Remington M15012US User manual

IMPORTANT: Read and understand this manual before
assembling or operating this chain saw. Improper use of
saw can cause severe injury. Keep this manual for future
reference.
MODELS: M15012US, M15014AS, M30016US, M30016AS,
M30016AW, M35016AW
ELECTRIC CHAIN SAW
OWNER’S MANUAL
ENGLISH
For parts contact: www.PartsFor.com

3www.remingtonpowertools.com
ENGLISH
CONTENTS
IMPORTANT SAFETY INFORMATION ....................................................................... 4
Before Operating Saw ............................................................................................................... 4
While Operating Saw................................................................................................................. 4
Kickback .................................................................................................................................... 5
Maintenance and Storage of Chain Saw................................................................................... 6
UNPACKING ................................................................................................................ 6
PRODUCT IDENTIFICATION ...................................................................................... 7
CHAIN SAW NAMES AND TERMS............................................................................. 8
QUICK START GUIDE................................................................................................. 9
ASSEMBLY................................................................................................................ 10
SAW CHAIN TENSION ADJUSTMENT .................................................................... 12
OPERATING CHAIN SAW......................................................................................... 13
Filling Oil Tank ......................................................................................................................... 13
Oiling Chain............................................................................................................................. 13
Clearing sprocket cover of debris............................................................................................ 13
Extension Cords ...................................................................................................................... 14
Cutting with the Chain Saw .....................................................................................................14
Felling a Tree (Cutting Down a Tree) ...................................................................................... 15
Limbing a Tree......................................................................................................................... 16
Bucking a Log.......................................................................................................................... 16
Trimming a Tree (Pruning)....................................................................................................... 17
CLEANING AND MAINTENANCE ............................................................................ 18
Cleaning Saw Body ................................................................................................................. 18
Care of Guide Bar ................................................................................................................... 18
Sharpening Saw Chain............................................................................................................ 18
Replacing Saw Chain .............................................................................................................. 19
STORAGE.................................................................................................................. 20
REPLACEMENT PARTS AND ACCESSORIES ....................................................... 20
REPAIR SERVICE ..................................................................................................... 20
Warranty Service..................................................................................................................... 20
Non-Warranty Service ............................................................................................................. 20
TROUBLESHOOTING............................................................................................... 21
TECHNICAL SERVICE .............................................................................................. 21
WARRANTY INFORMATION..................................................................................... 22
ILLUSTRATED PARTS BREAKDOWN..................................................................... 72
PARTS CENTRAL ..................................................................................................... 74
For parts contact: www.PartsFor.com

4
www.remingtonpowertools.com
ENGLISH
IMPORTANT SAFETY INFORMATION
BEFORE OPERATING SAW
1. Read and understand this owner’s manual
before operating chain saw.
2. Watch what you are doing. Use common
sense. Do not operate saw when you are
tired.
3. Use chain saw for cutting wood only. Do not
use chain saw for purpose not intended. Do
not use for cutting plastic, masonry, etc.
4. Only well-instructed adults should operate
chain saw. Never allow children to operate
chain saw.
5. Use only electrical voltage noted on model
plate of chain saw.
6. Use only extension cords marked for outdoor
use. See Extension Cord Requirements.
7. Do not operate chain saw
• while under the influence of alcohol, medi-
cation, or drugs
• in rain or in damp or wet areas
• where highly flammable liquids or gases are
present
• if saw is damaged, adjusted wrong, or not
fully and securely assembled
• if trigger does not turn saw on and off. Chain
must stop moving when you release trigger.
Have faulty switch replaced by authorized
service center (see Technical Service).
• while in a hurry
• while in tree or on a ladder unless trained to
do so
8. Wear snug-fitting clothes when operating
chain saw. Do not wear loose clothing or
jewelry. They can get caught in moving saw
chain.
9. Wear the following safety gear when operating
chain saw.
WARNING:Whenusinganelectric
chain saw, basic safety precautions
should always be followed to reduce
the risk of fire, electric shock, and
injury to persons, including the fol-
lowing:
READ ALL INSTRUCTIONS.
Make sure you read and understand all
instructions in Important Safety Infor-
mation. Improper use of this chain saw
can cause severe injury or death from
fire, electrical shock, body contact with
moving chain, or falling wood.
• heavy-duty gloves (wear rubber gloves
when working outdoors)
• steel-toed safety footwear with non-skid
soles
• eye protection such as safety glasses,
goggles, or face screen
• safety hard hat
• ear mufflers or ear plugs
• hair covering to contain long hair
• face or dust mask (if working in dusty
areas)
10. Before cutting, always provide the follow-
ing:
• clear work area
• secure footing
• planned retreat path from falling tree
11. Inspect tree before cutting down. Make sure there
are no dead limbs or branches that may fall on
you.
12. To reduce the risk of electric shock, this saw
has a polarized plug (one blade is wider than
the other). This plug will fit in a polarized
outlet only one way. If the plug does not fit
fully in the outlet of your extension cord,
reverse the plug. If it still does not fit, a polar-
ized extension cord will be necessary. Do not
change the plug in any way.
WHILE OPERATING SAW
1. Stay alert. Use common sense while operating
chain saw.
2. Keep work area clean. Cluttered areas invite
injuries.
3. Be aware of extension cord while operating
chain saw. Be careful not to trip over cord.
Keep cord away from chain and operator at
all times.
4. Keep children, animals, and bystanders away
from chain saw and extension cord. Only
chain saw user should be in work area.
5. Do not cut down a tree unless you are trained
or have expert help.
6. If two or more persons perform bucking and
felling operations at the same time, provide
plenty of distance between operations. Provide
distance of at least twice the height of tree
being felled.
7. Secure wood you are cutting by using clamps
or chocks.
8. Grip chain saw firmly with both hands. Never
operate chain saw with one hand. Never use
hand guard as handle.
9. Keep finger off trigger until ready to make
cut.
For parts contact: www.PartsFor.com

5www.remingtonpowertools.com
ENGLISH
90° Quadrant
Do Not Let
Guide Bar
Touch Here
Direction
IMPORTANT SAFETY INFORMATION
WARNING: Kickback may occur
when the nose or tip of the guide bar
touches an object, or when the wood
closes in and pinches the saw chain
in the cut. Tip contact in some cases
may cause a lightning fast reverse
reaction, kicking the guide bar up and
backtowardstheoperator.Pinchingthe
saw chain along the top of the guide
bar may push the guide bar rapidly
back towards the operator. Either of
these reactions may cause you to lose
control of the saw which could result
in serious injury to user.
KICKBACK
10. Before starting chain saw, make sure chain is
not touching anything.
11. To guard against electrical shock, avoid body
contact with grounded objects such as pipes,
fences, and metal posts.
12. Keep all parts of body away from chain when
saw is running.
13. Do not force chain saw while cutting. Apply
light pressure. It will do the job better and
safer at the rate for which it was intended.
14. Cut small brush and saplings with extreme
care. Slender material may catch in chain and
be whipped toward you. This could also pull
you off balance.
15. When cutting limb or tree trunk that is under
tension, use extreme caution. Be alert for
wood springing back. When wood tension is
released, limb could spring back and strike
operator causing severe injury or death.
16. Carry chain saw from one place to another
• with saw stopped and unplugged
• by holding front handle (never use hand
guard as handle)
• with finger off trigger
• with guide bar and chain to rear
Kickback Safety Devices On This
Saw
This saw has a low-kickback chain and reduced
kickback guide bar. Both items reduce the chance
of kickback. Kickback can still occur with this
saw.
Follow assembly instructions. Do not remove
front hand guard. Do not replace front hand guard
with substitute.
The following steps will reduce the risk of kick-
back.
• Use both hands to grip saw while saw is
running. Use firm grip. Thumbs and fingers
must wrap around saw handles.
• Keep all safety items in place on saw. Make
sure they work properly.
• Do not overreach or cut above shoulder
height.
• Keep solid footing and balance at all
times.
• Stand slightly to left side of saw. This keeps
your body from being in direct line with
chain.
WARNING: Some dust created by
powersanding,sawing,grinding,drill-
ing, and other construction activities
containschemicalsknown(tothestate
of California) to cause cancer, birth
defects, or other reproductive harm.
Some examples of these chemicals
are:
• lead from lead-based paints
• crystalline silica from bricks and ce-
ment and other masonry products
• arsenic and chromium from chemi-
cally-treated lumber
Your risk from theseexposuresvaries,
depending on how often you do this
typeof work. To reduceyour exposure
to these chemicals: work in a well ven-
tilated area, and work with approved
safety equipment, such as those dust
masks that are specially designed to
filter out microscopic particles.
WARNING: This product contains
chemicals known to the State of Cali-
forniatocausecanceror birth defects,
or other reproductive harm.
Figure 1 - Kickback Hazard Example: Do Not
Let Nose of Guide Bar Touch Object While
Chain is Moving
For parts contact: www.PartsFor.com

7www.remingtonpowertools.com
ENGLISH
Chain Tensioning Screw
Rear Handle
Power Cord
Guide Bar
Saw Chain
Front Handle Oil Cap
Trigger
Switch Lockout
Cord Hitch
Guide Bar Nose
Hand Guard
Chain Tensioning Screw
Rear Handle
Power Cord
Guide Bar
Saw Chain
Front Handle
Oil Cap
Trigger
Switch Lockout
Cord Hitch
Guide Bar Nose
Hand Guard
PRODUCT IDENTIFICATION
Models: M15012US, M15014AS, M30016US, M30016AS
Models: M30016AW, M35016AW
For parts contact: www.PartsFor.com

8
www.remingtonpowertools.com
Bucking Process of cutting a felled tree or log
into lengths.
Chock Block or wedge used to secure wood from
moving.
Felling Process of cutting down a tree.
Felling Cut Final cut when felling a tree. Make this
cut on opposite side of tree from notching cut.
Front Handle Located at front of saw body.
Front Hand Guard Shield between front handle
and guide bar. Protects left hand while using
saw.
Guide Bar Metal bar that extends from saw body.
The guide bar supports and guides chain.
Guide Bar Nose Tip or end of guide bar.
Guide Bar Retainer Bolt-like fastener that holds
guide bar in place during assembly and operation
of chain saw.
Kickback Quick backward and upward motion
of guide bar. Kickback may occur when tip of
guide bar touches an object while chain is mov-
ing. The guide bar will kick up and back towards
operator.
Limbing Process of cutting limb(s) from a felled
tree.
Low-Kickback Chain Chain that reduces chance of
kickback as required by ANSI B175.1.
Normal Cutting Position Stance used while making
bucking and felling cuts.
Notching Cut Notch cut in tree that directs fall of
tree.
Oiler Control System for oiling guide bar and
chain.
Power Head Chain saw without chain and guide
bar. Also known as saw body.
Pushback (Kickback, Pinch) Rapid pushback of
chain saw. Pushback may occur if chain along
top of guide bar is pinched, caught, or contacts a
foreign object.
Rear Handle Handle located at rear of saw
body.
Reduced Kickback Guide Bar Guide bar that
reduces chance of kickback.
Replacement Chain Chain that complies with
ANSI B175.1 when used with a specific saw. It
may not meet ANSI requirements when used with
other saws.
Saw Chain (Chain) Loop of chain having cutting
teeth for cutting wood. The motor drives chain.
The guide bar supports chain.
Spiked Bumper (Spike) Pointed teeth at front of
saw body beside guide bar. Keep spiked bumper
in contact with wood when felling or bucking. It
helps maintain position of saw while cutting.
Sprocket Toothed wheel that drives chain.
Switch Device that completes or interrupts electri-
cal circuit to motor of saw.
Switch Linkage This device connects switch
to trigger. It moves switch when you squeeze
trigger.
Switch Lockout Device that reduces accidental
starting of saw.
Trigger Device that turns saw on and off. Squeez-
ing trigger turns saw on. Releasing trigger turns
saw off.
Trimming (Pruning) Process of cutting limb(s)
from a living tree.
Undercut An upward cut from underside of log or
limb. This is done while in normal cutting position
and cutting with top of guide bar.
Unibody Main body of chain saw.
CHAIN SAW NAMES AND TERMS
For parts contact: www.PartsFor.com

9www.remingtonpowertools.com
ENGLISH
Whenchainbecomes looseduetostretching,
tension properly. See Saw Chain Tension
Adjustment for correct tensioning of saw
chain.
Use both hands to grip chain saw. Push
lockoutbuttonforwardwithrightthumb and
squeeze trigger. Make sure saw is running
at full speed before starting a cut.
Switch Lockout Button
Trigger
Connect extension cord to power cord and
power supply. Use built-in cord hitch or
knot method (inset) to secure together. See
Extension Cords for correct size.
Power
Cord
Cord
Hitch
Extension Cord
Slot
Pour motor oil (see Filling Oil Tank, page
10, for correct oil type) in oil tank (do not
use standard bar and chain oil). DO NOT
leave oil in tank when not in use.
Oil Bottle
Oil Squeeze Bulb
For complete information concerning your saw and its proper
usage, read and understand this owner’s manual thoroughly.
QUICK START GUIDE
If you are familiar with chain saws, their proper usage, and the saw you purchased is fully assembled,
use this Quick Start Guide to quickly begin using your new Remington brand chain saw.
For parts contact: www.PartsFor.com

10
www.remingtonpowertools.com
Towards
Guide Bar
Nose
Cutting
Edge
Guide Bar
Chain Tensioning
Screw
Turn tensioning
screw to move
Adjustment Block
L
O
C
K
E
D
Guide Bar Retainer
Rotated 90 Degrees to
Guide Bar Slot
Guide Bar
Drive Sprocket
U
N
L
O
C
K
E
D
Guide Bar Retainer
Positioned Parallel
to Guide Bar Slot
Guide Bar
Drive Sprocket
Note: Some models are pre-assembled. Assembly
is not needed on these models. See Saw Chain
Tension Adjustment
1. Lay chain out flat.
2. Loosen and remove guide bar nut and sprocket
cover.
3. Rotate guide bar retainer so that it is positioned
parallel to guide bar slot (see Figure 2).
4. Install guide bar onto saw body. Assemble
center slot of guide bar onto guide bar bolt
and guide bar retainer. Note: Make sure the
head of the guide bar retainer slides through
the guide bar slot as shown in Figure 2.
WARNING:Cuttingedgesonchain
aresharp.Use protective gloves when
handling chain.
IMPORTANT: Do not clamp chain saw
in vise during assembly.
Figure 3 - Locking Guide Bar Retainer
5. Rotate guide bar retainer 90 degrees as shown
in Figure 3.
Figure 2 - Unlocking Guide Bar Retainer
ASSEMBLY
Figure 5 - Chain Tensioning Screw and
Adjustment Block Location
7. Before installing sprocket cover to saw body,
turn the chain tensioning screw fully counter-
clockwise until it stops. This will position the
adjusting block towards the end of the chain
tensiong screw. (See Figure 5)
Figure 4 - Saw Chain Direction
6. Place chain around drive sprocket, along top
groove of guide bar, and around guide bar nose.
Note: Make sure cutting edges of chain are
facing in right direction. Position chain so
cutting edges on top of guide bar face guide
bar nose (see Figure 4 and indicator on side
cover of saw).
CAUTION: Do not place chain
on saw backwards. If chain is back-
wards, saw will vibrate badly and will
not cut.
For parts contact: www.PartsFor.com

11 www.remingtonpowertools.com
ENGLISH
Guide Bar
Adjusting
Hole
Sprocket Cover Tab
Tab Slot
Sprocket Cover Tab
Guide
Bar Nut
9. Insert the sprocket cover tab into the saw body
tab slot, Step 1. Then lower sprocket cover
onto guide bar bolt, Step 2 (See Figure 7).
NOTE: At this point the sprocket cover will
not be flush against the saw body.
10. Finger tighten the guide bar nut onto the guide
bar bolt. (See Figure 8).
Figure 8 - Guide Bar Bolt
11. Slowly slide guide bar into saw body until the
adjustment block goes into the round adjusting
hole on the guide bar. (See Figure 6) NOTE:
This locks the guide bar in place. You should
not be able to push or pull the guide bar.
12. Retighten the bar nut finger tight.
13. Adjust the saw chain tension. Follow the steps
under Saw Chain Tension Adjustment..
Figure 7 - Installing Sprocket Cover
Figure 6 - Pulling Guide Bar
8. Pull the guide bar away from the saw body
so that the guide bar is fully extended and the
slack is removed from the chain. (See Figure
6)
ASSEMBLY
For parts contact: www.PartsFor.com

12
www.remingtonpowertools.com
L
O
O
S
E
N
❶
Loosen nut...
Ifchainbecomesloosearound guide
bar, allow chain to cool then...
❷
T
I
G
H
T
E
N
T
I
G
H
T
E
N
Turn chain tensioning screw
clockwise to tension saw chain...
❸
Pull chain to check tension. Guide
links should not come out of guide
bar groove...
Tighten nut with wrench. A
slight sag of 1/8" between chain
and bottom of guide bar is
acceptable.
❺
❹Guide Bar
Approx.
5/32"
WARNING:Unplugchainsawfrom
power source before adjusting saw
chain tension.
WARNING:Cuttingedgesonchain
aresharp.Use protective gloves when
handling chain.
WARNING: Maintain proper
chain tension always. A loose chain
will increase the risk of kickback. A
loose chain may jump out of guide
bar groove. This may injure operator
and damage chain. A loose chain will
cause chain, guide bar, and sprocket
to wear rapidly.
IMPORTANT!
Failure to follow these instructions when ten-
sioning saw chain will damage saw and void the
warranty. For additional information call 1-800-
626-2237.
New saw chains will stretch. Check chain tension
frequently when first used and tighten when chain
becomes loose around guide bar.
SAW CHAIN TENSION ADJUSTMENT
For parts contact: www.PartsFor.com

13 www.remingtonpowertools.com
ENGLISH
Oil Bottle
Oil Squeeze Bulb
Wood Chips,
Twigs, and Debris
Sprocket Cover Guide Bar Nut
OPERATING CHAIN SAW
WARNING: Read and understand
this owner’s manual before operat-
ing this saw. Make certain you read
and understand all Important Safety
Information. Improper use of this
chain saw can cause severe injury
or death from fire, electrical shock,
or body contact with moving chain,
or falling wood.
FILLING OIL TANK
1. Remove oil cap.
2. Fill oil tank with SAE #30 motor oil. Note:
For temperatures below 30°F, use SAE #10
oil. For temperatures above 75°F, use SAE
#40 oil.
DO NOT use standard bar and chain oil.
3. Replace oil cap at once. Tighten oil cap firmly
for good seal. This will avoid oil seepage from
cap.
4. Wipe off excess oil.
Figure 9 - Oil Squeeze Bulb and Oil Bottle
Location
CLEARING SPROCKET COVER OF
DEBRIS
While operating the chain saw, wood chips, small
twigs, and other debris can occasionally build up
inside the sprocket cover. To properly maintain the
saw and keep it in good working order, periodic
removal of this debris may be required. To prop-
erly clear debris from the sprocket cover:
1. Unplug chain saw.
2. Loosen and remove guide bar nut (see Figure
10).
3. Turn chain tensioning screw counterclockwise
to loosen chain until sprocket cover is easily
removed.
4. After sprocket cover is removed, clear all
chips, twigs, and debris.
WARNING: Use caution when
clearing debris that is around chain.
Cutting edges on chain are sharp.
Use protective gloves when working
around or handling chain.
5. Once debris has been removed, follow steps 7
through 13 on pages 9 and 10 in the Assembly
section to re-assemble the sprocket cover to
the chain saw.
Figure 10 - Removing and Clearing Sprocket
Cover of Debris
OILING CHAIN
Manual Oil System
Always check oil level before using saw. Do not
attempt to operate the oil system while saw is
in operation. To oil chain, press squeeze bulb.
Oil will feed onto the guide bar and chain. Press
squeeze bulb at least once before each cut. Check
oil level often by looking at oil level through side
of oil bottle (see Figure 9).
Note: It is normal for oil to seep when saw
is not in use. It is necessary to empty oil
tank after each use to prevent seepage.
For parts contact: www.PartsFor.com

14
www.remingtonpowertools.com
Power Cord
Extension Cord
Cord Hitch
Trigger
Switch Lockout Button
Figure 11 - Looping Extension Cord over
Cord Hitch
Cord Length AWG Cord Size
25 feet 16 AWG
50 feet 16 AWG
100 feet 16 AWG
150 feet 14 AWG
Models: M15012US, M15014AS
Keep cord away from cutting area. Make sure cord
does not catch on branches or logs during cutting.
Inspect cords often. Replace damaged cords.
This chain saw is designed with an extension cord
hitch that prevents the extension cord from being
pulled loose during use. To use, form a loop with
the end of the extension cord, insert loop into slot in
rear of handle, and place loop over cord hitch (see
Figure 11. Gently pull loop against cord hitch
until slack is removed. Plug extension cord into
chain saw cord.
EXTENSION CORDS
Use proper extension cords with this saw. Use only
extension cords marked for outdoor use. The cord
must be marked with suffix W or W-A following
the cord type designation. Example: SJTW-A
or SJTW.
Use proper sized cord with this saw. Cord must be
heavy enough to carry current needed. An undersized
cord will cause voltage drop at saw. Saw will lose
power and overheat. Follow cord size requirements
listed below.
Cord Length AWG Cord Size
25 feet 16 AWG
50 feet 16 AWG
100 feet 14 AWG
150 feet 12 AWG
Models: M30016US, M30016AS, M30016AW,
M35016AW
Figure 12 - Lockout Button and Trigger
Location
CUTTING WITH THE CHAIN SAW
1. Connect saw to extension cord. Connect exten-
sion cord to power supply.
2. Make sure section of log to be cut is not laying
on ground. This will keep chain from touch-
ing ground as it cuts through log. Touching
ground with moving chain will dull chain.
3. Use both hands to grip saw. Always use left
hand to grip front handle and right hand to
grip rear handle. Use firm grip. Thumbs and
fingers must wrap around saw handles (see
Figure 12).
4. Make sure your footing is firm. Keep feet
apart. Divide your weight evenly on both
feet.
5. When ready to make a cut, push the lockout
button completely forward with the right
thumb and squeeze the trigger (see Figure 12).
This will turn saw on. Releasing trigger will
turn saw off. Make sure saw is running at full
speed before starting a cut.
6. When starting a cut, place moving chain against
wood. Hold saw firmly in place to avoid possible
bouncing or skating (sideways movement) of
saw.
7. Guide saw using light pressure. Do not force
saw. The motor will overload and can burn
out. It will do the job better and safer at the
rate for which it was intended.
8. Remove saw from a cut with saw running
at full speed. Stop saw by releasing trigger.
Make sure chain has stopped before setting
saw down.
9. Practice until you can maintain a steady, even
cutting rate.
For parts contact: www.PartsFor.com

15 www.remingtonpowertools.com
ENGLISH
Direction of Fall
Retreat Path
Retreat Path
45° Tree
Direction
of Fall
Hinge
2"
(5 cm)
2"(5 cm)
2nd Cut -
Upper Notch Cut
1st Cut -
Lower Notch
Cut
3rd Cut -
Felling Cut
Felling is the process of cutting down a tree. Make
sure your footing is firm. Keep feet apart. Divide
your weight evenly on both feet. Follow directions
below to fell a tree.
Before Felling a Tree
1. Before felling, inspect tree. Make sure there
are no dead limbs or branches that may fall
on you. Study natural lean of tree, location of
larger branches, and wind direction. This will
help you judge which way tree will fall.
2. Clear work area around tree.
3. Plan and clear a retreat path before felling.
Make retreat path opposite to planned direc-
tion of fall of tree and at 45° angle (see Figure
13).
WARNING:
• Avoid kickback. Kickback can result
in severe injury or death. See Kickback
to avoid risk of kickback.
• Do not fell a tree without ample skill
or expert help.
• Keepchildren,animals,andbystand-
ers away from area when felling a
tree.
• If two or more persons perform
bucking and felling operations at
the same time, provide ample dis-
tance between operations. Provide
distance of at least twice the height
of tree being felled.
WARNING: When felling a tree, be
aware of your surroundings. Do not
endanger any person, strike utility
lines, or cause property damage. If
tree strikes utility lines, contact utility
company at once.
FELLING A TREE (Cutting Down a Tree)
Figure 13 - Retreat Path From Tree
OPERATING CHAIN SAW
Figure 14 - Felling A Tree
4. Remove dirt, stones, loose bark, nails, staples,
and wire from tree where you will make felling
cuts.
WARNING: Do not cut all the way
throughtree.Leaveabout two inches
oftreediameteruncutdirectlybehind
felling notch (see Figure 14). This
uncut portion acts as a hinge. The
hinge helps keep tree from twisting
and falling in wrong direction.
B) Felling Cut
1. Make felling cut two inches higher than lower
notch cut and on opposite side of tree (see Figure
14). Keep felling cut parallel to lower notch
cut.
5. Stay on uphill side when felling tree. Tree
could roll or slide downhill after falling.
Felling Procedure
A) Felling Notch
A properly placed felling notch will determine
direction tree will fall. Place felling notch on
side of tree in direction you want tree to fall (see
Figure 14). Follow directions below to create a
felling notch.
1. Make lower notch cut as close to ground as
possible. Hold saw so guide bar is horizontal.
Cut 1/3 the diameter of tree trunk (see Figure
14). Note: Always make this horizontal lower
notch cut first. If you make this cut second,
tree can pinch chain or guide bar.
2. Start upper notch cut the same distance above
first cut as first cut is deep.
Example: If lower notch cut is eight inches deep,
start upper notch cut eight inches above it. Cut
downward at 45° angle. The upper notch cut
should meet end of lower notch cut (see Figure
14).
3.
Remove tree trunk wedge created by notching
cuts.
For parts contact: www.PartsFor.com

16
www.remingtonpowertools.com
Limbing is removing branches from a fallen tree.
Make sure your footing is firm. Keep feet apart.
Divide your weight evenly on both feet. Do not
remove larger limbs under tree that support log
off ground. Remove each limb with one cut (see
Figure 15). Clear cut limbs from work area often.
This will help maintain a safe work area.
Make sure you start your cut where limb will
not pinch saw during cutting. To avoid pinching,
start cut on freely hanging limbs from above
limb. Start cut on limbs under tension from under
limb. If pinch occurs, turn saw off, lift limb, and
remove saw.
WARNING:Whencutting limb that
isundertension,useextreme caution.
Be alert for wood springing back.
When wood tension is released, limb
could spring back and strike operator
causing severe injury or death.
LIMBING A TREE
WARNING: Avoid kickback. Kick-
back can result in severe injury or
death. See Kickback to avoid risk of
kickback.
WARNING: Be alert for falling
overhead limbs. Watch your footing
while exiting area.
Figure 15 - Limbing A Tree
WARNING: Avoid kickback.
Kickback can result in severe injury
or death. See Kickback to avoid risk
of kickback.
WARNING:
• If on slope, make sure log will not
roll down hill. Secure log by us-
ing wooden stakes. Drive wooden
stakesintogroundon downhill side
of log. Stand on uphill side of log
while cutting. Log may roll after
cutting.
• Never try cutting through two logs
at same time. This could increase
the risk of kickback.
• While cutting log, never hold log
with your hand, leg, or foot.
• While cutting log, never allow an-
other person to hold log.
• Turn offandunplugsawbeforemov-
ing from one place to another.
Bucking a log is cutting a log into sections. Make
sure your footing is firm. Keep feet apart. Divide
your weight evenly on both feet. When possible,
raise log or section off ground. Do this by using
limbs, logs, chocks, etc.
When cutting through log, maintain control by
reducing cutting pressure near end of cut. Do not
relax your grip on chain saw handles. Do not let
moving chain touch ground. Ground will dull
moving chain. After cutting through log, release
trigger to turn saw off before moving saw.
Follow directions below to buck a log.
Entire Length Of Log On Ground
Cut log from top (see Figure 16).
Figure 16 - Bucking Log With Entire Length
On Ground
BUCKING A LOG
OPERATING CHAIN SAW
2. Cut towards notch.
3. As felling cut nears hinge, tree should begin to fall.
Note: If needed, drive wedges into felling cut to
control direction of fall. If tree settles back and
pinches chain, drive wedges into felling cut to
remove saw. Only use wedges made of wood,
plastic, or aluminum. Never use wedge made of
steel. This could cause kickback and damage to
chain.
4. When tree begins to fall, quickly
• remove saw from felling cut
• release trigger to turn saw off
• put saw down
• exit area using retreat path
For parts contact: www.PartsFor.com

17 www.remingtonpowertools.com
ENGLISH
2" to 4"
(5 a 10 cm)
2nd Cut - Pruning
Cut (to avoid
pinching)
1st Cut - Pruning
Undercut
(to avoid splintering)
3rd Cut - Stub Undercut
(to avoid splintering)
6"
(15 cm)
4th Cut - Final Stub
Cut
1st
Cut
2nd
Cut
1st Cut
2nd Cut
Log Supported On One End
1. Make first cut on underside of log (see Figure
17). Use top of guide bar to make this cut. Cut
1/3 through diameter of log. This cut will keep
section from splintering when cut.
2. Make second cut directly above first cut. Cut
down to meet first cut. This cut will keep log
from pinching guide bar and chain.
Log Supported On Both Ends
1. Make first cut from above log (see Figure 18).
Cut 1/3 through diameter of log. This cut will
keep section from splintering when cut.
2. Make second cut on underside of log, directly
under first cut. Use top of guide bar to make
this cut. Cut up to meet first cut. This will keep
log from pinching guide bar and chain.
OPERATING CHAIN SAW
TRIMMING A TREE (Pruning)
Figure 17 - Bucking Log When Log Is
Supported On One End
Figure 18 - Bucking Log When Log Is
Supported On Both Ends
CAUTION: Seek professional
help if facing conditions beyond your
ability.
WARNING:Donotcutlimbshigher
than your shoulders.
WARNING: Do not operate chain
saw while
• in a tree
• on a ladder or any other unstable
surface
• in any awkward position
You may lose control of saw causing
severe injury.
Trimming a tree is the process of cutting limbs
from a living tree. Make sure your footing is firm.
Keep feet apart. Divide your weight evenly on both
feet. Follow directions below to trim a tree.
1. Make first cut six inches from tree trunk on
underside of limb. Use top of guide bar to
make this cut. Cut 1/3 through diameter of
limb (see Figure 19).
2. Move two to four inches farther out on limb.
Make second cut from above limb. Continue
cut until you cut limb off.
3. Make third cut as close to tree trunk as possible
on underside of limb stub. Use top of guide bar
to make this cut. Cut 1/3 through diameter of
stub.
4. Make fourth cut directly above third cut. Cut
down to meet third cut. This will remove limb
stub.
Figure 19 - Cutting A Limb
WARNING: Avoid kickback.
Kickback can result in severe injury
or death. See Kickback to avoid risk
of kickback.
For parts contact: www.PartsFor.com

18
www.remingtonpowertools.com
Guide Bar With Uneven Wear
Guide Bar
Normal Guide Bar
Guide Bar Groove
Oil Slot
Cleaning Groove With Putty Knife
Flat
File
Burr
Guide Bar
CARE OF GUIDE BAR
Uneven bar wear causes most guide bar problems.
Incorrect sharpening of chain cutter and depth
gauge settings often cause this. When bar wears
unevenly, it widens guide bar groove (see Figure
20). This causes chain clatter and rivet popping.
Saw will not cut straight. Replace guide bar if
this occurs.
Inspect guide bar before sharpening chain. A worn
or damaged guide bar is unsafe. A worn or damaged
guide bar will damage chain. It will also make cut-
ting harder.
CLEANING SAW BODY
CLEANING AND MAINTENANCE
WARNING: When cleaning saw
body,
• do not submerge saw in any liq-
uids
• do not use products that contain
ammonia, chlorine, or abrasives
• do not use chlorinated cleaning
solvents, carbon tetrachloride,
kerosene, or gasoline
WARNING: Unplug chain saw from
power source before servicing. Severe
injury or death could occur from electri-
cal shock or body contact with moving
chain.
WARNING:Cuttingedgesonchain
aresharp.Use protective gloves when
handling chain.
Keep saw body clean. Use a soft cloth dampened
with a mild soap and water mixture. Wipe saw body
to clean.
NOTICE: Below are instructions for
servicing your chain saw. Any ser-
vicing not mentioned below should
be done by an authorized service
center.
Normal Guide Bar Maintenance
1. Remove guide bar from chain saw.
2. Remove sawdust from guide bar groove peri-
odically. Use putty knife or wire (see Figure
21).
3. Clean oil slots after each day of use.
4. Remove burrs from sides of guide bar. Use
flat file to make side edges square.
Replace guide bar when
• bar is bent or cracked
• inside groove of bar is badly worn
Note: When replacing guide bar, see Replacement
Parts and Accessories for proper bar.
WARNING: Unplug chain saw from
power source before servicing. Severe
injury or death could occur from electri-
cal shock or body contact with moving
chain.
WARNING:Cuttingedgesonchain
aresharp.Use protective gloves when
handling chain.
SHARPENING SAW CHAIN
Keep chain sharp. Your saw will cut faster and
more safely. A dull chain will cause undue sprock-
et, guide bar, chain, and motor wear. If you must
force chain into wood and cutting creates only
sawdust with few large chips, chain is dull.
Figure 20 - Guide Bar Cross Section Showing
Uneven Bar Wear Figure 21 - Guide Bar Maintenance
For parts contact: www.PartsFor.com

19 www.remingtonpowertools.com
ENGLISH
FILE HOLDER
File Guide
Filing Direction
5/32" Round
File
30° Guide Mark
Groove
Depth Gauge (left
side of chain)
Top Plate (left
side of chain)
Right Side of Chain
Groove
Depth Gauge (right
side of chain)
Top Plate
(right side of
chain)
Figure 24 - Depth Gauge Tool On Chain
Flat File
Depth Gauge
Slot
Depth Gauge
Tool
Depth Gauge
Front Corner .025"
.635 mm
CLEANING AND MAINTENANCE
4. Hold file guide level. Make sure 30° mark
on file guide is parallel to center of guide bar
(see Figure 22). This will insure that you file
cutters at 30° angle.
5. File from inside towards outside of cutter
until sharp. Only file in this one direction (see
Figure 22). Note: Two or three strokes with
file should sharpen cutter.
6. After each cutter is sharpened, move chain
forward to sharpen next cutter. File all cutters
on one side of chain.
7. Move to other side of chain and repeat pro-
cess.
Filing Cutter Depth Gauges
The cutter depth gauge clearance is reduced as
cutters are sharpened. After every second or third
sharpening, reset cutter depth gauges.
1. Place depth gauge tool (.025") firmly across
top of two cutters. Make sure depth gauge
enters slot in depth gauge tool (see Figure
24).
2. Use medium flat file. File depth gauge level
with depth gauge tool.
3. Remove depth gauge tool. With flat file, round
off front corner of cutter depth gauge (see
Figure 25).
After several hand filings, have authorized service
center or sharpening service machine sharpen
chain. This will insure even filing.
Replacing Saw Chain
Replace chain when cutters are too worn to sharpen
or when chain breaks. Only use replacement chain
noted in this manual. Always include new drive
sprocket when replacing chain. This will maintain
proper driving of chain. Note: For proper chain
and drive sprocket, see Replacement Parts and
Accessories.
Figure 25 - Round Off Front Corner Of Depth
Gauge
Items Needed to Sharpen Chain
Purchase these items from your local dealer, hard-
ware store, or chain saw supplies outlet.
• 5/32" round file
• Depth gauge tool
• File guide
• Vise
• Medium sized flat file
Sharpening Cutters
Use file guide for 30° filing.
1. Adjust chain for proper tension (see Saw
Chain Tension Adjustment).
2. Clamp guide bar in vise to hold saw steady.
Note: Do not clamp chain.
3. Press 5/32" round file (attached to file guide)
into groove between top plate and depth gauge
on chain. File guide should rest on both top
plate and depth gauge (see Figure 23). Note:
File at midpoint of guide bar.
Figure 22 - File and File Guide Placement
On Chain
Note: This illustration shows file guide placement and
filing direction for sharpening cutters on left side of
chain.
Figure 23 - Chain Part Locations
For parts contact: www.PartsFor.com

23 www.remingtonpowertools.com
ESPAÑOL
®
IMPORTANTE: Lea cuidadosamente este manual antes de
armar u operar esta sierra eléctrica. El uso indebido de
la misma puede provocar graves lesiones. Guarde este
manual para consultarlo cuando lo necesite.
MODELOS: M15012US, M15014AS, M30016US, M30016AS,
M30016AW, M35016AW
SIERRA ELÉCTRICA
MANUAL PARA EL USUARIO
For parts contact: www.PartsFor.com

24
www.remingtonpowertools.com
EL CONTENIDO
INFORMACIÓN IMPORTANTE DE SEGURIDAD..................................................... 25
Antes de utilizar la sierra ......................................................................................................... 25
Al utilizar la sierra .................................................................................................................... 25
Contragolpes ........................................................................................................................... 26
Mantenimiento y almacenamiento de su sierra eléctrica ........................................................ 28
DESEMBALAJE ........................................................................................................ 28
IDENTIFICACIÓN DEL PRODUCTO......................................................................... 29
TERMINOLOGÍA........................................................................................................ 30
GUÍA RÁPIDA DE ARRANQUE ............................................................................... 31
ENSAMBLAJE........................................................................................................... 32
AJUSTE DE TENSIÓN DE LA CADENA SERRADA................................................ 34
USO DE LA SIERRA ELÉCTRICA............................................................................ 35
Lubricación .............................................................................................................................. 35
Lubricación de la cadena ........................................................................................................ 35
Remoción de restos de la tapa de la rueda dentada............................................................... 35
Cables de prolongación........................................................................................................... 36
Realización de cortes .............................................................................................................. 36
Tala de un árbol (Derribamiento de un árbol).......................................................................... 37
Desmembramiento de un árbol ............................................................................................... 38
Trozado de un tronco .............................................................................................................. 39
Poda de un árbol ..................................................................................................................... 40
LIMPIEZA Y MANTENIMIENTO ................................................................................ 41
Limpieza del cabezal............................................................................................................... 41
Cuidado de la barra de guía....................................................................................................41
Afilado de la cadena................................................................................................................ 42
Recambio de la cadena serrada ............................................................................................. 43
ALMACENAMIENTO................................................................................................. 43
SERVICIO TÉCNICO ................................................................................................. 44
ACCESORIOS Y PIEZAS DE REPUESTO ............................................................... 44
SERVICIO DE REPARACIÓN ................................................................................... 44
Servicio con garantía............................................................................................................... 44
Servicio sin garantía................................................................................................................ 44
DIAGNÓSTICO Y RESOLUCIÓN DE PROBLEMAS................................................ 45
INFORMACIÓN DE GARANTÍA................................................................................ 46
DESGLOSE ILUSTRADO DE PARTES .................................................................... 72
CENTRAL DE PIEZAS .............................................................................................. 74
For parts contact: www.PartsFor.com

25 www.remingtonpowertools.com
ESPAÑOL
LEA TODAS LAS INSTRUCCIONES.
Asegúrese de leer y comprender com-
pletamentetodaslas instrucciones en
InformaciónImportanteDeSeguridad.
Elusoindebidodeestasierraeléctrica
puedeprovocarlesionesgraves(yaun
la muerte) a causa de incendio, shock
eléctrico, el contacto del cuerpo con
la cadena en movimiento o la caída de
un trozo de árbol.
INFORMACIÓN IMPORTANTE DE SEGURIDAD
ANTES DE UTILIZAR LA SIERRA
1. Lea detenidamente este manual para el usuario
antes de utilizar la sierra eléctrica.
2. Proceda con cautela. Utilice el sentido común.
No utilice la sierra cuando se sienta cansa-
do.
3. Utilice la sierra sólo para cortar madera. No la
utilice con fines para los que no ha sido diseñada.
No la utilice para cortar plásticos, mampostería,
etc.
4. Sólo un adulto bien instruido debe utilizar la
sierra. Nunca permita que sea utilizada por
niños.
5. Utilice sólo el voltaje eléctrico indicado en la
placa del modelo de la sierra.
6. Utilice sólo cables de prolongación diseñados
para el aire libre. Consulte para conocer las
requisitos del Cable de Prolongación.
7. No utilice la sierra
• cuando se encuentre bajo la influencia de
alcohol, medicamentos o drogas;
• bajo la lluvia o en áreas húmedas o moja-
das;
• en presencia de líquidos o gases altamente
inflamables;
• cuando ésta se encuentre dañada, mal
ajustada o armada de manera incompleta e
insegura;
• si no es posible encenderla y apagarla me-
diante el gatillo. La cadena debe dejar de
moverse al soltar el gatillo. Si el interruptor
se encuentra defectuoso, hágalo reemplazar
en un centro de servicios autorizado (con-
sulte Servicio Técnico).
• cuando tenga prisa;
• cuando esté arriba de un árbol o sobre una
escalera, a menos que se encuentre capaci-
tado para hacerlo.
8. Al utilizar la sierra, lleve ropa ajustada. No
utilice ropa ni lleve accesorios sueltos, ya que
éstos pueden quedar atrapados en la cadena en
movimiento.
9. Utilice los siguientes elementos de seguridad
para utilizar la sierra eléctrica:
• guantes resistentes (utilice guantes de goma
para trabajar al aire libre);
• calzado resistente con suelas no resbaladi-
zas;
• protección ocular, tal como gafas de segu-
ridad o una pantalla facial;
• casco de seguridad;
• orejeras o tapones para los oídos;
• cubrecabellos, especialmente si tiene cabello
largo;
• máscara contra el polvo (el trabajar en zonas
polvorientas).
10.
Antes de comenzar a cortar, asegúrese de contar
con:
• zona de trabajo limpia;
• calzado firme;
• camino de retirada para el momento de caída
del árbol.
11. Inspeccione el árbol antes de talarlo. Asegú-
rese de que no tenga ramas o vástagos secos
que puedan caerle encima.
12. Para reducir el riesgo de shock eléctrico, esta
sierra tiene un enchufe polarizado (un conector
es más ancho que el otro) y sólo entrará de una
manera en un tomacorriente polarizado. Si el
enchufe no entra completamente en el tomaco-
rriente de su cable de prolongación, inviértalo.
Si, aun así, tampoco entra, necesitará un cable
de prolongación polarizado. No altere el enchufe
de manera alguna.
AL UTILIZAR LA SIERRA
1. Permanezca alerta. Utilice el sentido común.
2. Mantenga limpia el área de trabajo. Las áreas
de trabajo sucias pueden provocar lesiones.
3. Tenga en cuenta la posición del cable de pro-
longación. Asegúrese de no tropezar sobre él.
Manténgalo alejado de la sierra y del operario en
todo momento.
4. Mantenga a los niños, animales y observadores
alejados de la sierra y del cable de prolon-
gación. Sólo el operario de la sierra debe
permanecer en el área de trabajo.
5. No proceda a talar un árbol a menos que esté
entrenado o que disponga de un asistente con
experiencia.
ADVERTENCIA: Al utilizar una sie-
rra eléctrica, deben seguirse siempre
lasprecaucionesdeseguridadbásicas
para reducir el riesgo de incendios,
choque eléctrico y lesiones a perso-
nas, incluyendo las siguientes:
For parts contact: www.PartsFor.com
