Replas FLINDERS SETTING User manual

ASSEMBLYINSTRUCTIONS
IMPORTANT:Pleasereadcarefullybeforeassembling.
FLINDERS
SETTING
2.2m
InGround
TABLE:
1.Placetabletopfacedownonaflatsurface.
2.PlaceTablesupportsintoposition.
3.Securetablesupportstothetableframeusingthe40mmhexscrews,takingcarenottoovertightenasthiscould
stripthethread.
NOTE:Donottightenscrewsuntilallareinposition.

BENCHES:
1.Placebenchslatsfacedownonaflatsurface.
2.Attachbenchsupportstothebenchframeusingthe40mmhexscrews,takingcarenottoovertightenasthiscouldstrip
thethread.
NOTE:Donottightenscrewsuntilallareinposition.

Installation
Oncethesettinghasbeenisassembled,drillordigholesasperinstallationdiagram.

Placethesupportsoftheassembledsettingintotheholes.Positionthesettingandensurethatitiswellbracedtoprevent
movementandsagging.Atthisstageitisimportanttouseaspiritleveltocheckthatthetopishorizontalandthesupportsare
vertical.

Oncesatisfiedthatthesettingispositionedcorrectly,filltheholeswithconcrete,makingsureitispackedfirmlybeneathand
aroundthesupports.

Oncetheconcretehasset,removethebracing.
TABLE:

1XTableTop‐pre‐assembled
2XTableSupports
12X12gx40mmHexHeadscrews
COMPONENTSLIST
BENCHES:

2XBenchTops‐pre‐assembled
4XBenchSupports
16X12gx40mmHexHeadScrews
Ifyourequirefurtherinstallation
assistance,pleasecontactyoursupplier.

740mm
440mm
2200mm
1600mm
690mm 690mm
850mm
350mm
440mm
740mm
450mm 600mm
FLS-2200IG
FLINDERS
IN GROUND
SETTING
Post:
150mm x 150mm
Post:
125mm x 125mm
