Safety Usage Warnings
• — Do not use HMT-1Z1 while driving.
• — Always use your dominant eye for comfortable viewing.
Disposal of Old Electrical and Electronic Equipment
The symbol of the crossed-out wheeled bin indicates that within
the countries in the European Union, this product, and any
enhancements marked with this symbol, can not be disposed as
unsorted waste but must be taken to separate collection at their
end-of-life.
Disposal of Battery
Please check local regulations for disposal of batteries. The battery
should never be placed in municipal waste. Use a battery disposal
facility if available.

8
Guideline for Headphone and Earphone
To prevent possible hearing damage, do not listen at high volume
levels for long periods.
A pleine puissance, l’écoute prolongée du baladeur peut
endommager l’oreille de l’utilisateur.

9
i.Safe Safety Instructions
Introduction
This chapter contains information and safety regulations which are to be observed without
fail for safe operation of the device under the described conditions. Non-observance of this
information and instructions can have serious consequences and / or may violate regulations.
Please read the manual and these safety instructions before using the device. In case of any
doubt (in form of translation or printing errors), the English version shall apply.
Application
ATEX & IECEx
The HMT-1Z1 model T1100S is approved for use in zone 1, zone 2, zone 21 and zone 22 in
accordance with directives 2014/34/EU (ATEX) and the IECEx System.
NEC & CEC
The HMT-1Z1 model T1100S is approved for use in Division 1 and 2 Class I, II, III.
Manufacturer
i.Safe MOBILE GmbH
i_Park Tauberfranken 10
97922 Lauda-Koenigshofen; Germany

10
Faults and Damages
Before entering ex-hazardous areas, the safety of the device must be checked.
If there is any reason to suspect that the safety of the device has been compromised, it must be
withdrawn from use and removed from any ex-hazardous areas immediately.
Measures must be taken to prevent any accidental restarting of the device.
The safety of the device may be compromised, if, for example:
• Malfunctions occur
• The housing of the device shows damage
• The device has been exposed to excessive loads
• The device has been stored improperly
• Markings or labels on the device are illegible
• Permitted limit values have been exceeded
We recommend that a device displaying errors or which an error is suspected be sent back to
authorized service center to be checked.
Ex-relevant Safety Regulations
Use of this device assumes that the operator observes the conventional safety regulations and has
read and understood manual, safety instructions and certicate.
• Inside ex-hazardous areas the covers of all interfaces must be closed
• Exception is the audio jack cover. The audio jack can be used for approved headsets also
inside ex-hazardous areas
• To ensure the IP-protection, it has to be ensured that all gaskets are present and functional
• Physical connections to other equipment are only allowed outside ex-hazardous areas using
the i.safe PROTECTOR 1.0 USB-cable or other equipment approved by i.safe MOBILE GmbH

11
• During charging any headset or accessory must be unplugged from the audio jack
• The device may only be charged outside ex-hazardous areas using the i.safe PROTECTOR 1.0
USB-cable or other equipment approved by i.safe MOBILE GmbH
• The device may only be charged at temperatures between 5°C ... 40°C
• The battery is not removable by the user
• The device may not be exposed to any aggressive acids or alkalis
• The device may not be taken into zones 0 or 20
• The device must be protected from impacts with high impact energy, against excessive UV
light emission and high electrostatic charge processes
• The permitted ambient temperature range is -20°C to +60°C
• Only accessories approved by i.safe MOBILE GmbH may be used
• It is not allowed to do the adjustment of the head strap in ex-hazardous areas

12
General Information
RealWear HMT-1Z1 is intrinsically safe and is designed for skilled technicians and engineers
employed in eld service, equipment inspection, maintenance and complex manufacturing.
Head Mounted Tablet Models Covered
This user guide covers the following RealWear HMT-1Z1 model: T1100S. You can nd the model
name on the HMT-1Z1 device label on the rear side of the tablet.
Model number

13
Operating Frequency Bands
Wi-Fi operating frequency band(s) details and EIRP are as follows:
• 2412-2472: 15.89dBm
• 5180-5320: 17.09dBm
• 5500-5700: 17.37dBm
• 5745-5825: 12.98dBm
Bluetooth operating frequency band and EIRP is: 2402-2480: 12.16dBm
5G Wi-Fi Connection Information
Operations in the 5.15 — 5.35GHz band are restricted to indoor use only.

14
RealWear Support Information
For additional product and support information, use the following information:
• E-mail: [e-mail]
• Website: http://www.realwear.com
• Postal address: 600 Hatheway Road, Vancouver, WA — 98661

15
Safety Guidelines
Battery Performance
A rechargeable battery powers your device. The device comes with an inbuilt battery which
is not replaceable. Never use any uncertied charger. Use the battery only for its intended
purpose. Never use any charger or battery that is damaged. If the battery is completely
discharged, it may take a few minutes before the charging indicator appears on the display or
before the device can be used. The full performance of a new battery is achieved only after 3 to
4 complete charge and discharge cycles. The battery can be charged and discharged for multiple
cycles but it will eventually wear out. Unplug the charger from the electrical plug and the
device when not in use. Ensure that you do not leave the fully charged battery connected to the
charger. If left unused, a fully charged battery will lose its charge over time.
There is a risk of explosion while charging if an incorrect battery other than the
specied model is used.
Avoid Short Circuit
Do not short-circuit the battery. An accidental short-circuit can occur when a metallic object
such as a coin, clip, or pen causes direct connection of the positive (+) and negative (-) terminals
of the battery. This might happen, for example, when you carry a spare battery in your pocket or
toolbox. A short-circuit at the terminals may damage the battery or the connecting object.
Avoid High Temperatures
Leaving the battery in hot or cold places, such as in a closed car in summer or winter conditions,
will reduce the capacity and lifetime of the battery. For the best results, try to keep the battery
between -20°C and +60°C (-4°F and 140°F). A device with a hot or cold battery may not work
temporarily, even when the battery is fully charged. Battery performance is particularly limited

16
in temperatures well below freezing.
Battery Disposal
Do not dispose of the device in re as it contains an inbuilt battery which may explode. Dispose
of the device according to local regulations and recycle when possible. Do not dispose as
household waste. Do not dismantle, open or shred cells or batteries. In the event of a battery
leak, do not allow the liquid to come in contact with the skin or eyes. In the event of leak or a
hazard seek medical help immediately.
Child Safety
Do not allow children to play with your device or its accessories. Keep it out of their reach.
They could hurt themselves or others, or could accidentally damage the device or accessories.
Your device and its accessories may contain small parts, which could be detached and create a
choking hazard.
Health and Safety Warnings
Stop using RealWear HMT-1Z1 or its display immediately if you experience a headache, vertigo,
dizziness or nausea. Do not use the HMT-1Z1 display while operating any vehicle. Move the
boom arm completely out of your line of sight when not using the display. Maintain situational
awareness of your surroundings while using the HMT-1Z1.

17
SAR Information
Radiation Exposure Statement — The United States and Canada
This device meets the government’s requirements for exposure to radio waves.
This device is designed and manufactured not to exceed the emission limits for exposure to radio
frequency (RF) energy set by the Federal Communications Commission of the U.S. Government.
The exposure standard for wireless devices employs a unit of measurement known as the Specic
Absorption Rate, or SAR. The SAR limit set by the FCC is 1.6 W/kg. Tests for SAR are conducted
using standard operating positions accepted by the FCC with the device transmitting at its highest
certied power level in all tested frequency bands.
No minimum separation distance needs to be maintained between the user’s body and the
device, including the antenna, during body-worn operation to comply with the RF exposure
requirements in the United States and Canada.
The limit recommended by FCC and IC is 1.6 W/kg averaged over one (1) gram of tissue.
The highest SAR value of the HMT-1Z1 for use:
• By the ear is 1.31 W/kg (1g)
Radiation Exposure Statement — Europe
No minimum separation distance needs to be maintained between the user’s body and the
device, including the antenna during body-worn operation to comply with the RF exposure
requirements in Europe.
The limit recommended by RED is 2 W/kg averaged over ten (10) gram of tissue.
The highest SAR value of the HMT-1Z1 for use:
• By the ear is 0.34 W/kg (10g)

18
Radiation Exposure Statement — Canada
The product complies with the Canada portable RF exposure limit set forth for an uncontrolled
environment and is safe for intended operation as described in this manual. The further RF
exposure reduction can be achieved if the product can be kept as far as possible from the user
body or set the device to lower output power if such function is available.
Déclaration d’exposition aux radiations
Le produit est conforme aux limites d’exposition pour les appareils portables RF pour les
Etats-Unis et le Canada établies pour un environnement non contrôlé. Le produit est sûr pour
un fonctionnement tel que décrit dans ce manuel. La réduction aux expositions RF peut être
augmentée si l’appareil peut être conservé aussi loin que possible du corps de l’utilisateur ou que
le dispositif est réglé sur la puissance de sortie la plus faible si une telle fonction est disponible.
Charger Use Safety Instructions
To use the charger follow these instructions:
• -The device may only be charged outside ex-hazardous areas using the i.safe PROTECTOR
1.0 USB-cable or other equipment approved by i.safe MOBILE GmbH
• — Make sure that the cable plug is properly connected
• — Keep the charger away from liquids
• — In case of any strange smell or noise from the charger, disconnect it and contact
support
• — Before cleaning the cable or charger, disconnect from power supply
• — When using an extension cable, check the integrity of the ground conductor
• — Disconnect the charger from HMT-1Z1, once the battery is fully charged
• — Do not use this charger in wet areas

19
• — Do not insert or remove the plug with wet hands
• — Do not open the charger. For any issues, contact support
• — Do not cut, break or bend the cable in a knot
• — Do not put any objects on the cable that may let it overheat. It may damage the cable
and cause re or electrocution

20
Introduction
This section provides information on using your RealWear HMT-1Z1.
The list of items in the RealWear HMT-1Z1 box are:
• HMT-1Z1
• I.safe PROTECTOR 1.0 USB-cable
• Overhead strap
• Rear pad (detachable)
About the RealWear HMT-1Z1
RealWear HMT-1Z1 is the rst-generation intrinsically safe head mounted rugged tablet. You can
operate the tablet completely hands-free using only voice commands and head gestures This
hands-free operation is done using WearHF™ software, built into every RealWear device. The
HMT-1Z1 runs on Android 6.0.
