RCA RTU7074-B User manual

RTU7074-B
70" UHD LED TV
“This product is manufactured and sold by Curtis International Ltd.
RCA, the RCA logo, the two dogs (Nipper and Chipper) logo, are registered trademarks or trademarks of RCA Trademark Management and
are used under license by Curtis International Ltd.
Any other product, service, company, trade or product name and logo referenced herein are neither endorsed nor sponsored by RCA
Trademark Management or its affiliates.”

-1-
Contents
GETTING STARTED
USING THE REMOTE CONTROL
BATTERY REPLACEMENT
CAUTION : Danger of explosion if battery is incorrectly repla.ced
NOTES
WARNING :
·Point the remote control at the remote sensor located on the unit.
·When there is a strong ambient light source, the performance of the infrared remote sensor·may be degraded,
·The recommended effective distance for remote operation is about 16 feet (5 meters).
When the batteries become weak, the operating distance of the remote control is greatly
replace the batteries.
·If the remote control is not going to be used for a long time, remove the batteries to avoid
leakage corrosion.
·Do not mix old and new batteries. Do not mix ALKALINE, standard (CARBON-ZINC) or
(NICKEL-CADMIUM) batteries.
·Always remove batteries as soon as they become weak.
·Weak batteries can leak and severely damage the remote control.
Do not dispose batteries in a fire. Batteries may explode or leak.
Batteries shall not be exposed to excessive heat such as sunshine, fire or the like.
causing unreliable operation.
reduced and you will need to
damage caused by battery
rechargeable
Safety and warnings.......................................................................................2-3
Installation...................................................................................................4
Stand installation guide................................................................................. 7
................................................................................................... 8
Installation................................................................................................... 9
Remote Control............................................................................................10
Operation..................................................................................................... 11-15
Trouble Shooting...........................................................................................17
Wall Mount
Introduction..................................................................................................16

-2-
SAFETY AND WARNINGS
IMPORTANT SAFETY INSTRUCTION
TO REDUCE THE RISK OF ELECTRIC SHOCK, DO
NOT REMOVE COVER (OR BACK).NO USER
SERVICEABLE PARTS INSIDE. REFER SERVICING
TO QUALIFIED SERVICE PERSONNEL.
RISK OF ELECTRIC SHOCK
DO NOT OPEN!
CAUTION
CAUTION
The symbol indicates that dangerous
voltages constituting a risk of electric
shock are present within this unit.
The symbol indicates that there are
important operating and maintenance
instructions in the literaturaccompanying
this unit.
To reduce the risk of fire or electric
shock, do not expose this apparatus to
rain or moisture.
WARNING:
1) Read these instructions.
2) Keep these instructions.
3) Heed all warnings.
4) Follow all instructions.
5) Do not use this apparatus near water.
6) Clean only with dry cloth.
7) Do not block any ventilation openings,
install in accordance with the instructions.
8) Do not install near any heat sources such as
radiations, heat registers, stoves, or other
apparatus (including amplifiers) that produce
heat.
9) Do not defeat the safety purpose of the
polarized plug. If the provided plug does not fit
into your outlet, consult an electrician for
replacement of the obsolete outlet.
10) Protected the power cord from being
walked on or pinched particularly at plugs,
convenience receptacles, and the point where
they exit from the apparatus.
11) Only use attachments/accessories
specified by the manufacturer.
12) Unplug this apparatus during lighting
storms or when unused for long periods of
time.
13) Refer all servicing to qualified service
personnel. Servicing is required when the
apparatus has been damaged in any way, such
as power-supply cord or plug is damaged,
liquid has been spilled or objects have fallen
into the apparatus, the apparatus has been
exposed to rain or moisture, does not operate
normally, or has been dropped.
14) Mains plug is used as the disconnect
device, the disconnect device shall remain
readily operable.
15) The ventilation should not be impeded by
covering the ventilation openings with items,
such as newspapers, table-cloth, curtains, etc.
16) No naked flame sources, such as lighted
candles, should be placed on the apparatus.
17) Attention should be drawn to the
environmental aspects of battery disposal.
18) The use of apparatus in moderate climate.
19) The apparatus shall not be exposed to
dripping or splashing and that no objects filled
with liquids, such as vases, shall be placed on
the apparatus.
Warning: To avoid any injury caused by lean of
the product, please always ensure the whole
product was placed within the table surface in
horizontal.
The batteries shall not be exposed to
excessive heat such as sunshine, fire or
the like.
WARNING:
WARNING
Never place a television set in an unstable
location. A television set may fall, causing serious
personal injury or death. Many injuries,
particularly to children, can be avoided by taking
simple
precautions such as:
– Using cabinets or stands recommended by the
manufacturer of the television set.
– Only using furniture that can safely support the
television set.
– Ensuring the television set is not overhanging
the edge of the supporting furniture.
– Not placing the television set on tall furniture
(for example, cupboards or bookcases) without
anchoring both the furniture and the television set
to a suitable support.
– Not placing the television set on cloth or other
materials that may be located between the
television set and supporting furniture.
– Educating children about the dangers of
climbing on furniture to reach the television set or
its controls.
If your existing television set is being retained and
relocated, the same considerations as above
should be applied.

-3-
SAFETY AND WARNINGS
This symbol indicates that this product
incorporates double insulation between
hazardous mains voltage and user
accessible parts. When servicing use only
identical replacement parts.
This marking indicates that this product
should not be disposed with other
household wastes throughout the EU. To
prevent possible harm to the environment
or human health from uncontrolled waste
disposal, recycle it responsibly to promote
the sustainable reuse of material
resources. To return your used device,
please use the return and collection
systems or contact the retailer where the
product was purchased. They can take this
product for environmental safe recycling.
FCC STATEMENTS
NOTE: This unit has been tested and found to comply
with the limits for a Class B digital device, pursuant
to Part 15 of the FCC Rules. These limits are designed
to provide reasonable protection against harmful
interference in a residential installation.
This unit generates, uses and can radiate radio
frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful
interference to radio communication. However, there
is no guarantee that interference will not occur in a
particular installation. If this unit does cause harmful
interference to radio or television reception, which
can be determined by turning the unit off and on, the
user is encouraged to try to correct the interference
by one or more of the following measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the unit and
receiver.
-Connect the unit into an outlet on a circuit different
from that to which the receiver is connected.
- Consult the dealer or an experienced radio/TV
technician for help.
PERSONAL SAFETY NOTICE
ALWAYS read and follow all instructions for the installation
and use of the TV.
Place the TV in a location that is level and sturdy.
DO NOT place the TV on a furniture with drawers that can
be used as steps by small children.
DO NOT allow children to pull the TV or climb on the
furniture where the TV is placed.
DO NOT allow children to play in front of or around the TV.
ALWAYS route all the cables connecting to the TV so the
cables cannot be easily pulled and grabbed by children.
When installing the TV on a wall, please purchase a TV
mount recommended by a professional TV installer, and
follow the installation instructions that come with the TV
mount.
Before installing the TV on a wall, please check to make
sure the wall structure can support the weight of the TV and
the mount. If in doubt, please ask the advice from a
professional TV installer.
The terms HDMI and HDMI High-Definition
Multimedia Interface, and the HDMI Logo
are trademarks or registered trademarks
of HDMI Licensing Administrator, Inc. in
the United States and other countries.
Warning: Changes or modifications to this unit not expressly
approved by the party responsible for compliance could
void the user's authority to operate the equipment.

-4-
High voltages are used in the operation of this television
receiver. Do not the cabinet.
Refer servicing to qualified service personnel.
open
SAFETY AND WARNINGS
To prevent fire or electrical shock hazard, do not expose
the television receiver to rain or moisture.
Do not drop or push objects into the television cabinet
slots or openings. Never spill any kind of liquid on the
television receiver.
Do not block the ventilation holes on the back cover .
Adequate ventilation is essential to prevent failure of
electrical components.
of the TV
Do not trap the power supply cord under the television
receiver s .' stand
Never stand on, lean on, or suddenly push the television or
its stand. You should pay special attention to children.
Serious injury may result if it falls.
Do not place your television on an unstable cart, stand,
shelf or table. Serious injury to an individual and damage
to the television may result if it falls.
/or
When the television receiver is not used for an
extended period of time, it is advisable to disconnect
the AC power cord from the AC outlet.
Avoid exposing the television receiver to direct sunlight
and other sources of heat. Do not stand the television
receiver directly on other products which give off heat,
e.g. video cassette players and audio amplifiers. Do not
place naked flame sources, such as lighted candles on
the television. or near
Dim:51 5*320mm (不包括底座）
If the television is to be built into a compartment or similar
enclosure, the minimum distances must be maintained. Heat
build-up can reduce the life of your television, and can also
be dangerous.

INSTALLATION
Front panel
1. Remote control sensor.
2. Indicator LED:
RED STAND BY.
3. Key board.
REAR Connections
SIDE Connections
All the terminals are (from left to right):
AUDIO INPUT OPTICAL, VIDEO, .
All the terminals are (from left to right):
HDMI1(ARC), HDMI2, HDMI3, HEADPHONE, ,
Note: When HDMI has an input signal coming from a DVI source then the audio input signal must be
connected to the PC audio input.
USB Media Player RF.
-5-
Panel keys
L - AUDIO - RVIDEOOPTICAL
HDMI1(ARC) HDMI2 HDMI3 HEADPHONE R F USB Media Player
VOL CH
YPbPr CC MTS VGA
DTV
STRENGTH
TV AV HDMI
EPG
CH LIST FAV
TV
DISPLAY
S.M
P.M
30 30
3
1
21. Short press to turn on the TV.
2. When the TV is on, short press the button to
display the input list.
3. When the TV is on, press and hold the button to
power off the TV.

PRESET MODE (HDMI)
1
2
3
800*600
1024*768
60
60
37.88
48.36
RESOLUTION V.Freq.(Hz) H.Freq.(KHz)
1366*768 60 47.7
41280*768 60 47.3
5
1920*1080
60 67.5
63840*2160 30 67.5
750 112.5
860 135
3840*2160
3840*2160
Antenna
INSTALLATION
Note:
Aerial connections:IEC(female).
Input impendance:75 unbalanced.
-6-

STAND INSTALLATION GUIDE
Prepare to place the TV with the display side down on a flat surface. Due to the size and weight of this
TV, the use of 2 people is recommended when moving it. Ensure the table or desk you use provides
a flat, totally clean surface, and use a soft cloth between the face of the TV and the table to protect the
TV's screen.
1. Locate the 2PCS of the base stand into the gap in the bottom of the TV , and check that it is
securely held in place as per a) below.
2.Lock 4PCS screws in the designated location as per b) below and check each screw is firmly
tightened
Base Stand Assembly Instruction
the base stand
a)
b)
-7-
M6x18 mm

WALL MOUNT
Dimensions for Mounting Hole Pattern
-8-
A wall mount kit (purchased separately) would allow you to mount your RCA
TV on the wall. For detailed information on installing the wall mount, refer
to the instructions provided by the wall mount manufacturer. It is strongly
recommended to contact a technician for professional assistance for wall mount
installation.
-This TV is compatible with a 400mm x 200mm mounting hole pattern.RCA
- Do not mount your TV at more than a 15 degree tilt.RCA
- Always use two people to mount the TV to a wall.
- Do not install your Wall Mount Kit while your TV is turned on. It may result in
personal injury due to electric shock.
- 4 pcs of type M6 screws are required for installing the wall mount bracket to
your TV. Do not use screws that are longer than 10 mm. Screws that RCA
are too long may cause damage to the inside of the TV set.
- Do not fasten the screws too tight for this may damage the TV or cause the
TV to fall, resulting in personal injury. is not liable for these kinds of RCA
incidents.
Instruction for Wall Mount
400mm
200mm

INSTALLATION
-9-
AV Equipment
You can use the input terminals on TV set rear as follows.
Video Equipments: VCR, Multi Disc Player, DVD Player, Camcorder, Video Game, etc.
L - AUDIO - RVIDEOOPTICAL
HDMI1(ARC) HDMI2 HDMI3 HEADPHONE R F USB Media Player

REMOTE CONTROL
-10-
1: POWER
To set the TV standby or on.
2: NUMBER KEY
For direct access to program.
3:
Displays the main on-screen menu.
4: UP/DOWN/LEFT/RIGHT
Move the cursor upward/downward to the left/to
the right when marking a selection.
5: EXIT
Used to exit menu.
6: VOL+/-
To adjust sound level.
7: P.M
To switch picture mode.
8:
Press to display and select the available video
sources.
9: MUTE
To disable or enable the sound.
10: RECALL
To access the previously viewed program.
11: ENTER
Confirms selection.
12: TV DISPLAY
Displays/removes the program Information
13: S.M
To switch sound mode(Standard, Music, Movie,
Sports, Personal).
14: CH+/CH-
To access the next or previous program.
15: ASPECT
To change picture aspect .
16: CH LIST
Used to display the channel list.
17: EPG
Display all the information of DTV programs.
18: FAV
Used to access your favourite channels in digital
TV mode.
19: HDMI
Hot key directly go to HDMI source.
20: AV
Hot key directly go to AV source.
21: DTV STRENGTH
Used to display the DTV signal strength menu.
22: TV
Hot key directly go to TV source.
23: SLEEP
Press to set the sleep timer.
24: CC
Enable or disable the CC function.
25: USB
Select USB source input.
26: MTS
Switch the sound stereo.
27: COLOR KEYS
These control function of these buttons do not
apply to this model.
Remote Code: Toshiba format 0X0707
9
14
13
10
12
11
15
18
20
19
25
26
1
2
4
5
6
7
24
23
21
22
16
17
27
3 8
SLEEP USB

OPERATION
-11-
MENU
CC Mode CC Off
Basic Selection CC1
Advanced Selection Service1
Option
1. PICTURE MENU
In this menu,you can adjust the picture effect, such as
contrast, brightness, etc.
Press to select, press OK to adjust.
Note:
1).If you want to adjust contrast, brightness, color,
and sharpness, the picture mode must return to
personal status.
2).There are three color temperature modes can be
selected: Standard, Warm and Cool.
that 4.Setup menu
In this menu, you can the Menu language, Close
Caption, Restore Default etc.
Press to select, press OK to adjust.
select
4.1 Closed Caption
Transparent 25%
Closed Caption
Restore Default
Menu Language English
<
Option
Software Update(USB)
CEC
EDID switch
TTS
SW Version V1.XX
<
Color Temperature Normal
Noise Reduction Middle
< >
Aspect Ratio Auto
3. TIMER MENU
In this menu, you can adjust the sleep timer, time zone,
etc. Press to select,press OK to adjust.
Note:
1). Time zone, DST and the clock are available in
ATSC programming only.
Sleep Timer Off
<
Time
<
Time Zone Pacific
DST On
Time Format 12-hour
Auto Sync On
Clock 2015/5/10 9:12PM
2.AUDIO menu
In this menu, you can select the sound effect.
Press to select, press OK to select.
SPDIF Type RAW
Surround Sound
Off
Auto Volume
Off
Sound Mode Standard
Audio
< <
Note:
1). Five selectable sound modes: Standard, Music,
Movie, Sports, and .
2). Audio language is available in ATSC/TV
programming only.
3). Auto Volume is effective when input signal level is
too high or distortion of input signal is too high.
Personal
Audio Language English
MTS STEREO
Picture Mode Standard

OPERATION
-12-
1).CC Mode: Switching close caption mode.
2). Advanced selection: Available only for ATSC
program.
3).Option: Used to edit CC font.
Note:
1).Restore Default: Restore Default will clear all the
programs and reset all the settings to default value.
5. Channel MENU
In this menu, you can select digital and analog TV
Channels.
Press to select,press OK to adjust.
5.1 Air/Cable:
Select Air TV signal and cable TV signal.
5.2 Auto Scan: If this is the first time you turn on the
TV, you should scan all the TV channels first,
Press OK button to confirm, and the following menu
will be displayed.
Press OK button to select a scan type,you will see the
message below which indicates auto search is in
process.
Auto Scan
Favorite
Show/Hide
DTV Signal
Air/Cable Air
Channel
< <
5.3 Favorite:
Press OK button to choose/delete the favorite channel.
5.4 Show/Hide
Press OK button to display or hide current channel.
5.5 DTV signal
Display DTV strength signal. No selection or
adjustment is allowed.
Auto Scan DTV+ATV
Found:
Analog:
Digital:
0
0
0
Programme(S)
Programme(S)
Programme(S)
1%... RF CH 2 DTV+ATV
*Only under TV source, menu will show ,
other menu will not show .
6.LOCK MENU
In this menu, you can change the password and adjust
the V-chip setting.
Enter the password, it will go into the lock menu.
Factory default password is 0000.
6.1 Change Password
1) Enter old password: Input the old password.
2) Enter new password: Input the new password.
3) Confirm password: Input the new password again.
6.2 System Lock
When the System Lock switch is ON, the below
options listed below can be adjusted.
6.3 US
Press button the screen will display as follow.OK
1) TV: Press button, the screen will display as
follows:
OK
US
MPAA
TV
MENU OK
System Lock
US
Canada
RRT Setting
Change Password
Off
<
Lock
Reset RRT
<
No Yes
Are you sure to Auto Scan?
TV RATING
BLOCK
TV-NONE
TV-Y
TV-Y7
TV-G
TV-PG
TV-14
TV-MA
ALL
ALL
ALL
ALL
ALL
ALL
FV
V
V
V
S
S
S
L
L
L D
D
ALL

OPERATION
-13-
Canada
Canada Eng
MENU
Canada Fre
And use the OK key to switch lock/ unlock
feature.
Parental
Control
Rating Content FV
(Fantasy
violence)
V
(Violence)
S
(Sexual
situation)
L
(Adult
language)
D
(Sexually
suggestive
dialog)
Suggested
age
TV-Y (All
children)
TV-Y7(Direct to
order children)
TV-G(General
audience)
TV-PG(Parental
Guidance
suggested)
TV-14(Parents
strongly
cautioned)
TV-MA(Mature
audience only)
X
X
X
X
X
X
X
X
X
X
X
X
Content
2) MPAA: Switching the movie-rating control level;
N/A, G, PG, PG-13, R, NC-17, X.
Rating Description
Age
G General audiences, all ages admitted
PG Parental Guidance suggested. Some material may not be
suitable for children.
PG-13 Parents strongly cautioned. Some material .may be
inappropriate for children under 13.
R
NC-17
X
Restrict. Under 17 requires accompanying parent or adult
guardian(age varies in some jurisdictions)
No one 17 and under admitted.
X is an order rating that is unified with NC-17 but may be
encoded in the data of order movies.
1) Canada English: Switching the English rating control
level: EXEMPT, C, C8+, G, PG, 14+, 18+.
6.4 Canada
Press button, the screen will be displayed as
follow:
OK
ENTER
Rating Description
Age
C Children: Intended for younger children under the age of 8 years.
Pays careful attention to themes that could threaten their sense of
security and well-being.
C8+ Children over 8 years old: Contains no portrayal of violence as the
preferred, acceptable, or only way to resolve conflict; nor encourage
children to imitate dangerous acts which they may see on the screen .
G General: Considered acceptable for all age groups, Appropriate
viewing for the entire family, contains very little violence, physical,
verbal or emotional.
PG Parental Guidance: Intended for a general audience, but may not be
suitable for younger children (under the age of 8) because it could
contain controversial themes or issues.
14+ Over 14 Years: Could contain themes where violence is one of the
dominant elements of the storyline it must be integral to the
of plot or character. Language usage could be profane
and nudity present within the context of theme.
but
development
18+ Adults: Intended for viewers 18 years and older and might contain
depictions of violence, which while related to the development of
plot, character or themes, are intended for adult viewing. Could
contain graphic language and portrayals of nudity.
2) Canada French: Switching the French-rating control
level: G, 8ANS+, 13 ANS+, 16ANS+, 18ANS+.
Rating Description
Age
G General :All ages and children, contains minimal direct violence,
but may be integrated into the plot in a humorous or unrealistic
manner .
8ans+ General but inadvisable for young children :May be viewed by a
wide public audience, but could contain scenes disturbing to
children under 8 who cannot distinguish between imaginary and
real situations. Recommended for viewing with paren.
13ans+ Over 13 years: Could contain scenes of frequent violent scenes
and in tense violence.
16ans+ Over 16 years: Could contain frequent violent scenes and violence.
18ans+ Over 18 years: Only for adult viewing. Could contain frequent
violent scenes and extreme violence.
6.5 RRT setting
It can be adjusted when the TV is in ATSC digital mode and
the TV stream have RRT information.
6.6 Reset RRT
It can be adjusted when the TV is in ATSC digital mode and
the TV stream have RRT information.
7.1
JPEG files and MJPEG.
Connect the USB DEVICE that contains the
7. Displaying MEDIA files by using USB Port
You can display the JPEG and MP3,TXT files by using
the USB port that is located on the rear panel:
7.2 Press to enter input source menu.
7.3 In the input source menu,Press to
select USB, and then press OK.
INPUTSOURCE
HDMI3
TV
USB Media Player
AV

-14-
OPERATION
Enter

-15-
OPERATION
EXIT
EXIT
EXIT
then pressing enter button to call out the
control bar on the TV screen. When call out the control bar, select the Next Page, Prev Page
to go next or previous page. select Next and Prev. to go to next or previous chapter. when the
control bar didn't call out, press the button from the remote to go to next or previous page.
press the EXIT button from the remote can exit the control bar, press again to return submenu.

INTRODUCTION
-16-
Main features Accessories
70”wide screen for a complete home theater experience
Super slim LCD TV with LED backlight
3840 x 2160 native resolution for UHD performance
Integrated ATSC TV tuner for HDTV broadcast reception
HDMI inputs for true digital connections
Specifications
3840 x 2160
16:9
220W
2 x 10W
NTSC
Cable :1-135/ Air: 2-69(ATV&DTV)
Resolution:
Aspect Ratio:
TV System:
Video Signal System:
Receiving Channel:
Input Power Voltage:
Maximum Power Consumption:
Viewing Picture Size(diagonal)
Audio Output Power (THD 10%):
High-Definition Multimedia Interface(HDMI) Input x 3
70"
Composite Video Input
AC 100-240V 50/60Hz
ATSC Digital system and NTSC Analog system
x 1
Audio Input
Headphone Output
Optical
USB Media Player
x 1
x 1
x 1
x 1
Infrared Remote Control.................... 1
User’s M anual ................................. 1
Battery(AAA)................................... 2
Screw................................................ 4

Picture Audio
Snow Noise antenna position, direction
or connection
Inspection Check
Interference Noise electronic equipment,car/
motorcycle,fluorescent light
Normal Picture No Sound
Volume(check if muting function
is activated or if the audio system
connections are not correct)
No picture
Power cord is not inserted
Power switch is not opened
Contrast and brightness/volume
setup
Press standby key on the remote
control for inspecting
No Color Normal audio Color control
breaking up Normal audio
or weak retune channel
No Color Noise TVsystem
Normal audio
antenna position, direction
or connection
TROUBLE SHOOTING
Trouble phenomenon Symptom
Ghost
The LED TV panel is built with very high precision technology giving you fine picture details in
vibrant color. Occasionally, a few non-active pixels may appear on the screen as a fixed point of red,
green, blue, black or white. Please note this does not affect the performance of the product.
For service assistance and product information, please call: 1-800-968-9853.
Curtis International Ltd.
7045 BECKETT DRIVE, UNIT 15, MISSISSAUGA, ON, L5S 2A3 www.curtisint.com
No Sound
-17-
