Renesas Embedded
Application Programming Interface
Reference manual
User’s Manual
Rev.1.01 2007.02

Rev.1.01 2007.02.16
RJJ10J1643-0101
2
REVISION HISTORY
Rev. Summary Date
1.00 06.04.07
1.01 ・ Additions and corrections made for support of libraries for the H8/36094, H8/36077,
H8/36109, and R8C/24 and 25
・ Unnecessary periods in Chapter 1, “Instruction,” deleted
・ Port P73 of H8 deleted
・ Channels A–D written in CreateInputCapture corrected to input captures A–D
・ Error in writing “seroal” corrected to “serial”
・ Erroneous description of RAPI_70_STATES corrected
・ Error in writing of timer channel names corrected
・ Error in writing of input capture mode corrected
・ Error in writing of output compare mode corrected
・ Erroneous description of RAPI_OVERFLOW_BIT15 corrected
・ Support for R8C UART1 clock synchronous mode
・ RAPI_COUNT_CLEAR added to first arguments for the R8C and H8/300H in
__CreateInputCapture and __CreateOutputCompare
・ “External signal” deleted from the timer RD count source for the R8C in
__CreateInputCapture and __CreateOutputCompare
・ Following statements added to the item for timer RD in __SetTimerRegister and
__GetTimerRegister
・ [15]: Timer RD output master enable register 1
・ [16]: Timer RD output master enable register 2
・ [17]: Timer RD output control register
・ Explanation for clearing H8/300H module added to the description of __Create...,
__Open..., and __BasicOpen...
・ Explanation for setting H8/300H module for standby added to the description of
__Destroy..., __Close..., and BasicClose...
・ Return value in __PollingSerialReceiving changed from Boolean to unsigned int, and
explanation of return value and example program changed
・ Return value in __PollingSerialSending changed from Boolean to unsigned int, and
explanation of return value and example program changed
・ Remarks regarding use of port B on H8/300H added to __ReadIOPort and
__ReadIOPortRegister
07.02.16

Rev.1.01 2007.02.16
RJJ10J1643-0101
3
・ Description of third argument in __CreateInputCapture corrected
・ Wording “specified” unified to “specified”
・ RAPI_BOTH deleted from the description of timer B1 count edges of H8/300H in
__CreateEventCounter
・ RAPI_FTIOA and RAPI_FTIOB added to __CreatePulsePeriodMeasurementMode and
__CreatePulseWidthMeasurementMode
・ All occurrences of the word “Tiny” deleted
・ Description of second argument added to __GetPulsePeriodMeasurementMode,
__GetPulseWidthMeasurementMode, and __GetEventCounter
・ Description regarding timer V trigger of H8 in __CreateTimer, __CreateEventCounter,
and __CreatePulseWidthMeasurementMode corrected
・ Explanation of H8 interrupt settings and interrupt control register settings in
__SetSerialInterrupt corrected
・ Remarks on timer V of H8/300H in __EnableTimerRegister added
・ Specification of timer RA input pins of R8C in __CreatePulsePeriodMeasurementMode
and __CreatePulseWidthMeasurementMode as well as RAPI_TIOSEL_P1_7 and
RAPI_TIOSEL_P1_5 added
・ File name in program example corrected
・ Item “Reference” in __BasicSetSerialFormat deleted
・ __BasicSetSerialFormat added to “Reference” in __SetSerialFormat and
__SetSerialInterrupt
・ Error in writing of __CreateInput Capture and __CreateOutputCapture corrected
・ Explanation added to Section 2.1, “Overview”
・ Causes of clearing of timer W and timer RC counters in __CreateInputCapture deleted
・ RAPI_COMPARE_MATCH_A_STOP and RAPI_STOP added to the item for the R8C in
__CreateOutputCompare
・ Changed to RAPI_INT_LV_0 and RAPI_INT_LV_1 for H8/300H in __SetSerialInterrupt
・ Description relating to clock in __CreateTimer corrected
・ RAPI_TRC_FILTER and RAPI_TRD_FILTER added to filter specification for H8 in
__CreatePulsePeriodMeasurementMode and __CreatePulseWidthMeasurementMode
・ RAPI_TIMER_RD2 and RAPI_TIMER_RD3 added to timer RD of H8/36109
・ Description relating to timer V trigger input for H8/300H in __CreateTimer deleted
・ Description of pulse output function added to the item for R8C in
__CreateEventCounter
・ Description of timer RE usage added to items data3 and data5 for R8C in
__CreateOutputCompare
・ Filter function of timer RC and timer RD in __CreatePulsePeriodMeasurementMode,
__CreatePulseWidthMeasurementMode, and __CreateInputCapture corrected
・ Description that multiple defined values can be set for data1 in __EnableInterrupt
added
・ Description that RAPI_WITHOUT_SAMPLE_HOLD is specifiable in delay trigger
modes 0 and 1 of M16C in __CreateADC corrected
・ Description that RAPI_FOCOF is specifiable in repeat mode of R8C in __CreateADC
corrected

Rev.1.01 2007.02.16
RJJ10J1643-0101
4
・ RAPI_AN30, RAPI_AN31, RAPI_AN32, and RAPI_P9_GROUP added to the item for
data1 of M16C in __CreateADC
・ RAPI_AN30, RAPI_AN31, RAPI_AN32, and RAPI_P9_GROUP added to the item for
data1 of M16C in __EnableADC
・ Error in writing of H8/300H interrupt set values in __CreateOutputCompare corrected
・ Error in writing of timer RD and timer RD symbol name corrected
・ Description of gate function of M16C in __CreateEventCounter deleted
・ Description of H8/300H noise rejection function in __BasicSetSerialFormat added
・ Description of timer W input pins of H8/300H in
__CreatePulsePeriodMeasurementMode and __CreatePulseWidthMeasurementMode
deleted

Rev.1.01 2007.02.16
RJJ10J1643-0101
5
Table of Contents
Table of Contents ................................................................5
1. Introduction................................................................... 8
2. Driver ....................................................................... 9
2.1 Overview.................................................................. 9
2.2 Driver Features ............................................................ 10
2.3 Serial Interface Driver....................................................... 11
2.4 Timer Driver .............................................................. 12
2.4.1 Timer Mode ........................................................... 12
2.4.2 Event Counter Mode .................................................... 12
2.4.3 Pulse Width Modulation Mode (PWM Mode)................................. 12
2.4.4 Pulse Period Measurement Mode .......................................... 12
2.4.5 Pulse Width Measurement Mode........................................... 12
2.4.6 Input Capture Mode..................................................... 12
2.4.7 Output Compare Mode .................................................. 13
2.5 I/O Port Driver ............................................................ 14
2.6 External Interrupt Driver..................................................... 15
2.7 A/D Converter Driver ....................................................... 16
3. Standard Types ............................................................... 18
4. Library Reference ............................................................. 19
4.1 API List by Peripheral Facility ................................................ 19
4.2 Description of Each API ..................................................... 21
4.2.1 Serial I/O ............................................................. 22
__BasicOpenSerialDriver................................................... 22
__BasicCloseSerialDriver................................................... 23
__BasicSetSerialFormat .................................................... 24
__BasicStartSerialReceiving................................................. 29
__BasicStartSerialSending .................................................. 30
__BasicReceivingStatusRead ................................................ 31
__BasicSendingStatusRead.................................................. 33
__BasicStopSerialReceiving................................................. 34
__BasicStopSerialSending .................................................. 35
__OpenSerialDriver ....................................................... 36
__CloseSerialDriver ....................................................... 37
__ConfigSerialDriverNotify ................................................. 38
__SetSerialFormat......................................................... 41
__SetSerialInterrupt ....................................................... 42
__StartSerialReceiving ..................................................... 45
__StartSerialSending....................................................... 47
__StopSerialReceiving ..................................................... 49
__StopSerialSending....................................................... 50
__PollingSerialReceiving ................................................... 51
__PollingSerialSending..................................................... 52
4.2.2 Timer ................................................................54

Rev.1.01 2007.02.16
RJJ10J1643-0101
6
__CreateTimer ........................................................... 54
__EnableTimer ........................................................... 60
__DestroyTimer .......................................................... 62
__CreateEventCounter ..................................................... 64
__EnableEventCounter..................................................... 69
__DestroyEventCounter .................................................... 71
__GetEventCounter........................................................ 73
__CreatePulseWidthModulationMode ......................................... 75
__EnablePulseWidthModulationMode......................................... 80
__DestroyPulseWidthModulationMode ........................................ 82
__CreatePulsePeriodMeasurementMode ....................................... 83
__EnablePulsePeriodMeasurementMode ....................................... 88
__DestroyPulsePeriodMeasurementMode ...................................... 90
__GetPulsePeriodMeasurementMode.......................................... 92
__CreatePulseWidthMeasurementMode........................................ 94
__EnablePulseWidthMeasurementMode ....................................... 99
__DestroyPulseWidthMeasurementMode ..................................... 101
__GetPulseWidthMeasurementMode ......................................... 103
__CreateInputCapture..................................................... 105
__EnableInputCapture .................................................... 115
__DestroyInputCapture.................................................... 117
__GetInputCapture ....................................................... 119
__CreateOutputCompare .................................................. 121
__EnableOutputCompare .................................................. 133
__DestroyOutputCompare ................................................. 135
__SetTimerRegister ...................................................... 137
__EnableTimerRegister.................................................... 143
__ClearTimerRegister..................................................... 145
__GetTimerRegister ...................................................... 147
4.2.3 I/O Port ............................................................. 153
__SetIOPort ............................................................ 153
__ReadIOPort ........................................................... 158
__WriteIOPort........................................................... 162
__SetIOPortRegister...................................................... 166
__ReadIOPortRegister .................................................... 168
__WriteIOPortRegister .................................................... 170
4.2.4 External interrupt...................................................... 172
__SetInterrupt ........................................................... 172
__EnableInterrupt ........................................................ 176
__GetInterruptFlag ....................................................... 178
__ClearInterruptFlag...................................................... 180
4.2.5 A/D converter......................................................... 182
__CreateADC ........................................................... 182
__EnableADC........................................................... 191
__DestroyADC .......................................................... 196

Rev.1.01 2007.02.16
RJJ10J1643-0101
7
__GetADC ............................................................. 197
__GetADCAll........................................................... 198
__GetADCStatus......................................................... 199
__ClearADCStatus ....................................................... 200

Rev.1.01 2007.02.16
RJJ10J1643-0101
8
1. Introduction
The Renesas Embedded Application Programming Interface (API) is a unified API for
the microcomputers made by Renesas Technology Corporation.

Rev.1.01 2007.02.16
RJJ10J1643-0101
9
2. Driver
2.1 Overview
The library described herein provides a peripheral facility control program (peripheral
driver) for microcomputers. Use of the Renesas API permits the peripheral driver to be
built into a user program.
Configuration of Renesas APIs is shown below.
File name Description
rapi_ xxx _ yyy .lib
(
xxx = family name, yyy = series name)
This is the Renesas API library file. To use
Renesas APIs, specify this file as input file
for the linker.
rapi_ad_ xxx _ yyy .h
(
xxx = family name, yyy = series name)
This is the header file for A/D converter
driver APIs. To use A/D converter driver
APIs, be sure to include this file.
rapi_io_port_ xxx _ yyy .h
(
xxx = family name, yyy = series name)
This is the header file for I/O port driver
APIs. To use I/O port driver APIs, be sure
to include this file.
rapi_sif_ xxx _ yyy .h
(
xxx = family name, yyy = series name)
This is the header file for serial I/F driver
APIs. To use serial I/F driver APIs, be sure
to include this file.
rapi_timer_ xxx _ yyy .h
(
xxx = family name, yyy = series name)
This is the header file for timer driver
APIs. To use timer driver APIs, be sure to
include this file.
Interrupt_ xxx _ yyy .h
(
xxx = family name, yyy = series name)
This is the interrupt function source file for
Renesas APIs. To use Renesas APIs that
use interrupts, add this file to the user
program.
rapi_io_ xxx _ yyy .h
(
xxx = family name, yyy = series name)
This is the CPU control register definition
header file for Renesas APIs.

Rev.1.01 2007.02.16
RJJ10J1643-0101
10
2.2 Driver Features
The library described herein has the following features available as a peripheral driver.
(1) Serial I/O control feature
It comprises a serial interface driver, which sets or clears the conditions of serial
communication, as well as controls and manages the transmission/reception of
communication data.
(2) Timer control feature
It comprises a timer driver, which sets or clears the operating conditions of timers,
as well as controls the timer operation.
(3) I/O port control feature
It comprises an I/O port driver, which sets or clears the usage conditions of I/O ports, as
well as control data read/write operation.
(4) External interrupt control feature
It comprises an external interrupt driver, which sets or clears the usage conditions of
external interrupts, as well as controls interrupt operation.
(5) A/D converter control feature
It comprises an A/D converter driver, which sets or clears the usage conditions of A/D
converters, as well as controls A/D converter operation.

Rev.1.01 2007.02.16
RJJ10J1643-0101
11
2.3 Serial Interface Driver
The serial interface driver sets serial communication, clears settings, transmit/receives
data, and controls the status of serial communication.
There are two kinds of serial interface driver: a single-data transmission/reception API
and a multi-data transmission/reception API.

Rev.1.01 2007.02.16
RJJ10J1643-0101
12
2.4 Timer Driver
The timer driver sets the timer, clears timer settings, controls timer operation, and
acquires a counter value with respect to the following modes:
•Timer mode
•Event counter mode
•Pulse width modulation mode (PWM mode)
•Pulse period measurement mode
•Pulse width measurement mode
•Input capture mode
•Output compare mode
2.4.1 Timer Mode
In this mode, the timer counts the internally generated count source. When an
underflow or an overflow interrupt occurs, it calls a preset callback function.
2.4.2 Event Counter Mode
In this mode, the timer counts the external signal fed in from an input pin or an
overflow or underflow from other timer. When an underflow or an overflow interrupt
occurs, it calls a preset callback function.
2.4.3 Pulse Width Modulation Mode (PWM Mode)
In this mode, the timer outputs pulses in a given width successively. When an
underflow or an overflow interrupt occurs, it calls a preset callback function.
2.4.4 Pulse Period Measurement Mode
In this mode, the timer measures the pulse period of an external signal fed in from an
input pin. When an underflow or an overflow interrupt occurs, it calls a preset callback
function.
2.4.5 Pulse Width Measurement Mode
In this mode, the timer measures the pulse width of an external signal fed in from an
input pin. When an underflow or an overflow interrupt occurs, it calls a preset callback
function.
2.4.6 Input Capture Mode
In this mode, the timer latches the timer value upon an active signal edge or clock
pulse at an input pin, thereby generating an interrupt request. When an input capture
interrupt or an underflow or an overflow interrupt occurs, it calls a preset callback
function.

Rev.1.01 2007.02.16
RJJ10J1643-0101
13
2.4.7 Output Compare Mode
In this mode, the timer generates an interrupt request when the timer counter and a
comparison value match. When a compare match interrupt or an underflow or an
overflow interrupt occurs, it calls a preset callback function.

Rev.1.01 2007.02.16
RJJ10J1643-0101
14
2.5 I/O Port Driver
The I/O port driver sets the I/O port for input or output, writes data to the I/O port, and
reads data from the I/O port.

Rev.1.01 2007.02.16
RJJ10J1643-0101
15
2.6 External Interrupt Driver
The external interrupt driver sets external interrupts, controls external interrupts,
acquires the status of external interrupt flags, and clears external interrupt flags.

Rev.1.01 2007.02.16
RJJ10J1643-0101
16
2.7 A/D Converter Driver
The A/D converter driver sets the A/D converter, controls the A/D converter, clears
settings of the A/D converter, acquires the A/D converter value, acquires the status of the
A/D converter, and clears the status of the A/D converter.
[A/D converter driver usage example (single-shot mode)]
Here, a program example is shown for the A/D converter operating in single-shot mode
under the conditions given below.
CPU : R8C
Operating clock : fAD divided by 2
Resolution : 10 bits
Analog input pin : AN0 pin
A/D conversion start condition : Software trigger
Sample-and-hold : Enabled
A program flow and a program example are shown below.
(Program flow)
_
_CreateADC()
_
_EnableADC()
_
_GetADCStatus()
_
_GetADC()
_
_ClearADCStatus()
main()
Set the A/D converter in
single-shot mode
Start A/D conversion
A/D interrupt?
Clear the A/D interrupt flag
No
Yes
Read out the A/D conversion value

Rev.1.01 2007.02.16
RJJ10J1643-0101
17
Program example
#include "rapi_ad_r8c_13.h"
void main( void )
{
unsigned int status, data;
/* Set up A/D converter as one short mode */
__
CreateADC( RAPI
_
ONE
_
SHOT|RAPI
_
AN0|RAPI
_
FAD2|
RAPI_WITH_SAMPLE_HOLD|
RAPI_AD_OFF|RAPI_10BIT, 1, 0, 0 );
while( 1 ){
/* Disable A/D converter */
__EnableADC( RAPI_AN0| RAPI_AD_ON, 1 );
/* Check a flag bit of A/D converter interrupt */
do{
__GetADCStatus( &status );
} while( (*status & 0x0001) == 0 )
/* Get A/D convertered datas of A/D register */
__GetADC( &data );
/* Clear status of A/D convertered */
__ClearADCStatus( 0 );
}
}

Rev.1.01 2007.02.16
RJJ10J1643-0101
18
3. Standard Types
This section describes the standard types defined in the library. For details about the
set values, refer to the description of each API.
Standard type Description
Boolean The Boolean type represents the enum-type data that indicates
whether successful (RAPI_TRUE (= 1)) or failed (RAPI_FALSE (=
0)).
VoidFuncNotify The VoidFuncNotify type represents the type of the notification
function to be registered.
