed when a text message is being sent and the connection
is in progress.
!
Connection Fail icon. Displayed when a text message transmission has failed.
*
The asterisk symbol indicates whether the radio has stopped on a scan channel.

Copyright © 2015 RCA Communications Systems
RPX4500/RPX4600 P25 PORTABLE RADIO – USER MANUAL 17
4. MENU SYSTEM
Your RPX4600 P25 portable radio uses a programmed menu structure to access all the radio
features and functions. The structure of the menu can be configured using the PS to meet your
specific needs.
Normally the menus are divided into two menu lists, which are the Main menu list and the Setup
menu list. Menu selections that are not frequently accessed are normally put under the Setup
menu list.
The menu structure of the radio is illustrated in Figure 4.
Possible Menu entries are:
• Zone (usually the first menu as it is often accessed). • Radio Info.
• Squelch. • Mode.
• Mute Adjust (FM)/Monitor (Digital). • RSSI.
• Phonebook. • Crypto.
• Phonebook Edit. • Stored Calls.
• User Options. • Messages.
• Setup. • Scan Edit.
• Contrast. • Phone Call.
• Alert Volume. • Status
• Location Report. • Undefined (No Menu Entry).
The presence and order of the above menu selections is determined by your PS configuration.
The Setup menu is a special case entry. Setup is a subgroup that can have any of the menu
selections assigned to it. This means that less frequently used selections can be partly hidden
away under the Setup subgroup but still remain accessible.
The order and presence of the Setup subgroup selections is determined by your PS. For instance
Info, RSSI and Contrast could be placed under the Setup Menu.
The User Options menu group is also a menu subgroup. This subgroup usually contains on/off
functions, such as Key Beeps or Backlight.
To assist the user in menu key selection, a soft menu label will often appear above the function
keys. The label shows the user the current function for that key, which may change between
different menus.
Programming of menus is a configuration task normally performed by the system manager using
the PS software.

Copyright © 2015 RCA Communications Systems
RPX4500/RPX4600 P25 PORTABLE RADIO – USER MANUAL
18
4.1. MENU NAVIGATION
The M key is generally used to select Menu mode from the main Channel Screen. Once in Menu
mode, the / keys cycle through the menus.
To exit Menu mode, press the M key again or the Menu timeout will exit automatically. Generally,
pressing the M key while in a menu will navigate back to the next highest level of menu and the
OK key selects the function.
The / keys are generally used to navigate through a list of options, such as channels, or to
increase or decrease a value.
When the Menu key is first pressed, the numeric keys become short cut keys to functions.
Numeric keys can be programmed with functions using the PS, i.e. Scan.
To access these functions, you can press the ‘M’ or menu key from the channel screen and then
the numeric key assigned to that function.

Copyright © 2015 RCA Communications Systems
RPX4500/RPX4600 P25 PORTABLE RADIO – USER MANUAL 19
Figure 4. Menu Navigation
SRP9170/80 P25 PORTABLE RADIO – USER MANUAL TNM-U-E-0091
Sept 13 (Iss. 2.0) Page 23 MENU SYSTEM
When the Menu key is first pressed, the numeric keys become short cut keys to functions.
Numeric keys can be programmed with functions using the FPP, i.e. Scan.
To access these functions, you can press the ‘M’ or menu key from the channel screen and then
the numeric key assigned to that function.
Figure 4. Menu Navigation.
Select
Zone
OK
Back
Menu
ENTRY POINT = Default Screen
Normal
Channel
Screen
Channel
Back
Back
Back
Back
Back
Back
Back
Back
Back
Back
Back
Back
Back
Back
Back
Back
Back
Back
Back
Back
Back
Back
OK
OK
OK
OK
OK
OK
OK
OK
OK
OK
OK
Menu #1
Zone Select
Note: Example menus only shown.
Other Menus may be configured with the FPP.
Submenu
Submenu
Submenu
Submenu
Submenu
Submenu
Submenu
Key Beeps
ON/OFF
Backlight
ON/OFF
(Other User
Menu items)
Mode
Alert
Volume
Crypto Key
Radio Info
Contrast
User
Options
Menu #2
Setup Menu
Menu #3
(Optional)
Menu #x
(Optional) Menu #x
Menu #3
Back
OK OK Key
Back Key
Up Key
Down Key
Submenu Selections
RSSI
Mute
Adjust
Back
OK
Submenu
Squelch
Back
Note: Example menus only shown.
Other Menus may be congured with the PS.

Copyright © 2015 RCA Communications Systems
RPX4500/RPX4600 P25 PORTABLE RADIO – USER MANUAL
20
5. MENU SCREENS
The menu structure on the RPX4600 is configurable using the PS. In most cases, your
system administrator will set up the order and presence of the menu options to your specific
requirements.
This section describes all the menus that are currently available. It also describes the Channel
Screen which is the main default screen that is displayed after the radio is switched on.
Normally, the menus are divided into two menu lists - the Main Menu list and the Setup Menu
list.
In the default configuration, the Main Menu contains the Channel, Zone and Setup menus. This
allows access to the second ‘Setup’ menu level.
The Main Menu can be accessed from the default screen by selecting the ‘M’ (F1) button.
To access any of the menu options from the Main, Setup or User Options Menus, use the and
keys to scroll through the menu options and then press the ‘OK’ button when the required
menu is displayed.
Pressing the ‘Back’ key at any point will go back to the previous screen.
5.1. CHANNEL SCREEN
The Channel Screen shows the current channel and allows channel selection.Pressing the ‘M’ key
enters the Menu mode.
Radio channels may be configured
with the PS as specific frequencies
or as auto-scan types. When an
auto-scan channel is selected, it will
immediately go into scan mode.
Selecting another non-auto-scan
channel will stop the scan.
If a radio channel is defined as a P25
Conventional Digital Channel, it will
only receive P25 digital signals.
If a radio channel is defined as an
Analog FM channel, it will receive both
P25 Digital and Analog FM signals.
Note.
When an Analog FM channel is selected and in Monitor mode, all unencrypted digital
P25 traffic will be heard regardless of NAC or Talk Group.
Special Ops
Zone 4
