Realtime TK110 User manual

GPS VehicleTracker
USERMANUAL
(Model:TK110)
Version 4.0
(Date: June 2010)

GPS VehicleTrackerUserManual
Page1
CONTENT
Preface..............................................................................................................2
Functions&Features.........................................................................................3
Explanation on SMSMessage...........................................................................4
HowtoOperateIt...............................................................................................5
Arm/DisarmbyPhone Calling......................................................................5
SMSControlInstructions.............................................................................5
Authorizethe Alert-received Mobile.............................................................5
SOSAnti-robberyAlert.................................................................................8
MovementAlert............................................................................................8
Geo-FenceAlert..........................................................................................9
Over-speed Alert..........................................................................................9
Check the location withgooglemapslink.................................................10
The Setting forGPRSConnection.............................................................10
Re-define the AlertText inotherlanguages................................................11
HowtoTrack the Car.................................................................................12
Specifications...................................................................................................13
FAQs&Troubleshooting..................................................................................13
Installation........................................................................................................14
Packing List StandardPackage）...........................................................14
Wiring Diagram..........................................................................................15
Important NoticeonInstallation.................................................................17
AppendixI: HowtoTrack the Car....................................................................18

GPS VehicleTrackerUserManual
Page2
Preface
ThisMiniGPS VehicleTrackeristhemostcost-effectivedevicetotrack
yourvehicleortheotherobjects.It hasverysmallsize, soit canbeinstalled
inverysecretplace.Theinstallation&usage isveryeasy.
ThisMiniGPS trackercommunicateswithuserbySMS,soitcanwork
alone&themanagementcenterisnotamust.It isspeciallydesignedfor
individualvehicles,usercoulduseanyGSMmobilephonetosupervise,
controlandlocatethecarwithoutthethirdparty.
IftheGPS/SMSmanagementcenter(Model:TS01)issetup,many
useful&interestingfunctionscanberealized,suchasmonitoringmany
vehiclestogetherbymap,converting theGPScoordinateintothereal
address automatically.IfuserhasMAPINFOmapwithdetailedlandmarks,
thesoftwarecantranslatethecar slocationautomaticallyintothereal
physicaladdress (suchascityname,streetname,building,etc.),thensend
thisrealphysicaladdress touser smobilebySMS.
TheTrackerisalsosupported bytheonlineGPS/GPRStrackingplatform
(Model: TS02).Usercando thelivetracking on theplatform.
ReaditFirstly:
Pleasereadthismanualthoroughlybeforeyouusethedevice;please
keepitforfuturereference.
Attention:
Pleasekeepthedeviceawayfromthewater,humidity,hightemperature,
heavydust orstrongmagnetism.
Warning:
We strongly suggestuserlettheprofessionalcarelectriciantoinstallthe
system.

GPS VehicleTrackerUserManual
Page3
Functions&Features
(1) Checkthecar slocation,speed &directionviaSMS;
(2) Cutoffthecarpower/fuelsupplybySMS,tostopthecar;
(3) MovementAlert:
Oncethecarisparked,youcan sendtheSMSinstructiontoputthe
systeminmovementalertstatus.Then,ifthe carmoves,thesystemwill
sendSMStoinformyou. Itisaveryusefulfunction,whichenablesthe
trackertoworkasthecaralarmtoo;
(4) Geo-fenceAlert:
Usercan setacertainzonebySMS,oncethe vehiclerunsoverthefence,
thealarmwillsendSMStoinformyou;
(5) Over-speedAlert.
Usercan setacertainspeed limitationbySMS.Oncethevehicle
isrunningoverthisspeed,thesystemwillsendSMStoinformyou;
(6) Built-inrechargeablebackupbattery.Ifthesystemsmainpowersupplyis
cutofforlowenough, systemwillsendSMStowarnyou;
(7) Twokindsoflocationinformation;usercouldlocatethepreciselocation
byGPS.IfthereisnoGPS signal,usercouldalsolocatethecarbyCPS
(cellularpositioningsystem-locatedbyGSMnetwork)
(8) Monitorthevoicearoundthecarviatelephone;
(9) Anti-robberyswitch,sendoutSMSforhelpincaseofhijack;(optional
function)
(10)TrackthecarbySMSorbyonlinemapping(Thesoftwareisoptional).
(11)Flexibledesign,thesystemcanworkalonewithoutsupportofcenter.If
thecenterisset up,thefunctionscanbemuchstronger, youcanmonitor
&controlmanyvehiclesinthecenter,andtheinformationofvehicle s
location canbemoredetailed andfriendly.
(12)Anti-tamperdesign insmallsize, stable,reliable&easyinstallation.
(13)SupportSMS&GPRScommunication
(14)TheAlertTextinSMScanbere-defined indifferentlanguages.

GPS VehicleTrackerUserManual
Page4
Explanation onSMSMessage
Whenthealarmistriggered,itwill sendthe alertSMSmessagetothe
authorizedmobile. ThisSMSalarmmessage includes:
²Alarm type. “Berobbed”, “Powerfailure”, etc..
²Basestationscode ofGSMsignalrelaytower.TheGSMoperator
cantellyouthelocationbythiscode becausetheyhavetherelated
database.Insomecountries,thisfunctionisnot opentothepublic.
²Latitude&longitude.Usercouldlocatethecar sprecisepositionby
helpofGOOGLEMAP(http://maps.google.com/)orGOOGLE
EARTH(Download link: http://earth.google.com/).
²GPS signalsStatus: A: GPSssignalisavailable, thecarisatbroad
outsideplace;V: GPSssignalisshielded,thecarisatthe
underground; H: Thecarpass through10 GSMbasestations,butthe
received GPSsdatadoesn tchange,itmeansthatthereisnoGPS
signalorGPSsreceiverisdamaged
²Speed. Thecar sspeed inKM/H.
²Direction:Thecar sdirectionisshowedinthismessage.(In
coordinates,startfromlineofthenorthdirection,turnoverananglein
thecertaindegreeclockwise.)
Example:Theabovemessageshowsthat: theSOSanti-robberybuttonispressed
down.TheGSMbasestationcodeof thecaris25023722,thecarisatoutdoors&GPS
signalisavailable,thelatitude is23.1430N,thelongitudeis113.3390E,thecar sspeed
Alarm stype
GSMBase
Station Code Latitude
Direction
Speed
Longitude
GPS signal s
status

GPS VehicleTrackerUserManual
Page5
is0KM/H, and thecar sdirectionisnorth.
Howto OperateIt
Arm/Disarm byPhoneCalling
Usercouldalsousethe first alarm-received mobilephonetocallthe
systemSIMcardnumber,soastoarm/disarmthesystem.
Arm:Afterhearingseveralring tones,ifthesystemshang upthecall
automatically, andcallbackyou,itmeansthat thesystemisarmed.
Disarm:Afterhearing severalringtones,ifthesystemhangsup thecall
automatically, anddontcallbackyou,itmeansthatthesystemisdisarmed.
Note:
(1)Thereisnocommunicationfeeforthisoperation, it isaveryconvenient wayto
arm &disarm the system.
(2)The SIMcardinsidethe devicemusthavethefunction of CallerIDDisplay.
(3)Onlythe 1stauthorizedmobilephone canrealizethisfunction.
SMSControl Instructions
Usercan sendSMSinstructiontooperatethetrackerbyanymobile
phone,theformatoftheinstructionis:
UserPassword(******)+ Control Code(XXX)
Thedefaultuserpasswordis111111.
Iftheuserpasswordischanged,usershouldsendtheSMSinstruction
withthenewuserpasswordinsteadof111111.
XXXisthecontrolcode,all thelettersmustbecapitallettersorsmall
letters.
Thereisnospacebetweentheuserpassword&thecontrolinstruction.
Authorizethe Alert-received Mobile
Incaseofalarm,ifuserwantstogetthealertSMSfromthetracker,

GPS VehicleTrackerUserManual
Page6
he/sheneedssendthefollowing SMStoprogramthesystemfirstly:
111111*10Mobile#1*20Mobile#2*
Otherfunctions:
Mobile#1:itisused tocall thetrackerNo., systemwill bearmed
/disarmed
Mobile#2:itisusedtocallthetrackerNo.,systemwillsendback
location SMStothemobile#2
Example: Usersendsthe SMS 111111*1013922713571*2013711189059* tothe
tracker sSIMcardnumber, ifthereisanyalert, systemwill send alertSMStobothof
thesetwomobiles.If userusesmobile13922713571 tocall trackerNo., systemwill be
arm/disarm; if userusesmobile13711189059 tocall thetrackerNo., systemwill send
back locationSMStothe mobile[phone].
l111111PSWnnnnnn
Thisinstructionisused tochangetheuserpassword.Thelengthofthe
user spasswordis3~6 digits.Usersaresuggestedtochangetothenew
passwordinuse.
Example: UsersendstheSMS “111111PSW12345”tothesystemSIMcardnumber,
andgetstheconfirmedSMS “111111PSW12345”in3seconds. It meansthat the user
passwordhasbeen changedto12345.
Remark:Pleasekeepthepassworddeepinmind if it ischanged.
l111111ARM
Thisinstructionisused toarmthesystem.
ThesystemwillsendbacktheconfirmedSMStoyou,suchas “Unit
Armed! ……”
l111111DSM
Thisinstructionisused todisarm thesystem,tostopreceivingthealert
SMSfromthetracker.
ThesystemwillsendbacktheconfirmedSMStoyou,suchas “Unit
Disarmed! ……”

GPS VehicleTrackerUserManual
Page7
l111111CHK
Thisinstructionisusedtoinquirythevehicle slocation&systemsstatus.
Thesystemwill sendbacktheSMS,includesthesimilarinformation,
suchas “Unit Disarmed……”
l111111STP
Thisinstructionisused tocutoffthecar spowersupplyorfuelsupply, so
astostopthecar.
Thecarwillbecontrolled tostopgradually.
Attention: It isverydangeroustostopthecarwhen thevehicleisrunningathigh
speed. Wedo not takeanyresponsibilitytotheconsequencecausedbythisaction.
l111111STPNor 111111STP(N)
Thisinstruction isusedtostopthecarundertheconditionofspeed
limitation.
Ifthecarisrunning atspeedhigherthanN (KM/H),theinstructionwillnot
becarried out. Systemwill sendbackfeedbackSMS “Noparking,vehicle …”;
Ifthecar sspeed isless thanthevalueN ,itwill becontrolled tostopped
gradually.
Example: N=40.The carisrunningatspeedof50KM/H, usersend111111STP40
or111111STP(40) tosystem,thesystemwill sendback SMS “Noparking.”towarnuser
that the conditionisnot met. Oncethe car sspeedisabout39KM/H, thesystemwill
automaticallycarryout thisinstruction&stopthecar.
The Minimumvalue ofNis30KM/H
l111111RES
Thisinstructionisusedtorestorethecartonormalstatusafterstopping
thecar.
It isalsoused tostopthereceivingofSOSalertSMSoncethe
anti-robberySOSswitchispresseddown.
l111111MONP
Thisinstructionisusedtomonitorthevoicearoundthecar.TheSIMcard
insidethesystempaysforthecommunicationfee.
TheP isthetelephonewhichisusedtomonitorthevoice.When user
sendoutthisSMStothesystem,thesystemwillcallbackthetelephoneP,

GPS VehicleTrackerUserManual
Page8
usercouldlisteninthevoicearoundthecaruponpicking upthecall.
Ifyouusethepresentmobiletocarryoutthe monitoring,youcanletthe
Pasblank, sending111111MON isOK.
Example:P=13780012345. Ifusersends111111MON13780012345tosystem,the
systemwill call backthe phone[phone]immediately. Onceuponpickupthe call
fromthesystem,usercanhearthevoicearound.
l111111MON:PhoneNo.
Thisinstructionisusedtomonitorthevoicearoundthecar.Theuser s
telephonepaysforthecommunicationfee.
Example: Userusesthetelephone38351400tocarryout monitoringandpaythe
communicationfee, usercan send 111111MON:38351400 tothetrackerfirstly, thenuse
thisphone38351400tocall thetracker, it will beconnectedautomaticallytomonitorthe
voice.Thissetting isstored all the timeuntil youchangeit toanotherphoneno.
Remark:pleasedonot settheuser s1st alert-received phoneno.asthisphoneno.
SOSAnti-robberyAlert
It istheoptionalfunction,itneedstheoptionalcomponent:SOSswitch.
Ifyou programthe1st &2nd alert-received mobileonly,oncetheSOS
switchispressed down&holdforatleast3seconds,thesystemwillsend
alarmSMStothe1
st &2nd alert-received mobile.Usercansendcommand
111111RES toreleaseit.
Ifyouprogramthe3rd alert-received mobileasthecenternumber,once
theSOSswitchispressed down&holdforatleast3seconds, thesystemwill
ONLY sendalarm SMStothecenternumber.(the3rd mobileno.).Usercan
sendcommand111111RES toreleaseit.
MovementAlert
111111MOV0 todisablethemovement alert
111111MOV1 toenablethemovementalert,thepresentlocationisthe
center.
111111MOV tocheckthecenter sposition.
Oncethesystemisarmed,themovementalertwillbeautomatically
enabled.Oncethesystemisdisarmed,themovementalertwillbe
automaticallydisabled.

GPS VehicleTrackerUserManual
Page9
111111RAD:XR:a,YR:btodefinethedistancefortriggeringthealert
Example:If youwanttoset theradiusinlatitudeas60meters,radius
inlongitude as80 meters,youcansend111111RAD:XR:60,YR:80 tothe
tracker.Thissetting willbestoredinthetrackerallthetimeuntilyou
changeitagain.
Geo-FenceAlert
Format ofSMSinstructions:
111111FEN0 DisabletheGeo-fence
111111FEN1 EnabletheGeo-fence,usingthestored setting
111111FEN1() Enablethegeo-fence,using thelatitude&longitude of
presentlocation,thedistanceof latitude &longitude are1000 meters.
111111FEN Checkthesettingof geo-fence
111111RAL:XR:a,YR:b,X:c,Y:d
Or 111111RAL:XR:a,YR:b
Or 111111RAL:X:c,Y:d
XR:a,aisthedistanceof latitude(Meter)
YR:b,bisthedistanceof longitude (Meter)
X:c,cislatitude(degree),therangeofthe valueis0-90）
Y:d,dlongitude (degree), therangeofthevalueis0~180）
Remark: (1)RAL,XR,YR, X,Ymust beincapitalletter.
(2)TheSetting will be stored.
Example:If the fenceisacirclewithRadiusof 5000meters,the coordinatesof the
circlescenteris:latitude:+23.1400,longitude:+113.4500,thenthe SMSinstruction is:
111111RAL:XR:5000,Y:5000,X:23.1400,Y:113.4500 .Ifthe vehicleisrunningacross the
boundaryofthe fence,the systemwill automaticallysend outAlert SMS.
Over-speed Alert
111111SPD:X xisthespeed inKM/H,maximumvalueis255M/H

GPS VehicleTrackerUserManual
Page10
(Forexample:111111SPD:120,ifthecarspeedisover120KM/H,itwill
sendSMStowarnyou)
111111SPD:?tocheckthesettingofover-speedalert.
Defaultsetting:200KM/H
Howtodisablethisfunction:Youcan send111111SPD:250 todisablethis
Over-speedAlert
Remark:thisfunctionisjustforreference,becausetheremightbe some
delayorerrorindetecting thecar srealspeed byGPS.
Check the location withgooglemap slink
W111111,100
The Setting forGPRS Connection
TheGPRScommandisused fortheGPRSsetting.Userneedsthe
GPRSonlinetrackingserverfirstly.Formoreinformation,pleaserefertothe
GPRScommunicationprotocol.
1.111111WWW:IDN:*;IPN:*;APN:*;COM:*;RPT:*;
IDN: Thetracker sIDnumber,thelengthcannot belongerthan14,itcan
benumbersorletters.
IPN:TheIPaddress of theGPRSserver
APN:TheAccessPointNamefortheGSMSIMcard.
COM: TheSerialCOMport fortheGPRSserver
RPT: ThetimeintervalfortheuploadingGPRSpacket (Unit:10 sec.)
Example, if serverIPis:98.143.144.145,TCPportis8500, trackerIDis
13922713571.APNisCMNET,timeintervalis10seconds,thenthe
commandis:
111111WWW:IDN:13922713571;IPN:98.143.144.145;APN:CMNET;COM:8500;RPT:1;
2.W111111,013,B
B=0: closeGPRSfunction
B=1: openGPRSfunction

GPS VehicleTrackerUserManual
Page11
3.SeparateSMSCommand forGPRSSetting
SetIDforTK310 W******,010,ID TrackerIDmustnotover14 digits.
SetAPN W******,011,APN,APNName,APN
Password
IfnoAPNnameandpassword
required, just insertAPNonly;
APNdefaulted as ‘CMNET ;
APN+APNname+passwordnotover
39 characters.
SetIPAddress and Port W******,012,IP,Port IP:xxx.xxx.xxx.xxxPort:[1,65534]
Enable GPRS Tracking
Function
W******,013,X X=0,closeGPRS(default);
X=1, enableTCP
X=2, enableUDP
SetTimeIntervalfor
SendingGPRSPacket
W******,014,XXXXX XXXXX should beinfivedigitalsandin
unitof 10 seconds.
XXXXX=00000, toclosethisfunction;
XXXXX=00001~65535,timeintervalfor
sendingGPRSpacketandin unitof10
seconds.
Check thesettingofthe
parameters
W******,600
Check thepresentlocation W******,000 Check theGPScoordinates
Check thepresentlocation
withgooglemap slink
W******,100
Check thepresentlocation W******,001,pppppp Tochangethedefaultpasswordfrom
111111 tothenewone
Settimeintervalsforsending
location bySMS
W******,002,X Xisinminutes
Setover-speedalert
limitation
W******,005,X XisinKM/h
Re-define the Alert Text inotherlanguages
Step1: SwitchfromEnglishMode tootherlanguagemode
W111111,023,0: Defaultsetting, EnglishText Mode
W111111,023,1OtherlanguageText Mode
Step2: Defineyourowntextbythefollowingcommand:
111111TXT：nnstrDnnstrDnnstrDnnstrDnnstrDnnstrD
Remarks:

GPS VehicleTrackerUserManual
Page12
(1)6piecesofstringscanbedefined inonecommand.
(2)nn:2bits, range:01~24
(3)D: it canbe(,)or(!)
(4)thenumberoflettersineachstr. cannot bemorethan 8
(5)thecharacter(.),(.),(!)cannotbeshowed instr.
Example: 111111TXT:09vibración! istodefine thealarm textinSpanishwhen the
shocksensoristriggered
nn Str.
01 Patrolarea
02 Patrolarea
03 Patrolarea
04 Patrolarea
05 Berobbed
06 Powerfailure
07 Dooropened
08 Seekshelp
09 Bevibrated
10 Engineignited
11 Dooropened
12 Cross border
13 Linebroken
14 Lampalarm
15 Vehiclemoved
16 Exceedlimit
17 Noparking
18 Vehiclestopped
19 Unitdisarmed
20 Unitarmed
21 Notdefined
22 Notdefined
HowtoTrack the Car
(1).Track theCarbySMS
TheusercouldgetSMSalarmmessagefromthesystem,thismessage
includes2kindsoflocationinformation:
(1).Thecode oftheGSMnetworksbasestation.BythehelpoftheGSM
operator,thecarcouldbeeasilylocatedbecausetheGSMoperatorshave
thedatabaseoftheGSMnetworksbasestationcode.Butinmanycountries,

GPS VehicleTrackerUserManual
Page13
thisserviceisnotopentopublic.
(2).TheGPSslatitude&longitude,usercouldtrackthecar sprecise
location afterinputtingthemintheGOOGLEEARTH(pleasedownload it
from http://earth.google.com )
(Thedetailsareattached inAppendixI.)
(2).Track bytheManagementSoftware(Optional)
Thisfunctionisnotthestandardfunction.Itneedsthesupportofthe
managementcenter.Tosetupthecenter,usershouldbuythemanagement
software,GSMModem&digitalmap(MapinfoformatorGooglemap).The
centercanmonitormanyvehiclesatthesametimeonthemap,anditcould
translatetheprofessionalSMSalarmmessage(latitude,longitude,etc.)into
friendlyinformation(suchas: city, street…etc).
Specifications
Sizeof the mainunit: 7.5*5.4*2.5(CM)
Weight of the mainunit: 0.1KG
Working temperature: -20 ~65
Humidity: 0~95%
GSMfrequencies: 850MHz/900MHz/1800MHz/1900MHz
GPS chip: Latest SiRF-StarIII chipset
Working voltage: 12VDC/ or24 VDC
PowerConsumption:
Working current: ≤250mA;
Staticcurrent: ≤60mA;
Peakcurrent: 300mA;
InternalBackup battery:
Rechargeable 3.7V750mAhLi-ionbattery
FAQs &Troubleshooting
FAQ Troubleshooting
Call the tracker,it doesnot ring
(1)The GSMSIMcardhasno credit;
(2)The SIMcardisprotected byPINcode;
(3)Fixthe GSMantenna toopen placetotest;
(4)The SIMcardisplaced correctlyinthe slot;
(5)Check the connection of theGSMantenna,or

GPS VehicleTrackerUserManual
Page14
changeanotherGSMantenna totest;
Call the tracker,itrings,butit
doesn tsend back response
SMS
(1)The userpasswordiswrong, pleaseusethe
correct passwordorreset the passwordtotest;
(2)Lowpower,pleaseuseoutside 12VDCpower
supplytopoweron the unit totest
The mobilecan notrecievethe
alarm informations.The other
functionsareOK.
(1)The SIMcardinside the devicehasno credit;
(2)The SMSinstruction isnot incorrect format;
(2)The mailboxof the user smobileisfull;
No GPS signalorGPS signalis
weak
(1)Fixthe GPS antenna toopen placetotest;
(2)Pleasecheck theconnection ofthe GPS
antenna;
(3)Chang anotherGPS antenna totest;
(4)Incloudycondition,itisalittlehardtogetthe
GPS signal,and the GPS coordinatemighthave
someerrors.
Ican check the location,butI
can notgetthe alert SMSwhen
the carmoves
(1)Pleasesetup the systemfirstly.(authorize
SMS-received mobilenumber, etc);
(2)Inarming status,the deviceonlywarnyou
oncethe carmovesatabout50 meters away
fromthe parking place;
I can not stop mycar
(1)Check the formatofthe instruction ******STP
iscorrect ornot?
(2)Replaceanotherrelaytotest.
(3)The relayscontroloutputissuggested to
controlthe powersupplyloop ofthe fuel
pump.Insomecars,itcan alsoused to
controlthe engine ignition loop.
Ican tarm/disarm systemby
phonecall
(1)Onlythe 1stauthorized moiblenumbercan
realizethisfunciton;
(2)The SIMcardinside the devicemusthavethe
function of CallerIDDisplay.
Installation
PackingList（StandardPackage）

GPS VehicleTrackerUserManual
Page15
Standardpackage:
Componentname Quantities
Mainunit 1pc
GPS antenna 1 pc
GSMantenna 1 pc
4-pinswiring harness 1pc
Cut-offrelay 1pc
Microphone 1 pc
Optionalcomponents(notincludedinthestandardpackage):
Componentname Quantities
Anti-robberySOSSwitch 1pc
ShockSensor 1pc
12-PinsWiringharness 1pc
Wiring Diagram

GPS VehicleTrackerUserManual
Page16
ONOFF (BLACK) Ground
(RED) +12VDC
(Yellow)
White
Yellow
(White)
High-VoltageIngitonwinding
Green
Green
Relay P1
P2
P1 P2
EngineIgnition Loop
FuelPump'sPowerSupplyLoop
D
P1 P2
Fuel Pump'sMotor
Notes:
(1). The relay'scontroloutput (2green lines, no polarity)has2kindsofconnections. It can be
usedtocut off theengineignition loop orthe fuelpump'spowersupplyloop.It issuggested to
controlthe fuel pump.
(2). PleaseturntheswitchtoONposition. It istheswitchof the inside backup battery.
(3). The 12-pinswiring harness areoptional components.
(4). The SOSbutton and LEDarealreadyconnected inthe 12-pinswiring harness.
(5). The shocksensorisconnectedtothe 12-pinswiring harness
(6). The Orange line in12-pinsconnectorcanbe connected withpositiveof alarmsiren orcar
lamp. Nomatterin arming ordisarming status,onceit detects+12VDCsignal forat least 8
seconds, it willsendout alert.
1 2
3 4 +
CarBattery
5 6
11 12
3 4
9 10
1 2
7 8
ACCON
Blue
LED
Originalalarmsiren
Door Switch
Red Orange
SOSSwitch
yellow Black
GND
GND GND (Null)+12V
Arm/DisarmSignal line.
+12VDCvoltage: Disarmsystem
0VDC(Ground): ArmSystem
4P&12P
Connector Color No. Function&connection
Red 1 Positiveinput fromcarbattery DC12V）
Black 2 Negativeinput GND）
white 3 Relay spositivecontroloutput
4-PINconnector
yellow 4 Relay snegativecontroloutput

GPS VehicleTrackerUserManual
Page17
blue 1 ACC ONalertsignalinput
red 2 StatusindicatorLED
Orange 3 Integration line withthe originalcar
alarmssiren
yellow 4 Cardoorswitchinput
black 5 SOSswitchinput
green 6 Shock sensorinput
black 7 GND output
purple 8
Arming/disarming signalline. Onceit
detects+12VDC, systemwillbe
disarmed. Onceitis0Vsignal,itis
armed.
black 9 GND output
Red 10 +12VDC output (onlyinarming status)
black 11 GND output (sameasPin7 &Pin9)
12-PIN
connector
12 (Null)
Important Notice onInstallation
²Westronglyrecommendyoutoasktheprofessionalcarelectricianto
do theinstallation.
²PleaseprepareavalidGSMSIMcardinadvance.
²IMPORTANT: PleasedonotinsertorpullouttheSIMcardwhenthe
mainunithaspower.Beforedoingthisoperation,pleasedisconnect
theoutsidepowersupplylines,andturnofftheinternalbackup
batterysswitchfirstly.Thewrongoperation mightdamagethemain
unit.
²Pleasefixthemainunitatsecretplacetoavoidbeingdestroyedby
theft.Pleasekeep itawayfromthehigh-temperature,humidityor
strongmagneticobject.Pleasefasten ittightly.
²WhilemountingtheGPS antenna,theflatmagneticside mustbe
placed downside. Therecouldnotbeanymetal orshielded obstacles
aroundtheupsideoftheGPS antenna,sothatitcanreceivethe
satellitesignalfromupside theskyverywell,theGPS antennashould

GPS VehicleTrackerUserManual
Page18
beplacedatbroad&secretplacetoo.It shouldbedrewstraight and
keptawayfromthesoundboxorspeaker.
²WhilemountingtheGSMantenna,itshouldbeplaced atbroad &
secretplacewherethereisnoshieldedobstacle.
²TheGSMantennacantbeplaced alongwiththeGPS antennain
parallel.Itshouldbedrewstraightandkept awayfromthesoundbox
orspeaker.
²Afterinstallation,pleasetestthesystem&makesurethat it canGSM
signal&GPS signalverywell.Otherwise,fixtheGSMantennaor
GPS antennaat otherplacesuntilthesignalsareOK.
²Forsecurity,pleasefixtheGSM&GPS antennainsecret places.
Recommended places:(1).Downsidetheforewindshieldclass
(2).Downsidethe dashboard(3).Downsidewaterbrusher nometalcoat）
(4). Inside the dooredge of the car sroof. (nearbythe driving room).
AppendixI:HowtoTracktheCar
Track theCarbyGPRSCenter(Optional)
The usershouldsetup theirownGPRScenterfirstly,then programthe tracker
tosend GPS databyGPRSnetworktotheserver.Itisonline real-timetracking
whichisspecialforfleet management.
Track theCarbySMS&GoogleMap
The usercouldgetSMSalarmmessage fromthe system,thismessage
includes2kindsoflocationinformation:
(1).ThecodeoftheGSMnetworksbasestation.Bythe helpoftheGSM
operator,the carcouldbe easilylocated becausethe GSMoperatorshavethe
databaseofthe GSMnetworksbasestationcode.Butinmanycountries,this
serviceisnotopen topublic.
(2).The GPSslatitude&longitude,usercouldtrackthe car sprecise
locationafterinputting theminthe GOOGLEEARTH(pleasedownload itfrom
http://earth.google.com )or http://maps.google.com (Noted,pleaseadd the
minusbeforeX&Yif theyhave)
It iscost-effectivewayfortracking,butitisnotsoconvenientbecauseuser
must useinternet totrack byGoogleMap.

GPS VehicleTrackerUserManual
Page19
Track bytheSMSCenterSoftware&MapInfoMap(Optional)
Thisfunction isnotthestandardfunction.Itneedsthe supportofthe center(includes:
centersoftware,GSMModem&digitalmap). ThecentercantranslatetheGPS
coordinates intothereal address (suchas:city,street…etc)automatically.
Bythisway, the usercan directlyusemobiletosend aSMScommand, then he canget
the car srealaddress bySMS.Thereisnoneedofinternetconnection.Itisveryconvenient
forusers.
